Page 3: Table Of Contents
Loading Paper ................... 4-3 Loading Cover Paper ..............4-20 Loading Tabbed Sheets ..............4-22 Adding Toner ................... 4-26 Exchanging Toner Recovery Box ..........4-30 Replenishing Staples ..............4-32 Adding Paste Pellet to Perfect Binder PB-501/PB-502 ....4-43 bizhub PRO C6501 Contents-1...
Page 4: Table Of Contents
8.1.1 Control Panel ..................8-3 8.1.2 Copy Screen ...................8-6 8.1.3 Machine Status Screen ..............8-8 General Copy Operation ..............8-10 Positioning the Original ..............8-13 8.3.1 Positioning originals into the ADF ..........8-13 8.3.2 Positioning the Original on Original Glass ........8-17 Contents-2 bizhub PRO C6501...
Page 5: Table Of Contents
Using Paper Not Specified to Any Tray: Paper Setting ....9-44 9.6.4 Improving Unevenness on Large-Sized Paper or Feedability of Small- Sized Thick Paper in Duplex Printing ........... 9-57 Setting Reserve Job ............... 9-59 Copy Conditions Incompatible with Basic Job Settings ..... 9-61 bizhub PRO C6501 Contents-3...
Page 6: Table Of Contents
11.12 Repeating Original Image on One Sheet: Image Repeat ...11-45 11.12.1 Setting Repeat Times Automatically ...........11-45 11.12.2 Specifying Repeat Times: Repeat ..........11-49 11.13 Eliminating Copy Marks Along Borders: Frame Center Erase ..11-52 11.14 Copying Image in the Center of Copy Paper: Image Centering 11-56 Contents-4 bizhub PRO C6501...
Page 7: Table Of Contents
Attaching Cover Sheet (Post Inserter on FD-503) ...... 12-25 12.5 Output Modes Using Saddle Stitcher SD-506 ......12-28 12.5.1 Making Folded Booklet .............. 12-28 12.5.2 Folding Copies ................12-30 12.6 Using Folder/Finisher/Stitcher Functions Manually ....12-33 12.7 Using Perfect Binder PB-501/PB-502 ......... 12-37 bizhub PRO C6501 Contents-5...
Page 8: Table Of Contents
13.4.2 Recalling Stored Job Settings ............13-14 13.5 Recalling Previous Job Settings ..........13-16 13.6 Displaying Screen for Operation Guide: Help Mode ....13-18 13.7 Adjusting Response Time of Touch Keys: Accessibility ....13-19 13.8 Controlling/Monitoring Copier from Browser ......13-20 Contents-6 bizhub PRO C6501...
Page 9: Table Of Contents
To Check/Control Reserved Jobs ..........14-4 14.2.2 To Display Output History ............14-6 14.2.3 To Display Send History ............... 14-7 14.2.4 To Check Incomplete Jobs ............14-8 14.2.5 To Check/Operate Suspended Jobs ........... 14-9 15 Index bizhub PRO C6501 Contents-7...
Page 10 Please refer to this guide for how to use the Security Strengthen mode, and for detailed machine operation in Security Strengthen mode. To operate safely, be sure to read “Section 1: Introduction/ Safety Information” in “bizhub PRO C6501 User’s Guide - Copier” before using the machine. Contents-8...
Page 11 Introduction/ Safety Information...
Page 13 TAIN DOCUMENTS OR INFORMATION, RESULTING IN FINES OR IMPRIS- ONMENT FOR VIOLATORS. ACKNOWLEDGEMENTS: - KONICA MINOLTA, KONICA MINOLTA Logo, and The essentials of im- aging are registered trademarks or trademarks of KONICA MINOLTA HOLDINGS, INC. - bizhub is registered trademark of KONICA MINOLTA BUSINESS TECH- NOLOGIES, Inc.
Page 14: Energy Star
Automatic Duplex Copying To reduce paper consumption, use this function to make double-sided (du- plex) copies, automatically. We recommend that you utilize the Auto Low Power function, the Automatic Shut-Off function, and the Automatic Duplex Copying function. bizhub PRO C6501...
Page 15: License
Copyright (C) 1989, 1991 Free Software Foundation, Inc. 59 Temple Place, Suite 330, Boston, MA 02111-1307 USA Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed. Preamble bizhub PRO C6501...
Page 16 Finally, any free program is threatened constantly by software patents. We wish to avoid the danger that redistributors of a free program will individually obtain patent licenses, in effect making the program proprietary. To prevent bizhub PRO C6501...
Page 17 2. You may modify your copy or copies of the Program or any portion of it, thus forming a work based on the Program, and copy and distribute such bizhub PRO C6501...
Page 18 In addition, mere aggregation of another work not based on the Program with the Program (or with a work based on the Program) on a volume of a storage or distribution medium does not bring the other work under the scope of this License. bizhub PRO C6501...
Page 19 Program is void, and will automatically terminate your rights under this License. However, parties who have received copies, or rights, from you under this License will not have their licenses ter- minated so long as such parties remain in full compliance. bizhub PRO C6501...
Page 20 1-10 bizhub PRO C6501...
Page 21 GRAM "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRAN- TIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PUR- POSE. THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF bizhub PRO C6501 1-11...
Page 22 This license, the Lesser General Public License, applies to some specially designated software packages--typically libraries--of the Free Software Foundation and other authors who decide to use it. You can use it too, but we suggest you first think carefully about whether this license or the ordinary 1-12 bizhub PRO C6501...
Page 23 Therefore, we insist that any patent license obtained for a version of the library must be consistent with the full freedom of use specified in this license. bizhub PRO C6501 1-13...
Page 24 The precise terms and conditions for copying, distribution and modification follow. Pay close attention to the difference between a "work based on the library" and a "work that uses the library". The former contains code derived 1-14 bizhub PRO C6501...
Page 25 PRO C6501 1-15...
Page 26 But when you distribute the same sections as part of a whole which is a work based on the Library, the distribution of the whole must be on the terms of this License, whose permissions for other licensees 1-16 bizhub PRO C6501...
Page 27 PRO C6501 1-17...
Page 28 Library and its use are covered by this License. You must supply a copy of this License. If the work during execution displays copyright notices, you must include the copyright notice for the Library 1-18 bizhub PRO C6501...
Page 29 (in either source or binary form) with the major components (compiler, kernel, and so on) of the operat- ing system on which the executable runs, unless that component itself ac- companies the executable. bizhub PRO C6501 1-19...
Page 30 Library subject to these terms and conditions. You may not impose any further restrictions on the recipients' exercise of the rights granted herein. 1-20 bizhub PRO C6501...
Page 31 In such case, this License incorporates the limitation as if written in the body of this Li- cense. bizhub PRO C6501 1-21...
Page 32 ERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE LIBRARY (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCU- RATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE 1-22 bizhub PRO C6501...
Page 33 You should have received a copy of the GNU Lesser General Public License along with this library; if not, write to the Free Software Foundation, Inc., 59 Temple Place, Suite 330, Boston, MA 02111-1307 USA Also add information on how to contact you by electronic and paper mail. bizhub PRO C6501 1-23...
Page 34 Redistribution and use in source and binary forms, with or without modifica- tion, are permitted provided that the following conditions are met: 1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. 1-24 bizhub PRO C6501...
Page 35 WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. This product includes cryptographic software written by Eric Young (eay@cryptsoft.com). This product includes software written by Tim Hudson (tjh@cryptsoft.com). bizhub PRO C6501 1-25...
Page 36 3. All advertising materials mentioning features or use of this software must display the following acknowledgement: "This product includes crypto- graphic software written by Eric Young (eay@cryptsoft.com)" The word 'cryptographic' can be left out if the rouines from the library being used are not cryptographic related . 1-26 bizhub PRO C6501...
Page 37 The licence and distribution terms for any publically available version or de- rivative of this code cannot be changed. i.e. this code cannot simply be cop- ied and put under another distribution licence [including the GNU Public Licence.] bizhub PRO C6501 1-27...
Page 38: Available Features
Starts chapter pages on the right side (front pages) of the finished document. Only duplex mode (1-2) is compatible with this feature. Color Mode Copies full-colored originals or makes single-colored copies, and also ad- justs image quality of the copies. 1-28 bizhub PRO C6501...
Page 39 Insert Sheet Insert up to 26 blank or copied sheets from any tray, or inserts blank or cop- ied front and back covers from any tray to enhance the presentation of multi- page documents. bizhub PRO C6501 1-29...
Page 40 When copying from the original glass when the document cover is open, copies only the image area and not the exposed area of glass, which would otherwise copy as black. Output for Finisher FS-520/FS-607 with Paper Inserter PI-502: Cover sheet feeding Off Line Finisher mode 1-30 bizhub PRO C6501...
Page 41 Creates or removes a binding margin at the top, bottom, right and left edges (shift amount from 0 ~ 250mm, in 1mm increments); reduces image to pre- vent image loss (reduce & shift amount from 0 ~ 250mm, in 1mm incre- ments). bizhub PRO C6501 1-31...
Page 42 Prints stamp (Built-in Stamp, Set Numbering, Page No., Date/Time) and wa- termark (Watermark, Set Numbering, Copy Protect) onto the output copies to enhance the presentation and usefulness of the copies. Staple Selects the stapling position and number of staples. 1-32 bizhub PRO C6501...
Page 43 Z-Folded in Original Setting This feature sets the ADF to accept Z-folded originals. Zoom Selects fixed ratios, four reduction, four enlargement, and three user-set ra- tios. Zoom ratios can be selected from 25% ~ 400% in 0.1% increments. bizhub PRO C6501 1-33...
Page 44: Legal Restrictions On Copying
This machine also provides the forgery prevention function in order to pre- vent financial instruments from being copied illegally. We appreciate your understanding that the copied image may have some noise due to this forgery prevention function. 1-34 bizhub PRO C6501...
Page 45: Safety Information
This symbol warns against cause burns. A diagonal line indicates a prohibited course of action. This symbol warns against dismantling the device. A solid circle indicates an imperative course of action. This symbol indicates you must unplug the device. bizhub PRO C6501 1-35...
Page 46 Should any of these conditions be found, im- mediately turn OFF the power switch, unplug the power cord from the power outlet, and then call your authorized service representative. 1-36 bizhub PRO C6501...
Page 47 Overload could result in a fire. CAUTION • The outlet must be near the equipment and easily accessible. Otherwise you can not pull out the power plug when an emergency occurs. bizhub PRO C6501 1-37...
Page 48 Dust that accumu- lates between the plug terminals may cause a fire. Grounding WARNING • Connect the power cord to an electrical outlet that is equipped with a grounding terminal. 1-38 bizhub PRO C6501...
Page 49 • Do not let any object plug the ventilation holes of this product. Heat could accumulate inside the product, resulting in a fire or malfunction. • Do not use flammable sprays, liquids, or gases near this product, as a fire could result. bizhub PRO C6501 1-39...
Page 50 When checking the inside of the unit for mal- functions such as a paper misfeed, do not touch the locations (around the fusing unit, etc.) which are indicated by a “Caution HOT” cau- tion label. 1-40 bizhub PRO C6501...
Page 51 If the unit falls it may cause severe personal injury. The product may also be damaged or malfunction. Before successive holidays CAUTION • Unplug the product when you will not use the product for long periods of time. bizhub PRO C6501 1-41...
Page 52 Wait until the unit is no longer hot when you handle it directly with your hands. • Do not put the paste hopper and the paste tank unit close to fire. Paste is flammable and easy to catch on fire. 1-42 bizhub PRO C6501...
Page 53 Perfect Binder. This will prevent the dis- charge of heat, and may cause fire or break- down. • Do not change the temperature setting for the paste tank unit. This may cause fire or break- down. bizhub PRO C6501 1-43...
Page 54: Regulation Notices
FCC rules. INTERFERENCE-CAUSING EQUIPMENT STANDARD (ICES-003 ISSUE 4) (For Canada Users) This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. 1-44 bizhub PRO C6501...
Page 55 Dersom apparatet brukes på annen måte enn spesifisert I denne bruksan- visning, kan brukeren utsettes for usynlig laserstråling som overskrider grensen for laser klass 1. Dette en halvleder laser. Maksimal effekt till laserdiode er 15 mW og bøkge- lengde er 775 - 800 nm. bizhub PRO C6501 1-45...
Page 56 Om apparaten används på annat sätt än I denna bruksanvisning specificer- ats, kan användaren utsättas för osynlig laserstrålning, som överskrider gränsen för laserklass 1. Det här är en halvledarlaser. Den maximala effekten för laserdioden är 15 mW och våglängden är 775 - 800 nm. 1-46 bizhub PRO C6501...
Page 57 Notification for California Customers This product uses a CR Lithium Battery which contains perchlorate material. This perchlorate warning applies to perchlorate-containing lithium batteries sold or distributed in California, USA. "Perchlorate Material - Special handling may apply, See www.dtsc.ca.gov/ hazardouswaste/perchlorate." bizhub PRO C6501 1-47...
Page 58: Caution Notations And Labels
DO NOT INSERT your burned DO NOT TOUCH. finger into the two ADF hinge portions; otherwise you may be injured. CAUTION DO NOT put your hand between the main body and developing fixing unit; otherwise you may be injured. 1-48 bizhub PRO C6501...
Page 59 Introduction/ Safety Information WARNING DO NOT throw the toner recovery box into a fire. If it is thrown into a fire, the toner may ignite and cause a dangerous situation. bizhub PRO C6501 1-49...
Page 60 Introduction/ Safety Information CAUTION The paste tank unit is very hot. To avoid getting burned DO NOT TOUCH. 1-50 bizhub PRO C6501...
Page 61 Do not remove caution labels or notations. If any caution label or caution notation is soiled, please clean to make legible. If you cannot make them legible, or if the caution label or notation is damaged, please contact your service representative. bizhub PRO C6501 1-51...
Page 62: Space Requirements
(786) 61.4 10.2 (1561) (260) Main Body + OC-506 + OT-502 unit: inches (mm) 18.5 (470) 63.7 (1619) 40.2 (1021) 37.4 35.4 11.5 (950) (899) (293) 84.3 (2142) Main Body + OC-506 + OT-502 (Side view) 1-52 bizhub PRO C6501...
Page 63 (899) 84.3 (2142) Main body + DF-609 + PF-602 (side-view) unit: inches (mm) 63.7 (1619) 40.2 (1021) 11.5 30.2 (293) (766) 37.4 35.4 (950) (899) 84.3 (2142) Main body + DF-609 + PF-602 + SD-506 (side-view) bizhub PRO C6501 1-53...
Page 64 Main body + DF-609 + PF-602 + RU-504 + FD-503 unit: inches (mm) 8.0 (205) 15.5 (393) 63.7 46.4 (1619) (1179) 40.2 (1021) 46.1 29.9 37.3 (760) (1170) (947) (100) (100) (175) 128.0 (3252) Main body + DF-609 + PF-602 + RU-504 + SD-506 1-54 bizhub PRO C6501...
Page 65 (mm) (205) 15.5 (393) 63.7 (1619) 48.4 (1231) 40.2 (1021) 15.8 29.9 37.3 46.1 (400) (760) (947) (1170) (100) (100) (175) 143.8 (3652) Main body + DF-609 + PF-602 + RU-504 + FD-503 + SD-506 bizhub PRO C6501 1-55...
Page 66 8.0 (205) 15.5 (393) 63.7 48.1 (1619) (1223) 40.2 (1021) 22.1 29.1 29.9 46.1 37.3 (563) (740) (1170) (760) (947) (100) (175) (200) 183.2 (4655) Main body + DF-609 + PF-602 + RU-504 + SD-506 + PB-501/PB-502 1-56 bizhub PRO C6501...
Page 67 Main body + DF-609 + PF-602 + RU-504 + FD-503+ SD-506 + PB-501/PB-502 unit: inches (mm) (205) 15.5 (393) 63.7 (1619) 48.1 (1223) 40.2 (1021) 29.9 37.3 22.1 29.1 (760) (947) (563) (740) (100) (200) (175) 137.2 (3485) Main body + DF-609 + PF-602 + RU-504 + PB-501/PB-502 bizhub PRO C6501 1-57...
Page 68 (mm) (205) 15.5 (393) 63.7 (1619) 48.4 40.2 (1231) (1021) 10.0 21.4 15.8 29.9 28.3 (254) (544) (400) (760) (718) (100) (100) (175) (117) 124.7 (3168) Main body + LU-202 + RU-504 + FD-503 + FS-521 1-58 bizhub PRO C6501...
Page 69 (2142) Main body + DF-609 + LU-202 + FS-607 + PI-502 (side-view) Reminder Be sure to allow a clearance of 200 mm (7-3/4 in.) or more at the back of this machine for the ventilation duct. bizhub PRO C6501 1-59...
Page 70: Operation Precautions
- Copies that are to be kept for a long time should be stored where they are not exposed to light or high temperature in order to prevent them from fading or sticking together. - Adhesive that contains solvent (e.g., spray glue) may dissolve the toner on copies. 1-60 bizhub PRO C6501...
Page 71 Preparation for Use...
Page 73: Machine Configuration
Automatically feeds multiple originals one at a time to the Feeder) (option) original glass for copying. Sub power switch Turns on/off the copying and scanning functions. Turning it off will terminate all the functions other than printing, and then enter the sleep mode. bizhub PRO C6501...
Page 74 11" × 17" w, 8.5" × 14" w, 8.5" × 11" w/v, 5.5" × 8.5" w, A3 w, B4 w, A4 w, and B5 w/v plain paper (21 lb Bond). Front door Opens to allow removal of mishandled paper. bizhub PRO C6501...
Page 75 Total counter Indicates the total number of prints made. Black print counter Indicates the total number of black prints made 7 CAUTION The internal fixing unit is very hot. To avoid getting burned, DO NOT TOUCH. bizhub PRO C6501...
Page 76 Preparation for Use Paper Feeder Unit PF-602 bizhub PRO C6501...
Page 77 Pressed backward to slide the paper guides. Paper guides Slide the adjustable paper guides against the side edges of the copy paper. Bottom plate lock release Slide and turn to fix or release the bottom plate. knob bizhub PRO C6501...
Page 78 Preparation for Use Large Capacity Unit LU-202 bizhub PRO C6501...
Page 79 Fixes the rear end of copy paper. Rear stopper knobs Can be turned to move or fix the rear stopper. Tray bottom plate Goes up automatically when paper supply becomes low, and goes down when the paper loading button is pressed. bizhub PRO C6501...
Page 80 Preparation for Use Finisher FS-521 2-10 bizhub PRO C6501...
Page 81 Stapler unit conveyance lever Opens downward to remove mishandled paper. Stapler unit handle Withdraws the unit to allow removal of mishandled paper. Stapler unit knob Can be turned counterclockwise to ease removal of mis- handled paper. bizhub PRO C6501 2-11...
Page 82 Preparation for Use Folding Unit FD-503 2-12 bizhub PRO C6501...
Page 83: External View
Can be turned clockwise to ease removal of mishandled paper. Left side lever (right/left) Opens leftward to remove mishandled paper. Upper lever Opens upward to remove mishandled paper. Conveyance knob/2 Can be turned clockwise to ease removal of mishandled cover paper. bizhub PRO C6501 2-13...
Page 84 Preparation for Use Large Capacity Stacker LS-505 2-14 bizhub PRO C6501...
