- Page 1 Industrial Serial RS-232 to Fiber Converter KSC-200 Series Installation Guide DOC.111209-KSC-200...
- Page 2 (C) 2006 KTI Networks Inc. All rights reserved. No part of this documen- tation may be reproduced in any form or by any means or used to make any directive work (such as translation or transformation) without per- mission from KTI Networks Inc.
- Page 3 The information contained in this document is subject to change without prior notice. Copyright (C) All Rights Reserved. TRADEMARKS Ethernet is a registered trademark of Xerox Corp. FCC NOTICE This device complies with Class B Part 15 the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received including the interference that may cause.
-
Page 4: Table Of Contents
Table of Contents 1. Introduction ............5 1.1 Features ..................6 1.2 Specifications ................7 2. Installation ............11 2.1 Unpacking ..................11 2.2 Safety Cautions ................12 2.3 DIN-Rail Mounting ............... 13 2.4 Panel Mounting ................15 2.5 Applying Power ................17 2.6 Power Failure Relay Output ............ -
Page 5: Introduction
1. Introduction The converter is designed to provide the most versatile connection pos- sible between two RS-232 serial equipment using fiber optic cable. It allows any two pieces of serial equipment to communicate full-duplex over typical duplex fibers,or over optional single fiber up to 20km. The converter supports transparent conversion for not only RS-232 data lines, but also all RS-232 control signals. -
Page 6: Features
1.1 Features Transparent conversion for all RS-232 signals Supports RS-232 baud rate higher than 115.2K bps Auto adaptation and conversion to any RS-232 baud received Operation with no required configuration Extending all RS-232 signals over long optical cables Supports versatile optical cables: -ST/SC multimode duplex fibers -SC single mode duplex fibers -SC single mode single fiber... -
Page 7: Specifications
1.2 Specifications This figure shows the important components of the device:... - Page 8 Serial Interface (RS-232 Port) Connector DB9 female Pin Assignments DCE type Isolation RS-232 I/O and internal system Baud Rate Support Auto-detect, Up to 120K Connector Shield Connect to chassis ground Connection Distance 15 meters High ESD Tolerance +/-15KV on Tx, Rx lines Overvoltage Protection Cutoff if over +/-25V Isolation Optical isolation from internal system...
- Page 9 DC Power Interface Interface Screw-type terminal block 1. Two pairs for power wire cascading 2. One pair for power failure relay output DC Jack (-6.3mm/+D2.0mm) Operating Input Voltages +7V ~ +30V(+5%) Power consumption 2.1W @+7.5VDC input 2.14W @+12.6VDC input 2.4W @+30VDC input Basic Information Conversion Transparent for all RS-232 signals...
- Page 10 Certificate Part 15 Class B CE/EMC EMI EN50081-1 Class B EMS EN55024 CE/LVD Safety EN 60950 EN55022 EN61000-3-2 EN61000-3-3 EN 55024 IEC 61000-4-2 ESD Test IEC 61000-4-3 RS Test IEC 61000-4-4 EFT/BURST Test IEC 61000-4-5 Surge Test IEC 61000-4-6 CS Test IEC 61000-4-8 Magnetic Field IEC 61000-4-11...
-
Page 11: Installation
2. Installation 2.1 Unpacking Check that the following components have been included: • Information CD • The device unit • DIN-rail mounting bracket If any item is found missing or damaged, please contact your local reseller for replacement. The following are available optional accessories: •... -
Page 12: Safety Cautions
2.2 Safety Cautions To reduce the risk of bodily injury, electrical shock, fire, and damage to the equipment, observe the following precautions. • Do not service any product except as explained in your system documentation. • Opening or removing covers may expose you to electrical shock. Only a trained service technician should service components inside these compartments. -
Page 13: Din-Rail Mounting
2.3 DIN-Rail Mounting In the product package, a DIN-rail bracket is installed on the device for mounting the converter in a industrial DIN-rail enclosure. The steps to mount the device onto a DIN rail are: 1. Install the mounting bracket onto the device unit as shown below: 2. - Page 14 The final mechanical dimensions after installing DIN rail mounting bracket are: -14-...
