Draytek Vigor2960 series User Manual page 105

Available parameters are listed as follows:
Item
Profile
Enable This Profile
WAN Profile
Private IP
Use IP Alias
IP Alias
Apply
Cancel
4. Enter all the settings and click Apply.
5. A new profile has been added onto DMZ Host table.
Vigor2960 Series User's Guide
Description
Type the name of the profile.
Check the box to enable the DMZ Host profile.
Choose a WAN profile for such entry.
Type the private IP used for this entry.
Click Enable to invoke IP Alias function.
IP alias that can be selected and used for port redirection.
Before using it, please go to WAN>>General Setup and
enable the wan1 profile. Add several IP addresses under
Static mode for wan1.
Click it to save and exit the dialog.
Click it to exit the dialog without saving anything.
97