Page 85 Holds sets output in Non-sort mode or Collate mode (off- set). Outlet lever Opens downward to remove mishandled paper. Carriage Carries paper together with the stacker. Paper holder Mounts paper stopper for holding output paper. Paper stopper Holds output paper. bizhub PRO C6501 2-15...
Page 86 Preparation for Use Saddle Stitcher SD-506 2-16 bizhub PRO C6501...
Page 87 Opens upward to remove mishandled paper. Stapling unit Staples folded sets. Stapling unit knob Can be turned clockwise to feed mishandled paper. Outlet lever Opens leftward to remove mishandled paper. Outlet conveyance lever Opens downward to remove mishandled paper. bizhub PRO C6501 2-17...
Page 88 Preparation for Use Perfect Binder PB-501/PB-502 2-18 bizhub PRO C6501...
Page 89 Withdrawn to remove waste paper. Binding unit descending Can be turned downward to let the binding unit down for knob removal of mishandled paper. Jam position display Indicates the position of mishandled paper by LED lamps. bizhub PRO C6501 2-19...
Page 90 Binding unit releasing knob Can be turned downward to remove cover sheet from the binding unit in the top position. 2-20 bizhub PRO C6501...
Page 91 Preparation for Use Finisher FS-520 bizhub PRO C6501 2-21...
Page 92 Stacker conveyance lever Opens lower-leftward to remove mishandled paper. Staple cartridge Holds staple case to be replaced when supplying staples. Stacker unit handle Withdraws unit to allow removal of mishandled paper and replacement of staple cartridge. 2-22 bizhub PRO C6501...
Page 93 Preparation for Use Finisher FS-607 bizhub PRO C6501 2-23...
Page 94 Stacker conveyance lever Opens lower-leftward to remove mishandled paper. Stacker unit handle Withdraws unit to allow removal of mishandled paper and replacement of staple cartridge. Staple cartridge Holds staple case to be replaced when supplying staples. 2-24 bizhub PRO C6501...
Page 95 Hold cover sheets to fix the position. Upper tray Holds cover sheets for use in cover sheet mode. Lower tray Holds cover sheets for use in cover sheet mode. Lower tray guide plates Hold cover sheets to fix the position. bizhub PRO C6501 2-25...
Page 96 Preparation for Use Standard/Optional Equipment 2-26 bizhub PRO C6501...
Page 97 Preparation for Use bizhub PRO C6501 2-27...
Page 98 Preparation for Use 2-28 bizhub PRO C6501...
Page 99 Preparation for Use bizhub PRO C6501 2-29...
Page 100 Preparation for Use 2-30 bizhub PRO C6501...
Page 101 Preparation for Use bizhub PRO C6501 2-31...
Page 102: Turning On/Off The Power
Turn on the sub power switch. – The sub power switch is located at the front of the main body. When the sub power switch is turned on, the Power LED will turn green. 2-32 bizhub PRO C6501...
Page 103 Do you want to set reserve jobs while the machine is warming up? % Touch [COPY] tab to change the Machine Status Screen to the Copy Screen, then check that the message “Ready to set reserve job” is displayed in the message area. bizhub PRO C6501 2-33...
Page 104 For details, see page 5-22 of the POD Admin- istrator's reference. A user/section name and password may be required to operate the ma- chine. See page 2-43 for details. If a key counter or copy card is required, follow the instruction on the screen. 2-34 bizhub PRO C6501...
Page 105 Open the front door and left side door to reach it. Reminder When turning the main power switch off then on, be sure to wait 10 sec- onds or longer before turning it on again; otherwise the machine may not operate properly. bizhub PRO C6501 2-35...
Page 106: Automatically Returning To The Default Settings: Automatic Reset Setting
To change the selection of Output Application for Full-auto, see page 5- 40 of the POD Administrator’s reference. To select the copy conditions to be reset with each job completion, see page 5-19 of the POD Administrator's reference. 2-36 bizhub PRO C6501...
Page 107: To Use Machine When Power Save Led Lights
Timer Interrupt function. See page 2-41 for details. Detail The Power Save function has two modes: Auto Low Power and Auto Shut-Off. See the following description for details. This function can also be activated manually. For details, see page 2-40. bizhub PRO C6501 2-37...
Page 108 15 minutes/ 30 minutes/ 60 minutes/ 90 minutes/ 120 minutes/ 240 min- utes. See p. 5-26 or 6-6 of the POD Administrator’s reference for details. To exit Auto Low Power Press or touch any key on the control panel and touch panel. 2-38 bizhub PRO C6501...
Page 109 90 minutes/ 120 minutes/ 240 minutes, or can be deactivated. For details, see p. 5-26 or 6-6 of the POD Administrator’s reference. To exit Auto Shut-Off Press [Power Save]. The copying opera- tion will become available. bizhub PRO C6501 2-39...
Page 110 Keep POWER SAVER pressed more than one second to enter Low power mode Detail The machine is initially set to activate the Shut-Off function manually. To use Low Power instead, see p. 5-26 or 6-6 of POD Administrator’s ref- erence. 2-40 bizhub PRO C6501...
Page 111 The machine power will be turned off automatically after 5 minutes from this state if a password is not en- tered. Or, if the following message is displayed, proceed to step 3. Input desired copy time $ hour(s) $# minute(s) bizhub PRO C6501 2-41...
Page 112 3 hour(s) 07 minute(s) Copying is available until the set time is up. When the machine operation is finished, press [Power Save] for one second or longer, then release it. The machine returns to OFF condition. 2-42 bizhub PRO C6501...
Page 113: Making User Authentication
Copy quantity limit for each section can also be set. When the machine is turned on, one of the following User Authentication screen will be displayed according to the authentication setting. Copying will be available by the following procedure. bizhub PRO C6501 2-43...
Page 114 When machine operation is completed, press [Access]. The initial state will be restored, with the User Authentication Screen displayed on the touch panel. Note If the message “Copy limit reached” is displayed and machine operation becomes unavailable, contact your administrator. 2-44 bizhub PRO C6501...
Page 115 Paper and Original Information...
Page 117: Paper Information
17 to 81 lb Bond LU-202) Cover feeding tray (Perfect 22 to 43 lb Bond Binder PB-501/PB-502) Post Inserter Upper/Lower 13 to 81 lb Bond tray (attached to Folding Unit Cover paper for perfect binding: 22 to 43 lb Bond FD-503) bizhub PRO C6501...
Page 118 Z-Fold, Tri-Fold-in, Tri-Fold-out, Half Fold: 17 to 36 lb Bond Double Parallel, Gate Fold: 17 to 24 lb Bond Large Ca- Secondary 17 to 81 lb Bond pacity (sub) tray Stacker Stacker 17 to 68 lb Bond LS-505 bizhub PRO C6501...
Page 119 Although the Finisher FS-520/FS-607 can actually handle paper of the weight less than 17 lb Bond as described above, the paper fed from trays 1 to 5 and bypass tray will be 17 lb Bond at minimum. bizhub PRO C6501...
Page 120 1,500 sheets (21 lb Bond) (13" × 19" w, 12" × 18" w, 11" × 17" (normal w, 8.5" × 14" w, SRA3 w, SRA4 w/v, A3 w, B4w) /punch) Primary 30 sheets (main) tray (fold) Large capac- Secondary Max. 200 sheets ity stacker (sub) tray LS-505 bizhub PRO C6501...
Page 121 10 to 30-sheet-bound set: 50 sets 31 to 150-sheet-bound set: 35 sets or until detected as full load 151 to 300-sheet-bound set: until detected as full load Secondary Max. 200 sheets (with Full load detection function activated) (sub) tray bizhub PRO C6501...
Page 122 Max. folded sheets in Multi Tri-Fold: 3 sheets (16 to 21 lb Bond) / 1 sheet (22 to 28 lb Bond) Multi Tri-Fold: 50 sets for 1-sheet-folded set Punch Kit PK-512 Unlimited (option for Finisher FS- 520/FS-607) Output tray OT-502 150 sheets bizhub PRO C6501...
Page 123 20 sheets 20 sheets 15 sheets Bond * Up to 2 cover sheets (53 lb Bond max.) can be inserted from paper inserter. In this case, the stapling capacity mentioned above includes the number of attached cover sheet. bizhub PRO C6501...
Page 124: Paper Size
+ body set’s thickness (1 mm or more) + 3mm or more of trimming width if trimming, mode is specified. Max. 12.10" × 18.58" (307 mm × 472 mm) to Min. 5.47" × 10.98" (139 mm × 279 mm) (Custom size) 3-10 bizhub PRO C6501...
Page 125 12" × 18" w, 11" × 17" w, 8.5" × 14" w, 8.5" × 11" w/v, 5.5" × 8.5" v, SRA4 w, A3 w, B4 w, A4 w/v, B5 w/v, A5 v Custom Size: Max. 12.36" × 18.03" (314 mm × 458 mm) to Min. 7.17" × 5.83" (182 mm × 148 mm) bizhub PRO C6501 3-11...
Page 126 :13"×19" w and B6 w are available for straight output only. Custom Size: Max. 13.03" × 19.21" (331 mm × 483 mm) to Min. 5.04" × 5.83" (128 mm × 148 mm) Tab Paper: 8.5" × 11" v, A4 v 3-12 bizhub PRO C6501...
Page 127 12" × 18" w, 11" × 17" w, 8.5" × 14" w, 8.5" × 11" w, SRA3 w, tray SRA4 w/v, A3 w, B4 w, A4 w, B5 w Custom Size: Max. 12.76" × 18.11" (324 mm × 460 mm) to Min. 7.17" × 10.12" (182 mm × 257 mm) bizhub PRO C6501 3-13...
Page 128 B5 w/v, A5 w/v, B6 w, A6 w Custom Size: Max. 13.03" × 19.21" (331 mm × 488 mm) to Min. 3.94" × 5.83" (100 mm × 148 mm) Tab Paper: 8.5" × 11" v, A4 v 3-14 bizhub PRO C6501...
Page 129 Paper size for cover sheets to be used in perfect binding can be specified in the Output Application setting. See page 12-47 for details. Cover sizes available for perfect binding differ from the above mentioned. See page 12-44 for details. bizhub PRO C6501 3-15...
Page 130 - Store paper in a cool, dry area. Using damp paper may cause a paper misfeed. - Keep partially used packages tightly wrapped during storage. - Do not place paper packages vertically to store. Paper curl due to the vertical storage may cause a paper misfeed. 3-16 bizhub PRO C6501...
Page 131: Original Information
- Original that are bound together with glue - Original pages that have been cut or contain cutouts - Label sheets - Offset printing masters - Original with binder holes - Original that have just been printed with this machine bizhub PRO C6501 3-17...
Page 132 The original glass is fragile. Do not place too heavy originals, or do not press strongly when thick original is placed and is under pressure of ADF, otherwise the glass may be broken and you may be injured. 3-18 bizhub PRO C6501...
Page 133 Original size 5.0" × 5.5" to 11.7" × 17.0" (128 mm × 139.7 mm to 297 mm × 431.8 mm) Feeder capacity 100 sheets (21 lb Bond) Curling tolerance 10 mm or less Original placement Face up bizhub PRO C6501 3-19...
Page 134 Feeder capacity 100 sheets (21 lb Bond) Curling tolerance 10 mm or less Original placement Face up (see page 8-15 for details.) Note See below for the guide width of each combination. 11x17 8.5x11 x8.5 x11 3-20 bizhub PRO C6501...
Page 135 5.0" × 5.5" to 11.7" × 17.0" (128 mm × 139.7 mm to 297 mm × 431.8 mm) Feeder capacity 100 sheets (21 lb Bond) Curling tolerance 10 mm or less Original placement Face up; orientation same as copy paper bizhub PRO C6501 3-21...
Page 137 Supplies & Handling...
Page 139: Loading Paper
Reminder Paper setting for each tray can be made from the Machine Status Screen or from the Copy Screen using the [Paper Setting] key. Be sure to load the specified paper; otherwise machine trouble may be caused. bizhub PRO C6501...
Page 140 See the size indication on the bottom plate of the tray to determine the position of the side guide plate. – Push down the lock lever firmly until it clicks in position in order to fix the side guide plate. bizhub PRO C6501...
Page 141 When paper is seated properly, close the paper feed roller. Gently push in the tray until it locks into place. – The indicator “ ” on the Machine Status Screen or Copy Screen will change to “ ”. bizhub PRO C6501...
Page 142 Do not move the stopper forcibly, otherwise it may be damaged. Be sure that the rear guide plate is securely aligned to the paper; other- wise machine trouble may be caused. bizhub PRO C6501...
Page 143 The indicator “ ” on the Machine Status Screen and Copy Screen will change to “ ”. When copying is completed, close the bypass tray. bizhub PRO C6501...
Page 144 Withdraw the tray to be supplied with paper. – To load the same size as loaded before, proceed to step 4. Loosen the paper guide knobs. – Turn the four paper guide knobs counterclockwise to loosen them. bizhub PRO C6501...
Page 145 – Pushing the guide lock release le- ver, move the front edge guide to the edge of the paper. When paper is seated properly, close the paper feed roller. bizhub PRO C6501...
Page 146 Be sure that the side paper guides and front edge guide are securely aligned to the paper; otherwise the machine cannot detect the correct paper size, or machine trouble may occur. Do not bump the tray into the main body; otherwise machine trouble may be caused. 4-10 bizhub PRO C6501...
Page 147 Slide both paper guides closely until it stops. – Turn the four paper guide knobs counterclockwise to loosen them. – Pushing the paper guide lock re- lease lover, move the both guides closely until it stops. bizhub PRO C6501 4-11...
Page 148 Load paper so that the left side edge is aligned with the left side lining of the tray. – Pushing the guide lock release le- ver, move the front edge guide to the edge of the paper. 4-12 bizhub PRO C6501...
Page 149 Be sure that the side paper guides and front edge guide are securely aligned to the paper; otherwise the machine cannot detect the correct paper size, or machine trouble may occur. Do not bump the tray into the main body; otherwise machine trouble may be caused. bizhub PRO C6501 4-13...
Page 150 When that automation is completed, the paper amount indicator on the Machine Status Screen and Copy Screen changes to “ ”. Withdrawing the tray at this point, you will find that t he bottom plate has been elevated to the top position. 4-14 bizhub PRO C6501...
Page 151 If not, readjust paper guides. Turn the bottom plate lock release knob counterclockwise to unlock the tray bottom plate. The tray bottom plate goes down. bizhub PRO C6501 4-15...
Page 152 Be sure that the side paper guides and front edge guide are securely aligned to the paper; otherwise the machine cannot detect the correct paper size, or machine trouble may occur. Do not bump the tray into the main body; otherwise machine trouble may be caused. 4-16 bizhub PRO C6501...
Page 153 – Turn the four paper guide knobs and two rear stopper knobs counter- clockwise to loosen them. – Move the upper part of the two paper guides to the appropriate positions according to the size indication. bizhub PRO C6501 4-17...
Page 154 Move the position of the rear stopper to the appropriate positions according to the size indication on the size indication on the bottom plate. – Turn the two rear stopper knobs clockwise to fix the rear stopper. 4-18 bizhub PRO C6501...
Page 155 Do not load above the limit indicated on the tray paper guides. Be sure that the rear stopper is correctly positioned according to the paper size to be loaded; otherwise paper misfeed or machine trouble may occur. bizhub PRO C6501 4-19...
Page 156: Loading Cover Paper
The paper setting for loaded cover paper will be required in perfect binding procedure. See page 12-47 for details. To load cover paper in cover feeding tray of Perfect Binder PB-501/PB- Withdraw the cover feeding tray. Open the paper feed roller. 4-20 bizhub PRO C6501...
Page 157 Be sure that the side guide plates and rear edge guide are securely aligned to the paper; otherwise a paper jam may be caused. Do not bump the tray into the perfect binder; otherwise machine trouble may be caused. bizhub PRO C6501 4-21...
Page 158: Loading Tabbed Sheets
Press the release lever of the front side guide plate to move the side guide plates, and also move the rear edge guide to the edge of the paper. Push in the tray until it locks into place. 4-22 bizhub PRO C6501...
Page 159 Specify the paper type as tabbed sheets for the bypass tray. – See page 9-44 for specifying the paper type of the bypass tray. Place tabbed sheets on the tray. – Place paper referring to the illustration shown above. bizhub PRO C6501 4-23...
Page 160 Do not load above the limit level on the side guide plate. Be sure that the side guide plates and rear edge guide are securely aligned to the paper; otherwise the machine cannot detect the correct paper size, or machine trouble may occur. 4-24 bizhub PRO C6501...
Page 161 Set paper aligning it to the paper feed roller side of the tray. – Move the side guide plates, and also move the rear stopper to the edge of the paper. Refer to page 4-17 for details. Close the tray top door. bizhub PRO C6501 4-25...
Page 162: Adding Toner
7 WARNING Precaution for the empty toner bottle If it is thrown into a fire, the toner may ignite and cause a dangerous situation. DO NOT THROW toner or the empty toner bottle into a fire! 4-26 bizhub PRO C6501...
Page 163 If toner gets in your eyes, immediately flush them with water, and then seek professional medical attention. To exchange the toner bottle Open the toner access door. Unlock and open the toner bottle cover of the empty toner bottle. bizhub PRO C6501 4-27...
Page 164 Tap both top and bottom of the new toner bottle on a solid sur- face five times each, then shake the bottle at least five times. Remove the cap from the new toner bottle, then put it to the used empty one. 4-28 bizhub PRO C6501...
Page 165 Close and lock the toner bottle cov- er, then close the toner access door. Reminder The toner bottle cover cannot be locked if the toner bottle is not set in place. Be sure to fully insert it. bizhub PRO C6501 4-29...
Page 166: Exchanging Toner Recovery Box
If it is thrown into a fire, the toner may ignite and cause a dangerous situation. DO NOT THROW the toner recovery box into a fire! To exchange toner recovery box Open the toner recovery box door on the rear-right side of the machine. 4-30 bizhub PRO C6501...
Page 167 Set the new toner recovery box, then close the toner recover box door. Reminder Be sure to completely cover the used toner inlet with the sticker, other- wise the used toner may leak out to soil the machine. bizhub PRO C6501 4-31...
Page 168: Replenishing Staples
When the staple cartridge of the Finisher FS-521 becomes empty, the Staple Cartridge indicator lights in red in the option status area of the Machine Sta- tus Screen. Follow the procedure below to replenish staples. Open the Finisher door. 4-32 bizhub PRO C6501...
Page 169 Set the staple roll into the staple car- tridge. – Open the staple cartridge cover, then set the staple roll into the cartridge. – Close the cover, then remove the lock tape pulling it in horizontal direction. bizhub PRO C6501 4-33...
Page 170 Return the stapler unit to its original position. Close the Finisher door. Reminder Do not pull the lock tape upward, otherwise the tape may rip and remain inside the cartridge so that the staples cannot be used. 4-34 bizhub PRO C6501...
Page 171 Stitcher. Remove the empty cartridge. – Hold both left and right sides of the staple cartridge, then draw it forward. The machine is mounted with two staple cartridges. Be sure to re- move the empty one. bizhub PRO C6501 4-35...
Page 172 Supplies & Handling Set the new cartridge. – Check that the top side of the staple cartridge is up, otherwise it cannot be inserted. Close the left side door of the Saddle Stitcher. 4-36 bizhub PRO C6501...
