FOREWORD
This repair manual has been prepared to provide information on
the repair methods (including cutting and welding operations,
but excluding painting) recommended by TOYOTA for collision-
damaged body components of the TOYOTA CAMRY.
Applicable models:
This manual consists of body repair methods, exploded dia-
grams and illustrations of the body components and other infor-
mation relating to body panel replacement such as handling pre-
cautions, tools, equipment, etc. However, it should be noted that
the front fenders of all TOYOTA models are bolted on and re-
quire no welding.
Body construction will sometimes differ depending on specifica-
tions and country of destination. Therefore, please keep in mind
that the information contained herein is based on vehicles for
general destinations.
For the service of specifications and repair procedures other
than collision-damaged body components of the TOYOTA
CAMRY, refer to the following repair manuals.
Manual Name
CAMRY Chassis and Body Repair Manual
CAMRY Repair Manual (USA and Canada)
Electrical Wiring Diagram
(Ex. USA and Canada)
(USA and Canada)
1S, 1S-E, 2S, 2S-C, 2S-E, 3S-FE & 3S-GE
Engine Repair Manual (Ex. USA and
Canada)
1C, 2C & 2C-T Engine Repair Manual
(Ex. USA and Canada)
Fundamental Painting Procedures
Fundamental Body Repair Procedures
All information contained in this manual is the most up-to-date
at the time of publication. However, specifications and proce-
dures are subject to change without prior notice.
SV20, 21 series
CV20 series
TOYOTA MOTOR CORPORATION
Pub. No.
36216E
Model Year
Version
EWD027E
Model Year
Version
RM051E
RM025E
36438E
BRM002E
