SPLIT-TYPE,HEAT PUMP AIR CONDITIONERS
TECHNICAL MANUAL
PUG & PUGH
<Cooling>
AK
PUG18
Models
BK
AK
PUG24
BK
AK
PUG30
BK
AK
PUG36
BK
AK
PUG42
BK
Applies to: 208/230 VAC
Single and Three Phase Models

Condensing Units

<Heat Pumps>
PUGH18
PUGH24
PUGH30
PUGH36
PUGH42
MITSUBISHI ELECTRIC
ADVANCED AND EVER ADVANCING
AK
BK
AK
BK
AK
BK
AK
BK
AK
BK
The Slim Line.
From Mitsubishi Electric.
NO. SP-007

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi Electric PUG18AK

Summary of Contents for Mitsubishi Electric PUG18AK

  • Page 1: Condensing Units

    SPLIT-TYPE,HEAT PUMP AIR CONDITIONERS NO. SP-007 TECHNICAL MANUAL PUG & PUGH Condensing Units <Cooling> <Heat Pumps> PUG18 PUGH18 Models PUG24 PUGH24 PUG30 PUGH30 PUG36 PUGH36 PUG42 PUGH42 Applies to: 208/230 VAC Single and Three Phase Models The Slim Line. From Mitsubishi Electric.
  • Page 2 CONTENTS FEATURES ................SP-007-2 SPECIFICATIONS ..............SP-007-3 STANDARD OPERATING DATA........SP-007-5 PERFORMANCE DATA - OPERATING PRESSURE ..SP-007-8 COOLING MODE ............SP-007-8 HEATING MODE............SP-007-21 DIMENSIONS & CLEARANCES........SP-007-24 OPERATING RANGE ............SP-007-25 REFRIGERANT CHARGE (R-22 (oz)) ADJUSTMENT FOR OPTIMUM PERFORMANCE ........SP-007-26 CAPACITY CORRECTION FACTORS FOR VARIOUS PIPE LENGTHS..............SP-007-27 MICROPROCESSOR CONTROL ........SP-007-28 ELECTRICAL ..............SP-007-31 REFRIGERANT SYSTEM ..........SP-007-37...
  • Page 3 IS A HEAT PUMP 2. PUG OUTDOOR CONDENSING UNITS ARE DESIGNED SPECIFICALLY FOR USE WITH MITSUBISHI ELECTRIC PK, PC AND PL MR. SLIM INDOOR UNITS OF MATCHING NOMINAL CAPACITY These units are provided with an outdoor circuit board that is “standard to all models” and operates all functions of the condensing unit.