-
Page 15: Panel Mounting
2.4 Panel Mounting The device is provided with an optional panel mounting bracket. The bracket support mounting the device on a plane surface securely. The mounting steps are: 1. Install the mounting bracket on the device unit. 2. Screw the bracket on the device unit. 3. - Page 16 The screw locations and final dimension are shown below: -16-...
-
Page 17: Applying Power
2.5 Applying Power The power specifications of the device are: Operating Voltage +7 ~ +30VDC Power Consumption Max. 2.4W @30VDC The device provides two types of power interfaces, terminal block and DC power jack for receiving DC power input from external power supply. Using Terminal Blocks Either DC1 interface or DC2 interface can be used to receive DC power from an external power system. - Page 18 Power wires: 24 ~ 12AWG (IEC 0.5~2.5mm Install the power source wires with the plug properly. Screw the wire with plug securely. Then, plug in DC1 contacts. If cascading the power to next device is needed, install the power wires and plug for another switch.
- Page 19 Using DC Power Jack DC Jack Connector: Jack D 6.3mm D 2.0mm AC Power Adapters: Optional commercial rated adapters are available for purchasing. Rated AC120V/60Hz DC7.5V 1A Rated AC230V/50Hz DC7.5V 1A Rated AC100V/50-60Hz DC7.5V 1A Rated AC240V/50Hz DC7.5V 1A Connect power adapter DC plug to the DC power jack of the converter before connecting to the AC outlet.
-
Page 20: Power Failure Relay Output
2.6 Power Failure Relay Output The device provides a relay output to report power failure event to a remote alarm monitoring system. The replay output is provided with two contacts labeled PF+ and PF- in the terminal block interface. Use the provided 2P terminal plug for signal wiring and plug into the PF+/ - contacts. -
Page 21: Rs-232 Port Pin Assignment Table
2.7.1 RS-232 Port Pin Assignment Table Pin# Signal Name Input/Output Received Line Signal Detect Output TX Data Output RX Data Input DTE Ready Input Signal Ground Output DCE Ready Output Clear To Send Input Request To Send Output Ring Indicator Output -21-... -
Page 22: Cable For Connection To Pc Com Port
2.7.2 Cable for Connection to PC COM Port Connecting to 9-pin DTE device (Computer or PC COM) Connecting to 25-pin DTE device (Computer or PC COM) -22-... -
Page 23: Making Fiber Port Connection
2.8 Making Fiber Port Connection Depending on the model purchased, the fiber port provides one of the following connector types: Duplex ST, Duplex SC, Single SC. Connecting Multimode Duplex Fiber Make sure the RX-to-TX connection rule is followed on the both ends of the fiber cable. - Page 24 Connecting Single Mode Single Fiber For Bi-Di (Bidirectional) single fiber connection which use two different wavelengths for TX and RX respectively over single SM fiber cable, only one connector is provided on the fiber port and only one fiber cable is used.
-
Page 25: Application
2.9 Application The converter can be used to extend the distance between two serial devices via fiber cables. The distance can be 2km, 20km, and even up to 100km. The following example illustrates a PC performs serial communocation with another RS-232 device far apart: The converter converts all signals of the COM port of the PC to optical signals and sends to the other converter far apart over fiber cable. -
Page 26: Led Indicators
3 LED Indicators The following figure shows the locations of the LED indicators: 3.1 LED Indicators DISPLAY STATE INTERPRETATION Power status The device is powered on. The device is powered off. 232 TX RS-232 TX RS-232 TX data is present No RS-232 TX data 232 RX RS-232 RX... -
Page 27: Appendix: Model Optical Specifications
Appendix: Model Optical Specifications Model Fiber Port Specifications Model Wavelength Tx Power Sensitivity Max.Rx 200-T 1310nm -20~-14 -32dBm -8dBm 200-C 1310nm -20~-14 -31dBm 0dBm 200-SL2 1310nm -15~-7 -30dBm -7dBm 200-SL4 1310nm -5~ 0 -34dBm 0dBm 200-SL6 1310nm -5~ 0 -35dBm 0dBm 200-W3515 Tx 1310nm...