Page 173 Cartridge indicator lights in red in the option status area of the Machine Status Screen. Follow the procedure below to replenish staples. Open the Finisher door. Pull out the stacker unit. – Pull out the stacker unit slowly by holding the stacker unit handle until it stops. bizhub PRO C6501 4-37...
Page 174 Remove the empty staple case from the staple cartridge. Insert the new staple case into the staple cartridge. – Do not remove the staples remaining inside the cartridge; otherwise, the first sheet output after the replenishment will not be stapled. 4-38 bizhub PRO C6501...
Page 175 Supplies & Handling Return the stacker unit to its original position. Close the Finisher door. bizhub PRO C6501 4-39...
Page 176 Cartridge indicator lights in red in the option status area of the Machine Sta- tus Screen. Follow the procedure below to replenish staples. Open the Finisher door. Pull out the stacker unit. – Pull out the stacker unit slowly by holding the stacker unit handle until it stops. 4-40 bizhub PRO C6501...
Page 177 – Do not remove the staples re- maining inside the cartridge; oth- erwise, the first sheet output after the replenishment will not be stapled. bizhub PRO C6501 4-41...
Page 178 Set the staple cartridge. – Insert the cartridge while sliding it along the stapler rail, then push down and in to secure it in place. Return the stacker unit to its original position. Close the Finisher door. 4-42 bizhub PRO C6501...
Page 179: Adding Paste Pellet To Perfect Binder Pb-501/Pb-502
Do not touch the lever in the paste hopper with your hand to avoid breakdown. Be sure to loosen the paste pellets inside the bag before adding them. If paste pellets stick inside the paste hopper, see page 5-5 for details. bizhub PRO C6501 4-43...
Page 180 Supplies & Handling To add paste pellet Loosen the paste pellets inside the bag. Open the paste hopper cover. Supply the paste hopper with paste pellet. 4-44 bizhub PRO C6501...
Page 181 Close the paste hopper cover. Reminder Do not add the paste pellet above the limit level indicated inside the paste hopper. Be sure to close the paste hopper cover firmly, otherwise an error message will be displayed. bizhub PRO C6501 4-45...
Page 182: Disposing Punch Waste
When the waste basket of Folding unit FD-503 becomes full, the Punch Waste Basket indicator lights in red in the option status area of the Machine Status Screen. Follow the procedure below to empty the waste basket. 4-46 bizhub PRO C6501...
Page 183 Supplies & Handling Open the Folding unit door, then withdraw the waste basket. Empty the waste basket. bizhub PRO C6501 4-47...
Page 184 Supplies & Handling Return the waste basket to its origi- nal position, then close the Folding unit door securely. 4-48 bizhub PRO C6501...
Page 185 607 becomes full, the Punch Waste Basket indicator lights in red in the op- tion status area of the Machine Status Screen. Follow the procedure below to empty the waste basket. Open the Finisher door. Withdraw the waste basket. bizhub PRO C6501 4-49...
Page 186 Supplies & Handling Empty the waste basket. Return the waste basket to its origi- nal position, then close the Finisher door securely. 4-50 bizhub PRO C6501...
Page 187: Disposing Trimmings
Follow the procedure below to empty the waste basket. Withdraw the waste basket. – The waste basket cannot be withdrawn while machine opera- tion is in progress. Be sure to confirm that the machine has stopped its operation before withdrawing the waste basket. bizhub PRO C6501 4-51...
Page 188 Close the top cover of the waste bas- ket, then return it to its original posi- tion. Reminder Be sure to return the waste basket to its original position, otherwise the trimming function cannot be performed. 4-52 bizhub PRO C6501...
Page 189 If printing job is in progress, a message will be displayed on the Copy Screen. Follow the procedure below to empty the dust box. Open the front door of the perfect binder. Withdraw the dust box. bizhub PRO C6501 4-53...
Page 190 Reminder Do not open the front door while machine operation is in progress, otherwise a paper jam may be caused. Be sure to confirm that the machine has stopped its operation before opening the front door. 4-54 bizhub PRO C6501...
Page 191: Removing Finished Sets From Large Capacity Stacker Ls-505
Open the large capacity stacker door. – Once the stacker holds a sheet of output paper, the large capacity stacker door will be locked and cannot open till the stacker unit goes down fully to the carriage. bizhub PRO C6501 4-55...
Page 192 Remove the sheets from the car- riage. The stacker unit can be removed from the carriage. Return the carriage to its original po- sition, then close the large capacity stacker door. 4-56 bizhub PRO C6501...
Page 193 To secure paper on the carriage Remove the paper stopper form the carriage. Mount the paper stopper on the pa- per holder. – Pull the two projections of paper stopper to the holder, then raise the other side as illustrated. bizhub PRO C6501 4-57...
Page 194 Pull up and turn the paper stopper as illustrated. – Remove the stopper from the pa- per holder. Return the paper stopper to its origi- nal position. Return the paper stopper properly; otherwise the Stacker door may not be closed. 4-58 bizhub PRO C6501...
Page 195: Suspending/Restarting Output To Finisher Fs-521
(main) tray. – There will be no trouble in restarting the output job with printed sheets left in the tray. In this case, the LED of the Suspension button will remain lit. bizhub PRO C6501 4-59...
Page 196 Press [Start] on the control panel to restart the output job. The machine will resume printing. Detail To cancel the output job without restarting it, press [Stop]. See the following subsection "To cancel the suspended job" for details. 4-60 bizhub PRO C6501...
Page 197 Supplies & Handling To cancel the suspended job Press [Stop] on the control panel. A popup menu will be displayed for selecting whether or not to cancel the suspended job. Touch [Stop Job]. bizhub PRO C6501 4-61...
Page 199 Troubleshooting...
Page 201: If "Please Call Service C-####" Message Is Displayed
Make note of the report code number "C-####" indicated in the second line of the message area. Turn OFF the sub power switch and main power switch. Unplug the machine. Contact your service representative and report the condition and report code number. bizhub PRO C6501...
Page 202 (ex. Tray 2). 7 CAUTION Precaution for limited use The machine should not keep operating by limited use for long time. Be sure to contact your service representative immediately when the Call for Service Screen is displayed. bizhub PRO C6501...
Page 203: If Paste Pellets Stick Inside Paste Hopper
Follow the procedure below for recovery. To clear the stuck paste pellets Open the paste hopper cover. Raise the pellet stacking correction lever. Push in the pellet stacking correction lever and then draw it out just one time. bizhub PRO C6501...
Page 204 Close the paste hopper cover. Detail If this action for recovery fails, the message "Please Call Service SC15- 17" will be displayed on the touch panel. (Service Call Screen) Please contact your service representative immediately. bizhub PRO C6501...
Page 205: Clearing Mishandled Paper
A jam code can be displayed in the message area of the Jam Position Screen. Contact your service representative, if desired. Before performing the clearing procedure, see page 1-48 for the caution label locations inside the machine. bizhub PRO C6501...
Page 206 The internal fixing unit is very hot. To avoid getting burned, DO NOT TOUCH. Be especially careful not to put your hand into the fixing unit area when withdrawing the fixing conveyance unit to remove mishandled paper. bizhub PRO C6501...
Page 207 Troubleshooting 7 CAUTION Precaution for getting injured Be careful of removing staples stuck inside the machine so as not to get injured. bizhub PRO C6501...
Page 208: If [Machine] Tab Blinks In Orange
[MACHINE] tab may blink in orange. If the Jam Position Screen is displayed after touching [Detail Check], follow the procedure on page 5-7 to remove mishandled paper. 5-10 bizhub PRO C6501...
Page 209 To change the tray selection Touch the desired tray key. Touch [OK] to restore the Machine Status Screen. Press [Start]. Copy paper will be delivered from newly selected tray to continue the printing operation. bizhub PRO C6501 5-11...
Page 210 Follow the procedure for each to continue the machine operation. Procedure Replace paper in the tray with that specified in the paper setting, then touch [Change]. Press [Start] to start the printing operation. 5-12 bizhub PRO C6501...
Page 211 Occasional memory overflow may occur if the installed memory is inadequate for the copy conditions selected, and the machine will stop its operation with the following popup screen displayed. Touch [Stop]. All the scanned data will be cleared to terminate the job. bizhub PRO C6501 5-13...
Page 212: If Power Off/On Screen Is Displayed
Follow the procedure below to turn the machine power off then on. To turn machine power off/on Turn OFF the sub power switch. Turn OFF the main power switch. Wait about 10 seconds. Turn ON the main power switch and sub power switch. 5-14 bizhub PRO C6501...
Page 213: Troubleshooting Tips
AFTER [Reset] IS PRESSED Originals should conform to the recommended size and weight. Position originals properly in the ADF. Set to use ADF in the Initial Setting. See page 5-40 of POD Ad- ministrator’s reference for details. bizhub PRO C6501 5-15...
Page 214: Troubleshooting
Machine Status Screen. Empty the waste basket. COPIES CANNOT BE STA- Check to make sure the side guide plates are securely aligned to PLED OR PUNCHED IN the copy paper in the paper tray to be used. POSITION 5-16 bizhub PRO C6501...
Page 215 USING PERFECT BINDING, Check to see if the front door of perfect binder, perfect binder tray COPIES CANNOT BE cover or paste hopper cover is open. BOUND Securely close the front door/perfect binder tray cover/paste hopper cover. bizhub PRO C6501 5-17...
Page 217 Maintenance...
Page 219: Cleaning The Machine
Cleaning the ADF Guide Cover Keep the ADF guide cover clean; otherwise soil marks may be copied or the original size cannot be detected correctly. Raise the ADF, then clean the cover with a soft, dry cloth. bizhub PRO C6501...
Page 220 Clean the control panel with a soft, dry cloth. Reminder Pressing too hard on the control panel or the touch panel may damage them. Never use a household detergent, glass cleaner, benzine, or thinner to clean the control panel and touch panel. bizhub PRO C6501...
Page 221: Checking Copy Count
10.1 mm - 20.0 mm 20.1 mm - 30.0 mm - Total Bodies - Total Thickness To check the counters Press [Utility/Counter] on the control panel. The Utility Menu Screen will be displayed. Check the counter information. bizhub PRO C6501...
Page 222 Touching [Exit] will exit the Utility mode and restore the previous screen. If [Perfect Bind Count] is displayed on the screen, touching it will display three types of perfect binding count. When finished with checking, touch [Close]. bizhub PRO C6501...
Page 223 After the counter list is printed out, the Utility mode will be released automatically and the previous screen will be restored. Note Touching [Detail] in step 4 will also display the [System Info.] key. Touch this key to display the system information of this machine. bizhub PRO C6501...
Page 224: Cleaning Conveyance Belt Of Saddle Stitcher Tray
To clean the conveyance belt Fully withdraw the saddle stitcher tray, then open the tray stand. – Never fail to open the tray stand, otherwise the machine may be damaged. bizhub PRO C6501...
Page 225 Clean the bottom plate of the saddle stitcher tray. – Wipe the whole surface of the bottom plate with a soft cloth slightly dampened with alcohol (cleaner). Return the tray stand to its original position, then return the saddle stitcher tray. bizhub PRO C6501...
Page 226 Maintenance Reminder Be sure to clean the whole round of the conveyance belt. Never return the saddle stitcher tray to its original position with the tray stand opened. 6-10 bizhub PRO C6501...
Page 227: If "Receiver Exchange" Message Is Displayed
The machine manager can call for service using the Utility setting. See page 6-139 of POD Administrator’s reference. In this case, you don’t have to make a call for preventive maintenance, because your machine has been monitored automatically by your service representative. bizhub PRO C6501 6-11...
Page 228: Preventive Maintenance
The machine manager can call for service using the Utility setting. See page 6-139 of POD Administrator’s reference. In this case, you don’t have to make a call for preventive maintenance, because your machine has been monitored automatically by your service representative. 6-12 bizhub PRO C6501...
Page 229: Precautions For Paste Pellets And The Perfect Binder
See page 12-40 for details. - Do not overload the paste hopper with paste pellets. - Do not touch the lever in the paste hopper with your hand to avoid breakdown. bizhub PRO C6501 6-13...
Page 231 Specifications...
Page 233: Main Body Specifications
Specifications Specifications Main Body Specifications Main Body Item Description Name bizhub PRO C6501 Type Console type Document holder Stationary Photoconductor Luminous source Xenon lamp Copying system Laser electrostatic transfer method Developing system Dry-type dual-component reverse magnetic brush devel- oping Fusing system...
Page 234: Specifications
Space requirements 11.5" (293 mm) or more on the back 3.9" (100 mm) or more on both sides In order to incorporate improvements, these product specifications are sub- ject to change without notice. bizhub PRO C6501...
Page 235: Option Specifications
Upper tray (tray 4): 3,000 sheets (21 lb Bond) Lower tray (tray 5): 3,000 sheets (21 lb Bond) Dimensions 37.3 (W) × 29.5 (D) × 41.1(H) inches Weight Approx. 375 lb Power source Supplied from main body bizhub PRO C6501...
Page 236: Large Capacity Unit Lu
(331 mm × 488 mm) to min. 8.27" × 14.96" (210 mm × 380 mm) paper Secondary (sub) tray: 200 sheets Power source Supplied from internal battery Dimensions 30.9 (W) × 28.5 (D) × 40.2 (H) inches Weight Approx. 243 lb bizhub PRO C6501...
Page 237 (See p. 3-6 for details.) Staple cartridge Contains 5,000 staples Power source Supplied from main body Dimensions 21.4 (W) × 28.5 (D) × 40.2 (H) inches Width including primary (main) tray: 31.4 inches/ 36 inches (pulled out) Weight Approx. 176 lb bizhub PRO C6501...
Page 238 (See p. 3-13 for details.) Paper tray capacity See p. 3-7 for details. Maximum power consumption 270VA Dimensions 46.1 (W) × 30.5 (56.7" when tray is pulled out) (D) × 40.2 (H) inches Power source Supplied from internal battery bizhub PRO C6501...
Page 239 200 sheets (Full-load detection- function is available.) Warm-up time Approx. 20 minutes Dimensions 51.3 (W) × 30.5 (D) × 48.2 (H) inches Weight Approx. 463 lb Power source Supplied from internal battery Power consumption 1,000 W max. bizhub PRO C6501...
Page 240 See p. 3-8 for details. Maximum power consumption 80 W or less Dimensions 16.7 (W) × 25.8 (26.6 when primary (main) tray is attached/ 56.7 when the tray is pulled out) (D) × 39.0 (H) inches Weight Approx. 143 lb 7-10 bizhub PRO C6501...
Page 241 13.5 (18.5" when tray is pulled out) (W) × 17.9 (D) × 6.6 (H) inches Weight Approx. 4.1 lb Other Options Original cover OC-506 Dehumidification fan heater HT-503/504 Hard disk unit HD-506 Relay unit RU-504 Image controller bizhub PRO C6501 7-11...
Page 243 Before Making Copies...
Page 245: Control Panel And Basic Screens
Before Making Copies Before Making Copies Control Panel and Basic Screens 8.1.1 Control Panel Name Description Keypad Enters values for various settings, including the print quantity and password. [Reset] key Restores machine to the initial settings. bizhub PRO C6501...
Page 246: Before Making Copies
Displays various screens and messages to allow the func- tion setting. Power LED Lights up in red when the main power is turned on, then turns green when the sub power switch is turned on. Data LED Blinks while a print job is being received. bizhub PRO C6501...
Page 247 7 CAUTION The touch panel is covered with glass. Do not drop heavy objects on the glass, or put excess weight or pres- sure on it; otherwise the glass may break or scratched and you may be injured. bizhub PRO C6501...
Page 248: Copy Screen
Used to display the Job List Screen. Set Number indicator Indicates the print quantity entered from the control panel keypad. [Application] key Touched to select various application functions. [MACHINE] tab Used to display the Machine Status Screen. bizhub PRO C6501...
Page 249 Displays the icon of the original settings currently speci- fied. [Original Setting] key Touched to specify the condition of the original to be scanned. Machine status icons Display to indicate various machine status. Message area Displays the machine status and procedure required at that time. bizhub PRO C6501...
Page 250: Machine Status Screen
Displays the paper setting made for each tray, and also displays the paper sizes loaded in the Post inserter. The currently selected tray will be indicated in different color. Job list Displays the current status of the jobs to be operated on the machine. bizhub PRO C6501...
Page 251 Displays the current status of scanning job. Icon area Displays various machine status icons. Message area Displays messages concerning machine status. With Per- fect Binder PB-501/PB-502 installed, also indicates the current state of the equipment such as warming up/shut off. bizhub PRO C6501...
Page 252: General Copy Operation
Position the original. – For details on positioning the original, see page 8-13. Display Copy Screen. – Touch [COPY] tab on the Machine Status Screen to display the Copy Screen. 8-10 bizhub PRO C6501...
Page 253 For details on entering print quantity, see page 8-18. Entered quantity will be displayed on the touch panel. Press [Start] on the control panel. – When the machine starts scan- ning the original, the current job status will be displayed on the popup menu. bizhub PRO C6501 8-11...
Page 254 The Job List Screen is provided to change the operation order of reserve jobs or cancel the reserve job. See page 14-3 for details. To suspend the job in progress, press [Stop]. For details, see "To Stop Scanning/Printing" on page 8-22. 8-12 bizhub PRO C6501...
Page 255: Positioning The Original
UP) in the ADF. – The direction of the original should conform to the original di- rection icon displayed on the Copy Screen. Up to 100 sheets of the original can be set at a time. bizhub PRO C6501 8-13...
Page 256 Before Making Copies Adjust paper guides. Reminder Once closed, do not open the document feeder, otherwise the selected copy conditions may be altered automatically. 8-14 bizhub PRO C6501...
Page 257 Up to 100 sheets of the original can be set at a time. Adjust paper guides. Reminder Once closed, do not open the document feeder, otherwise the selected copy conditions may be altered automatically. Detail To use the Mixed mode, see procedure on page 9-10. bizhub PRO C6501 8-15...
Page 258 Up to 100 sheets of the original can be set at a time. Adjust paper guides. Reminder Once closed, do not open the document feeder, otherwise the selected copy conditions may be altered automatically. Detail To use the Z-Folded original mode, see procedure on page 9-12. 8-16 bizhub PRO C6501...
