Page 1: Snow Thrower
Snow Thrower Model PO85TE27 Operating & Maintenance Instructions Instructions d’utilisation et de maintenance Briggs & Stratton Power Products Group, LLC 406679 09/27/06 Jefferson, WI 53549 PRINTED IN U.S.A. www.briggspowerproducts.com... - Page 2 REPAIR PARTS MODEL PO85TE27(96198000600) ENGINE 25--2 25--1 25--3 25--2 25--4 Ref. Drive Page Ref. Auger Housing Page Key No. Part No. Description Key No. Part No. Description 198563 CORD, STARTER 74610516 SCREW 5/16--24X1.00 TEC ENGINE * 198556 SPRING, IDLER TRACTION DRIVE...
-
Page 3: Gear Case
REPAIR PARTS MODEL PO85TE27(96198000600) GEAR CASE Key No. Part No. Description Key No. Part No. Description 73800400 NUT, HEX LOCK 1/4--20 404965 HOUSING, GEARCASE, RH 404953 WASHER, FLAT 404959 SEAL, OIL 404955 NUT,1/4--20 404960 BEARING, FLANGE 404956 COLLAR,THRUST 404952 KEY, WOODRUFF #605... - Page 4 REPAIR PARTS MODEL PO85TE27(96198000600) FRAME Ref. Engine Page Ref. Auger Housing Page Ref. Drive Page...
-
Page 5: Cover, Bottom
REPAIR PARTS MODEL PO85TE27(96198000600) FRAME Key No. Part No. Description 198573X479 COVER, BOTTOM 198574 SCREW, 1/4--20X .63 198756X008 IDLER ASSEMBLY, AUGER 198576 PIN, HAIR .38DIAX1.64LG 198580 PIN, CLEVIS 3/16” DIA 198577 SPRING, TENSION 405484 ASSY., SPRING ATTACH 72110612 BOLT, 3/8--16X1.25 CARR. - Page 6 REPAIR PARTS MODEL PO85TE27(96198000600) DRIVE Ref. Shift Yoke Page Ref. Frame Page Ref. Wheel Page Ref. Wheel Page Ref. Wheel Page Ref. Wheel Page...
- Page 7 REPAIR PARTS MODEL PO85TE27(96198000600) DRIVE Key No. Part No. Description 198600X008 LF AXLE, SWING PLATE YZ 198588 CHAIN, ROLLER #420x19.00 198591 BEARING AND RETAINER, ASSY 198592 WASHER 198584 SCREW, TAP 5/16--18x0.5 198815 ASSY, HEX SHAFT 198596 CHAIN, ROLLER #420x18.00 LG...
-
Page 8: Repair Parts
REPAIR PARTS MODEL PO85TE27(96198000600) AUGER HOUSING... - Page 9 REPAIR PARTS MODEL PO85TE27(96198000600) AUGER HOUSING Key No. Part No. Description 405010 PULLEY, 4L 6.12X .67 74950512 SCREW, 5/16--18X.63 851074 WASHER, FLAT 11050500 LOCKWASHER 5/16 407452 SPACER 188909 BEARING, BALL 199879 BOLT, HEX 5/16--18X .50 198541 NUT, 5/16--18 HEXWDFLLK 405686X428...
- Page 10 REPAIR PARTS MODEL PO85TE27(96198000600) HANDLE Ref. Engine Page...
- Page 11 REPAIR PARTS MODEL PO85TE27(96198000600) HANDLE Key No. Part No. Description 198700X479 HANDLE, UPPER LH 198701X479 HANDLE, UPPER RH 198711 SCREW, 5/16--18X2.75 198662 WASHER, FLAT 10040500 WASHER, SPTLK .31X.58X.08 198683 NUT, 5/16--18 REGHEX YZ 198709 STOP, RED PLASTIC 198708 GRIP 198698X479...
- Page 12 REPAIR PARTS MODEL PO85TE27(96198000600) CHUTE ROD Ref. Handle Assy 852--9 852--5 852--8 852--13 Ref. Auger Housing Assy 852--10 852--11 852--1 852--2 852--6 852--7 852--3...
- Page 13 REPAIR PARTS MODEL PO85TE27(96198000600) CHUTE ROD Key No. Part No. Description 852--1 198853 ASSEMBLY, YOKE & ROD 852--2 198861 WASHER, COMPRRESSION SPRING 852--3 198862 GEAR, CHUTE ROTATION 9T 852--5 400192 PIN, COTTER 852--6 405339 BRACKET, GEAR MOUNT 852--7 198863 PIN, HAIR...
-
Page 14: Discharge Chute
REPAIR PARTS MODEL PO85TE27(96198000600) DISCHARGE CHUTE Ref. Auger Housing Page... - Page 15 REPAIR PARTS MODEL PO85TE27(96198000600) DISCHARGE CHUTE Key No. Part No. Description 198661 BOLT, 5/16--18 X 1.00 CARG. 198662 WASHER, FLAT 751153 NUT, 5/16--18 NYLOCK 198662 WASHER 198851 KNOB, WING 3.00 198539 BOLT, 5/16--18X1.5 198842 CHUTE UPPER 198661 BOLT, CARRIAGE 5/16--18x1...
- Page 16 REPAIR PARTS MODEL PO85TE27(96198000600) SHIFT YOKE Key No. Part No. Description 198725X479 ROD, SHIFT 198727 SCREW, 1/4--20X.75 73800400 NUT, 1/4--20 198736 KNOB, SLIP 198737 LEVER, SPRING 198727 SCREW, 1/4--20X.75 73800400 NUT, 1/4--20 198732X008 ROD ASSY., SPEED SELECT 198945 RETAINER, RING...
- Page 17 REPAIR PARTS MODEL PO85TE27(96198000600) PANEL Key No. Part No. Description 198717x428 PANEL 198720 BOLT, CARRIAGE 198722 WASHER 73800400 NUT, 1/4--20 NYLOCK YZ...
- Page 18 REPAIR PARTS MODEL PO85TE27(96198000600) WHEELS Ref. Drive Page Key No. Part No. Description 199039 SHAFT, AXLE 198679 SPRKT & HUB 198667 SCREW, 1/4--20 x 1.75 73800400 NUT, 1/4--20 HEX NYLOCK 198680 BEARING, AXLE 400025 FLATWASHER 199040 BUSHING, WHEEL 405067x417 TIRE & RIM, RIGHT 198674 SCREW, 1/4--20X1.75 HH...
