SECTION 7

7-1 CABINET PARTS

[MAIN UNIT]
REF. ORDER. NO.
DS3 5030002760 L3-0200HAY-3
EP7 8930063020 SRCN-2721-SP-N-W
J2 6450002250 HSJ1456-010320
J3 6450001680 HSJ1120-010010
R315 7210003061 TP76N00N-15F-A103-2251A
S2 2260002840 SKHLLFA010
S27 2250000180 EC10SP16-47
MC1 7700002480 SKB-2746LPC
MP3 8930061890 2721 LCD holder
MP4 8210020570 2721 refl ector
[CHASSIS UNIT]
REF. ORDER. NO.
SP1 2510001060 K036NA500-47
W1 8900009640 OPC-963
J1 6910015910 Antenna connector-104
J2 6910015860 IMSA-6277S-02A-G
MP1 8010019451 2721 chassis-1
MP2 8210020530 2721 T-front panel
8210020730 2721 S-front panel
MP8 8210020550 2721 rear panel
MP9 8310060760 2721 window plate
MP10 8930062620 2721 window sheet
MP12 8930061790 2721 keyboard
8930062760 2721 4-key
MP13 8930061710 2721 main seal
MP14 8930063060 2721 terminal rubber
MP16 8930064660 2721 side plate (A)
MP17 8930061860 2721 top plate
MP20 8930061880 2721 mic sponge
MP21 8930059360 2600 release button
MP22 8930063030 2721 release plate
MP25 8830001720 2721 antenna nut
MP26 8810009220 Scerw B0 2 x 8 ZK (BT)
MP27 8810009560 Scerw M2 x 6 ZK
MP28 8810008970 Scerw M2 x 3.5 NI-ZU (BT)
MP29 8610011930 Knob N-318
MP30 8610011920 Knob N-319
MP31 8810010160 Scerw M3 x 5 SUS ZK
MP32 8930063051 2721 plate-1
MP33 8930046020 1123 sheet (A)-1
MP34 8930056540 Spring (AH)
MP35 8830001700 VR nut (Q)
MP36 8830001690 VR nut (R)
MP37 8510016360 2721 main shield
MP38 8510016350 2721 antenna plate
MP42 8930062960 White sheet (R)
MP47 8930048870 2056 A-sponge
Screw abbreviations
MECHANICAL PARTS AND DISASSEMBLY
DESCRIPTION QTY.
DESCRIPTION QTY.
[F33GT], [F34GT]
[F33GS], [F34GS]
[F33GT], [F34GT]
[F33GS], [F34GS]
11
B0, BT: Self-tapping
ZK: Black
SUS: Stainless
NI-ZU: Nickel-zinc
[PA UNIT]
REF. ORDER. NO.
1 J702 6910015890
[FUSE UNIT]
2
REF. ORDER. NO.
1
1
J901 6910015880
[ACCESSORIES]
1
1
1 REF. ORDER. NO.
1
EP1 3310002321
EP2 0800007541
1
MP1 8010019540
1
MP3 8210020560
1
MP4 8810004860
MP5 8930063051
1
1
1
1
1
1
1
1
1
1
1
1
1
1
EP1
1
1
1
1
1
2
2
1
1
1
1
1
2
1
1
1
1
1
1
7 - 1
DESCRIPTION
IMSA-9230B-1-02Z140-T
DESCRIPTION
IMSA-9230B-1-02Z141-T
DESCRIPTION
FA-SC55V-1
BP-231 ACC-1
MB-94 ACC
2721 JACK PANEL
Screw M2 x 6 ZK
2721 PLATE-1
MP1
EP2
MP3
QTY.
1
QTY.
1
QTY.
1
1
1
1
2
1
MP4