Page 259: Positioning The Original On Original Glass
– The direction of the original should conform to the Orig- inal direction icon displayed on the Copy Screen. Gently close the ADF to prevent the original from shifting on the glass. bizhub PRO C6501 8-17...
Page 260: Setting Print Quantity
0 Print quantity can be entered in any instance of the procedure unless the control panel keypad is temporarily used for entering other values. Enter the desired print quantity from the control panel keypad. Entered quantity will be displayed on the touch panel. 8-18 bizhub PRO C6501...
Page 261 Press [C] (clear quantity). The quantity displayed on the touch panel will return to 0001. Enter the correct quantity from the control panel keypad. Newly entered quantity will be displayed on the touch panel. bizhub PRO C6501 8-19...
Page 262: Setting Job During Warmup
Position the original FACE UP in the ADF or FACE DOWN on the orig- inal glass. – For details on positioning the original, see page 8-13. Press [Start]. – When scanning the original for the job is started, the popup menu will appear on the Copy Screen. 8-20 bizhub PRO C6501...
Page 263 The Job List Screen is provided to change the operation order of reserve jobs or cancel the reserve job. See page 14-3 for details. To suspend the job in progress, press [Stop]. For details, see "To Stop Scanning/Printing" on page 8-22. bizhub PRO C6501 8-21...
Page 264: To Stop Scanning/Printing
The current machine operation of the selected job will be suspended, and the popup menu will be displayed on the Copy Screen. Touch the desired key on the popup menu. – The popup menu will vary according to the job in progress. 8-22 bizhub PRO C6501...
Page 265 Touching [Stop Job] will delete all the scanned data. Scanning a job in Separate Scan mode: Touch [Stop Job] to cancel the job, or touch [Continue] to complete the job. Reminder Touching [Stop Job] will delete all the scanned data. bizhub PRO C6501 8-23...
Page 266 Touching [Stop Job] will delete all the scanned data. Scanning and printing the job using Program Job: Touch [Stop Job] to cancel the job, or touch [Continue] to complete the job. Reminder Touching [Stop Job] will delete all the scanned data. 8-24 bizhub PRO C6501...
Page 267 If machine has been set to display the Copy Screen as the initial screen, touch [MACHINE] tab to restore the Machine Status Screen. Press [Stop]. Machine operation will be ceased, and the following popup menu will be displayed. bizhub PRO C6501 8-25...
Page 268 Touch [Print] to stop printing and continue the scanning job. Touch [Scan/Print] to cancel both scanning and printing jobs. Touch [Continue] to complete both jobs. Reminder All the data scanned for stopped job will be deleted. 8-26 bizhub PRO C6501...
Page 269 Basic Job Settings...
Page 271: Original Setting
Right & Left binding. 0 The machine is set to match the binding direction of the original with the binding direction of copies in Output Application setting automatically. For details, see p. 5-20, 5-48, or 6-134 of POD Administrator’s reference. bizhub PRO C6501...
Page 272 Touch [Top] in the Bind Direction area to highlight it. Touch [OK] to complete the setting and return to the Copy Screen. – Touch [Default Set] to restore the initial setting, or touch [Cancel] to resume the previous setting. bizhub PRO C6501...
Page 273: Specifying Orientation Of The Original: Direction
Select for the original positioned in the ADF with the top toward the right side of the machine. Or, select for the original positioned on the original glass with the top toward the left side of the machine. bizhub PRO C6501...
Page 274 Touch the desired original direction key to highlight it. Touch [OK] to complete the setting and return to the Copy Screen. – Touch [Default Set] to restore the initial setting, or touch [Cancel] to resume the previous setting. bizhub PRO C6501...
Page 275: Specifying Original Type: Image/Type
Select for copying the original including both text and photo image. This mode is specified as factory default. Original Text/Photo Select to reproduce a half-tone photo image. The copy will closely rep- resent the half-tones of the original image. Original Photo bizhub PRO C6501...
Page 276 Select for copying colored original with small text, such as a map. Type Use this function to improve the image quality by specifying the printed orig- inal type. Description Select for normal original. Select for photo-printed original. Select for copied original. Select for original printed using ink-jet printer. bizhub PRO C6501...
Page 277 Select the desired mode for each of Image and Type. Touch [OK] to complete the setting and return to the Copy Screen. – Touch [Default Set] to restore the initial setting, or touch [Cancel] to resume the previous setting. bizhub PRO C6501...
Page 278: Copying Mixed Size Originals: Mixed
For details, see "Separate Scan Mode" on page 9-21. 0 With Mixed specified, Auto Paper Select will function automatically. To copy onto a single and desired paper size, manually specify Auto Zoom. For details, see page 9-30. 9-10 bizhub PRO C6501...
Page 279 The Original Setting Screen will be displayed. Touch [Mixed] to highlight it. Touch [OK] to complete the setting and return to the Copy Screen. – Touch [Default Set] to restore the initial setting, or touch [Cancel] to resume the previous setting. bizhub PRO C6501 9-11...
Page 280: Copying Z-Folded Original: Z-Folded
The Original Setting Screen will be displayed. Touch [Z-Folded] to highlight it. Touch [OK] to return to the Copy Screen. – Touch [Default Set] to restore the initial setting, or touch [Cancel] to resume the previous setting. 9-12 bizhub PRO C6501...
Page 281: Specifying Original Thickness: Thickness
For the original of normal thickness (13 to 28 lb Bond), select [Nor- mal]. Touch [OK] to return to the Copy Screen. – Touch [Default Set] to restore the initial setting, or touch [Cancel] to resume the previous setting. bizhub PRO C6501 9-13...
Page 282: Copying Non-Standard Size Original: Custom
Position the original. Touch [Original Setting] on the Copy Screen. The Original Setting Screen will be displayed. Touch [Custom]. The Custom Size Screen will be displayed. 9-14 bizhub PRO C6501...
Page 283 Selecting from standard size keys: Touch the desired size key to highlight it. The machine scans the special size original as selected standard size. – Selecting [Full Area]: Select [Full Area] for small original that cannot be detected. bizhub PRO C6501 9-15...
Page 284 (3) Touch [Size Registration] to display the Size Registration Screen. (4) Touch the desired number key to highlight it, using [Next] and [Previous] as needed. Select the key with a name displayed to over- write the size and name registered for that key. 9-16 bizhub PRO C6501...
Page 285 (6) Enter the desired name, then touch [OK] to return to the previous screen. (7) Touch [Close] to restore the Size Setting Screen. (8) Touch [OK] to return to the Custom Size Screen with specified size displayed. bizhub PRO C6501 9-17...
Page 286 Touch [OK]. The Original Setting Screen will be restored. Touch [OK] to return to the Copy Screen. – Touch [Default Set] to restore the initial setting, or touch [Cancel] to resume the previous setting. 9-18 bizhub PRO C6501...
Page 287: Copying Tabbed Originals: Tab Paper
0 The magnification ratio will be fixed to 1.000 (100%). Position the original. Touch [Original Setting] on the Copy Screen. The Original Setting Screen will be displayed. Touch [Tab Paper]. The Tab Paper Screen will be displayed. bizhub PRO C6501 9-19...
Page 288 Touch the desired size key to highlight it, then touch [OK]. The Original Setting Screen will be restored. Touch [OK] to return to the Copy Screen. – Touch [Default Set] to restore the initial setting, or touch [Cancel] to resume the previous setting. 9-20 bizhub PRO C6501...
Page 289: Separate Scan Mode
Using the original glass, place the first page FACE DOWN on the original glass. – Using the ADF, load the original arranged in page order with page one on the top. Make copying selections on the Copy Screen, as desired. bizhub PRO C6501 9-21...
Page 290 – Repeat steps 4 and 5 for all origi- nal pages to be scanned. When scanning is completed, touch [Separate Scan] to exit the Sepa- rate Scan mode. 9-22 bizhub PRO C6501...
Page 291 [Start]. All the data in memory will be output. Detail To delete the scanned data without printing or to suspend the printing job, press [Stop]. See "To Stop Scanning/Printing" on page 8-22 for de- tails. bizhub PRO C6501 9-23...
Page 292: Selecting Color Mode
Hue/Saturation/Brightness, Color Balance, Dot in Screen, Color Text in Image Distinction Level, Type in Original Setting Position the original. Touch the desired color mode key on the Copy Screen to highlight it. – [Full Color] is already highlighted if initial settings are restored. 9-24 bizhub PRO C6501...
Page 293 – Touching Single Color will display the Single Color Screen. Select the desired color key, then touch [OK]. Select additional copy conditions, as desired. Enter the desired print quantity, then press [Start] on the control panel. bizhub PRO C6501 9-25...
Page 294: Zoom
Specifying paper size will release 1.000 magnification and set Auto Zoom automatically. In this case, touch [×1.0] to highlight it again. Detail The initial settings may be altered by the machine manager. Details can be referred in POD Administrator’s reference, page 5-40. 9-26 bizhub PRO C6501...
Page 295: Changing Magnification Ratio
Then, use the screen keypad to enter the desired magnification ra- tio. The entered ratio will be displayed on the screen. If wrong number is entered, continue by entering the correct number. Touching arrow keys [+] and [,] will change the ratio in 0.001 (0.1%) steps. bizhub PRO C6501 9-27...
Page 296 If wrong number is entered, continue by entering the correct number. Touching arrow keys [+] and [,] will change the ratio in 0.001 (0.1%) steps – Enlarge/Reduce: Touch the desired zoom key in the Enlarge/Reduce area. 9-28 bizhub PRO C6501...
Page 297 Basic Job Settings – Preset Zoom: Touch the desired preset zoom key in the Preset Zoom area. Touch [OK] to return to the Copy Screen. – Touch [Cancel] to resume the previous setting. bizhub PRO C6501 9-29...
Page 298: Setting Magnification Ratio Automatically: Auto Zoom
The machine detects the original size automatically. Touch a tray key on the Copy Screen to select the desired paper size. – Selected tray key will be highlighted, and the [Auto Zoom] key will also be highlighted. 9-30 bizhub PRO C6501...
Page 299: Simplex/Duplex Setting
0 The machine is set to match the original binding direction and copy bind- ing direction automatically. For details, see p. 5-20, 5-48, or 6-134 of POD Administrator’s reference. bizhub PRO C6501 9-31...
Page 300 (3) To make normal double-sided copies (having the same edge as page top) from double-sided originals printed upside down on the back pages, touch [Top] in the Bind Direction area to highlight it. (4) Touch [OK] to return to the Copy Screen. 9-32 bizhub PRO C6501...
Page 301 (2) Touch the desired binding direction key to highlight it. To make double-sided copies arranged upside down on the back pages, se- lect [Top]. (3) Touch [OK] to return to the Copy Screen. For details in specifying binding direction of double-sided copies, see page 12-7. bizhub PRO C6501 9-33...
Page 302: Making Double-Sided Copies Using Original Glass
The Separate Scan key will be automatically highlighted on the screen. – DO NOT press [Reset] at this point, otherwise the Separate Scan mode will be released to disable the machine from scanning the original placed on the original glass. 9-34 bizhub PRO C6501...
Page 303 (2) Touch the desired binding direction key to highlight it. To make double-sided copies arranged upside down on the back pages, se- lect [Top]. (3) Touch [OK] to return to the Copy Screen. For details on specifying binding direction of double-sided copies, see page 12-7. bizhub PRO C6501 9-35...
Page 304 Scan mode. Press [Start] to print. All the data in memory will be output. Detail To delete the scanned data without printing, or to suspend the printing job, press [Stop]. For details, see page 8-22. 9-36 bizhub PRO C6501...
Page 305: Making Single-Sided Copies From Double-Sided Originals
ADF. 0 The normal single-sided copies (having the same edge as page top) can be made from double-sided originals printed upside down on the back pages. Position the original in the ADF. bizhub PRO C6501 9-37...
Page 306 [Top] in the Bind Direction area to highlight it. (4) Touch [OK] to return to the Copy Screen. For details of original direction setting, see page 9-5. For details of original binding direction, see page 9-3. 9-38 bizhub PRO C6501...
Page 307: Paper Setting
Detail The User Setting allows you to delete the registered paper specifications. It also gives efficiency in registering more than one sort of specifications. For details, see page 2-8 of POD Administrator’s reference. bizhub PRO C6501 9-39...
Page 308: Selecting Paper Size Automatically: Auto Paper Select
0 Auto Paper Select will not select the tray of the size specified as Custom. Press [Reset] on the control panel. If the machine is equipped with the ADF, close it securely before pressing [Reset]. – [Auto Paper Select] is initially selected on the Copy Screen. 9-40 bizhub PRO C6501...
Page 309 In this case, load the paper of the size referred in the message. Reminder Auto Paper Select may not function for the tray of selected size due to the paper specifications registered for that tray. bizhub PRO C6501 9-41...
Page 310: Turning On/Off The Rotation
Follow the procedure below to release/resume this function. Prerequisites 0 Copy paper sizes: 8.5" × 11" v/w, 5.5" × 8.5" v/w 0 Original sizes: 11" × 17" w, 8.5" × 14" w, 8.5" × 11" v/w, 5.5" × 8.5" v/w 9-42 bizhub PRO C6501...
Page 311 When Rotation is released, the Rotation icon on the Copy Screen will disappear to indicate that this function is cancelled. Touch to deselect [Rotation Off] to resume this function. When Rotation is resumed, the Rotation icon will be displayed on the screen. bizhub PRO C6501 9-43...
Page 312: Using Paper Not Specified To Any Tray: Paper Setting
The changed setting will not be cleared when copying job is com- pleted using that tray. Touch [Paper Setting]. – The same setting is available from the [Paper Setting] keys on both Copy Screen and Machine Status Screen. The Paper Setting Screen will be displayed. 9-44 bizhub PRO C6501...
Page 313 (3) Touch [OK] to return to the Paper Setting Screen. (4) Touch [Size Setting] to specify the paper size. For setting proce- dure, see step 6. (5) Touch [OK] to return to the Paper Setting Screen. bizhub PRO C6501 9-45...
Page 314 In this case, the paper name cannot be changed. (2) Touch [Paper Type], then select the desired paper type. Touch [OK] to complete the setting. The trays 4 and 5 exclusively allow the selection of four types of coated paper. 9-46 bizhub PRO C6501...
Page 315 [+ <--> –] to specify the value to be positive or negative. Use the screen keypad or arrow keys [,] and [+] to enter the desired adjustment value. Touch [OK] to complete the setting, or touch [Reset] to clear the setting. bizhub PRO C6501 9-47...
Page 316 Touch [Punched] if the paper has punch holes, or touch [No Punched] if not, then touch [OK]. (7) Make a selection for Colored Paper. Touch [Non White] when using colored paper, or touch [White] for white paper. 9-48 bizhub PRO C6501...
Page 317 Basic Job Settings (8) Touch [OK] to return to the Paper Setting Screen with the new specifications displayed. bizhub PRO C6501 9-49...
Page 318 (3) Use [Next] or [Previous] to scroll the list to the key to be regis- tered with a new setting, then touch it to highlight it. Selecting a key having a name already displayed will overwrite and clear the existing data. The Name Input Screen will be displayed. 9-50 bizhub PRO C6501...
Page 319 (1) Touch [Size Setting], then touch [Standard] to highlight it. The tray can be set to detect some specific standard sizes, if de- sired. Touch [Search Size Set], select the desired size to highlight it, then touch [OK]. (2) Touch [OK] to complete the setting. bizhub PRO C6501 9-51...
Page 320 (4) Touch [Lead Edge], [Rear Edge], or [Center] to specify the de- sired image position. (5) Touch [OK] to complete the setting and return to the Paper Set- ting Screen. Touching [Fix] will complete the setting and directly return to the Copy Screen. 9-52 bizhub PRO C6501...
Page 321 (9) Touch [Close] to restore the Size Setting Screen. (10) Touch [OK] to complete the setting and return to the Paper Set- ting Screen. Touching [Fix] will complete the setting and directly return to the Copy Screen. bizhub PRO C6501 9-53...
Page 322 The smallest size of the custom size can be changed. Contact your service representative for details. Use the [Size] key provided on the Machine Status Screen to dis- play the actual dimensions specified for the tray loaded with cus- tom paper size. 9-54 bizhub PRO C6501...
Page 323 (2) Touch the desired tabbed paper size key to highlight it. (3) Touch [OK] to complete the setting. Touch [Close] on the Paper Setting Screen. The Copy Screen will be restored with the new paper specifications displayed on the specified tray key. bizhub PRO C6501 9-55...
Page 324 Setting range: 0.0 to 999.9 (5) Touch [Adjustment Start]. (6) Repeat steps (2) to (5) until the desired result is obtained. Touch [Close] to complete the front side setting. (7) Similarly, touch [Back] and repeat the chart adjustment, if desired. 9-56 bizhub PRO C6501...
Page 325: Improving Unevenness On Large-Sized Paper Or Feedability Of Small Sized Thick Paper In Duplex Printing
Turn the fixing conveyance unit lever leftward to withdraw the conveyance fixing unit. Holding the handle on the left side of the fixing unit, push it up to open the left side cover of the fixing unit. bizhub PRO C6501 9-57...
Page 326 7 CAUTION The internal fixing unit is very hot. To avoid getting burned, DO NOT TOUCH. 9-58 bizhub PRO C6501...
Page 327: Setting Reserve Job
If the machine is initially set to display the Copy Screen after scan- ning job is started, the above popup menu will provide only the [Close] key. Touching [Close] will also display the Copy Screen to make the reserve job setting. bizhub PRO C6501 9-59...
Page 328 – To check and operate the reserve jobs, touch [JOB LIST] tab to dis- play the Job List Screen. See page 14-3 for details. Detail If any trouble occurs on a reserve job, see page 5-10. 9-60 bizhub PRO C6501...
Page 329: Copy Conditions Incompatible With Basic Job Settings
E E E E E E E E E E Separate Scan (during scanning) E E E E Interrupt Copy (When Current comp.) Interrupt Copy (Stop Immediately) C C C IP Scanner Reserve Job Without ADF Coin Vendor (parallel) Coin Vendor (serial/card management) bizhub PRO C6501 9-61...
Page 330 E E E E E E E E E E E E E E E E E E (during scanning) Interrupt Copy (When Current comp.) Interrupt Copy (Stop Immediately) IP Scanner Reserve Job Without ADF Coin Vendor (parallel) Coin Vendor (serial/card management) 9-62 bizhub PRO C6501...
