SCHEMATIC DIAGRAMS
Everio
2 S ERVICE MANUAL
2007
YF180
GZ-MG150US, GZ-MG155US,
COPYRIGHT© 2007 Victor Company of Japan, Limited
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
HARD DISK CAMCORDER
GZ-MG157US
CD-ROM No.SML200703
COPYRIGHT© 2007 Victor Company of Japan, Limited
GZ-MG150USM [M7E313]
GZ-MG155USM,GZ-MG157USM [M7E315]
No.YF181SCH
2007/3
Advertisement
Table of Contents
Related Manuals for JVC GZ-MG150US
Summary of Contents for JVC GZ-MG150US
- Page 1 SCHEMATIC DIAGRAMS HARD DISK CAMCORDER YF180 2007 2 S ERVICE MANUAL Everio GZ-MG150US, GZ-MG155US, GZ-MG157US CD-ROM No.SML200703 GZ-MG150USM [M7E313] GZ-MG155USM,GZ-MG157USM [M7E315] COPYRIGHT© 2007 Victor Company of Japan, Limited Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) No.YF181SCH...
-
Page 2: Notes Of Schematic Diagram
CHARTS AND DIAGRAMS CIRCUIT BOARD NOTES 1. Foil and Component sides 4. Voltage measurement NOTES OF SCHEMATIC DIAGRAM 1) Foil side (B side) : Parts on the foil side seen from foil face (pattern face) 1) Regulator (DC/DC CONV) circuits Safety precautions are indicated. - Page 3 BOARD INTERCONNETION OPE. UNIT (Page2-23) INT MIC OP BLOCK ZOOM (Page2-24) SNAP MODE <FPC-M1-601C> YTU94074-26 YTU94074-10 YTU94074-22 YTU94077-26 YTU94077-10 <FPC-M1-108> YTU94077-22 CN104 YTU94105-40 YTU94077-40 CN107 CN106 CN105 CN102 39 DRV_3.3V /3.3V /3.3V 37 XHDDASP /DASP- 36 XHDCS1 /CS1- 35 XHDCS0 /CS0- 34 HDA2 /DA2...
-
Page 4: Main(Main I/F) Schematic Diagram
MAIN(MAIN I/F) SCHEMATIC DIAGRAM TO OPE.UNIT TO HDD TELE,WIDE,PHOTO-KEY,POWER,TRIGGER,GND 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 CN104 CN102 QGF0508F4-10X... -
Page 5: Main(Cpu) Schematic Diagram
MAIN(CPU) SCHEMATIC DIAGRAM L1001 NQL38DK-470X AL_3.1V IC1005 TO MAIN I/F,REG AL_3.1V IC1009 TO MAIN I/F C1013 AK6512CAM-X AL_3VSYS C1014 (CN108,CN110) YCBCJVSNS8031-X R1063 10k TO MAIN I/F(CN101) LIT_3V IC1006 TO OP DRIVE REG_3VSYS R2033T-F-X HOLD IC1007 L1002 REG_3.1V X1002 RESET S-80823CNNB-G-W NQL38DK-100X NAX0564-001X 32KOUT... -
Page 6: Main(Audio) Schematic Diagram
MAIN(AUDIO) SCHEMATIC DIAGRAM MAIN(AUDIO) Q2401 2SC4617/RS/-X REG_4.9V REG_3.1V TO REG L2402 R2401 4.7k Q2403 2SC4617/RS/-X L2401 R2402 4.7k C2403 10/6.3 C2401 R2408 C2402 10/6.3 OPEN 10/6.3 C2404 R2403 10/6.3 R2202 OPEN R2204 220k C2224 C2202 C2204 C2405 C2203 C2205 OPEN IC2201 AK4666VQ C2624... -
Page 7: Main(Dsp) Schematic Diagram