  • Page 4: Specifications

    SPECIFICATIONS PK SERIES – AIR CONDITIONING SYSTEMS System Indoor Outdoor BTU/h S.E.E.R. E.E.R PKG18FK1 PK18FK1 PUG18 18,000 12.0 11.0 PKG24FK1 PK24FK1 PUG24 24,000 12.0 11.2 PKG30FK1 PK30FK1 PUG30 29,600 12.0 11.2 PKG36FK1 PK36FK1 PUG36 34,200 12.0 11.1 PKH SERIES – HEAT PUMP SYSTEMS BTU/h BTU/h System...
  • Page 5 Specifications subject to change without notice. *cooling tested at 95DB/75WB O/D and 80 DB/67 WB I/D. (Deg.F) † heating tested at 47-53/70-60 (deg.F) ELECTRICAL SPECIFICATIONS - AIR CONDITIONING CONDENSING UNITS Model PUG18AK PUG24AK PUG30AK PUG36AK PUG42AK Compressor 1 PH 45.0 63.0 72.5...
  • Page 6 STANDARD OPERATING DATA PKH-FK INDOOR UNITS WITH PUG AND PUGH OUTDOOR UNITS SP007-5...
  • Page 7 STANDARD OPERATING DATA INDOOR UNITS WITH PUG AND PUGH OUTDOOR UNITS SP007-6...
  • Page 8 STANDARD OPERATING DATA INDOOR UNITS WITH PUG AND PUGH OUTDOOR UNITS SP007-7...
  • Page 9 PERFORMANCE DATA – OPERATING PRESSURES PK/H18FK PUG/H18 with (Indoor Air = 710 CFM) 75°F Outdoor Air Temperature Net Sensible Cooling Capacity (Btu/Hr) Pressures Indoor Cooling Total (psig) Wet Bulb Capacity Power Indoor Dry Bulb (°F) (°F) (Btu/Hr) (Watts) Suction Disch. 18,288 14.51 1,261...
  • Page 10 PERFORMANCE DATA – OPERATING PRESSURES PK/H24FK PUG/H24 with (Indoor Air = 640 CFM) 75°F Outdoor Air Temperature Net Sensible Cooling Capacity (Btu/Hr) Pressures Indoor Cooling Total (psig) Wet Bulb Capacity Power Indoor Dry Bulb (°F) (°F) (Btu/Hr) (Watts) Suction Disch. 22,555 13.40 1,683...
  • Page 11 PERFORMANCE DATA – OPERATING PRESSURES PK/H30FK PUG/H30 with (Indoor Air = 990 CFM) 75°F Outdoor Air Temperature Net Sensible Cooling Capacity (Btu/Hr) Pressures Indoor Cooling Total (psig) Wet Bulb Capacity Power Indoor Dry Bulb (°F) (°F) (Btu/Hr) (Watts) Suction Disch. 30,074 14.73 2,042...
  • Page 12 PERFORMANCE DATA – OPERATING PRESSURES PK/H36FK PUG/H36 with (Indoor Air = 990 CFM) 75°F Outdoor Air Temperature Net Sensible Cooling Capacity (Btu/Hr) Pressures Indoor Cooling Total (psig) Wet Bulb Capacity Power Indoor Dry Bulb (°F) (°F) (Btu/Hr) (Watts) Suction Disch. 34,747 14.60 2,380...
  • Page 13 PERFORMANCE DATA – OPERATING PRESSURES PL/H18FK PUG/H18 with (Indoor Air = 600 CFM) 75°F Outdoor Air Temperature Net Sensible Cooling Capacity (Btu/Hr) Pressures Indoor Cooling Total (psig) Wet Bulb Capacity Power Indoor Dry Bulb (°F) (°F) (Btu/Hr) (Watts) Suction Disch. 18,288 13.85 1,321...
  • Page 14 PERFORMANCE DATA – OPERATING PRESSURES PL/H24FK PUG/H24 with (Indoor Air = 710 CFM) 75°F Outdoor Air Temperature Net Sensible Cooling Capacity (Btu/Hr) Pressures Indoor Cooling Total (psig) Wet Bulb Capacity Power Indoor Dry Bulb (°F) (°F) (Btu/Hr) (Watts) Suction Disch. 24,384 14.81 1,646...
  • Page 15 PERFORMANCE DATA – OPERATING PRESSURES PL/H30FK PUG/H30 with (Indoor Air = 1,060 CFM) 75°F Outdoor Air Temperature Net Sensible Cooling Capacity (Btu/Hr) Pressures Indoor Cooling Total (psig) Wet Bulb Capacity Power Indoor Dry Bulb (°F) (°F) (Btu/Hr) (Watts) Suction Disch. 30,480 14.35 2,124...
  • Page 16 PERFORMANCE DATA – OPERATING PRESSURES PL/H36FK PUG/H36 with (Indoor Air = 1,060 CFM) 75°F Outdoor Air Temperature Net Sensible Cooling Capacity (Btu/Hr) Pressures Indoor Cooling Total (psig) Wet Bulb Capacity Power Indoor Dry Bulb (°F) (°F) (Btu/Hr) (Watts) Suction Disch. 34,747 14.31 2,428...
  • Page 17 PERFORMANCE DATA – OPERATING PRESSURES PL/H42FK PUG/H42 with (Indoor Air = 1,090 CFM) 75°F Outdoor Air Temperature Net Sensible Cooling Capacity (Btu/Hr) Pressures Indoor Cooling Total (psig) Wet Bulb Capacity Power Indoor Dry Bulb (°F) (°F) (Btu/Hr) (Watts) Suction Disch. 41,656 14.18 2,938...
  • Page 18 PERFORMANCE DATA – OPERATING PRESSURES PC/H24EK PUG/H24 with (Indoor Air = 830 CFM) 75°F Outdoor Air Temperature Net Sensible Cooling Capacity (Btu/Hr) Pressures Indoor Cooling Total (psig) Wet Bulb Capacity Power Indoor Dry Bulb (°F) (°F) (Btu/Hr) (Watts) Suction Disch. 24,384 13.67 1,784...
  • Page 19 PERFORMANCE DATA – OPERATING PRESSURES PC/H30EK PUG/H30 with (Indoor Air = 830 CFM) 75°F Outdoor Air Temperature Net Sensible Cooling Capacity (Btu/Hr) Pressures Indoor Cooling Total (psig) Wet Bulb Capacity Power Indoor Dry Bulb (°F) (°F) (Btu/Hr) (Watts) Suction Disch. 29,261 13.83 2,116...
  • Page 20 PERFORMANCE DATA – OPERATING PRESSURES PC/H36EK PUG/H36 with (Indoor Air = 1,100 CFM) 75°F Outdoor Air Temperature Net Sensible Cooling Capacity (Btu/Hr) Pressures Indoor Cooling Total (psig) Wet Bulb Capacity Power Indoor Dry Bulb (°F) (°F) (Btu/Hr) (Watts) Suction Disch. 36,170 14.95 2,419...
  • Page 21 PERFORMANCE DATA – OPERATING PRESSURES PC/H42EK PUG/H42 with (Indoor Air = 1,100 CFM) 75°F Outdoor Air Temperature Net Sensible Cooling Capacity (Btu/Hr) Pressures Indoor Cooling Total (psig) Wet Bulb Capacity Power Indoor Dry Bulb (°F) (°F) (Btu/Hr) (Watts) Suction Disch. 42,672 15.02 2,840...

