SOFTWARE ADJUSTMENT (continued)
ADJUSTMENT
ADJUSTMENT CONDITION
• Enter software adjustment mode (Refer
ADJUSTMENT
1
page 5-12).
ITEM (2)
S-METER
• Push [2] key to enter the S-meter adjust-
ment
(MAIN BAND)
• Connect an SSG to [VHF ANT] connector
and set as
Frequency
Level
• Receiving
• Set an SSG as
2
Frequency
Level
• Receiving
• Set an SSG as
3
Frequency
Level
• Receiving
• Set an SSG as
4
Frequency
Level
• Receiving
• Set an SSG as
5
Frequency
Level
Modulation
• Receiving
• Set an SSG as
6
Frequency
Level
• Receiving
• Set an SSG as
(SUB BAND)
7
Frequency
Level
• Receiving
• Set an SSG as
8
Frequency
Level
• Receiving
• Set an SSG as
9
Frequency
Level
• Receiving
*This output level of a standard signal generator (SSG) is indicated as SSG's open circuit.
:
: 146.0200 MHz
: OFF
:
: 146.0200 MHz
: 3.2 µV* (–97 dBm)
:
: 146.0200 MHz
: 1 mV* (–47 dBm)
:
: 146.0200 MHz
: OFF
:
: 146.0200 MHz
: 3.2 µV* (–97 dBm)
: OFF
:
: 146.0200 MHz
: 32 µV* (–77 dBm)
:
: 146.0200 MHz
: OFF
:
: 146.0200 MHz
: 3.2 µV* (–97 dBm)
:
: 146.0200 MHz
: 1 mV* (–47 dBm)
5 - 13
DISPLAY
USB
USB
USB
USB
USB
USB
FM
FM
FM
SUB
USB
SUB
USB
SUB
USB
OPERATION
Push [RIT] key to store the "S0" level
into memory, and to step next.
Push [RIT] key to store the "S9" level
into memor, and to step next.
Push [RIT] key to store the "S9+60"
level into memory, and to step next.
Push [RIT] key to store the "S0" level
into memory, and to step next.
Push [RIT] key to store the "S9" level
into memory, and to step next.
Push [RIT] key to store the "S9+60"
level into memory, and to step next.
Push [RIT] key to store the "S0" level
into memory, and to step next.
Push [RIT] key to store the "S9" level
into memory, and to step next.
Push [RIT] key to store the "S9+60"
level into memory, and to step next.