Page 331 C C C IP Scanner C C C *5 C C C C C C C C C C C C C C Reserve Job C C C Without ADF Coin Vendor (parallel) Coin Vendor (serial/card management) bizhub PRO C6501 9-63...
Page 332 (Stop Immediately) IP Scanner C C C C C C C C C C C C C C C C C C C C C C Reserve Job Without ADF Coin Vendor (parallel) Coin Vendor (serial/card management) 9-64 bizhub PRO C6501...
Page 333 (Stop Immediately) IP Scanner C C C C C C C C C C C C C C C C C C C C C Reserve Job Without ADF Coin Vendor (parallel) Coin Vendor (serial/card management) bizhub PRO C6501 9-65...
Page 334 “Select paper size” will be displayed when [Start] is pressed.) *20 Unavailable to select APS. *24 Unreleasable unless condition in the far left column is selected. *30 Full Color mode is selected automatically when turning on Print on Cov- 9-66 bizhub PRO C6501...
Page 335 Color Adjustment...
Page 337: About Colors
Various colors can be creat- ed by mixing cyan (C), magenta (M), and yellow (Y) pigments (such as ink or toner), however, black (K) is actually used as the fourth color in addition to the three primary pigments. bizhub PRO C6501 10-3...
Page 338 (B). The above three elements are called the three attributes of color. With these three attributes, the Munsell color system has been created to de- scribe colors in a three-dimensional space. Brightness Saturation 10-4 bizhub PRO C6501...
Page 339: Color Copy Quality
To enhance the copy quality, this machine allows you to modify colors by means of the three attributes of color based upon the human eye and per- ception. The following methods are provided: Adjust the density of the whole image. Original Density bizhub PRO C6501 10-5...
Page 340 Adjust the hue, saturation, and brightness. Original Saturation Brightness The hue adjustment leads the color of the image to another color adjacent in the color circle of red (R), yellow (Y), green (G), cyan (C), blue (B), and magen- ta (M). 10-6 bizhub PRO C6501...
Page 341 Color Adjustment Change the hue by varying the image’s red (R), green (G), and blue (B) indi- vidually or mutually. Original Green Blue bizhub PRO C6501 10-7...
Page 342 Color Adjustment Change the hue by varying the image’s cyan (C), magenta (M), yellow (Y), and black (K) individually or mutually. Original Cyan Magenta Yellow Black 10-8 bizhub PRO C6501...
Page 343 Dot screen Black Images Color Images Dots Dots Line screen Color Images Black Images Line Line bizhub PRO C6501 10-9...
Page 344 This function also allows you to ob- tain the optimum print results by modifying the standard for image distinction level according to the character size of the text or its proportion in the whole original. Solid Solid Detected as text 10-10 bizhub PRO C6501...
Page 345 In addition to the color adjustment and image reproduction methods, this machine allows you to apply the following filters to improve the copy image quality. Sharpen the outline of the image. (Sharpness) Original Sharpness Increase the contrast of the image. (Contrast) Original Contrast bizhub PRO C6501 10-11...
Page 346 Dot Screen. The Image Distinction Level function will help in selecting the most appropriate method for each part of the original to make the copies of scanned image. For further improvement, use Copy Density or apply filters for Sharpness, Contrast, and Glossy. 10-12 bizhub PRO C6501...
Page 347 [Quality Adjust.] key, so that the setting screen of that function can be directly accessed by a single touch from the Copy Screen. See page 5-35 of POD Administrator’s reference, if desired. bizhub PRO C6501 10-13...
Page 348: Adjusting Density Level
To adjust Copy Density Follow the procedure below to select the exposure (density) manually to make darker or lighter copies. Position the original. Touch [Quality Adjust.] on the Copy Screen. The Quality Adjustment Screen will be displayed. 10-14 bizhub PRO C6501...
Page 349 Do you want to resume the previous setting? % Touch [Cancel]. Do you want to restore the initial setting? % Touch [Default Set]. Do you want to check the adjustment result? % Touch [Adj. Proof Copy] to print a sample copy. bizhub PRO C6501 10-15...
Page 350 To adjust Background Adjust the background whiteness when copying newspaper or recycled pa- per original. Background Original Position the original. Touch [Quality Adjust.] on the Copy Screen. The Quality Adjustment Screen will be displayed. 10-16 bizhub PRO C6501...
Page 351 Adjust the density level of the background. – Touch the desired level key from [–1] to [–4] to make the back- ground lighter, or from [+1] to [+4] to make it darker. – Touch [Standard] to select the middle density level. bizhub PRO C6501 10-17...
Page 352 To adjust B-Side Prevent Adjust the density level of the back side lighter when copying dark originals. Position the original. Touch [Quality Adjust.] on the Copy Screen. The Quality Adjustment Screen will be displayed. 10-18 bizhub PRO C6501...
Page 353 Do you want to resume the previous setting? % Touch [Cancel]. Do you want to restore the initial setting? % Touch [Default Set]. Do you want to check the adjustment result? % Touch [Adj. Proof Copy] to print a sample copy. bizhub PRO C6501 10-19...
Page 354 The Copy Screen will be restored with the [B-Side Prevent] key dis- played and highlighted under the [Quality Adjust.] key. Use this key to directly jump to the B-Side Prevent Screen, if any set- ting change is desired. 10-20 bizhub PRO C6501...
Page 355: Changing Colors Using Rgb Values
To change the hue of the printed image in Single Color mode, see "Changing Colors Using CMYK Value" on page 10-41. To modify RGB value Position the original. Touch [Quality Adjust.] on the Copy Screen. The Quality Adjustment Screen will be displayed. bizhub PRO C6501 10-21...
Page 356 Do you want to resume the previous setting? % Touch [Cancel]. Do you want to restore the initial setting? % Touch [Default Set]. Do you want to check the adjustment result? % Touch [Adj. Proof Copy] to print a sample copy. 10-22 bizhub PRO C6501...
Page 357 The Copy Screen will be restored with the modified color key displayed and highlighted under the [Quality Adjust.] key. Use this key to directly jump to that color adjustment screen, if any set- ting change is desired. bizhub PRO C6501 10-23...
Page 358: Changing Colors Using Hsb Values
Change the color of the copy image by making adjustments to Hue, Satura- tion, and Brightness. To adjust Hue Position the original. Touch [Quality Adjust.] on the Copy Screen. The Quality Adjustment Screen will be displayed. Touch [Hue] to display the Hue Screen. 10-24 bizhub PRO C6501...
Page 359 To adjust the hue by setting fine adjustment in each color of RGB, touch [RGB Adjustment] to display the Fine Adjustment Screen. – Make fine adjustment on each color, then touch [OK] to return to the Hue Screen. bizhub PRO C6501 10-25...
Page 360 Use this key to directly jump to the Hue Screen, if any setting change is desired. To adjust Saturation Position the original. Touch [Quality Adjust.] on the Copy Screen. The Quality Adjustment Screen will be displayed. 10-26 bizhub PRO C6501...
Page 361 Make the desired adjustment. – Touch the desired level key from [–1] to [–4] to make the colors calm, or from [+1] to [+4] to make them vivid. – Touch [Standard] to select the middle level. bizhub PRO C6501 10-27...
Page 362 Touch [Close] on the Quality Adjustment Screen. The Copy Screen will be restored with the [Saturation] key displayed and highlighted under the [Quality Adjust.] key. Use this key to jump to the Saturation Screen, if any setting change is desired. 10-28 bizhub PRO C6501...
Page 363 Color Adjustment To adjust Brightness Position the original. Touch [Quality Adjust.] on the Copy Screen. The Quality Adjustment Screen will be displayed. Touch [Brightness] to display the Brightness Screen. bizhub PRO C6501 10-29...
Page 364 Touch [Close] on the Quality Adjustment Screen. The Copy Screen will be restored with the [Brightness] key displayed and highlighted under the [Quality Adjust.] key. Use this key to jump to the Brightness Screen, if any setting change is desired. 10-30 bizhub PRO C6501...
Page 365: Adjusting Sharpness
Use this function to sharpen the outline of copy image. To adjust Sharpness Position the original. Touch [Quality Adjust.] on the Copy Screen. The Quality Adjustment Screen will be displayed. Touch [Sharpness] to display the Sharpness Screen. bizhub PRO C6501 10-31...
Page 366 Touch [Close] on the Quality Adjustment Screen. The Copy Screen will be restored with the [Sharpness] key displayed and highlighted under the [Quality Adjust.] key. Use this key to jump to the Sharpness Screen, if any setting change is desired. 10-32 bizhub PRO C6501...
Page 367: Adjusting Contrast
Use this function to increase the contrast of copy image. To adjust Contrast Position the original. Touch [Quality Adjust.] on the Copy Screen. The Quality Adjustment Screen will be displayed. Touch [Contrast] to display the Contrast Screen. bizhub PRO C6501 10-33...
Page 368 Touch [Close] on the Quality Adjustment Screen. The Copy Screen will be restored with the [Contrast] key displayed and highlighted under the [Quality Adjust.] key. Use this key to jump to the Contrast Screen, if any setting change is desired. 10-34 bizhub PRO C6501...
Page 369: Setting Image Distinction Level
For details on detecting images, see "What Is Image Distinction Level?" on page 10-10. To set Image Distinction Level Position the original. Touch [Quality Adjust.] on the Copy Screen. The Quality Adjustment Screen will be displayed. bizhub PRO C6501 10-35...
Page 370 [+1] to [+4] to increase the proportion of colored text. – Touch [Standard] to select the middle level. Touch [OK]. The Quality Adjustment Screen will be restored. Do you want to resume the previous setting? % Touch [Cancel]. 10-36 bizhub PRO C6501...
Page 371 The Copy Screen will be restored with the [Distinction] key displayed and highlighted under the [Quality Adjust.] key. Use this key to jump to the Image Distinction Level Screen, if any set- ting change is desired. bizhub PRO C6501 10-37...
Page 372: Selecting Screen Type Or Compression
In this case, select Compression to give priority to compressing the scanned data. The Dither method is used instead of Line Screen or Dot Screen. Auto Auto selects an appropriate reproducing method automatically according to the selected copy conditions. This mode is initially selected. 10-38 bizhub PRO C6501...
Page 373 Color Adjustment To select reproducing method Position the original. Touch [Quality Adjust.] on the Copy Screen. The Quality Adjustment Screen will be displayed. Touch [Screen] to display the Screen Setting Screen. bizhub PRO C6501 10-39...
Page 374 Touch [Close] on the Quality Adjustment Screen. The Copy Screen will be restored with the [Screen] key displayed and highlighted under the [Quality Adjust.] key. Use this key to jump to the Screen Setting Screen, if any setting change is desired. 10-40 bizhub PRO C6501...
Page 375: Changing Colors Using Cmyk Value
The adjustment value ranges from –10 to +10. To adjust Color Balance Position the original. Touch [Quality Adjust.] on the Copy Screen. The Quality Adjustment Screen will be displayed. Touch [Color Balance] to display the Color Balance Screen. bizhub PRO C6501 10-41...
Page 376 The Copy Screen will be restored with the [Color Balance] key dis- played and highlighted under the [Quality Adjust.] key. Use this key to jump to the Color Balance Screen, if any setting change is desired. 10-42 bizhub PRO C6501...
Page 377: Selecting Glossy
Touch [Close] on the Quality Adjustment Screen. The Copy Screen will be restored with the [Glossy] key displayed and highlighted under the [Quality Adjust.] key. Do you want to restore the initial setting? % Touch [Default Set]. bizhub PRO C6501 10-43...
Page 378 Color Adjustment Detail Setting Glossy will lower the copy speed. For details, see page 2-6 of POD Administrator’s reference. 10-44 bizhub PRO C6501...
Page 379: Copy Conditions Incompatible With Color Adjustment
C C C Saturation C C C Brightness C C C Screen C C C Sharpness C C C Contrast C C C Distinction C C C Color Balance C C C Glossy C C C bizhub PRO C6501 10-45...
Page 380: Color Adjustment
Brightness Screen Sharpness Contrast Distinction Color Balance Glossy Application Output Application Image Edit Copy Conditions Incompatible with Color Adjustment Copy Density Adjust Background B-Side Prevent RGB Adjustment Saturation Brightness Screen Sharpness Contrast Distinction Color Balance Glossy 10-46 bizhub PRO C6501...
Page 381 B: Condition in the top row is selected automatically. Releasable. C: Not specified D: Condition in the far left column does not function (ignored). E: Not grayed out but unavailable Image Distinction Level: Color Text only is grayed out or released auto- matically. bizhub PRO C6501 10-47...
Page 383 Application Functions...
Page 385: To Use Application Function
To display Application Screen Touch [COPY] tab on the Machine Status Screen to display the Copy Screen. Touch [Application] on the Copy Screen. – The Application Screen will be displayed on the touch panel. bizhub PRO C6501 11-3...
Page 386 Do you want to resume the initial setting? % Press [Reset] on the control panel. Touch [OK] on the Application Screen to return to the Copy Screen. Reminder Only with the Copy Screen displayed, you can press [Start] to start cop- ying. 11-4 bizhub PRO C6501...
Page 387 [Application] key, so that the setting screen of that function can be directly accessed by a sin- gle touch from the Copy Screen. See page 5-35 of POD Administrator’s reference, if desired. bizhub PRO C6501 11-5...
Page 388: Inserting Sheets And Covers: Insert Sheet
Back Cover + Blank A blank sheet for back cover will be inserted as the last sheet of copied set. The same result will be obtained when making double-sided cop- ies. 11-6 bizhub PRO C6501...
Page 389 6th sheet of copied set. The 5th page of double-sided original is simplex-copied onto the inser- tion, which will be the 5th sheet of copied set. bizhub PRO C6501 11-7...
Page 390 11th and 12th pages of double-sided original are duplex-copied. A blank insertion will be added as the 6th sheet of copied set, after the 5th page of double-sided original is simplex-copied. 11-8 bizhub PRO C6501...
Page 391 To use any other paper type/size than the specified paper, touch [Paper Setting] on the Copy Screen to change the setting tempo- rarily. page 9-39 for details. Touch [Application] on the Copy Screen. Touch [Insert Sheet] on the Application Screen. bizhub PRO C6501 11-9...
Page 392 Touch [None] if no cover is desired, [Print] to insert a copied front/back cover, or touch [Blank] to insert a blank front/back cover. – Touch [OK] to complete the setting and return to the Insert Sheet Screen, or touch [Cancel] to restore the previous setting. 11-10 bizhub PRO C6501...
Page 393 To enter the 16th to 30th page locations, touch [,] to scroll to the next page. – Touch [OK] to complete the setting and return to the Insert Sheet Screen, or touch [Cancel] to restore the previous setting. bizhub PRO C6501 11-11...
Page 394 Using the Front/Back Cover mode in combination, the post inserter covers will be added as the first and last covers. – Touch [OK] to complete the setting and return to the Insert Sheet Screen, or touch [Cancel] to restore the previous setting. 11-12 bizhub PRO C6501...
Page 395 The Copy Screen will be restored, with highlighted [Insert Sheet] key displayed under the [Application] key. Use this key to jump to the subsequent screen to make any setting change. Enter the desired print quantity from the control panel keypad, then press [Start]. bizhub PRO C6501 11-13...
Page 396: Locating Title Pages On The Right Side: Chapters
1%2 mode with None selected for Chapter paper. 2%2 + Print Insertion The same page insertion is performed as above, and the chapter pages (2/3 and 5/6) will be printed on paper from another tray source. 11-14 bizhub PRO C6501...
Page 397 0 Use Stamp together with this function to print chapter number onto chapter page in addition to page number, numbering, or watermark num- bering. Position the original. Touch [Application] on the Copy Screen. Touch [Chapters] on the Application Screen. bizhub PRO C6501 11-15...
Page 398 % The second entry will be ignored on the screen. Touch [OK] to complete the setting. – To restore the previous setting, touch [Cancel]. – To release the Chapters function with the current setting remained, touch [Function Off]. 11-16 bizhub PRO C6501...
Page 399 Enter the desired print quantity from the control panel keypad, then press [Start]. Note Touch [Booklet Pagination] on the Chapters Screen to use this function. In this case, touching [OK] on the Booklet Pagination Screen will return to the Chapters Screen. bizhub PRO C6501 11-17...
Page 400: Lay Out Several Pages Onto One Sheet: Combine Originals
4 in 1 Select this setting to print four original images onto one sheet. The page arrangement (Numbering Direction) can be specified. Horizontal order, left binding Horizontal order, right binding Vertical order, left binding Vertical order, right binding 11-18 bizhub PRO C6501...
Page 401 0 If the original is placed on the original glass, Separate Scan mode will function automatically. 0 Auto Zoom is automatically selected. Normally the fixed size of Tray 1 will be selected. (Available to be changed manually.) Position the original. Touch [Application] on the Copy Screen. bizhub PRO C6501 11-19...
Page 402 Touch [OK] to complete the setting. – To restore the previous setting, touch [Cancel]. – To release the Combine Originals function with the current setting remained, touch [Function Off]. 11-20 bizhub PRO C6501...
Page 403 Auto Zoom is automatically selected. When selecting any tray other than the one that is set and displayed on the Copy Screen, touch the desired tray key. Enter the desired print quantity from the control panel keypad, then press [Start]. bizhub PRO C6501 11-21...
Page 404: Making A Multiple Page Signature Booklet Booklet Pagination
0 Auto Zoom is automatically selected. Select the desired paper size. Position the original. Load the desired copy paper size in a tray. Available paper sizes are 11" × 17" w, 8.5" × 14" w, 8.5" × 11" w, – and 5.5" × 8.5" w. 11-22 bizhub PRO C6501...
Page 405 Touch [Left Bind] or [Right Bind] if you want to change the output order. Touch [OK] to complete the setting. – To restore the previous setting, touch [Cancel]. – To release the Booklet Pagination function with the current setting remained, touch [Function Off]. bizhub PRO C6501 11-23...
Page 406 Use this key to jump to the subsequent screen to make any setting change. Auto Zoom is selected automatically. To release Auto Zoom, select the desired magnification, then select paper size. Enter the desired print quantity from the control panel keypad, then press [Start]. 11-24 bizhub PRO C6501...
Page 407: Inserting Different Original Images Into Printed Sets Insert Image
1%2 mode. The first scanned image will be inserted after page 2 of the finished set, and the second scanned image will be inserted after page 5. bizhub PRO C6501 11-25...