  • Page 22: Heating Mode

    PERFORMANCE DATA – OPERATING PRESSURES HEATING MODE PKH18FK/PUGH18 PKH24FK/PUGH24 INDOOR AIR 70° INDOOR AIR 70° Outdoor Heating Compressor Outdoor Heating Compressor Capacity Flow Current Capacity Flow Current Pressure (psig) Pressure (psig) (deg °F) (BTUH) (CFM) (Amps) Disch. Suction (deg °F) (BTUH) (CFM) (Amps)
  • Page 23 PERFORMANCE DATA – OPERATING PRESSURES HEATING MODE PLH18FK/PUGH18 PLH24FK/PUGH24 INDOOR AIR 70° INDOOR AIR 70° Outdoor Heating Compressor Outdoor Heating Compressor Capacity Flow Current Capacity Flow Current Pressure (psig) Pressure (psig) (deg °F) (BTUH) (CFM) (Amps) Disch. Suction (deg °F) (BTUH) (CFM) (Amps)
  • Page 24 PERFORMANCE DATA – OPERATING PRESSURES HEATING MODE PCH24EK/PUGH24 PCH30EK/PUGH30 INDOOR AIR 70° INDOOR AIR 70° Outdoor Heating Compressor Outdoor Heating Compressor Capacity Flow Current Capacity Flow Current Pressure (psig) Pressure (psig) (deg °F) (BTUH) (CFM) (Amps) Disch. Suction (deg °F) (BTUH) (CFM) (Amps)
  • Page 25 DIMENSIONS & CLEARANCES Required clearances of 18 inches on all sides and above the unit. Comply with all local codes as necessary. SP007-24...

  • Page 26: Operating Range

    OPERATING RANGE 1) POWER SUPPLY Min. Max. 198V 208V 230V 253V 1 Phase 60Hz 208/230V Guaranteed voltage range 2) OPERATING TEMPERATURE RANGE Air intake temperature Indoor Outdoor Function Condition DB ( -F ) WB ( -F ) DB ( -F ) WB ( -F ) Standard temperature Maximum temperature...

  • Page 27: Refrigerant Charge (R-22 (Oz)) Adjustment

    REFRIGERANT CHARGE (R-22 (oz)) ADJUSTMENT FOR OPTIMUM PERFORMANCE 1) Copeland Scroll “KC” Compressors Factory Subtract Charge Add Charge rating pt. Charge Model 25 ft 25 ft 50 ft 75 ft 100 ft 125 ft 150 ft PUG/H18 PUG/H24 PUG/H30 PUG/H36 PUG/H42 2) Copeland Scroll “K4/K3”...
  • Page 28 CAPACITY CORRECTION FACTORS FOR VARIOUS PIPE LENGTHS 1) COOLING CAPACITY Refrigerant piping length ( one way ) MODEL 25ft 40ft 55ft 70ft 85ft 100ft 115ft 130ft 150ft 0.992 0.983 0.978 0.966 0.959 0.950 0.945 PUG/H18 0.981 0.968 0.952 0.940 0.925 0.913 0.900 0.886...

