- Page 1 SBC-FITPC2 Single-board PC Reference Guide...
-
Page 2: Table Of Contents
Table of Contents Revision Notes ......................3 Overview........................4 2.1......................4 IGHLIGHTS 2.2.......................5 EATURES System Components....................6 3.1. CPU ....................6 NTEL 3.2........................7 HIPSET 3.3....................7 RAPHICS YSTEM 3.4......................7 UDIO YSTEM 3.5............9 OWER YSTEM AND OWER ONSUMPTION Peripheral Interfaces &... -
Page 3: Revision Notes
1. Revision Notes 01-Jun-2009 First release... -
Page 4: Overview
2. Overview 2.1. Highlights The SBC-FITPC2 is a tiny, single board PC Full-featured PC single board based on Intel's Atom Z530 processor and computer, tiny and power saving US15W chipset. It runs all standard Intel Atom Z530 CPU @ 1.6 GHz operating systems and software packages. -
Page 5: Features
2.2. Features "Option" column specifies the configuration code required to control the particular feature. "+" means that the feature is available always. Feature Specifications Option Intel Atom Processor: Z530 - 1.6Ghz @533MHz FSB, or Z510 - 1.1GHz @400MHz FSB. L2-512KB (dynamic sizing), L1- 32KB IC, 24KB DC. -
Page 6: System Components
3. System Components 3.1. Intel Atom CPU The SBC-FitPC2 utilizes an Intel® Atom Z5xx series CPU. The Intel® Atom Z5xx series processor is built on 45-nanometer process technology — the first generation of low-power IA-32 micro-architecture specially designed for the new class of Mobile Internet Devices (MID). -
Page 7: Chipset
Execute Disable Bit support for enhanced security 3.2. Chipset The SBC-FitPC2 uses an Intel® System Controller Hub (Intel® SCH) US15W chipset. The Intel® SCH chipset component of the Atom low power platform, combines functionality normally found in separate GMCH (integrated graphics, processor interface, memory controller) and ICH (on-board and end-user I/O expansion) components into a single component consuming less than 2.3 W of thermal design power. - Page 8 channel high-definition audio codec chip. • The headphone stereo output connects to the on-board audio jack (P4). This output is designed to drive a 8Ω - 32Ω headphone or line output. • The line-in and microphone inputs are connected to dedicated 3.5mm audio jacks, P9 and P15 respectively.
-
Page 9: Power System And Power Consumption
3.5. Power System and Power Consumption The SBC-FitPC2 is designed to work with a large range of power sources. It provides stable system functionality with input voltage in the range of 7.5V-15V. An unregulated power supply may be used as long as peaks of supply voltage don’t exceed the input voltage range. -
Page 10: Peripheral Interfaces & Connectors
4.1. USB Interface (P1, P2, U11, U12) The SBC-FitPC2 USB provides a total of 6 USB ports. The USB interface is provided directly by Intel® SCH USB controller that implements UHCI and EHCI host controller architecture and complies with USB 1.1 and 2.0 standards. -
Page 11: Hdmi Connector (J14)
Name Name SD_DAT3 SD_DAT1 SD_CCMD SD_DAT2 VCC_SDIO SD_CLK SD_CD SD_DAT0 4.3. HDMI Connector (J14) The SBC-FitPC2 provides a DVI interface using an HDMI connector. Connector J14, standard HDMI-A connector: Name TMDS_Data2+ TMDS_Data2- TMDS_Data1+ TMDS_Data1- TMDS_Data0+ TMDS_Data0- TMDS_Clock+ TMDS_Clock- DDC_SCL DDC_SDA... -
Page 12: Audio Interface (P4, P9, P15)
1.5mm internal diameter. Outer contact is connected to GND and inner contact to VCC_IN. The connector is compatible with the power supply available from CompuLab. 4.5. Audio Interface (P4, P9, P15) The SBC-FitPC2 provides 2-channel high-definition audio. The following interfaces are provided: •... -
Page 13: Parallel Ata Interface (P6)
Parallel ATA Interface (P6) This interface is available only in modules without the “S” option. The SBC-FitPC2 parallel ATA (PATA) interface is provided directly by an Intel® SCH PATA controller. PATA interface supports only the primary channel, with one master and one slave device. -
Page 14: Serial Ata Interface (P100)
Serial ATA Interface (P100) This interface is available only in modules with the “S” option. The SBC-FitPC2 Serial ATA (SATA) interface is formed from the PATA interface using a PATA to SATA converter. Refer to the PATA interface description for supported transfer modes. -
Page 15: Mini Pci-Express Interface (P27)
Name VCC5 VCC5 VCC5 4.8. mini PCI-express Interface (P27) The SBC-FitPC2 provides one mini PCI-express expansion slot. PCI-express port Mechanical support is provided only for full-length (50.95mm) mini PCI-express card support. Mini PCI-express connector pinout: Name Name WAKE# +3.3V_STBY +1.5V... -
Page 16: Ethernet (P26)
+3.3V_STBY 4.9. Ethernet (P26) The SBC-FitPC2 provides one Gigabit Ethernet port implemented using a Realtek RTL8111x Gigabit Ethernet controller. The RTL8111x offers data transmission over a CAT 5 UTP or CAT 3 UTP (10Mbps only) cable. Functions such as Crossover Detection and Auto-Correction, polarity correction,... -
Page 17: Led's And Push Buttons
The SBC-FitPC2 features a Consumer Infrared receiver, based on a programmed micro controller with USB interface. Mechanical Considerations and Connectors’ Location The 3D solidworks model and “dxf” assembly files of the SBC-FitPC2 board may be downloaded from [Developer] >> [fit-PC2] section of CompuLab’s web-site. 6. Operating Temperature Ranges... - Page 18 WLAN module, please refer to the component’s datasheet. The SBC-FitPC2 is available with three options of operating temperature range: Range Temp. Description Commercial to 70 Sample cards from each batch are tested for the lower and upper temperature limits.
