QUICK GUIDE
Operating
Instructions
Air Conditioner
Indoor Unit
Outdoor Unit
S-PA7GKD
U-PA7GKD
S-PA9GKD
U-PA9GKD
S-PA12GKD
U-PA12GKD
Operating Instructions
Air Conditioner
Indoor Unit
CS-YE9MKE
CS-YE12MKE
CS-YE18MKE
ENGLISH
Before operating the unit, read these operating instructions
thoroughly and keep them for future reference.
© Panasonic Home Appliances Air-Conditioning
(Guangzhou) Co., Ltd. 2010. Unauthorized
copying and distribution is a violation of law.
Outdoor Unit
CU-YE9MKE
CU-YE12MKE
CU-YE18MKE
F567885
Advertisement
Related Manuals for Panasonic CS-YE9MKE
Summary of Contents for Panasonic CS-YE9MKE
- Page 1 QUICK GUIDE Operating Instructions Air Conditioner Indoor Unit Outdoor Unit S-PA7GKD U-PA7GKD © Panasonic Home Appliances Air-Conditioning S-PA9GKD U-PA9GKD S-PA12GKD U-PA12GKD (Guangzhou) Co., Ltd. 2010. Unauthorized copying and distribution is a violation of law. F567885...
-
Page 2: Table Of Contents
ENGLISH Thank you for purchasing Panasonic Air Conditioner TABLE OF CONTENTS SAFETY PRECAUTIONS ........................8~9 REMOTE CONTROL ........................10~11 INDOOR UNIT ............................ 12 TROUBLESHOOTING ........................13 INFORMATION ........................... 62~67 PRODUCT SPECIFICATION ......................68 QUICK GUIDE .......................BACK COVER NOTE: The illustrations in this manual are for explanation purposes only and may differ from the actual unit. It is... -
Page 3: Operation Condition
OPERATION CONDITION Use this air conditioner under the following temperature range Indoor Outdoor Temperature (°C) *DBT *WBT *DBT *WBT Maximum COOLING Minimum Maximum * DBT: Dry bulb temperature HEATING Minimum * WBT: Wet bulb temperature NOTICE: • This model is not suitable for 24 hours non-stopping operation in heating mode below -5°C. When the outdoor temperature is below -5°C and you use this model out of above conditions, the outdoor unit might be frozen up and stop operation for protection control. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS To prevent personal injury, injury to others, or property damage, please comply the following. WARNING Incorrect operation due to failure to follow instructions may cause harm or damage, the seriousness of which is classified as below: INDOOR UNIT AND OUTDOOR UNIT This appliance is not intended for use by persons (including children) with reduced WARNING... - Page 5 WARNING CAUTION POWER SUPPLY INDOOR UNIT AND OUTDOOR UNIT If the supply cord is damage, it must be Do not wash the indoor unit with water, replaced by the manufacturer, its service agent benzene, thinner or scouring powder to avoid or similarly qualified persons in order to avoid damage or corrosion at the unit.
-
Page 6: Remote Control
REMOTE CONTROL TO ADJUST AIRFLOW DIRECTION (5 OPTIONS) AIR SWING Maximum distances: 8m • Keeps the room ventilated. • In COOL mode, if AUTO is set, the louver swing up/down automatically. • In HEAT mode, if AUTO is set, the horizontal louver fix at predetermined position. -
Page 7: To Set The Timer
TO SET THE TIMER DELAY ON AND OFF TIMER (12-HOUR TIMER SETTING) For example, to start the air conditioner 7 hours later and stop 10 hours later. • When you want the air conditioner to turn ON or OFF 1 To select the Delay ON and OFF Timer, press the automatically. -
Page 8: Indoor Unit
INDOOR UNIT • Switch off the power supply before cleaning. • Do not touch the aluminium fin, sharp parts may cause injury. CAUTION WASHING INSTRUCTIONS HINT • Do not use benzene, thinner or scouring powder. • To ensure optimal performance of the unit, cleaning •... -
Page 9: Troubleshooting
TROUBLESHOOTING The following symptoms do not indicate malfunction. SYMPTOM CAUSE Mist emerges from indoor unit. ► • Condensation effect due to cooling process. Water flowing sound during operation. ► • Refrigerant flow inside the unit. The room has a peculiar odour. ►... -
Page 10: Product Specification
PRODUCT SPECIFICATION Indoor Unit Outdoor Unit CS-YE9MKE CS-YE12MKE CS-YE18MKE CU-YE9MKE CU-YE12MKE CU-YE18MKE Model COOL HEAT COOL HEAT COOL HEAT Single, 230V,50Hz Single, 230V,50Hz Single, 230V,50Hz [kW] 0.760 0.880 1.020 1.105 1.660 1.615 Power/Current 3.60 4.10 4.90 5.20 7.90 7.70 R410A... - Page 12 MEMO...
- Page 13 MEMO...
-
Page 14: Quick Guide
Pursuant to at the directive 2004/108/EC, article 9(2) Selecteer de gewenste temperatuur. Panasonic Testing Centre Programe a temperatura desejada. Panasonic Service Europe, a division of Ρυθμίστε την επιθυμητή θερμοκρασία. Panasonic Marketing Europe GmbH Настройка на желаната температура. Winsbergring 15, 22525 Hamburg, F.R. Germany...