MAIN(DSP) SCHEMATIC DIAGRAM IC3004 ACHI0 L3012 X3001 ACHI0 TC7S66FU-X SHORT NAX0931-001X ACHI1 ACHI1 ACHI2 R3105 ACHI2 1.2k ACHI3 ACHI3 C3085 ACHI4 ACHI4 ACHI5 ACHI5 TO CDS/TG ACHI6 ACHI6 ACHI7 C3086 ACHI7 ACHI8 ACHI8 XCHDDMACK ACHI9 XCHDDMACK ACHI9 C3044 CHDDMARQ ACHI10 0.01 CHDDMARQ ACHI10... -
Page 8: Main(Cds/Tg) Schematic Diagram
MAIN(CDS/TG) SCHEMATIC DIAGRAM MAIN(CDS/TG) L4201 REG+CCD L4202 TO REG C4201 D4201 REG-CCD R4210 4.7/16 1SS355-X OPEN C4202 4.7/16 L4203 R4201 C4203 C4206 100K 22/6.3 4.7/25 CAM_3.1V TO MAIN I/F(CN101),REG C4228 TO CCD R4218 C4217 22/6.3 C4219 VDIN TO DSP,CPU CN105 R4219 QGF0543F3-22X HDIN... - Page 9 MAIN(OP DRIVE) SCHEMATIC DIAGRAM IC4903 IC4902 S-1112B31MC-W MM1614GN-X MAIN(OP DRIVE) C4924 1 2 3 C4923 1 2 3 C4925 C4926 C4927 L4902 REG_4.9V_IC4901 REG_4.9V NQL38DK-100X C4903 10/10 OPEN L4901 REG_3.1V_IC4901 REG_3.1V C4902 10/10 L4904 NQL38DK-100X C4941 OPEN R4955 C4942 R4959 C4935 C4936 R4954...
-
Page 10: Main(Reg) Schematic Diagram
MAIN(REG) SCHEMATIC DIAGRAM DC_CHECK CHRG_EVR I_MTR R6005 1k TO CPU REGRTC_OUT R6006 1k REGRTC_CLK R6007 1k IC6003 REG_CS R6008 OPEN SYS_RSTL TO MAIN I/F(CN110),CPU IC6002 OPEN R6016 OPEN C6012 OPEN TO MAIN I/F(CN103) BATT+ F6002 NMFZ007-2R5X-K R6019 0Ω TO MAIN I/F(CN108) ADP_DC R6001 0Ω... -
Page 11: Main(Usb) Schematic Diagram
MAIN(USB) SCHEMATIC DIAGRAM MAIN(USB) SREG_3.1V TO DSP REG_4.9V 3.1V R8365 OPEN REG_3.1V TO MAIN I/F(CN108) VBUS R8334 OPEN IC8304 REG_1.8V TO DSP,REG R8330 L8303 L8305 C8340 USBDN S-1112B31MC-W SHORT SHORT TO MAIN I/F C8337 R8329 USBDP R8360 USBDN_CR SHORT R8354 #FAULT TO MAIN I/F(CN108) R8361... -
Page 12: Main(1394Phy) Schematic Diagram
MAIN(1394PHY) SCHEMATIC DIAGRAM MAIN(1394PHY) L8802 REG_3.1V L8801 NQR0565-001X NQR0154-004X C8802 C8801 C8811 C8810 C8808 0.01 0.01 C8809 0.01 TO AUDIO,DSP AOMCLK C8807 TO DSP PHY1394_RST PHYLREQ LREQ AGND R8801 PHYSCLK SYSCLK PHY1394_CNA PHYCTL0 CTL0 PHYCTL1 CTL1 PHYD0 PHYD1 AVDD IC8801 PHYD2 TSB41AB1ZQE-X PHYD3... -
Page 13: Ope.unit Schematic Diagram
OPE.UNIT SCHEMATIC DIAGRAM CCD SCHEMATIC DIAGRAM <OPE.UNIT> TO MAIN I/F (CN104) ZOOM_SW FULL HALF REG_3.1V FULL_SW TO MAIN (CDS/TG) HALF_SW CN5001 C5006 MODE_SW 22 GND 21 GND DIAL_ON 20 SUB C5005 19 H1 DIAL_OFF 18 H2 MODE TRIG_SW 17 RG 16 V6 TRIG 15 V5... -
Page 14: Ope Schematic Diagram
OPE SCHEMATIC DIAGRAM TO SPEAKER CN403 QGA1001F1-02X 1mm_ML DIRECT DVD DIRECT B.UP AUTO/INFO REC/PB MENU R403 R402 R401 6.8k 3.3k S406 S405 S404 S403 S402 NSW0198-001X NSW0198-001X NSW0198-001X NSW0198-001X NSW0198-001X TO MAIN CN401 QGF0549C2-30W SPK- 29 SPK+ TO MONITOR CAM_3.1V CN402 QGF0534F2-22X 27 CAM_3.1V... -
