Introduction Desktop or Shelf Installation This Quick Installation Guide gives step-by-step instructions for setting up all D-Link switches. Please note that the model you have purchased may appear slightly different from those shown in When installing the switch on a desktop or shelf, the the illustrations.
Additional help available online http://www.dlink.com, http://www.dlink.com.uk, or through our offices listed at the back of the User’s Guide. Figure 3. Installing the switch in a standard-sized equipment rack Step 3 Understanding Device Network Connections At this point, please connect the AC power cord into an electrical outlet (preferably one that is grounded and surge protected) and into the rear of the switch.
