Poulan Pro 414944 Owner's Manual

Poulan pro snow thrower owner's manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

IMPORTANT MANUAL
OWNER'S MANUAL
MODEL NUMBER:
PP13TEPH30
SNOW THROWER
Always Wear Eye Protection During Operation
Do Not Throw Away
WARNING:
Read the Owner's Manual and
fol low all Warnings and Safety
In struc tions. Fail ure to do so
can result in serious injury.
414944 Rev. 2 09.26.07 TH
Printed in U.S.A.

Advertisement

Table of Contents
loading

Related Manuals for Poulan Pro 414944

Summary of Contents for Poulan Pro 414944

  • Page 1 Always Wear Eye Protection During Operation Do Not Throw Away WARNING: Read the Owner's Manual and fol low all Warnings and Safety In struc tions. Fail ure to do so can result in serious injury. 414944 Rev. 2 09.26.07 TH Printed in U.S.A.

  • Page 2: Safety Rules

    Safe Operation Practices for Walk-Behind Snow Throwers This snow thrower is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury. Look for this symbol to point out im- por tant safety precautions.

  • Page 3: Table Of Contents

    6. When cleaning, repairing or inspecting the snow thrower, stop the engine and make certain the collector/ impeller and all moving parts have stopped. Disconnect the spark plug wire and keep the wire away from the plug to prevent someone from accidentally starting the engine.
  • Page 4 PARTS PACKED SEPARATELY IN CARTON...

  • Page 5: Assembly / Pre-Operation

    ASSEMBLY / PRE-OPERATION Read these instructions and this manual in its entirety before you attempt to assemble or operate your new snow thrower. Reading the entire manual will familiar- ize you with the unit, which will assist you in assembly, operation and maintenance of the product.
  • Page 6 ASSEMBLY / PRE-OPERATION INSTALL TRACTION DRIVE CONTROL ROD (See Figs. 3 and 4) The traction drive control rod has the long loop on the end of the spring as shown. 1. Slide rubber sleeve up rod and hook end of spring into pivot bracket with loop opening down as shown.

  • Page 7: Assembly / Pre-Operation

    ASSEMBLY / PRE-OPERATION INSTALL DISCHARGE CHUTE / CHUTE ROTATER HEAD (See Fig. 7) NOTE: The multi-wrench provided in your parts bag may be used to install the chute rotater head. 1. Place discharge chute assembly on top of chute base with discharge opening toward front of snow thrower.

  • Page 8: Operation

    OPERATION KNOW YOUR SNOW THROWER READ THIS OWNER'S MANUAL AND ALL SAFETY RULES BEFORE OPERATING YOUR SNOW THROWER. Compare the illustrations with your snow thrower to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. These symbols may appear on your snow thrower or in literature supplied with the product.
  • Page 9 SPARK PLUG SAFETY IGNITION CHOKE CON- TROL THROTTLE / ENGINE CONTROL RECOIL POWER (AUXILIARY) CORD STARTER PLUG ELECTRIC HANDLE START BUTTON PRIM ER NOTE: ITEMS ABOVE ARE SHOWN IN THEIR TYPICAL LOCATION ON THE ENGINE. ACTUAL LOCATION MAY VARY WITH THE ENGINE ON YOUR UNIT.
  • Page 10 The operation of any snow thrower can result in foreign objects thrown into the eyes, which can result in severe eye damage. Always wear safety glasses or eye shields while operating your snow thrower or performing any ad just - ments or repairs.

  • Page 11: To Move Forward And Backward

    AUGER CONTROL LEVER FIG. 15 USING THE CLEAN-OUT TOOL (See Fig. 16) In certain snow conditions, the discharge chute may be- come clogged with ice and snow. Use the clean-out tool to dislodge this blockage. When cleaning, repairing, or in spect ing, make certain all controls are disengaged and the auger/impeller and all moving parts have stopped.

  • Page 12: Before Starting The Engine

    NOTE: It is not recommended to operate the snow thrower over gravel or rocky surfaces. Objects such as gravel, rocks or other debris, can easily be picked up and thrown by the impeller, which can cause serious personal injury, property dam age or damage to the snow thrower.

  • Page 13: To Start Engine

    30 days or longer. Empty the gas tank, start the engine and let it run until the fuel lines and carburetor are empty. Use fresh fuel next sea- son. See Storage In struc tions for ad di tion al information. Never use engine or car bu re tor cleaner products in the fuel tank or per ma nent damage may occur.

  • Page 14: Maintenance Schedule

    GENERAL REC OM MEN DA TIONS The warranty on this snow thrower does not cover items that have been sub ject ed to operator abuse or negligence. To receive full value from the warranty, operator must maintain snow thrower as in struct ed in this manual. Some ad just - ments will need to be made periodically to properly maintain your snow thrower.

  • Page 15: Cleaning

    V-BELTS Check V-belts for deterioration and wear after every 50 hours of operation and replace if necessary. The belts are not ad just able. Replace belts if they begin to slip from wear. (See “TO REMOVE BELT COVER” in the Service and Adjustments section of this manual).

