PC Setup
PC Setup
- This TV provides Plug and Play capability, meaning that the PC adjusts automatically to the TV's settings. The TV sends config-
uration information (EDID) to the PC using the Video Electronics Standard Association (VESA) Display Data Channel (DDC)
protocol.
- The TV perceives 640x480, 60Hz as DTV 480p based on the PC graphic card. Change the screen scanning rate for the graphic
card accordingly.
How to connect
1. To get the best picture quality, adjust the PC graphics card to 1024x768, 60Hz.
2. Use the TV's RGB INPUT, RGB-PC or RGB-DTV for video connections, depending on your PC connector.
• If the graphic card on the PC does not output analog and digital RGB simultaneously, connect only one of either RGB INPUT,
RGB-PC or RGB-DTV to display the PC on the TV.
• If the graphic card on the PC does output analog and digital RGB simultaneously, set the TV to either RGB or DVI; (the other
mode is set to Plug and Play automatically by the TV.)
3. Then, make the corresponding audio connections. If using a sound card, adjust the PC sound as required.
How to use
1. Turn on the PC and the TV.
2. Turn on the display by pressing the POWER button on the TV's remote control.
3. Select RGB-PC input source in main input option of SETUP menu. (Refer to P.20)
4. Check the image on your TV. There may be noise associated with the resolution, vertical pattern, contrast or brightness in PC
mode. If noise is present, change the PC mode to another resolution, change the refresh rate to another rate or adjust the
brightness and contrast on the menu until the picture is clear. If the refresh rate of the PC graphic card can not be changed,
change the PC graphic card or consult the manufacturer of the PC graphic card.
NOTES: • Depending on the graphics card, DOS mode may not work if you use a DVI-I cable.
• Avoid keeping a fixed image on the TV's screen for a long period of time. The fixed image may become permanently
imprinted on the screen. Use the Orbiter screen saver when possible.
• The synchronization input form for Horizontal and Vertical frequencies is separate.
Monitor Display Specifications (RGB-PC / DVI-PC Mode)
Horizontal
Resolution
Frequency(KHz)
31.468
640x350
37.861
31.469
720x400
37.927
31.469
37.861
640x480
37.500
43.269
16 DLP Projection TV
Vertical
Resolution
Frequency(Hz)
70.09
85.08
800x600
70.08
85.03
59.94
72.80
75.00
1024x768
85.00
Horizontal
Vertical
Frequency(KHz)
Frequency(Hz)
35.156
56.25
37.879
60.31
48.077
72.18
46.875
75.00
53.674
85.06
48.363
60.00
56.476
70.06
60.023
75.02
