- Page 1 INSTALLATION/OPERATION MANUAL MIRATRON WIRELESS REMOTE CONTROL RADIO MAYCO MODEL C30HDZ Revision #0 (09/09/09) THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Warranty ......... 3 Overview ........4 Specifi cations ........ 5 Care And Handling ......6 Parts ..........7 Antenna Mounting ......7-8 Mounting Bracket Installation ..9 Receiver Mounting ......10 Throttle Cable Removal ....11 Control Box Removal ..... 12 Cable Installation ...... -
Page 3: Warranty
WARRANTY LIMITED ONE YEAR WARRANTY Miratron Incorporated, hearafter referred to as Miratron, is providing this warranty in lieu of all other express or implied warranties, including any warranty of merchantability or fi tness for a particular purpose. This warranty is buyer’s exclusive remedy for all claims against Miratron. Miratron shall not be liable for any consequential or incidental damages. -
Page 4: Overview
OVERVIEW ALWAYS read manual before attempting to operate the equipment. Failure not to read manual could cause severe equipment damage and or damage to the receiver and transmitter. Make sure work area is safe to operate radio control receiver and transmitter. -
Page 5: Specifi Cations
SPECIFICATIONS Table 1. Specifi cations Miratron Model Number: RX4 Radio Control Receiver CMD16-0138 ~ (MQ P/N EM98216) General: Power Requirements 12-24VDC, 500mA max Radio: Frequency Standard 902-928 MHz, FHSS, ISM Band Frequecy Control Direct FM FCC ID OUR9XCITE (Standard) Receiver Sensitivity -106 dBM CMD16-0138 ~ (MQ P/N EM98216) Transmitter:... -
Page 6: Care And Handling
CARE AND HANDLING Transmitter: Clean transmitter gently with a damp cloth. DO NOT immerse transmitter in water, or spray with hose. DO NOT store outside. DO NOT drop transmitter or otherwise subject transmitter to physical shock. DO NOT expose transmitter to extreme temperatures. -
Page 7: Parts
PARTS/ANTENNA MOUNTING Parts: Make sure all parts are accounted for before performing the installation. The following parts are included with the kit: Radio Transmitter Radio Receiver Spiral Antenna with associated mounting hardware Coaxial Antenna Cable Data /Power Cable (5-wire) ... -
Page 8: Antenna Mounting
ANTENNA MOUNTING Install the radio receiver mounting bracket as shown in Figure 2. Install radio receiver as shown in (Figure 3). onnect BNC end of coaxial antenna cable to BNC connector on radio control receiver. STEP 3 LOCKING FLANGE ANTENNA RUBBER GASKET COAXIAL... -
Page 9: Mounting Bracket Installation
MOUNTING BRACKET INSTALLATION Receiver Mounting Bracket Installation Install the radio receiver mounting bracket to the frame of the C30HDZ as shown in Figure 2. Using the bracket as a template, mark the holes to be drilled on the frame. Drill two 3/8-diameter holes into the frame as shown in Figure 2. After both holes have been drilled, deburr each hole opening. -
Page 10: Receiver Mounting
RECEIVER MOUNTING Radio Receiver Mounting Using a 1/4-20 x 1-1/4 bolt (2), 1/4 lock washer (2), 1/4 fl at washer (2) and 1/4 nut (2), mount the radio control receiver onto the radio receiver mounting bracket as shown in Figure 3. Figure 3. -
Page 11: Throttle Cable Removal
THROTTLE CABLE REMOVAL NOTICE The removal of the control box may not be required. If wiring connections, crimping and splicing can be made without removing the box, then disregard control box/ throttle cable removal instructions. Throttle Cable Removal Remove air fi lter. Using a 7/8-inch wrench loosen the jam nut (Figure 4) that secures the throttle cable to the control box. -
Page 12: Control Box Removal
CONTROL BOX REMOVAL Control Box Removal Using a 10 mm wrench, remove the upper bolt (Figure 5) that secures the control box bracket to the engine. Using a 13 mm wrench, remove the lower bolt that secures the control box to the engine V-belt cover. Position control box so that wire side is facing upwards. -
Page 13: Cable Installation
CABLE INSTALLATION Data Cable Connections Wire data cable into control box as shown in Figure 6. Splice RED wire labeled BATT+. and connect to relay K1, pin 30 (12 volt key switch ON). Disconnect engine fuel solenoid BLACK ground wire from the control panel support bracket. -
Page 14: Wiring Diagram
WIRING DIAGRAM 12-PIN DATA CABLE I V E 5-WIRES FRAME GROUND (BLACK) REMOTE (WHITE) TERMINAL RING BLACK YELLOW REMOTE CABLE BATT + (RED) WHITE SPLICE DEUTZ ENGINE NO PUMP ON CONNECTOR (WHITE) E-STOP (WHITE) IGNITION SPLICE SPLICE SWITCH BLACK HOUR METER RED WIRE (ADD) -
Page 15: Transmitter/Receiver
TRANSMITTER/RECEIVER The defi nitions below describe the controls and functions of the Miratron Transmitter and Radio Control Receiver (Figure 7). Transmitter Power On Switch — Place this switch in the ON position to turn on the transmitter. Be sure to place this switch in the OFF position when the system is not in use. -
Page 16: Transmitter/Receiver
TRANSMITTER/RECEIVER Functional Test Perform the functional test procedure below to test the remote control radio system. Start the engine as outlined on the operator’s manual. Place the transmitter power ON/OFF switch (Figure 7) in the ON position. Place the pumping control switch on the control box in the REMOTE ON position. -
Page 17: Troubleshooting
TROUBLESHOOTING Table 2. Troubleshooting Symptom Possible Problem Solution Transmitter does not LED status indicator not Turn transmitter power function at all fl ashing. switch ON. Weak dead battery, replace batteries. Check orientation of batteries. Make sure transmitter has LED indicator not lit when be matched (paired) to power ON/OFF switch is receiver. -
Page 18: System Wiring Diagram
SYSTEM WIRING DIAGRAM Figure 8. System Wiring Diagram PAGE 18 — INSTALLATION OPERATION MANUAL — REV. #0 (09/09/09) - Page 19 NOTE PAGE INSTALLATION/OPERATION MANUAL — REV. #0 (09/09/09) — PAGE 19...
-