  • Page 16: Service And Adjustments

    SERVICE AND ADJUSTMENTS WARNING: To avoid serious injury, before performing any service or ad just ments: 1. Be sure throttle is in STOP position. 2. Remove safety ignition key. 3. Make sure the augers and all mov ing parts have completely stopped. 4.

  • Page 17: To Replace Belts

    SERVICE AND ADJUSTMENTS TO REPLACE BELTS (See Fig. 25) The auger and traction drive belts are not adjustable. If the belts are damaged or begin to slip from wear, they should be replaced. It is recommended that the belt(s) be replaced by a Sears service centre/department.

  • Page 18: Storage

    TO REMOVE WHEELS (See Fig. 26) • Remove the klik pin and remove wheel from axle. IMPORTANT: When installing wheel, be sure to use the axle hole closest to the end of the shaft – do not use the hole in the wheel hub (if equipped). Inner hole in axle and hole in wheel hub are not used for your model snow thrower.

  • Page 19: Troubleshooting

    TROUBLESHOOTING See appropriate section in manual unless directed to an authorized service centre/department. PROBLEM CAUSE Does not start 1. Fuel shut-off valve (if so equipped) in OFF position. 2. Safety ignition key is not inserted. 3. Out of fuel. 4. Throttle in STOP position (or ON/OFF switch is OFF).

  • Page 20: Repair Parts

    SNOW THROWER - MODEL PP13TEPH30 (96198000900) REPAIR PARTS AUGER HOUSING / IMPELLER ASSEMBLY...
  • Page 21 SNOW THROWER - MODEL PP13TEPH30 (96198000900) REPAIR PARTS AUGER HOUSING / IMPELLER ASSEMBLY KEY PART DESCRIPTION 191079 Pulley, Impeller 188909 Bearing Assembly, Flange 155377 Nut, Hex Flange 5/16-18 180355 Bolt, Flat Head, Carriage 5/16-18 x 5/8 72270505 Bolt, Carriage 5/16-18 163183 Bolt, Hex Head 5/16-18 x 5/8 404930X428...
  • Page 22 SNOW THROWER - MODEL PP13TEPH30 (96198000900) REPAIR PARTS CONTROL PANEL / DISCHARGE CHUTE...
  • Page 23 SNOW THROWER - MODEL PP13TEPH30 (96198000900) REPAIR PARTS CONTROL PANEL / DISCHARGE CHUTE KEY PART NOTE: All component dimensions given in U.S. inches. IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your snow thrower and void your warranty. DESCRIPTION 414280 Knob, Lever, Black...
  • Page 24 SNOW THROWER - MODEL PP13TEPH30 (96198000900) REPAIR PARTS HANDLES...
  • Page 25 SNOW THROWER - MODEL PP13TEPH30 (96198000900) REPAIR PARTS HANDLES KEY PART 412682X479 412681X479 169675 17060408 412677 196333X008 412679X008 412683X479 74780524 74780528 414519X479 414518X479 751153 19131316 178899 193447 180485 72120618 178643X479 180447 180926 178669 17000616 412680 408059 182906 175262 184471 17060410 178831 412675X004 178666...
  • Page 26 SNOW THROWER - MODEL PP13TEPH30 (96198000900) REPAIR PARTS DRIVE...
  • Page 27 SNOW THROWER - MODEL PP13TEPH30 (96198000900) REPAIR PARTS DRIVE KEY PART NOTE: All component dimensions given in U.S. inches. IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your snow thrower and void your warranty. DESCRIPTION 17490508 Screw 1/4-20 x 1/2...
  • Page 28 SNOW THROWER - MODEL PP13TEPH30 (96198000900) REPAIR PARTS CHASSIS / ENGINE / PULLEYS 10 21 6 42...
  • Page 29 SNOW THROWER - MODEL PP13TEPH30 (96198000900) REPAIR PARTS CHASSIS / ENGINE / PULLEYS KEY PART 192873 180522 74780520 150078 59289 166785 175330 405029 10040500 17490508 410420 85179 178828 403842 150406 187786 74780524 175331 180523 74610516 409475 180478 178813 400026 850263 851084 193607 409161...
  • Page 30 SNOW THROWER - MODEL PP13TEPH30 (96198000900) REPAIR PARTS WHEELS / DECALS 32 30 32 30...

  • Page 31: Repair Parts

    196753X421 Wheel Assembly, 16", with Power Steering, RH 700279 Clip, Retainer 12000045 Ring, Retaining DESCRIPTION 181037 Decal, Danger 416837 Decal, Poulan Pro, 13.0 / 30" 181035 Decal, Danger, Deflector 181042 Decal, Danger 406989 Decal, Poulan Pro 181033 Decal, Instruction 415399...

  • Page 32: Warranty

    This is a limited Warranty within the meaning of that term as defined in the Magnuson-Moss Act of 1975. LIMITED WARRANTY In Canada contact: Poulan Pro, Customer Service Department 5855 Terry Fox Way Mississauga, Ontario L5V 3E4...

This manual is also suitable for:

96198000900Pp13teph30