Page 408 To clear an incorrect entry, touch [Delete]. Repeat this procedure to make all the page entry. – Up to 30 image insertion locations can be specified. To enter the 16th to 30th locations, touch [,] to scroll to the next page. 11-26 bizhub PRO C6501...
Page 409 [Application] key. Use this key to jump to the subsequent screen to make any setting change. The [Separate Scan] key on the Copy Screen also appears highlighted to show that the Separate Scan mode is automatically selected. bizhub PRO C6501 11-27...
Page 410 9 and 10 for all the originals in page order. Touch [Separate Scan] to exit the Separate Scan mode. Enter the desired print quantity from the control panel keypad, then press [Start]. The machine will start printing when ready for output. 11-28 bizhub PRO C6501...
Page 411: Dividing Spread Image Into Right And Left Pages: Book Copy
Front Cover + Spread Printed sets will be output from the front cover page, then divided doc- ument pages according to pagination. The original should be scanned from the front cover, then page spread originals in page order. bizhub PRO C6501 11-29...
Page 412 The original should be scanned from the front cover, back cover, then page spread originals in page order. e.g. Using Booklet Pagination in combination to make a booklet: Mode key Description Spread + Booklet Pagination ......Front/Back Cover + Spread + Booklet Pagination ......11-30 bizhub PRO C6501...
Page 413 100 sheets, and load them from the block with the first page. – When selecting the Front Cover or Front/Back Cover + Spread mode, follow the procedure on pages 11-29 and 30 to scan the front cover first. bizhub PRO C6501 11-31...
Page 414 Touch [Booklet Pagination] on the Book Copy Screen to display the Booklet Pagination Screen, then select the desired mode. For de- tails, see page 11-22. – Touch [OK] to complete the setting and return to the Book Copy Screen. 11-32 bizhub PRO C6501...
Page 415 When all originals are scanned, touch [Separate Scan] to exit the Sep- arate Scan mode. Enter the desired print quantity from the control panel keypad, then press [Start]. The machine will start printing when ready for output. bizhub PRO C6501 11-33...
Page 416: Programming Different Settings For An Output Job Program Job
0 The paper size specified for the first job will be applied to all subsequent JOBs. 0 Max. 100 JOBs can be programmed for an output job. 0 Program Job settings cannot be stored in Program Memory. Position the original. Touch [Application] on the Copy Screen. 11-34 bizhub PRO C6501...
Page 417 Press [Start] to start scanning. When scanning for the current JOB is completed, the popup menu will be displayed to ask you whether or not to store the scanned image data as a JOB for printing in specified copy conditions. bizhub PRO C6501 11-35...
Page 418 Touch [Decision] to store the current JOB images. – To delete the scanned images, touch [Cancel]. Repeat above steps until all JOB originals are scanned. When all originals are scanned, touch [Separate Scan] to exit the Sep- arate Scan mode. 11-36 bizhub PRO C6501...
Page 419 The setting made at this time will be applied to all subsequent JOBs. Enter the desired print quantity from the control panel keypad. – Entered quantity will be the count of complete set. Press [Start]. The machine will start printing in conditions specified for each JOB. bizhub PRO C6501 11-37...
Page 420: Dividing An Image For Enlarged Copy Multi-Page Enlargement
0 The output size can be selected (standard size) or determined when a magnification ratio is entered on the screen. Position the original on the original glass, then close the ADF or original cover. The machine will detect the original size placed on the original glass. 11-38 bizhub PRO C6501...
Page 421 Touch the desired tray key to highlight it. If Auto Paper Select is selected (initial setting), the largest paper size loaded in a tray will be selected automatically. Touch [Application] on the Copy Screen. Touch [Multi-Page Enlargement] on the Application Screen. bizhub PRO C6501 11-39...
Page 422 Use this key to jump to the subsequent screen to make any setting change. Enter the desired print quantity from the control panel keypad, then press [Start]. The machine will start printing when ready for output. 11-40 bizhub PRO C6501...
Page 423: Erasing Outside Area Of Original: Non-Image Area Erase
0 Original size should be larger than 1.18 × 1.18 in. Position the original on original glass with the ADF or original cover kept open. – Do not close the ADF/original cover. Touch [Application] on the Copy Screen. bizhub PRO C6501 11-41...
Page 424 See page 6-28 of POD Administrator’s reference. Non-Image Area Erase may perform incorrectly if the lighting in the work place is directly over the original glass. In this case, consult your service representative about an appropriate place for installation. 11-42 bizhub PRO C6501...
Page 425: Reversing Color In Image: Neg./Positive Reverse
- Full Color: Copies in complementary colors of the four colors. - Auto Color: Makes a reversed image according to the original image (de- tected as Full Color or Black). Procedure Position the original. Touch [Application] on the Copy Screen. bizhub PRO C6501 11-43...
Page 426 This key can also be used to display the Application Screen for making setting change. Enter the desired print quantity from the control panel keypad, then press [Start]. The machine will start printing when ready for output. 11-44 bizhub PRO C6501...
Page 427: Repeating Original Image On One Sheet: Image Repeat
0 Use the Size Manual Input mode to repeat a part of the original, not the entire image, by specifying the scanning area. 0 Size Auto Detect mode uses Non-Image Area Erase to automatically de- tect the original size with the ADF/original cover kept open. bizhub PRO C6501 11-45...
Page 428 Touch [Image Repeat] on the Application Screen. Make setting for Size Manual Input or Size Auto Detect, as desired. – To select Size Manual Input: Touch [Manual] to highlight it, then use [+]/[,] to specify the de- sired horizontal/vertical width. 11-46 bizhub PRO C6501...
Page 429 To select Size Auto Detect: Touch [Auto] to highlight it. Touch [OK] to complete the setting. – To restore the previous setting, touch [Cancel]. – To release the Image Repeat function with the current setting re- mained, touch [Function Off]. bizhub PRO C6501 11-47...
Page 430 Size Input Screen. Touch this key to highlight it, if desired, so that the screen may be directly accessed from the Copy Screen or Check Screen to change the setting you made. See page 13-5 for details. 11-48 bizhub PRO C6501...
Page 431: Specifying Repeat Times: Repeat
Position the original. – Both ADF and original glass are available. The scanning area varies according to the selected paper size, original direction, and select- ed repeat mode. Touch [Application] on the Copy Screen. bizhub PRO C6501 11-49...
Page 432 Touch [2 Repeat], [4 Repeat], or [8 Repeat] to highlight it. Touch [OK] to complete the setting. – To restore the previous setting, touch [Cancel]. – To release the Image Repeat function with the current setting re- mained, touch [Function Off]. 11-50 bizhub PRO C6501...
Page 433 Available copy modes are 1->1 and 1->2. Selecting [1->2] will select [Separate Scan] automatically. Enter the desired print quantity from the control panel keypad, then press [Start]. The machine will start printing when ready for output. bizhub PRO C6501 11-51...
Page 434: Eliminating Copy Marks Along Borders: Frame Center Erase
Both ADF and original glass are available. When lowering the ADF/original cover onto thick original (e.g. open book), do not press it down too hard. Keep the ADF/original cover open, if required. Touch [Application] on the Copy Screen. 11-52 bizhub PRO C6501...
Page 435 Application Functions Touch [Frame Center Erase] on the Application Screen. Touch [Erase/All Sides], [Erase/Each Side], or [Center Erase] to high- light it. – Use Frame erase and Center erase in combination, if desired. bizhub PRO C6501 11-53...
Page 436 Touch the desired side key on the right side of the screen to high- light the erase amount in the illustration, then use [,] and [+], or touch panel keypad to enter the desired erase amount. 11-54 bizhub PRO C6501...
Page 437 Use this key to jump to the subsequent screen to make any setting change. Enter the desired print quantity from the control panel keypad, then press [Start]. The machine will start printing when ready for output. bizhub PRO C6501 11-55...
Page 438: Copying Image In The Center Of Copy Paper: Image Centering
– If Book Copy is used in combination, the original smaller than the selected paper size will be printed in the center of the copy paper without image division performed. 11-56 bizhub PRO C6501...
Page 439 The machine will start printing when ready for output. Reminder Image Centering may perform incorrectly if the lighting in the work place is directly over the original glass. In this case, consult your service repre- sentative about an appropriate place for installation. bizhub PRO C6501 11-57...
Page 440: Adjusting Position Of Copy Image: Page Margin - Shift
Down Right Left Original Down Left Copies Prerequisites 0 Available shift direction: Top, Bottom, Right, Left 0 Shift amount: 0 to 250 mm in 1 mm increments Position the original. Touch [Application] on the Copy Screen. 11-58 bizhub PRO C6501...
Page 441 Application Functions Touch [Page Margin] on the Application Screen. Touch [Shift]. bizhub PRO C6501 11-59...
Page 442 For entering the page space amount, shift direction is not needed to be specified. – Setting the shift amount in 0.1 mm increments is also available by User/Administrator setting. For details, see page 5-47 or 6-134 of POD Administrator’s reference. 11-60 bizhub PRO C6501...
Page 443 Image Repeat has been already selected. Use this function to make the desired amount of blank space between the two images on a page. Page space Booklet Original Page space 2 Repeat In Repeat Page space Original bizhub PRO C6501 11-61...
Page 444 Position of Copy Image: Page Margin - Shift" on page 11-58. Left binding margin Left Right Down Front Back Front Right binding margin Right Left Down Originals Front Back Back Top binding margin Left Right Right Left Down Back Front 11-62 bizhub PRO C6501...
Page 445 0 Shift amount: 0 to 250 mm in 1 mm increments Position the original. Touch [Application] on the Copy Screen. Touch [Page Margin] on the Application Screen. Touch [Reduce & Shift]. bizhub PRO C6501 11-63...
Page 446 Use this key to jump to the subsequent screen to make any setting change. Enter the desired print quantity from the control panel keypad, then press [Start]. The machine will start printing when ready for output. 11-64 bizhub PRO C6501...
Page 447: Printing Additional Information: Stamp/Image Overlay
The following seven modes are provided for the Stamp function. See page 11-99 for details on using these modes in combination. Mode Description Built-in Stamp Set Numbering Page No. bizhub PRO C6501 11-65...
Page 448 - Start number setting for Set Numbering mode - Start number setting for Page No. mode - Character size/type setting for Page No. and Date/Time modes - Cover/Insert print setting for Page No. - Color setting 11-66 bizhub PRO C6501...
Page 449 Application Functions Mode Description Copy Protect Arabesque Cherry Lattice blossoms bizhub PRO C6501 11-67...
Page 450: Printing Stamp Onto Copies: Built-In Stamp
0 To use this function, the optional HDD (HD-506) is required to be installed in the machine. Position the original. Touch [Application] on the Copy Screen. Touch [Stamp/Image Overlay] on the Application Screen. Touch [Built-in Stamp]. 11-68 bizhub PRO C6501...
Page 451 Use this key to jump to the subsequent screen to make any setting change. Enter the desired print quantity from the control panel keypad, then press [Start]. The machine will start printing when ready for output. bizhub PRO C6501 11-69...
Page 452: Printing Distribution Number: Set Numbering
Application Functions 11.17.2Printing Distribution Number: Set Numbering Print a distribution number onto the specified position of copies. Procedure Position the original. Touch [Application] on the Copy Screen. Touch [Stamp/Image Overlay] on the Application Screen. Touch [Set Numbering]. 11-70 bizhub PRO C6501...
Page 453 Use this key to jump to the subsequent screen to make any setting change. Enter the desired print quantity from the control panel keypad, then press [Start]. The machine will start printing when ready for output. bizhub PRO C6501 11-71...
Page 454: Printing Page Number: Page No
Application Functions 11.17.3Printing Page Number: Page No. Print a page number onto the specified position of copies. Procedure Position the original. Touch [Application] on the Copy Screen. Touch [Stamp/Image Overlay] on the Application Screen. Touch [Page No.]. 11-72 bizhub PRO C6501...
Page 455 Use this key to jump to the subsequent screen to make any setting change. Enter the desired print quantity from the control panel keypad, then press [Start]. The machine will start printing when ready for output. bizhub PRO C6501 11-73...
Page 456: Printing Date/Time: Date/Time
Application Functions 11.17.4Printing Date/Time: Date/Time Print date and time onto the specified position of copies. Procedure Position the original. Touch [Application] on the Copy Screen. Touch [Stamp/Image Overlay] on the Application Screen. Touch [Date/Time]. 11-74 bizhub PRO C6501...
Page 457 Use this key to jump to the subsequent screen to make any setting change. Enter the desired print quantity from the control panel keypad, then press [Start]. The machine will start printing when ready for output. bizhub PRO C6501 11-75...
Page 458: Printing Watermark Onto Copies: Watermark
Prerequisites 0 To use this function, the optional HDD (HD-506) is required to be installed in the machine. Position the original. Touch [Application] on the Copy Screen. Touch [Stamp/Image Overlay] on the Application Screen. Touch [Watermark]. 11-76 bizhub PRO C6501...
Page 459 Use this key to jump to the subsequent screen to make any setting change. Enter the desired print quantity from the control panel keypad, then press [Start]. The machine will start printing when ready for output. bizhub PRO C6501 11-77...
Page 460: Printing Distribution Number As Watermark: Set Numbering
Print a distribution number in the specified form repeatedly over the scanned image. Procedure Position the original. Touch [Application] on the Copy Screen. Touch [Stamp/Image Overlay] on the Application Screen. Touch [Set Numbering] in the Watermark area. 11-78 bizhub PRO C6501...
Page 461 Use this key to jump to the subsequent screen to make any setting change. Enter the desired print quantity from the control panel keypad, then press [Start]. The machine will start printing when ready for output. bizhub PRO C6501 11-79...
Page 462: Printing Watermark And Background Pattern: Copy Protect
0 The character size of watermark is 44 points. 0 Printed position of watermark is the same as of Set Numbering of Water- mark. Position the original. Touch [Application] on the Copy Screen. Touch [Stamp/Image Overlay] on the Application Screen. 11-80 bizhub PRO C6501...
Page 463 [Function Off]. Touch [OK] on the Application Screen. The Copy Screen will be restored, with highlighted [Stamp/Overlay] key displayed under the [Application] key. Use this key to jump to the subsequent screen to make any setting change. bizhub PRO C6501 11-81...
Page 464 Application Functions Enter the desired print quantity from the control panel keypad, then press [Start]. The machine will start printing when ready for output. 11-82 bizhub PRO C6501...
Page 465: Detailed Setting In Stamp/Watermark
Touch [OK] to complete the setting and return to the previous screen. Setting start number in Set Numbering Touching [Start Number] on the Set Numbering Screen will display the fol- lowing screen to allow you to specify the start number. bizhub PRO C6501 11-83...
Page 466 [+], or touch panel keypad to enter the desired start number. Up to two digits can be specified. Touch [Start Chapter] under Chapter to highlight it, then enter the de- sired start chapter. Touch [OK] to complete the setting and return to the previous screen. 11-84 bizhub PRO C6501...
Page 467 Touch [OK] to complete the setting and return to the previous screen. Setting print page in Page No. This function allows you to print the page number on the front cover and in- sertions, if Print/Blank Insert Paper mode of Insert Sheet has already been selected. bizhub PRO C6501 11-85...
Page 468 Use this function to select the desired color in Built-in Stamp, Set Number- ing, Page No., and Date/Time. Procedure Touch one of the seven color keys to highlight it. Touch [OK] to complete the setting and return to the previous screen. 11-86 bizhub PRO C6501...
Page 469: Overlaying Image Onto Printed Pages: Image Overlay
Position the overlaying original. – Position a sheet of original faceup in the ADF or facedown on the original glass. Touch [Application] on the Copy Screen. Touch [Stamp/Image Overlay] on the Application Screen. Touch [Image Overlay] to highlight it. bizhub PRO C6501 11-87...
Page 470 Repeat steps 9 and 10 for all originals. Touch [Separate Scan] to exit the Separate Scan mode. Enter the desired print quantity from the control panel keypad, then press [Start]. The machine will start printing when ready for output. 11-88 bizhub PRO C6501...
Page 471: Storing Overlay Image In Hdd/ Overlaying Image Stored In Hdd Program Overlay
Image Store Store in HDD Overlaying Image Recall overlaying Image Output Output Recalled Image Overlay originals Copies in Overlay Memory mode Procedure Position the overlaying original facedown on the original glass. Touch [Application] on the Copy Screen. bizhub PRO C6501 11-89...
Page 472 Application Functions Touch [Stamp/Image Overlay] on the Application Screen. Touch [Program Overlay]. The Image Store/Recall Screen will be displayed. Proceed to step 9 for recalling the image already stored in HDD. 11-90 bizhub PRO C6501...
Page 473 The Copy Screen to store the overlaying image will be displayed. Select copy conditions, as desired. If a popup menu is displayed to prompt you that the entered image name has been already used, see page 11-93. bizhub PRO C6501 11-91...
Page 474 Position the original to be overlaid. – Position the original either in the ADF or on the original glass. Press [Start] to scan. – Repeat steps 12 and 13 for all originals. Touch [Separate Scan] to exit the Separate Scan mode. 11-92 bizhub PRO C6501...
Page 475 [OK]. If the popup menu shows [OK] only, the existing image data cannot be over- written. Touch [OK] to enter a new name. Either of the above two can be specified in the Administrator setting. bizhub PRO C6501 11-93...
Page 476: Copy Conditions Incompatible With Application Functions
Page Margin (Shift) Page Margin (Reduce & Shift) Image Repeat Image Repeat (Auto) Image Repeat (2/4/8 Repeat) Frame Erasure Center Erase Stamp Watermark Copy Protect Image Overlay Program Overlay o o o Storing an Overlay Image 11-94 bizhub PRO C6501...
