This gas grill must be used only outdoors in a well-ventilated space and must not be used inside a
building, garage, screened-in porch, gazebo or any other enclosed area.
DANGER
IF YOU SMELL GAS:
• Shut off gas to the appliance.
• Extinguish any open flame.
• Open lid.
• If odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department.
Notice to Installer: Leave these instructions with the grill owner for future reference.
Fax: (705)725-2564 email: wecare@napoleonproducts.com web site: www.napoleongrills.com
Napoleon Appliance Corp.,
214 Bayview Dr., Barrie, Ontario, Canada L4N 4Y8 Phone: (705)726-4278
Serial No.
XXXXXX000000
MODEL NO.
PRESTIGE II 450
INFRARED
WARNING
Do not try to light this appliance without
reading the "LIGHTING" instructions section of
this manual.
Do not store or use gasoline or other flammable
liquids or vapors in the vicinity of this or any
other appliance. An L.P. cylinder not connected
for use must not be stored in the vicinity of
this or any other appliance. If the information
in these instructions is not followed exactly, a
fire or explosion may result, causing property
damage, personal injury or death.
APPLY SERIAL NUMBER LABEL FROM CARTON
N415-0201CE APR 21/11

Advertisement

Table of Contents
loading

Related Manuals for Napoleon PRESTIGE II 450

Summary of Contents for Napoleon PRESTIGE II 450

  • Page 1 APPLY SERIAL NUMBER LABEL FROM CARTON Serial No. XXXXXX000000 MODEL NO. PRESTIGE II 450 INFRARED WARNING DANGER Do not try to light this appliance without reading the “LIGHTING” instructions section of IF YOU SMELL GAS: this manual.

  • Page 2: Conditions And Limitations

    NAPOLEON will not be responsible for the installation, labor or any other costs or expenses related to the re-installation of a warranted part, and such expenses are not covered by this warranty.

  • Page 3: Safe Operating Practices

    WARNING! Failure to follow these instructions could result in property damage, personal injury or death. Read and follow all warnings and instructions in this manual prior to operating grill. Safe Operating Practices • This gas grill must be assembled exactly according to the instructions in the manual. If the grill was store assembled, you must review the assembly instructions to confirm correct assembly and perform the required leak tests before operating the grill.

  • Page 4: Gas Cylinder

    Gas Cylinder Use only gas cylinders, which meet national and regional codes. The minimum cylinder size for butane units is 13kg, and for propane units is 6kg. Ensure that the cylinder can provide enough fuel to operate the appliance. If in doubt, check with your local gas supplier. •...

  • Page 5: Leak Testing Instructions

    Bubbles will indicate a gas leak. Either tighten the loose joint or have the part replaced with one recommended by the Napoleon Customer Care department and have the grill inspected by a certified gas installer. If the leak cannot be stopped, immediately shut off the gas supply, disconnect it, and have the grill inspected by a certified gas installer or dealer.

  • Page 6: Lighting Instructions

    Lighting Instructions Rear Burner Lighting Hole Igniter Right Burner/Infra Red Burner Left Burner Centre Burner Off Position WARNING! Open lid WARNING! Ensure all burner controls are in the off position. Slowly turn on the gas supply valve. Main Tube Burner Rear Burner Lighting Main Infrared Burner Side Burner Lighting...

  • Page 7: Cooking Instructions

    Should a flare-up occur, move food away from the flames and reduce the heat. Leave the lid open. See Your All Season Grill cookbook by Napoleon for more detailed instructions. Infrared Main Burner Use (If Equipped): Follow the Infrared Burner Ignition procedures and operate on high for 5 minutes with the lid closed or until the ceramic burners glow red.
  • Page 8 Any juices or oils that escape from the food drip onto the charcoal and vaporize into smoke giving the food its delicious grilled taste. The Napoleon infrared burner cooks in the same way. In each burner, 10,000 ports –...

  • Page 9: Cleaning Instructions

    Cleaning The Outer Grill Surface: Do not use abrasive cleaners or steel wool on any painted, porcelain or stainless steel parts of your Napoleon Grill. Doing so will scratch the finish. Exterior grill surfaces should be cleaned with warm soapy water while the metal is still warm to the touch. To clean stainless surfaces, use a stainless steel or a non-abrasive cleaner.