  • Page 29: Microprocessor Control

    MICROPROCESSOR CONTROL 1. COOLING/HEATING OPERATION Outdoor unit operation is activated by delivery of a 12VDC signal from the indoor unit. Cooling only units have 2 low voltage control wires from the indoor unit to the outdoor unit. Heat pump units have 3 low voltage control wires from the indoor to the outdoor unit.
  • Page 30 MICROPROCESSOR CONTROL 3. OUTDOOR BOARD FUNCTIONALITY A. High Pressure Safety Switch (HPSS). Opens at approx 420 PSIG and closes at approx 320 PSIG. There is no bypass on this switch. When the switch opens it immediately stops the compressor and outdoor fan. When it closes the system can restart providing the indoor unit has not entered a P8 fault code.
  • Page 31 MICROPROCESSOR CONTROL J. Line Voltage. Line voltage is input and output from the circuit board on the terminals marked “L1” and “L2”. There are four terminals marked “L1”, the purpose of each is as follows. One is “L1” input to the board while the remaining three are outputs to one side of the Transformer, Crankcase Heater and the Outdoor Fan Motor.
  • Page 32 ELECTRICAL SP007-31...
  • Page 33 ELECTRICAL SP007-32...
  • Page 34 ELECTRICAL SP007-33...
  • Page 35 ELECTRICAL SP007-34...
  • Page 36 ELECTRICAL SP007-35...
  • Page 37 ELECTRICAL SP007-36...
  • Page 38 REFRIGERANT SYSTEM A. PUG PIPING DIAGRAM SP007-37...
  • Page 39 REFRIGERANT SYSTEM B. PUGH HEAT PUMP MODELS SP007-38...