Page 15: Monitor Schematic Diagram
MONITOR SCHEMATIC DIAGRAM MONITOR R7504 3.3k S7501 NSW0297-002X R7501 R7502 R7503 CROSS KEY 3.3K 6.8K FUNCTION INDEX_BATT RIGHT S7502 S7503 NSW0198-001X NSW0198-001X LEFT DOWN TO OPE TL7601 TL7602 TL7603 TL7604 TL7605 TL7606 TL7607 TL7608 TL7609 CN7601 LCD_CS AU_LV_OUT AU_LV_CLK HRPLCD VDLCD HDLCD MON_B... -
Page 16: Voltage Charts
VOLTAGE CHARTS BATT TERMINAL SCHEMATIC DIAGRAM <MAIN> MODE MODE MODE MODE MODE PLAY PLAY PLAY PLAY PLAY PIN NO. PIN NO. PIN NO. PIN NO. PIN NO. IC121 -0.1 Q7001 Q3001 12.6 12.6 12.6 Q7002 IC3001 IC3002 Q3701 IC3003 15.0 IC1001 IC3004 12.0... -
Page 17: Main Circuit Board
MAIN CIRCUIT BOARD CAUTION : FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH SAME TYPE AND RATED FUSE(S). ATTENTION : POUR UNE PROTECTION PERMANENTE CONTRE LES RISQUE D'INCENDE, REMPLACER LES FUSIBLES PAR UNAAUTRE DE MEME TYPE ET DE MEME TENSION. Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) <01>MAIN LYB10090-001A... - Page 18 MAIN CIRCUIT BOARD CAUTION : FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH SAME TYPE AND RATED FUSE(S). ATTENTION : POUR UNE PROTECTION PERMANENTE CONTRE LES RISQUE D'INCENDE, REMPLACER LES FUSIBLES PAR UNAAUTRE DE MEME TYPE ET DE MEME TENSION. Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) <01>MAIN LYB10090-001A...
- Page 19 CCD,OPE,MONITOR AND BATT TERMINAL CIRCUIT BOARDS Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) <02>CCD <05>MONITOR LYB10092-001A LYB10089-001A COMPONENT SIDE(A) COMPONENT SIDE(A) FOIL SIDE(B) S7501 C5004 C5002 C5001 Q5002 Q5001 R5007 C5006 R5006 FOIL SIDE(B) <04>OPE LYB10089-001A...
-
Page 20: Power System Block Diagram
POWER SYSTEM BLOCK DIAGRAM BATT MAIN CDS/TG TERMINAL CN105 CN105 REG+CCD 19,20 REG+CCD T_BATT REG-CCD IC5001 OP BLOCK 21,22 REG-CCD D_BATT BATT_CHK ADP_L IC1001 IC4201 AL_3.1V Q6701,Q6703 CAM_3.1V BT651 CN651 CN103 Q6001 F6002 REG_4.9V BATT_+ Q5001 4.9V AL_3VSYS T_BATT TO BATTERY IC6001 D_BATT IC1004... -
Page 21: Video System Block Diagram
VIDEO SYSTEM BLOCK DIAGRAM MONITOR MAIN LCD MODULE CN101 CN401 CN402 CN7601 CN7602 VA(R) CN5001 CN105 MON_R CCD_OUT VB(G) MON_G GREEN VC(B) MON_B BLUE IC4201 IC5001 H1, H2 19,20 OP BLOCK ( CDS/TG ) ( 1/6 Inch CCD Image sensor ) X4201 V1-V4 13-16... - Page 22 Victor company of Japan, Limited Camcorder Category 12, 3-chome, Moriya-cho, Kanagawa-ku, Yokohama-city, Kanagawa-prefecture, 221-8528, Japan (No.YF181) Printed in Japan...