Page 477 Neg-/ Positive Reverse Page Margin (Shift) Page Margin (Reduce & Shift) Image Repeat Image Repeat (Auto) Image Repeat (2/4/8 Repeat) Frame Erasure Center Erase Stamp Watermark Copy Protect Image Overlay Program Overlay Storing an Overlay Image bizhub PRO C6501 11-95...
Page 478 C C C Watermark C C C Copy Protect C C C Image Overlay C C C Program Overlay C C C o o o o o o o o Storing an Overlay Image C C C 11-96 bizhub PRO C6501...
Page 479 Image Overlay *10 *10 o o o Program Overlay *10 *10 o o o o o o o o o o o o o o o o o o o Storing an Overlay Image bizhub PRO C6501 11-97...
Page 480 A: Condition in the top row is selected automatically. Unreleasable. B: Condition in the top row is selected automatically. Releasable. C: Not specified D: Condition in the far left column does not function (ignored). E: Not grayed out but unavailable 11-98 bizhub PRO C6501...
Page 481 *19 Only 2 in 1 and 2 Repeat modes are available. *21 Incompatible if cover sheets are fed from a main body tray. Compatible if fed from the post inserter tray. *22 Compatible if cover sheets are fed from the cover feeding tray of Perfect Binder. bizhub PRO C6501 11-99...
Page 483 Output Applications...
Page 485: Selecting An Output Tray
Touch [Output Appli.] on the Copy Screen. The Output Application Screen will be displayed. Output tray positions are indicated as square marks on the front image of the machine, and the tray mark currently selected appears highlighted. bizhub PRO C6501 12-3...
Page 486 On the popup menu, touch [Permit] if you allow paper from several jobs to pile up in the large capacity stacker, or touch [Prohibit] if you do not. 12-4 bizhub PRO C6501...
Page 487 This setting is initially specified as Prohibit. Touch [OK] on the Output Tray Selection Screen. The Output Application Screen will be restored, with the selected tray mark highlighted. Touch [OK] on the Output Application Screen. The Copy Screen will be restored. bizhub PRO C6501 12-5...
Page 488 Never return the Saddle stitcher tray to its original position with the tray stand opened. Be careful not to exceed the finisher tray / stacker capacity when selecting the print quantity, otherwise unexpected trouble may be caused. 12-6 bizhub PRO C6501...
Page 489: Setting Binding Direction For Duplex Copies
0 The top binding mode is effective only when duplex mode is selected. 0 Resetting the machine will restore the right & left binding mode. Position the original. Touch [Output Appli.] on the Copy Screen. The Output Application Screen will be displayed. bizhub PRO C6501 12-7...
Page 490 Output Applications Touch [Top] under Bind Direction to select it. Touch [OK]. 12-8 bizhub PRO C6501...
Page 491: Sorting/ Stapling Copies (Finisher Fs-521)
Output to the secondary (sub) tray Non-sort/Collate: Non-sort/Collate mode outputs multiple copies of the original set. No offset output is available. Uncollate : Uncollate mode groups together multiple copies of each original. No offset output is available. bizhub PRO C6501 12-9...
Page 492 Face up uncollated non-sorted/collated uncollated non-sorted/collated This section describes the following output methods: Non-sort/ Collate/ Uncollate output to the primary (main) tray Stapled output to the primary (main) tray Collate/ Uncollate output to the secondary (sub) tray 12-10 bizhub PRO C6501...
Page 493: Non-Sort/ Collate/ Uncollate Output To The Primary (Main) Tray
Output tray positions are indicated as square marks on the front image of the machine, and the tray mark currently selected appears highlighted. If the primary (main) tray is not selected, touch [Output Tray] to select it. See page 12-3 for details. bizhub PRO C6501 12-11...
Page 494 Detail The Suspension button allows you to temporarily stop printing in order to take out the printed sheets delivered to the primary (main) tray. See page 4-59 for details. 12-12 bizhub PRO C6501...
Page 495: Stapling Output To The Primary (Main) Tray
Output Application icon shows the stapling position currently selected. If you want to change the stapling position, proceed to the following steps. Touch [Output Appli.] on the Copy Screen. The Output Application Screen will be displayed. bizhub PRO C6501 12-13...
Page 496 To release the Staple function with the current stapling position setting remained, touch [Function Off]. The Output Application Screen will be restored. Touch [OK] on the Output Application Screen. The specified output mode icon will be displayed on the Copy Screen. 12-14 bizhub PRO C6501...
Page 497 Detail The Suspension button allows you to temporarily stop printing in order to take out the printed sheets delivered to the primary (main) tray. See page 4-59 for details. bizhub PRO C6501 12-15...
Page 498: Collate/ Uncollate Output To The Secondary (Sub) Tray
Position the original. Touch [Output Appli.] on the Copy Screen. The Output Application Screen will be displayed. Select the secondary (sub) tray as the output tray. – Touch [Output Tray] to display the Output Tray Selection Screen. 12-16 bizhub PRO C6501...
Page 499 Select output face (Face Down / Face Up), and output order (1 to N / N to 1) as needed. Touch [OK] on the Output Application Screen. The specified output mode icon will be displayed on the Copy Screen. bizhub PRO C6501 12-17...
Page 500 Be careful not to exceed the finisher tray capacity when selecting the print quantity, otherwise unexpected trouble may be caused. Note The Suspension button will not function when printed sheets are delivered to the secondary (sub) tray. 12-18 bizhub PRO C6501...
Page 501: Output Modes Using Folding Unit Fd-503
Primary (Main) tray: Half Fold, Z-Fold, Punch, Non-sort (straight delivery) Fold mode tray: Tri-Fold-in, Tri-Fold-out, Double Parallel, Gate Fold Note A secondary (sub) tray is also available in place of the fold mode tray. Contact your service representative, if desired. bizhub PRO C6501 12-19...
Page 502: Punching File Holes In Copies
If you want to change the number of punch holes and punch position, proceed to the following steps. Touch [Output Appli.] on the Copy Screen. The Output Application Screen will be displayed. 12-20 bizhub PRO C6501...
Page 503 To release the Punch function with the current number of punch holes and punch position setting remained, touch [Function Off]. The Output Application Screen will be restored. Touch [OK] on the Output Application Screen. The specified output mode icon will be displayed on the Copy Screen. bizhub PRO C6501 12-21...
Page 504 Output Applications Reminder Be careful not to exceed the finisher tray capacity when selecting the print quantity, otherwise unexpected trouble may be caused. 12-22 bizhub PRO C6501...
Page 505: Folding Copies
(main) tray of Finisher FS-521 before starting the job. Position the original. Touch [Output Appli.] on the Copy Screen. The Output Application Screen will be displayed. Touch [Fold]. The Folding Type Setting Screen will be displayed. bizhub PRO C6501 12-23...
Page 506 Touch [OK] on the Output Application Screen. The specified output mode icon will be displayed on the Copy Screen. Reminder Be careful not to exceed the finisher tray capacity when selecting the print quantity, otherwise unexpected trouble may be caused. 12-24 bizhub PRO C6501...
Page 507: Attaching Cover Sheet (Post Inserter On Fd-503)
See page 4-20 for details on loading covers, and see page 12-37 for details of perfect binding. Covers and insertions Copied set with Copied set with cover attached in covers and staple mode insertions attached bizhub PRO C6501 12-25...
Page 508 Do not load more than 500 sheets (20 lb Bond) for each of the upper and lower trays. Do not load above the limit line indicated on the guide plate. Be careful not to exceed the finisher tray capacity when selecting the print quantity, otherwise unexpected trouble may be caused. 12-26 bizhub PRO C6501...
Page 509 As shown below, push the both roller lock levers inside to lock them. Reminder Be sure to lock the rollers on both side, when locking the paper rollers. Do not lock the paper rollers in usual operation. bizhub PRO C6501 12-27...
Page 510: Output Modes Using Saddle Stitcher Sd-506
Fold & Staple and Trimming Fold & Staple Detail For detailed specifications, see page 3-3 and page 7-8. Procedure Position the original. Touch [Output Appli.] on the Copy Screen. The Output Application Screen will be displayed. Touch [Fold & Staple]. 12-28 bizhub PRO C6501...
Page 511 If the tray is not fully withdrawn, the machine will detect that the tray is filled up, even with less number of finished sets than that specified in specifications. Reminder Never return the saddle stitcher tray to its original position with the tray stand opened. bizhub PRO C6501 12-29...
Page 512 0 Using Multi Tri-Fold mode, the finished sets will be delivered to the multi- folding mode tray. Position the original. Touch [Output Appli.] on the Copy Screen. The Output Application Screen will be displayed. Touch [Multi Half Fold] or [Multi Tri-Fold] to select it. 12-30 bizhub PRO C6501...
Page 513 Touch [Outside Print] or [Inside Print] to select it. Touch [OK]. – To restore the previous setting, touch [Cancel]. – To release the function with current setting remained, touch [Function Off]. The Output Application Screen will be restored. bizhub PRO C6501 12-31...
Page 514 The triple-folded sets will be delivered into the multi-folding mode tray. Reminder Never return the saddle stitcher tray to its original position with the tray stand opened. 12-32 bizhub PRO C6501...
Page 515: Using Folder/Finisher/Stitcher Functions Manually
0 Multi-feed detection is a feature that automatically stops the machine if more than one sheet is fed at a time. The post inserter is designed to bizhub PRO C6501 12-33...
Page 516 – When selecting folding (from 6 styles), press the Fold selection button to turn on the desired mode lamp. Punching and stapling can be combined. When combining them, turn on the lamps for both functions. 12-34 bizhub PRO C6501...
Page 517 To interrupt the operation, press the Start/Stop button again. Start/Stop button – If multi-feeding is detected and the machine stops even if single sheet is fed, press the Multi-Feed Detection button to turn on the lamp below. Multi-Feed Detection button bizhub PRO C6501 12-35...
Page 518 The Suspension button of Finisher FS-521 is unavailable for the job using a manual function. To fold or fold&staple booklet-styled prints manually, arrange the printed sheets as shown below before placing them into the post inserter. 48 1 26 23 26 23 48 1 12-36 bizhub PRO C6501...
Page 519: Using Perfect Binder Pb-501/Pb-502
Body set Back side of front cover Back side of back cover Head Cover Cover trimming Spine width Foot Front side of front cover Front side of back cover bizhub PRO C6501 12-37...
Page 520 Blank Body set: duplex, Cover print: Off Blank Blank Blank Blank Body set: duplex, Cover print: On, Cover print side: simplex Blank Blank Body set: duplex, Cover print: On, Cover print side: duplex Body set Cover 12-38 bizhub PRO C6501...
Page 521 Body set: duplex, Cover print: Off Blank Blank Blank Blank Blank Body set: duplex, Cover print: On, Cover print side: simplex Blank Blank Blank Body set: duplex, Cover print: On, Cover print side: duplex Blank Body set Cover bizhub PRO C6501 12-39...
Page 522 Please contact your service representative, if desired. Touch [PB heater] on the Machine Status Screen to start the heater of the perfect binder warming up. 12-40 bizhub PRO C6501...
Page 523 [PB heater] on the Machine Status Screen. While the heater of the perfect binder is warming up or ready for operation, the [PB heater] key shows highlighted on the Machine Status Screen. bizhub PRO C6501 12-41...
Page 524 [Function Off] touched on the Perfect Binding Screen or with [Reset] pressed on the control panel. If not using the perfect binder, be sure to turn off the heater by touching [PB heater] on the Machine Status Screen. 12-42 bizhub PRO C6501...
Page 525 Auto Low Power/Auto Shut-Off functions on the main body. Please be careful not to allow the paste pellets to deteriorate. Note Touching [PB heater] will not function if any perfect binding jobs are entered. bizhub PRO C6501 12-43...
Page 526 Standard/Recycled: 10 sheets min. to 300 sheets max., or within 30 mm thick* Fine/Colored/Matted: 10 sheets min. to 150 sheets max., or within 15 mm thick* Z-folded insertions: 4 sheets max. for standard/recycled, or 2 sheets max. for simplex-copied 12-44 bizhub PRO C6501...
Page 527 151 to 300-sheet-bound set: Until detected as full load 0 Secondary (sub) tray capacity: 200 sheets (Full-load detection function is available.) *1: Specify the custom body size from the Paper Presetting Screen. For details, see page 9-44. bizhub PRO C6501 12-45...
Page 528 *5: Detecting the first column as full load, the machine automatically shifts the sets in the first column to the second column, if empty, then again starts to pile the sets in the first column. 12-46 bizhub PRO C6501...
Page 529 If Cover Trimming is desired, be sure to use the size that secures 3 mm to 40 mm of trimming width. Touch [COPY] tab to display the Copy Screen, select the tray loaded with paper for body sets, and change the paper setting as required. bizhub PRO C6501 12-47...
Page 530 If you previously know the time to use the perfect binder, calculate the timing to turn on the heater with required warmup time, then manually turn it on by touching [PB heater] on the Machine Status Screen. 12-48 bizhub PRO C6501...
Page 531 Touch the tray loaded with covers in step 3 to highlight it, then touch [Paper Set Change]. If any tray other than tray 1 to 5 is selected, the Cover Print setting in step 7 will be limited to Cover Print Off. bizhub PRO C6501 12-49...
Page 532 Touch [Size Setting] to display the Size Setting Screen. If the desired cover size is previously registered, touch [Recall], then proceed to the step on page 12-53. – Touch [Custom Size] to display the Custom Size Setting Screen. 12-50 bizhub PRO C6501...
Page 533 Screen, which has nothing to do with this perfect binding operation. – Specify the paper type and weight. Touch [Change] to display the Change Setting Screen. Touch [Type] to select the desired paper type, then touch [OK]. bizhub PRO C6501 12-51...
Page 534 On the Change Setting Screen, touch [Weight] to select the desired paper weight, then touch [OK] twice. If unsuitable selection is made, the binding operation will not be performed. Select the desired one from [22-28 lb Bond], [29-36 lb Bond], and [37-43 lb Bond]. 12-52 bizhub PRO C6501...
Page 535 To recall the paper setting previously registered, touch [Recall] on the Paper Setting Screen to display the Recall Setting Screen, select the desired key, then touch [OK]. – Touch [Close], then touch [OK] on the Cover Tray Screen. bizhub PRO C6501 12-53...
Page 536 Specify the spine width. – Touch [Spine Width (1-30 mm)] to display the Spine Width Screen. Use the screen keypad, upper/lower arrow keys, or the control panel keypad to enter the desired value, then touch [OK]. 12-54 bizhub PRO C6501...
Page 537 Make fine adjustments for the lead edge, trimming width, and image position of the cover. – Touch Fine Adjustment to display the Fine Adjustment Screen. bizhub PRO C6501 12-55...
Page 538 Enter the desired print quantity from the control panel keypad. – Proof copy is recommended before making multiple sets. – After proof copying, the thickness of body set will be displayed on the Perfect Binding Screen. Use this information if making any adjustment. 12-56 bizhub PRO C6501...
Page 539 – Open the perfect binder tray cover. The perfect binder tray cover will not open while the machine operation is in process, and also the feeding button will not function. bizhub PRO C6501 12-57...
Page 540 Take out the books, then close the perfect binder tray cover. Reminder Never open the front door of the perfect binder while the machine operation is in process; otherwise the machine immediately stops the operation and paper jam may be caused. 12-58 bizhub PRO C6501...
Page 541: Using Finisher Fs-520
Example: Make 3 copied sets from 4 original sheets Non-sort Staple Collate Uncollate 2 staples Offset by 30mm 1 oblique Offset by 30mm staple bizhub PRO C6501 12-59...
Page 542 Face up Face up uncollated non-sorted/collated uncollated non-sorted/collated This section describes the following output methods: Non-sort/Collate/Uncollate output to the primary (main) tray Stapled output to the primary (main) tray Non-sort/Collate/Uncollate output to the secondary (sub) tray 12-60 bizhub PRO C6501...
Page 543 For Collate output, touch [Collate] to highlight it. – For Uncollate output, touch [Uncollate] to highlight it. – Select output face (Face Down / Face Up), and output order (1 to N / N to 1) as needed. bizhub PRO C6501 12-61...
Page 544 Be careful not to exceed the finisher tray capacity when selecting the print quantity, otherwise unexpected trouble may be caused. 12-62 bizhub PRO C6501...
Page 545 Output Application icon shows the stapling position currently selected. If you want to change the stapling position, proceed to the following steps. Touch [Output Appli.] on the Copy Screen. The Output Application Screen will be displayed. bizhub PRO C6501 12-63...
Page 546 To release the Staple function with the current stapling position setting remained, touch [Function Off]. The Output Application Screen will be restored. Touch [OK] on the Output Application Screen. The specified output mode icon will be displayed on the Copy Screen. 12-64 bizhub PRO C6501...
Page 547 Be careful not to exceed the finisher tray capacity when selecting the print quantity, otherwise unexpected trouble may be caused. bizhub PRO C6501 12-65...
Page 548 Position the original. Touch [Output Appli.] on the Copy Screen. The Output Application Screen will be displayed. Select the secondary (sub) tray as the output tray. – Touch [Output Tray] to display the Output Tray Selection Screen. 12-66 bizhub PRO C6501...
Page 549 Touch [OK] on the Output Application Screen. The specified output mode icon will be displayed on the Copy Screen. Reminder Be careful not to exceed the finisher tray capacity when selecting the print quantity, otherwise unexpected trouble may be caused. bizhub PRO C6501 12-67...
Page 550: Punching File Holes In Copies (Punch)
For detailed specifications, see page 3-3 and page 7-11. Position the original. Touch [Punch] on the Copy Screen. – Punched sheets will be delivered to the primary (main) tray. The Output Application icon shows the number of punch holes and punch position currently selected. 12-68 bizhub PRO C6501...
Page 551 If you want to change the number of punch holes and punch position, proceed to the following steps. Touch [Output Appli.] on the Copy Screen. The Output Application Screen will be displayed. Touch [Hole-Punch]. The Hole-Punch Screen will be displayed. bizhub PRO C6501 12-69...
Page 552 Touch [OK] on the Output Application Screen. The specified output mode icon will be displayed on the Copy Screen. Reminder Be careful not to exceed the finisher tray capacity when selecting the print quantity, otherwise unexpected trouble may be caused. 12-70 bizhub PRO C6501...
