- Page 1 COLOR TELEVISION AV-T2122 INSTRUCTIONS...
-
Page 2: Table Of Contents
Thank you for purchasing this JVC color television. To ensure your complete understanding, please read this manual thoroughly be- fore operation. WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION: TO ENSURE PERSONAL... -
Page 3: Connections
C O N N E C T I O N S FRONT & REAR PANEL DIAGRAMS Front Panel Rear Panel... -
Page 4: Connecting The Antenna And Vcr
C O N N E C T I O N S CONNECTING THE ANTENNA AND VCR • For further details, refer to the manuals provided with the devices you are connecting. • Connecting cables are not supplied. Illustration of AV-T2122 To video To audio To RF... - Page 5 CONNECTING OTHER EXTERNAL DEVICES Illustration of AV-T2122 To video To audio output output VCR (for playing) C O N N E C T I O N S Note: When connecting mon- Note: The sound and picture To audio To video...
-
Page 6: Getting Started
G E T T I N G REMOTE CONTROL CHANGING THE BATTERIES Be sure to use only size AA/R6/UM-3 batteries. Raise the latch on the remote's back cover to remove it. Insert the two supplied batteries, carefully noting the “+” and “–” markings on the batteries and remote control. -
Page 7: Power
G E T T I N G POWER Press the Power button ( If the TV will not be turned on even if you press the P mode. Press the P button on the remote control to turn on the TV. OWER To turn the power off, press the P red. -
Page 8: Using The Menu
U S I N G USING THIS GUIDE: Throughout this guide there are certain symbols we use as shorthand to show you what to do. When you see them, keep these factors in mind: œ❷ Up and down arrows mean press the or M the up or down buttons allows you to: •... -
Page 9: Initial Setup
AUTO TUNER SETUP During Auto Tuner Setup, the TV will automatically scan through all avail- able channels and memorize the active ones so that when you scan, you do not pick up weak or noisy channels. œ❷ To AUTO TUNER SETUP ➛❿... -
Page 10: Tint
P I C T U R E TINT (NTSC ONLY) NOTE: Tint allows you to adjust the levels of To exit the Picture red and green in the picture. The tint Settings menu, option appears only when the TV color press the Exit system is NTSC. -
Page 11: Sound Settings
S O U N D BASS The Bass level adjustment feature allows you to increase or decrease the level of lower frequencies in the TV’s sound. œ❷ To BASS ¤¤❿ To emphasize bass ¤¤➛ To reduce bass œ❷ To move to next TREBLE The Treble level adjustment feature allows you to increase or decrease the... -
Page 12: General Items
G E N E R A L SET CLOCK The Clock is the heart of all timer functions. You must set the clock before any timer functions will work. œ❷ To SET CLOCK ➛❿ To operate TIME ➛❿ To set the hour (AM/PM) ¤❷... -
Page 13: Channel Summary
CHANNEL SUMMARY You can add or delete channels from the channel scanning. You can also lock out any “unauthorized” viewers from one or up to all 181 channels. œ❷ To CHANNEL SUMMARY ➛❿ To operate You can manually set channels to scan that were too weak to be picked up during Auto Tuner Setup. -
Page 14: Set Lock Code
G E N E R A L SET LOCK CODE The Lock Code locks and unlocks Channel Guard. Write this three digit number down and keep it where would-be viewers will not look for it! œ❷ To SET LOCK CODE ➛❿... -
Page 15: Button Functions
B U T T O N DISPLAY The Display screen shows the current status of timers and inputs. ISPLAY 12:20 PM SLEEP TIMER ON/OFF TIMER EVERYDAY ON TIME 7:00 PM OFF TIME 10:00 PM The channel or AV input (Channel 07) Current time (12:20 PM) Sleep Timer status minutes remaining (Off) -
Page 16: Number Buttons (10 Key Pad)
B U T T O N NUMBER BUTTONS 10 KEY PAD Press two of the number buttons to move to single and double digit channels. To move to Channel 7: 0 (zero) 7 (seven) 100 + BUTTON The 100+ button accesses all chan- nels above Channel 99. -
Page 17: Return
B U T T O N RETURN+ There are two kinds of Return. Return+ — Set a “Return Channel” to return to after scanning with C + and hold for 3 seconds ETURN RETURN CHANNEL PROGRAMMED ! Scan with C HANNEL ETURN Note: To cancel a Return channel,... -
Page 18: Troubleshooting
T R O U B L E S H O O T I N G PROBLEMS There is no power • See if the power cord became unplugged. • Perhaps you have experienced a blown circuit breaker or fuse or a power outage. There is no picture •... -
Page 19: Specifications
External input/output Headphone jack Dimensions (W Weight Accessories Design and specifications subject to change without notice. AV-T2122 PAL-M, PAL-N, NTSC-M M, N VHF 2 to 13, VHF 14 to 69 Sub Mid, Super, Hyper and Ultra bands BTSC (Multi Channel Sound) - Page 20 VICTOR COMPANY OF JAPAN, LIMITED LCT1040-001A-D 0601-TN-JII-AUD...
