Thank you for purchasing this product.
Please read these instructions carefully before using this product, and save this manual for future use.
If you have any questions, visit : www.panasonic.com/support
Register online at www.panasonic.com/register
Please also read through the "Owner's Manual <Setup>".
P
DVD Home Theater Sound System
Firmware updates
Panasonic is constantly improving the unit's firmware to ensure that our
customers are enjoying the latest technology.
Panasonic recommends updating your firmware as soon as you are
notified.
For details, refer to "Firmware updates" (
http://panasonic.jp/support/global/cs/ (This site is in English only.)
(U.S. customers only)
Owner's Manual
<Operations>
Model No. SC-XH105
7) or
VQT5J81
Advertisement
Table of Contents
Related Manuals for Panasonic SC-XH105
Summary of Contents for Panasonic SC-XH105
- Page 1 <Operations> DVD Home Theater Sound System Model No. SC-XH105 Firmware updates Panasonic is constantly improving the unit’s firmware to ensure that our customers are enjoying the latest technology. Panasonic recommends updating your firmware as soon as you are notified. For details, refer to “Firmware updates” ( 7) or http://panasonic.jp/support/global/cs/ (This site is in English only.)
-
Page 2: Important Safety Instructions
Responsible Party: Panasonic Corporation of North America Two Riverfront Plaza, Newark, NJ 07102-5490 Support Contact: http://www.panasonic.com/contactinfo VQT5J81... -
Page 3: Precautions
Precautions To dispose or transfer this unit WARNING The unit may keep the user settings information in the unit. If you Unit discard this unit either by disposal or transfer, then follow the procedure to return all the settings to the factory presets to delete To reduce the risk of fire, electric shock or product damage, the user settings. -
Page 4: Table Of Contents
Table of contents Accessories Getting started IMPORTANT SAFETY INSTRUCTIONS ..2 Check the supplied accessories before using this Precautions ......3 unit. -
Page 5: Package Contents
Package contents Check the package contents before using this unit. Main unit (SA-XH105) CENTER FRONT SURROUND (SB-HC3010) (SB-HF3010) (SB-HS3010) SUBWOOFER (SB-HW3010) VQT5J81... -
Page 6: Media Information
Media information ∫ Region management information The unit can playback DVD-Video discs of the ∫ Playable media following regions codes, including “ALL”: DVD-Video Video Example: DVD-R Video, Xvid, MOV, JPEG, MP3 DVD-R DL DVD-RW Video +R/+RW/+R DL ∫ Finalize Music CD Music [CD-DA], Any DVD-R/RW/R DL, +R/+RW/+R DL and VCD, SVCD... -
Page 7: Setting Up The System
∫ HDMI ≥ Use the ARC* compatible High Speed HDMI cables. Non-HDMI-compliant cables cannot be utilized. It is recommended that you use Panasonic’s HDMI cable. When outputting 1080p signal, please use HDMI cables 5.0 meters (16.4 ft.) or less. * ARC is an abbreviation of Audio Return Channel, also known as HDMI ARC. -
Page 8: Overview
Control reference guide 17 18 19 VQT5J81... - Page 9 [3, 4, 2, 1] [Í] Turn the unit on and off Move the highlight for selection [Í TV] [OK] Turn the TV on and off Confirm the selection [AV, INPUT] [OPTION] Switch the input select of TV Show Option menu ( [SUBTITLE] [RETURN Change the subtitle settings...
-
Page 10: Enjoying Tv With The Speakers Of The System
Playback Enjoying TV with the Basic operations speakers of the system Turn on the TV and select the appropriate video input. When the system is connected to the HDMI Press [Í]. terminal of an ARC-compatible TV, the speakers of the system output the sound of the TV. Insert the media. -
Page 11: Hdmi Cec
“HDMI CEC” Listening to the Radio This unit supports “HDMI CEC” (Consumer You can preset up to 30 channels. Electronics Control) function. Tuning and presetting See the owner’s manual for connected equipment for operational details. Press [RADIO]. Preparation Set “HDMI CEC” to “On” ( 13). -
Page 12: Changing The Sound Settings
Changing the sound Option menu Advanced operations settings A variety of playback operations and settings can be performed through this menu. Sound Mode/Subwoofer Level Available options differ depending on the playing contents and the condition of the unit. ∫ Sound Mode Press [OPTION]. -
Page 13: Setup Menu
Setup menu ∫ Power Off Link Select the desired power off link setting of this unit Change the unit’s settings if necessary. The for HDMI CEC operation. settings remain intact even if you switch the unit Video/Audio to standby. When the TV is turned off, this unit will turn off automatically. - Page 14 ∫ 5.1ch Front Layout Delay time for the Center speaker Subtract the distance 1 from 3 When you place all the speakers in a row at the front, adjust the settings to achieve optimum Distance (Approx.) Setting effects. 34 cm 1.0 ms 68 cm 2.0 ms...
-
Page 15: Speaker Installation Option
Speaker installation VIDEO option ∫ Resolution Select suitable picture quality with your TV. Consult a qualified building contractor when (Video recordings will be converted to, and output attaching the speakers to a wall. Improper as, high-definition video.) attachment may result in damage to the wall and ≥... -
Page 16: Troubleshooting Guide
Do you have the latest firmware installed? Thread a cord to the speaker. Panasonic is constantly improving the unit’s ≥ Use a cord of less than ‰ 2.0 mm ( firmware to ensure that our customers are enjoying the latest technology. - Page 17 This unit does not recognize the USB Radio connection correctly. Disconnect and re-connect the USB cable. If Distorted sound or noise is heard. it still does not recognize the connection, turn Adjust the position of the antenna. this unit off and on again. USB devices may not be recognized by this A beat sound is heard.
-
Page 18: Specifications
Specifications VIDEO SECTION GENERAL Signal system PAL/NTSC Video output Output level: 1.0 Vp-p (75 ≠) Power consumption Approx. 38 W Output connector: Power consumption in Approx. 0.5 W Pin jack (1 system) standby mode HDMI AV output* Output connector: Power supply AC 120 V, 60 Hz Type A (19 pin) 1 system 430 mm k 55 mm k 322 mm... -
Page 19: Limited Warranty (Only For U.s.a.)
If your product does not work properly because of a defect in materials or “LIMITED WARRANTY COVERAGE”. workmanship, Panasonic Corporation of North America (referred to as “the THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR warrantor”) will, for the length of the period indicated on the chart below, which CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS starts with the date of original purchase (“warranty period”), at its option either... -
Page 20: Index
United States and other countries. MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson. “DVD Logo” is a trademark of DVD Format/Logo Licensing Corporation. Panasonic Corporation of North America Two Riverfront Plaza, Newark, NJ 07102-5490 http://www.panasonic.com Panasonic Corporation 2014 VQT5J81...