  • Page 10: Maintenance Instructions

    Maintenance Instructions We recommend this gas grill be thoroughly inspected and serviced annually by a qualified service person. WARNING! Always wear protective gloves and safety glasses when cleaning your grill. WARNING! Turn off the gas at the source and disconnect the unit before servicing. To avoid the possibility of burns, maintenance should be done only when the grill is cool.
  • Page 11 WARNING! Hose: Check for abrasions, melting, cuts, and cracks in the hose. If any of these conditions exist, do not use the gas grill. Have the part replaced by your Napoleon Gas Grill dealer or qualified gas installer. Aluminum Castings: Clean castings periodically with warm soapy water. Aluminum will not rust, but high temperatures and weathering can cause oxidation to occur on aluminum surfaces.

  • Page 12: Troubleshooting

    Troubleshooting Problem Possible Causes Solution Low heat / Low flame when Improper lighting procedure. Ensure lighting procedure is followed valve turned to high. carefully. All gas grill valves must be in the off position when the tank valve is turned on.
  • Page 13 Cracked ceramic tile. Allow burner to cool and inspect very closely for cracks. If any cracks are found, contact your authorized Napoleon dealer to order a replacement burner assembly. Leaking gasket surrounding the ceramic Contact your authorized Napoleon dealer...

  • Page 14: Ordering Replacement Parts

    KEEP YOUR RECEIPT AS PROOF OF PURCHASE TO VALIDATE YOUR WARRANTY. Ordering Replacement Parts Warranty Information MODEL: DATE OF PURCHASE: SERIAL NUMBER: (Record information here for easy reference) Before contacting the Customer Care Department, check the NAC Website for more extensive cleaning, maintenance, troubleshooting and parts replacement instructions at www.napoleongrills.com.