Page 553: Using Finisher Fs-607
Output to the secondary (sub) tray Non-sort/Collate : Non-sort/Collate mode outputs multiple copies of the original set. No offset output is available. Uncollate : Uncollate mode groups together multiple copies of each original. No offset output is available. bizhub PRO C6501 12-71...
Page 554 Face up uncollated non-sorted/collated uncollated non-sorted/collated This section describes the following output methods: Non-sort/ Collate/ Uncollate output to the primary (main) tray Stapled output to the primary (main) tray Collate/ Uncollate output to the secondary (sub) tray 12-72 bizhub PRO C6501...
Page 555 Output tray positions are indicated as square marks on the front image of the machine, and the tray mark currently selected appears highlighted. If the primary (main) tray is not selected, touch [Output Tray] to select it. See page 12-3 for details. bizhub PRO C6501 12-73...
Page 556 Be careful not to exceed the finisher tray capacity when selecting the print quantity, otherwise unexpected trouble may be caused. 12-74 bizhub PRO C6501...
Page 557 Output Application icon shows the stapling position currently selected. If you want to change the stapling position, proceed to the following steps. Touch [Output Appli.] on the Copy Screen. The Output Application Screen will be displayed. bizhub PRO C6501 12-75...
Page 558 To release the Staple function with the current stapling position setting remained, touch [Function Off]. The Output Application Screen will be restored. Touch [OK] on the Output Application Screen. The specified output mode icon will be displayed on the Copy Screen. 12-76 bizhub PRO C6501...
Page 559 Be careful not to exceed the finisher tray capacity when selecting the print quantity, otherwise unexpected trouble may be caused. bizhub PRO C6501 12-77...
Page 560 Position the original. Touch [Output Appli.] on the Copy Screen. The Output Application Screen will be displayed. Select the secondary (sub) tray as the output tray. – Touch [Output Tray] to display the Output Tray Selection Screen. 12-78 bizhub PRO C6501...
Page 561 Touch [OK] on the Output Application Screen. The specified output mode icon will be displayed on the Copy Screen. Reminder Be careful not to exceed the finisher tray capacity when selecting the print quantity, otherwise unexpected trouble may be caused. bizhub PRO C6501 12-79...
Page 562: Making Folded Booklet (Multi Half Fold / Fold&Staple)
20 sets max. of 5-sheet-folded & stapled booklet (paper length 300 mm or more) 15 sets max. of 5-sheet-folded & stapled booklet (paper length 299 mm or less) Position the original. Touch [Output Appli.] on the Copy Screen. The Output Application Screen will be displayed. 12-80 bizhub PRO C6501...
Page 563 Touch [Fold & Staple] or [Multi Half Fold] to highlight it. Touch [OK] on the Output Application Screen. The specified output mode icon will be displayed on the Copy Screen. With Multi Half Fold selected, Booklet Pagination in Application is also selected automatically. bizhub PRO C6501 12-81...
Page 564: Folding Copies In Three (Multi Tri-Fold)
0 Selecting Inside Print automatically sets the output face to Face Up, while Outside Print sets to Face Down. Position the original. Touch [Output Appli.] on the Copy Screen. The Output Application Screen will be displayed. 12-82 bizhub PRO C6501...
Page 565 To release the function with current setting remained, touch [Function Off]. The Output Application Screen will be restored. Touch [OK] on the Output Application Screen. The specified output mode icon will be displayed on the Copy Screen. bizhub PRO C6501 12-83...
Page 566 Procedure Position the original. Touch [Punch] on the Copy Screen. – Punched sheets will be delivered to the primary (main) tray. The Output Application icon shows the number of punch holes and punch position currently selected. 12-84 bizhub PRO C6501...
Page 567 If you want to change the number of punch holes and punch position, proceed to the following steps. Touch [Output Appli.] on the Copy Screen. The Output Application Screen will be displayed. Touch [Hole-Punch]. The Hole-Punch Screen will be displayed. bizhub PRO C6501 12-85...
Page 568 Touch [OK] on the Output Application Screen. The specified output mode icon will be displayed on the Copy Screen. Reminder Be careful not to exceed the finisher tray capacity when selecting the print quantity, otherwise unexpected trouble may be caused. 12-86 bizhub PRO C6501...
Page 569: Cover Sheet Feeding (Paper Inserter)
0 The cover paper size should be the same as copy paper size. 0 Max. 30 insertions are available including front and back covers, with page designation ranging from 1 to 999. 0 Cover paper loaded in the paper inserter cannot be copied. bizhub PRO C6501 12-87...
Page 570 Output Applications Load cover paper into the upper and lower trays of the paper inserter. Upper tray Lower tray Use Insert Sheet or Booklet Pagination function to attach covers to the output copies. 12-88 bizhub PRO C6501...
Page 571: Using Finisher Fs-520/Fs-607 Manually
Staple (1 staple / 2 staples) – Fold & Staple – Multi Tri-Fold - Finisher FS-607 + Paper inserter PI-502 + Punch kit PK-512 – Staple (1 staple / 2 staples) – Fold & Staple – Multi Tri-Fold – Punch bizhub PRO C6501 12-89...
Page 572 – Punch: Place paper face UP. – Fold&Staple: Place the front of the finished set UP. – Multi Tri-Fold: Place the outside of the fold UP. Lower tray – Align the guide plate with the paper. 12-90 bizhub PRO C6501...
Page 573 To select only the Punch mode, turn off all the other mode lamps. Press Start/Stop button. Do you want to stop the output operation? % Press Start/Stop button on the operation panel of paper inserter. bizhub PRO C6501 12-91...
Page 574: Loading/Sorting A Volume Of Copies (Large Capacity Stacker Ls 505)
Output tray positions are indicated as square marks on the front image of the machine, and the tray mark currently selected appears highlighted. If the stacker or secondary (sub) tray is not selected, touch [Output Tray] to select the desired one. See page 12-3 for details. 12-92 bizhub PRO C6501...
Page 575 The specified output mode icon will be displayed on the Copy Screen. Reminder Be careful not to exceed the stacker or secondary (sub) tray capacity when selecting the print quantity, otherwise unexpected trouble may be caused. bizhub PRO C6501 12-93...
Page 576: Copy Conditions Incompatible With Output Applications
Tri-Fold-out (Inside Print) Double Parallel (Inside Print) Gate Fold (Inside Print) Half Fold (Inside Print) Tri-Fold-in (Outside Print Tri-Fold-out (Outside Print) Double Parallel (Outside Print) Gate Fold (Outside Print) Half Fold (Outside Print) Z-Fold Perfect binding 12-94 bizhub PRO C6501...
Page 577 Tri-Fold-out (Inside Print) Double Parallel (Inside Print) Gate Fold (Inside Print) Half Fold (Inside Print) Tri-Fold-in (Outside Print Tri-Fold-out (Outside Print) Double Parallel (Outside Print) Gate Fold (Outside Print) Half Fold (Outside Print) Z-Fold Perfect binding *20 *20 bizhub PRO C6501 12-95...
Page 578 C C C Half Fold (Inside Print) C C C Tri-Fold-in (Outside Print Tri-Fold-out (Outside Print) Double Parallel (Outside Print) Gate Fold (Outside Print) Half Fold (Outside Print) Z-Fold C C C Perfect binding *22 *22 12-96 bizhub PRO C6501...
Page 579 Tri-Fold-out (Inside Print) Double Parallel (Inside Print) Gate Fold (Inside Print) Half Fold (Inside Print) Tri-Fold-in (Outside Print Tri-Fold-out (Outside Print) Double Parallel (Outside Print) Gate Fold (Outside Print) Half Fold (Outside Print) Z-Fold Perfect binding bizhub PRO C6501 12-97...
Page 580 1 C C 1 1 1 1 1 1 1 1 1 1 1 1 Half Fold (Outside Print) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 Z-Fold Perfect binding 12-98 bizhub PRO C6501...
Page 581 *27 o for 1 to N, A for N to 1 in FS-521 Vice versa in FS-520/FS-607 *28 A for 1 to N, o for N to 1 in FS-521 Vice versa in FS-520/FS-607 *29 Grayed out when turning on Print on Cover. bizhub PRO C6501 12-99...
Page 583 Advanced Information...
Page 585: Checking Feature Selections Before Copying: Mode Check
Position the original, then select the desired copy conditions on the Copy Screen. – Or, use Separate Scan mode to scan all originals. Press [Mode Check] on the control panel. The Check Screen will be displayed. bizhub PRO C6501 13-3...
Page 586 Check Screen, then touch [Change]. – The LCD will display an appropriate screen to change the copying condition selected. Change the setting as desired, then touch [OK] to restore the Check Screen to return to the checking steps. 13-4 bizhub PRO C6501...
Page 587 The confirmation popup menu will appear on the Check Screen. – Touch [Yes] to cancel the function, or [No] to restore. – If making a sample copy, proceed to the next step. – To start printing, proceed to step 7. bizhub PRO C6501 13-5...
Page 588 If the desired selection cannot be changed, press [Reset] to delete all the data in memory and restart the job setting. Change the print quantity as required, then press [Start]. – If proof copying has been made, the machine will simply start printing without scanning originals. 13-6 bizhub PRO C6501...
Page 589: Making Sample Set For Checking Results: Proof Copy
If Separate Scan mode has been used, a sample set will be delivered immediately. Check the sample copy for specified copy conditions. – Some conditions can be changed from the Copy Screen. See page 13-4 for details. bizhub PRO C6501 13-7...
Page 590 Advanced Information Change the settings or print quantity, as required, then press [Start]. – If the desired selection cannot be changed, press [Reset] to delete all the data in memory and restart the job setting. 13-8 bizhub PRO C6501...
Page 591: Interrupting Job In Progress: Interrupt Mode
The [Interrupt] LED starts flashing, then keeps lighted when machine is ready for Interrupt mode. The Copy Screen for interrupt copying will be displayed. Set copy conditions, as desired. – All copy conditions except Reserve mode can be specified. bizhub PRO C6501 13-9...
Page 592 Position the original, then press [Start] to start the interrupt copying. When interrupt copying is completed, press [Interrupt] again. The [Interrupt] LED turns out and the settings of the previous job will be restored. Press [Start] to resume copying. 13-10 bizhub PRO C6501...
Page 593: Storing And Recalling Job Conditions: Mode Memory
0 Up to 30 jobs can be stored. Make job selections from the Copy Screen. Press [Mode Memory] on the control panel. The Mode Memory Screen will be displayed. Touch [Store]. The Job Store Check Screen will be displayed. bizhub PRO C6501 13-11...
Page 594 The key with a lock icon displayed is locked and cannot be selected. – Touch [OK] to proceed to the screen for entering the job name. 13-12 bizhub PRO C6501...
Page 595 Touch [OK] on the Mode Memory Screen to complete the setting and return to the Copy Screen. Note If you do not wish to enter a name, simply touch [OK]. The key displays 16 asterisks (*) in place of a name. bizhub PRO C6501 13-13...
Page 596: Recalling Stored Job Settings
Touching [Next] will display the keys from 19 to 30. – The desired job can also be selected by entering two-digit number from the control panel keypad. Touch [Job Check]. The Job Recall Check Screen displays to enable you to review the settings. 13-14 bizhub PRO C6501...
Page 597 Advanced Information Review the settings, then touch [OK]. The settings of the selected job will be recalled on the restored Copy Screen. Press [Start] to print. bizhub PRO C6501 13-15...
Page 598: Recalling Previous Job Settings
0 The previous job settings can be recalled even after the machine power is turned off then on. Position the original. Press [Mode Memory] on the control panel. The Mode Memory Screen will be displayed. Touch [Pre-Job Recall]. The [Job Check] key will be active on the screen. 13-16 bizhub PRO C6501...
Page 599 – Recalled settings can be altered from this screen. See p. 13-3 for details. Touch [OK]. The settings of the previous output job will be recalled on the Copy Screen. Press [Start] to print. bizhub PRO C6501 13-17...
Page 600: Displaying Screen For Operation Guide: Help Mode
05 Hard keys provides information on function and operation of the keys on control panel. 06 Parts exchange provides information on adding toner, loading paper, adding staples, and emptying punch/trimmer waste basket. To Display Help Screen Press [Help] on the control panel. 13-18 bizhub PRO C6501...
Page 601: Adjusting Response Time Of Touch Keys: Accessibility
[Accessibility] will not make any change in the touch key operation. To deactivated this function, press [Accessibility] for one second or longer. The Accessibility LED goes off, and normal response time will be restored in touch key operation. bizhub PRO C6501 13-19...
Page 602: Controlling/Monitoring Copier From Browser
This setting is available in the Web Utilities function. For details, see page 8-18 of POD Administrator's reference. When using Multi Monitor, the IP address of all the machines to be monitored should be specified. This setting is available in the Web 13-20 bizhub PRO C6501...
Page 603 Start the web browser, then enter the IP address of the main body in the address bar. The Web Utilities screen will be displayed. Click [Remote Panel] on the Web Utilities screen. The browser displays control panel and touch panel screen currently displayed on the machine. bizhub PRO C6501 13-21...
Page 604 To replay the operation, click [Execute]. Clicking [Lock Real Panel] will activate the Operation panel lock function to void any operation from the touch panel and control panel. In this case, the machine operation is available from the Remote Panel only. 13-22 bizhub PRO C6501...
Page 605 The state of the machine, touch panel screen, and job condition will be displayed. Clicking the touch panel screen on the Remote Monitor will display the Remote Panel in an exclusive window to allow the machine op- eration from PC. bizhub PRO C6501 13-23...
Page 606 When the Operation panel lock function is activated, the Remote Monitor displays the lock screen of the touch panel. Click the lock screen to enable the machine operation from the Remote Panel. For details of the Remote Panel, see page 13-21. 13-24 bizhub PRO C6501...
Page 607 The Remote Panel will also be displayed in the same browser. Clicking the touch panel screen on the desired Remote Monitor displayed in the browser will display the Remote Panel of the selected machine to allow its operation from PC. bizhub PRO C6501 13-25...
Page 608 When the Operation panel lock function is activated, the Remote Monitor displays the lock screen of the touch panel. Click the lock screen to enable the machine operation from the Remote Panel. For details of the Remote Panel, see page 13-21. 13-26 bizhub PRO C6501...
Page 609 Job Management...
Page 611: Overview Of Job List Screen
The Job List Screen will be displayed. Touch the desired key at the bottom of the screen. – See the following pages for details of each subsequent screen. Touch other tab key to exit the Job List Screen. bizhub PRO C6501 14-3...
Page 612: Job Operation On Job List Screen
Touch [JOB LIST] tab on the Copy Screen, then touch [Reserved Job] if not highlighted. Check the status of the reserved jobs. – Touch [Next] to scroll, if 8 or more jobs are entered. Select the desired job, then select the job operation. 14-4 bizhub PRO C6501...
Page 613 To check the settings of reserve job: Touch to highlight the desired reserve job key, then touch [Details]. Check the settings of the selected job on the screen. Touch [Close] to return to the Job List Screen. bizhub PRO C6501 14-5...
Page 614: To Display Output History
Touch [Next] to scroll, if 8 or more jobs are entered. Touch the desired job key, then touch [Details]. Detailed settings of the selected job will be displayed. Touch [Close] to return to the previous screen. 14-6 bizhub PRO C6501...
Page 615: To Display Send History
Touch [Next] to scroll, if 8 or more jobs are entered. Touch the desired job key, then touch [Details]. Detailed settings of the selected job will be displayed. Touch [Close] to return to the previous screen. bizhub PRO C6501 14-7...
Page 616: To Check Incomplete Jobs
- Cause: Memory Full, Cancel, etc.(cause for which the job was not completed) Touch [JOB LIST] tab on the Copy Screen, then touch [Incomplete]. Check the status of the incomplete jobs. – Touch [Next] to scroll, if 8 or more jobs are entered. 14-8 bizhub PRO C6501...
Page 617: To Check/Operate Suspended Jobs
The letters Suspended on the key appears red to prompt you that a suspended job remains in the machine. Check the status of the suspended jobs. – Touch [Next] to scroll, if 8 or more jobs are entered. Select the desired job, then select the job operation. bizhub PRO C6501 14-9...
Page 618 To check the settings of suspended job: Touch to highlight the desired job key, then touch [Details]. Check the settings of the selected job on the screen. Touch [Close] to return to the Job List Screen. 14-10 bizhub PRO C6501...
Page 619 Index...
Page 621 Automatic Reset Setting 2-36 Collate/ Uncollate Output to the Available Features 1-28 Secondary (Sub) Tray 12-16 12-66 12-78 Color Adjustment 10-3 Background 10-16 Color Balance 10-41 Before successive holidays 1-41 Color Copy Quality 10-5 Bind Direction 9-3 bizhub PRO C6501 15-3...
Page 622 Double Parallel 12-19 12-23 Help Screen 13-18 Hole-Punch 12-21 12-69 12-85 HSB Model 10-4 ENERGY STAR 1-4 HSB Value 10-24 Energy Star 1-4 Hue 10-6 10-24 Enlarge/Reduce 9-28 Hue (H) 10-4 Exchanging Toner Recovery Box 4- 15-4 bizhub PRO C6501...
Page 623 Loading Tabbed Sheets 4-22 Original Information 3-17 Loading/Sorting a Volume of Copies Original Setting 9-3 12-92 Output Applications 12-3 Output History 14-6 Output Modes Using Folding Unit Machine Configuration 2-3 FD-503 12-19 Machine Status Screen 8-8 bizhub PRO C6501 15-5...
Page 624 Reserved Job 14-4 Power LED 8-4 Reset key 8-3 Power OFF/ON Screen 5-14 RGB Model 10-3 Power plug 1-38 RGB Value 10-21 Power Save key 8-4 Rotation 9-42 Power Save LED 2-37 Power source 1-37 1-60 15-6 bizhub PRO C6501...
Page 625 Stop/Resume the job in process 8- Wake-up Screen 2-33 WARNING 1-35 Storage of Copies 1-60 Warning and Precaution Symbols 1- Storing Job Conditions 13-11 Sub power switch 2-3 2-32 Waste basket (Folding unit) 2-13 Suspended Job 14-9 bizhub PRO C6501 15-7...
Page 626 Index Waste basket (Stitcher) 2-17 Watermark 11-76 Web browser 13-20 Weekly Timer 2-41 When moving the machine 1-41 Yellow (Y) 10-8 Z-Fold 12-19 12-23 Z-Folded 9-12 Zoom 9-26 Zoom (individual) 9-28 Zoom (proportional) 9-27 15-8 bizhub PRO C6501...

This manual is also suitable for:

Bizhub pro c6501

Konica Minolta bizhub pro C6501 User Manual

1 Introduction/Safety Information

2 Preparation for Use

3 Paper and Original Information

4 Supplies & Handling

5 Troubleshooting

6 Maintenance

7 Specifications

8 Before Making Copies

9 Basic Job Settings

10 Color Adjustment

11 Application Functions

12 Output Applications

Quick Links

Troubleshooting

Related Manuals for Konica Minolta bizhub pro C6501

Summary of Contents for Konica Minolta bizhub pro C6501
