- Page 1 INSTRUCTION MANUAL PC15OO/155O WITH LED615 KEYPAD...
- Page 2 Department of Communications Notice NOTICE: The Canadian Department of Communications label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements. The Department does not guarantee the equipment will operate to the user's satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company.
- Page 3 SYSTEM REFERENCE ZONE PROTECTED AREA ZONE TYPE ____________________________ ________________________________ ____________________________ ________________________________ ____________________________ ________________________________ ____________________________ ________________________________ ____________________________ ________________________________ ____________________________ ________________________________ KEYPAD ZONE [F] FIRE ______________________________________________ KEYPAD ZONE [A] AUXILIARY ________________________________________ KEYPAD ZONE [P] PANIC _____________________________________________ PROGRAMMED CODE NUMBERS: MASTER CODE NUMBER: ____________________________________________ SYSTEM ENTRY TIME _____ SECONDS SYSTEM EXIT TIME ________ SECONDS FOR SERVICE:...
-
Page 4: About Your Security System
GENERAL SYSTEM OPERATION Your security system is made up of a DSC PC1500 or PC1550 control panel, one or more LED615 keypads and various sensors and detectors. The control panel will be mounted out of the way in a utility closet or in a basement. -
Page 5: Master Code
MASTER CODE The 4 digit Master Code is used to arm and disarm the security system, to program additional security codes and to change other system features. The Master Code will be supplied to you by your installer. All keypad entries are made by pressing one key at a time. -
Page 6: Disarming The System
ENTRY DELAY OFF ARMING ∗ If you wish to arm your system and eliminate the entry delay, enter [ ][9] before your access code. The “Armed” light will flash as a reminder that the system is armed and has no entry delay. An entry through any zone programmed as a delay zone will create an instant alarm. -
Page 7: Alarm Test
ALARM TEST ∗ Enter [ ][6][Master Code][8] for a 2-second test of the keypad lights, keypad buzzer, battery and the bell/siren. Press [#] to return to Ready. PROGRAMMING SECURITY CODES The Master Code ∗ Enter [ ][5][current Master Code][1][new Master Code] Press [#] to return to Ready. - Page 8 Zone light(s) when ON in the disarmed mode, indicate an open zone. e.g. open door, window, etc. Refer to zone chart on the keypad door for zone information. Press [#]..When an error is made in entering code, then enter code again.
- Page 9 Ready light ON - System is ready for arming. Ready light OFF - System has an open zone which must be closed or bypassed before arming. Memory light ON means an alarm has ∗ occurred. Press [ ] then [3]. Zone light will come ON to indicate which zone caused the alarm.
-
Page 10: Alarm Memory Display
ALARM MEMORY DISPLAY If the “Memory” light is ON, an alarm has occurred during the last armed period. The alarm memory will automatically be displayed when the system is disarmed (See Disarming the System). ∗ Press [ ] then [3] to display the zone which caused the alarm. Press [#] to return to Ready. -
Page 11: Viewing Trouble Conditions
ZONE BYPASSING (Continued) For security reasons, your installer may prevent the bypass command from working on certain zones. The “Bypass” light is ON as long as ONE or more zones are bypassed. Do not unintentionally arm the system with zones bypassed. -
Page 12: Testing Your System
[P] Panic Holding this key down for two seconds causes a steady tone on your siren or bell if your installer has programmed this key for audible operation. An auxiliary warning device is also activated if your installer has connected it to your system. -
Page 13: Maintenance
8. When testing is complete, call and advise the monitoring station. MAINTENANCE With normal use, the system requires minimum maintenance. The following points should be observed. 1. Do not wash the keypad with a wet cloth. Light dusting with a barely damp cloth should remove normal accumulations of dust. -
Page 14: Limited Warranty
• If the exit is above the ground level, an approved fire ladder or rope should be provided as well as training in its use. • Exits on the ground level should be kept clear. Be sure to remove snow from exterior patio doors in winter;... - Page 16 PRINTED IN CANADA 29000179 R1 ©1993,2000 DIGITAL SECURITY CONTROLS LTD. www.dsc.com www.dsc.com Toronto, Canada • www.dsc.com www.dsc.com www.dsc.com...