  • Page 15: Getting Started

    CAUTION! During unpacking and assembly we recommended you wear work gloves and safety glasses for your protection. Although we make every effort to make the assembly process as problem free and safe as possible, it is characteristic of fabricated steel parts that the edges and corners might be sharp and could cause cuts if handled incorrectly.
  • Page 16 3/8”(10mm) 2 X N570-0086 (#14 x 1/2”) If necessary the center panel can be tapped down with a rubber mallet. Si nécessaire, le panneau central peut être enfoncé avec un maillet en caoutchouc. Het middelste paneel kan indien nodig met een rubberen hamer worden ingeslagen.
  • Page 17 2 x N570-0086 (#14 x 1/2”) 3/8”(10mm) If necessary the cross beam can be tapped down with a rubber mallet. Si nécessaire, le barre de traverse peut être enfoncé avec un maillet en caoutchouc. Het dwarsbalk kan indien nodig met een rubberen hamer worden ingeslagen.
  • Page 18 1 x N485-0009 If necessary the magnet bracket can be tapped down with a rubber mallet. Si nécessaire, le support à aiment peut être enfoncé avec un maillet en caoutchouc. Het magneet beugel kan indien nodig met een rubberen hamer worden ingeslagen.
  • Page 19 4 x N570-0086 (#14 x 1/2”) 3/8”(10mm) Two people are required for this step. Deux personnnes son nécessaires pour cette étappe. Voor deze stap zijn twee mensen nodig. Für diesen schritt Sind zwei personen erforderlich. Per questa operazione sono richieste due persone.
  • Page 20 disposable grease tray jetable du récipient à graisse wegwerp afdruipbakje Fett-Auffangbehälter (Einweg) vassoio raccolta dei grassi, a perdere ”Rasvakuppi joka asetetaan rasvapellin alle (poisheitettävä).” 3/8”(10mm) 1 x N570-0086 (#14 x 1/2”) www.napoleongrills.com...
  • Page 21 2 x N570-0029 (1/4-20 X 3/8”) 3/8”(10mm) 2 x N735-0002 (1/4”) www.napoleongrills.com...
  • Page 22 10 x N570-0076 (#8 X1/2”) 3/8”(10mm) 4 x N570-0086 (#14 X1/2”) Twist tab to lock in place. Tournez la patte pour verrouiller. Draai de haak om hem op zijn plaats te bevestigen Lasche drehen, um sie zu verriegeln. Per bloccare, girare l’aletta. Tuerza la lengüeta para bloquearla.
  • Page 23 N305-0021 N305-0022 Ensure holes in sear plates are positioned to the front of the grill. Assurez-vous que les trous dans les plaques de brûleur soient placés à l’avant du gril. Zorg dat de gaten in de schroeiplaten zich aan de voorkant van de gril bevinden.
  • Page 24 Rotisserie Kit Assembly Instruction (included with most rear burner units) Assemble rotisserie kit components as shown. Instructions D’assemblage De L’ensemble De Rôtissoire (inclus avec la plupart des appareils avec brûleur arrière) Assemblez les composantes de la rôtissoire tel qu’illustré. Monteerinstructies voor de Roterende Braadkit (inclusief de meeste achterbranders) Monteer de componenten van de roterende braadkit zoals weergegeven.
  • Page 25 Proper Hose Connection Branchement Adéquat Du Boyau Juiste Slang Verbinding Ordnungsgemäßer Schlauchanschluss Collegamento Corretto Del Tubo Conexión correcta del conector flexible Oikein tehty letkun kiinnitys WARNING! The installation must be performed by a licensed gas fitter, and all connections must be leak tested before operating the grill.
  • Page 26 WARNING! Ensure the hose does not contact any high temperature surfaces, or it may melt and leak causing a fire. AVERTISSEMENT! Assurez-vous que le boyau ne touche à aucune surface à haute température sinon il risque de fondre, de provoquer une fuite et causer un feu. WAARSCHUWING! Zorg ervoor dat de spuitslang geen contact heeft met hete oppervlaktes, want de slang kan smelten, een lekkage veroorzaken met brandgevaar als gevolg.
  • Page 27 Bubbles will indicate a gas leak. Either tighten the loose joint or have the part replaced with one recommended by the Napoleon Customer Care department and have the grill inspected by a certified gas installer. If the leak cannot be stopped, immediately shut off the gas supply, disconnect it, and have the grill inspected by a certified gas installer or dealer.
  • Page 28 ITEM PART # DESCRIPTION 450RBI n135-0040g left side lid casting / moulage gauche du couvercle n385-0129 NAPOLEON logo/ logo NAPOLEON w450-0005 logo spring clips / écrous à ressort pour logo n510-0002 black silicone lid bumper / pare-chocs du couvercle (silicone noir) n335-0059...
  • Page 29 Parts List / Liste Des Pièces ITEM PART # DESCRIPTION 450RBI n530-0027 gas supply hose/regulator - UK / tuyau d’alimentation en gaz/regulateur UK n530-0028 gas supply hose - NL / tuyau d’alimentation en gaz NL n345-0006 gas supply hose - FR / tuyau d’alimentation en gaz FR n530-0032 gas supply hose - DE / tuyau d’alimentation en gaz DE n455-0013...
  • Page 30 Lijst met onderdelen / Stückliste ITEM ONDERDEELNR. OMSCHRIJVING 450RBI n135-0040g gietwerk deksel, linkerzijde / Linke Seite des Deckelgussteils n385-0129 NAPOLEON-Logo w450-0005 borqveren logo / Logohalterung n510-0002 zwarte siliconen stootrand deksel / Deckelanschlag aus schwarzem Silicon n335-0059 roestvrijstalen dekselinzetstuk / Deckeleinsatz aus Rostfreistahl...
  • Page 31 www.napoleongrills.com...
  • Page 32 FAX TO: 705 727 4282 ACCESSORIES & PARTS ORDER FORM PLEASE PRINT CLEARLY CONTACT NAME:______________________________________________________________________ SHIP TO :_____________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ TEL :_________________________________ FAX :______________________________ EMAIL: __________________________________________________________________ VISA OR MASTERCARD # :_______________________________________ EXPIRY DATE: _____________ SIGNATURE:_____________________________________________________________________________ QUANTITY PART NUMBER DESCRIPTION TAXES MAY APPLY SHIPPING EXTRA IF CONFIRMATION IS REQUIRED PLEASE INCLUDE A FAX NUMBER OR EMAIL ADDRESS...
  • Page 33 www.napoleongrills.com...

Table of Contents
