Whirlpool ADP 952 WHM Service Manual page 4

26.03.1997 / Page 4
Doc. No: 4812 718 12394
Technical data
Reedcontact
flow meter
salt control
rinse aid control
Spray arm block
NTC
15 ˚C
20 ˚C
30 ˚C
40 ˚C
50 ˚C
60 ˚C
70 ˚C
80 ˚C
85 ˚C
75 kΩ
62 kΩ
43 kΩ
28 kΩ
19 kΩ
13 kΩ
9 kΩ
6 kΩ
5 kΩ
Whirlpool Europe
Customer Service
Regeneration
Volume
Position 0
after wash cycles
water hardness
Position 1
after wash cycles
water hardness
Position 2
after wash cycles
water hardness
Position 3
after wash cycles
water hardness
Position 4
after wash cycles
water hardness
Position 5
after wash cycles
water hardness
Position 6
after wash cycles
water hardness
Salt consumption
for regeneration
Number of cycles
with 2 kg salt
S E R V I C E
3
300 cm
--
0-5 ˚dh
0-0,9 mmol/l
0-9 ˚Fh
6-8
6-10 ˚dh
1-1,8 mmol/l
10-18 ˚Fh
5-6
11-15 ˚dh
1,9-2,7 mmol/l
19-27 ˚Fh
4
16-21 ˚dh
2,8-3,7 mmol/l
28.37 ˚Fh
3
22-28 ˚dh
3,8-5,0 mmol/l
38-50 ˚Fh
2
29-35 ˚dh
5,1-6,3 mmol/l
51-63 ˚Fh
1
36-60 ˚dh
6,4-10,7mmol/l
64-107 ˚Fh
77 g
26