  • Page 40: Refrigerant System

    REFRIGERANT SYSTEM SERVICE PORTS There are 4 service ports available to service technicians. One port is located at each of the two “ball valves” and two additional ports are located directly above the ball valves. The purpose of each is: A.
  • Page 41 PARTS BREAKDOWN A. STRUCTURAL PARTS – ALL PUG AND PUG/H MODELS PUG/PUGH - ALL Q'ty/set No. Parts No. Parts Name Specifications PUG/H18 PUG/H24 PUG/H30 PUG/H36 PUG/H42 501371FRP FRONT HOLD-DOWN/DECAL STRIP PAINTED 501367FRP COIL SEAL/CORNER PANEL PAINTED –––– –––– –––– –––– 501368FRP COIL SEAL/CORNER PANEL PAINTED...
  • Page 42 PARTS BREAKDOWN B. FUNCTIONAL PARTS – PUG AKB MODELS PUGxxAKB (w/K3 & 4 Comp.) Q'ty/set No. Parts No. Parts Name Specifications PUG/H18AKB PUG/H24AKB PUG/H30AKB PUG/H36AKB PUG/H42AKB 416053FRP FLOW CONTROL (3/8" I.D.) 416057FRP FIELD CONNECTOR w/SWIVEL (3/8" I.D.) 416076FRP RESTRICTOR .056" dia. ––––...
  • Page 43 PARTS BREAKDOWN PUGxxAKB (w/K3 & 4 Comp.) Q'ty/set Parts No. Parts Name Specifications PUG18AKB PUG24AKB PUG30AKB PUG36AKB PUG42AKB BOLT (5/16 - 18 x 1-5/8) w/WASHER 13 702086FRP CRANKCASE HEATER ASSEMBLY 537960FRP –––– –––– –––– 537961FRP CRANKCASE HEATER ASSEMBLY –––– –––– COMPRESSOR 200303FRP ZR18K4-PFV...
  • Page 44 PARTS BREAKDOWN C. FUNCTIONAL PARTS – PUG BKB MODELS PUGxxBKB (w/KC Comp.) Q'ty/set Parts No. Parts Name Specifications PUG18BKB PUG24BKB PUG30BKB PUG36BKB PUG42BKB 416053FRP FLOW CONTROL (3/8" I.D.) 416057FRP FIELD CONNECTOR w/SWIVEL (3/8" I.D.) 416076FRP RESTRICTOR –––– –––– –––– –––– .056"...
  • Page 45 PARTS BREAKDOWN PUGxxBKB (w/KC Comp.) Q'ty/set No. Parts No. Parts Name Specifications PUG18BKB PUG24BKB PUG30BKB PUG36BKB PUG42BKB 13 702086FRP BOLT (5/16 - 18 x 1-5/8) w/WASHER CRANKCASE HEATER ASSEMBLY 537960FRP –––– –––– –––– CRANKCASE HEATER ASSEMBLY 537961FRP –––– –––– COMPRESSOR 200312FRP ZR18KC-PFV ––––...
  • Page 46 PARTS BREAKDOWN D. FUNCTIONAL PARTS – PUGH AKB MODELS PUGHxxAKB (w/K3 & 4 Comp.) Q'ty/set No. Parts No. Parts Name Specifications PUGH18AKB PUGH24AKB PUGH30AKB PUGH36AKB PUGH42AKB 416053FRP FLOW CONTROL (3/8" I.D.) 416057FRP FIELD CONNECTOR w/SWIVEL (3/8" I.D.) 416076FRP RESTRICTOR .056" dia. ––––...
  • Page 47 PARTS BREAKDOWN PUGHxxAKB (w/K3 & 4 Comp.) Q'ty/set No. Parts No. Parts Name Specifications PUGH18AKB PUGH24AKB PUGH30AKB PUGH36AKB PUGH42AKB 13 702086FRP BOLT (5/16 - 18 x 1-5/8) w/WASHER CRANKCASE HEATER ASSEMBLY 537960FRP –––– –––– –––– CRANKCASE HEATER ASSEMBLY 537961FRP –––– ––––...
  • Page 48 PARTS BREAKDOWN E. FUNCTIONAL PARTS – PUGH BKB MODELS PUGHxxBKB (w/KC Comp.) Exception: PUGH42BKB Q'ty/set Parts No. Parts Name Specifications PUGH18BKB PUGH24BKB PUGH30BKB PUGH36BKB PUGH42BKB 416053FRP FLOW CONTROL (3/8" I.D.) 416057FRP FIELD CONNECTOR w/SWIVEL (3/8" I.D.) 416076FRP RESTRICTOR .056" dia. ––––...
  • Page 49 PARTS BREAKDOWN PUGHxxBKB (w/KC Comp.) Exception: PUGH42BKB Q'ty/set Parts No. Parts Name Specifications PUGH18BKB PUGH24BKB PUGH30BKB PUGH36BKB PUGH42BKB BOLT (5/16 - 18 x 1-5/8) w/WASHER 13 702086FRP 537960FRP CRANKCASE HEATER ASSEMBLY –––– –––– –––– CRANKCASE HEATER ASSEMBLY 537961FRP –––– –––– 200312FRP COMPRESSOR ZR18KC-PFV...
  • Page 50 PARTS BREAKDOWN F. ELECTRICAL PANEL – PUG AKB MODELS PUGxxAKB (w/K3 & 4 Comp.) Q'ty/set Parts No. Parts Name Specifications PUG18AKB PUG24AKB PUG30AKB PUG36AKB PUG42AKB 300184FRP DUAL CAPACITOR 35+5@370VAC –––– –––– –––– 300177FRP DUAL CAPACITOR –––– –––– –––– –––– 45+5@370VAC 300176FRP DUAL CAPACITOR 50+5@370VAC...
  • Page 51 PARTS BREAKDOWN G. ELECTRICAL PANEL – PUG BKB MODELS PUGxxBKB (w/KC Comp.) Q'ty/set Parts No. Parts Name Specifications PUG18BKB PUG24BKB PUG30BKB PUG36BKB PUG42BKB 300196FRP DUAL CAPACITOR 30+5@370VAC –––– –––– –––– –––– 300184FRP DUAL CAPACITOR 35+5@370VAC –––– –––– –––– –––– 300165FRP DUAL CAPACITOR 35+5@440VAC ––––...
  • Page 52 PARTS BREAKDOWN H. ELECTRICAL PANEL – PUGH AKB MODELS PUGHxxAKB (w/K3 & 4 Comp.) Q'ty/set Parts No. Parts Name Specifications PUGH18AKB PUGH24AKB PUGH30AKB PUGH36AKB PUGH42AKB 300184FRP DUAL CAPACITOR 35+5@370VAC –––– –––– –––– 300177FRP DUAL CAPACITOR 45+5@370VAC –––– –––– –––– –––– 300176FRP DUAL CAPACITOR 50+5@370VAC...
  • Page 53 PARTS BREAKDOWN I. ELECTRICAL PANEL – PUGH BKB MODELS PUGHxxBKB (w/KC Comp.) Exception: PUGH42BKB Q'ty/set Parts No. Parts Name Specifications PUGH18BKB PUGH24BKB PUGH30BKB PUGH36BKB PUGH42BKB 300196FRP DUAL CAPACITOR 30+5@370VAC –––– –––– –––– –––– 300184FRP DUAL CAPACITOR 35+5@370VAC –––– –––– –––– ––––...
  • Page 54 2001 MITSUBISHI ELECTRIC ENGINEERING CO., LTD. New publication, effective May. 2001 Distributed in May. 2001 No.OC247 REVISED EDITION-A Specifications subject to change without notice. Distributed in Mar. 2001 No.OC247 Printed in Atlanta 07/2001...
  • Page 55 3400 Lawrenceville Suwanee Road Suwanee, Georgia 30024 ● Toll Free: 800-433-4822 Toll Free Fax: 800-889-9904 ● www.mrslim.com Specifications are subject to change without notice.
