CD RECEIVER
RECEPTOR CON CD
RECEPTEUR CD
For installation and connections, refer to the separate manual.
Para la instalación y las conexiones, refiérase al manual separado.
Pour l'installation et les raccordements, se référer au manuel séparé.
INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MANUEL D'INSTRUCTIONS
/I
SEL
ATT
40W
4
X
SSM
TEXT
VCR CONTROL
7
VCR
8
9
10
11
1
2
3
4
5
SOUND
For customer Use:
Enter below the Model No. and
Serial No. which are located on
the top or bottom of the cabinet.
Retain this information for future
reference.
Model No.
Serial No.
KD-SX1000R
KD-SX1000R
KD-SX1000R
TP
DISP
RDS
MO/RND
PTY
RPT
INT
EXT
BAND
12
6
CD-
TUNER
CD
CH
VNN3874-631S
[J]
Advertisement
Table of Contents
Related Manuals for JVC KD-SX1000RJ
Summary of Contents for JVC KD-SX1000RJ
- Page 1 CD RECEIVER RECEPTOR CON CD RECEPTEUR CD For installation and connections, refer to the separate manual. Para la instalación y las conexiones, refiérase al manual separado. Pour l’installation et les raccordements, se référer au manuel séparé. INSTRUCTIONS MANUAL DE INSTRUCCIONES MANUEL D’INSTRUCTIONS KD-SX1000R KD-SX1000R...
- Page 2 – Consult the dealer or an experienced radio/TV technician for help. Identification and Certification labels Bottom of the main unit NAME/RATING PLATE US JVC CORP.41 SLATER DRIVE ELMWOOD PARK, N.J. 07407 MANUFACTURED AT MADE IN Product complies with DHHS Rules 21 CFR Subchapter J in effect at date of manufacture.
-
Page 3: Table Of Contents
Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. CONTENTS BASIC OPERATIONS ... 4 RADIO BASIC OPERATIONS ... 5 Listening to the radio ... 5 Storing stations in memory ... -
Page 4: Basic Operations
Select the source. To operate the tuner, see pages 5 – 17. To operate the CD player, see pages 18 – 22. To operate the CD changer, see pages 40 – 42. To operate the external component connected to the LINE IN plugs, see page 43. -
Page 5: Radio Basic Operations
RADIO BASIC OPERATIONS Listening to the radio When using this unit in an area other than North or South America: You need to change the AM/ FM channel intervals. See “Changing AM/FM channel intervals” on page 33. BAND TUNER (FM1) (FM2) (FM3) To search stations... -
Page 6: Storing Stations In Memory
Storing stations in memory You can use one of the following two methods to store broadcasting stations in memory. • Automatic preset of FM stations: SSM (Strong-station Sequential Memory) • Manual preset of both FM and AM stations FM station automatic preset: SSM You can preset 6 local FM stations in each FM band (FM1,FM2 and FM3). -
Page 7: Manual Preset
Manual preset You can preset up to 6 stations in each band (FM1,FM2,FM3 and AM) manually. EXAMPLE: Storing an FM station of 88.3 MHz into the preset number 1 of the FM1 band BAND TUNER Repeat the above procedure to store other stations into other preset numbers. -
Page 8: Tuning Into A Preset Station
Tuning into a preset station You can easily tune into a preset station. Remember that you must store stations first. If you have not stored them yet, see pages 6 and 7. BAND TUNER To change the display information while receiving an FM RDS station Press DISP. -
Page 9: Rds Operations
What you can do with RDS RDS (Radio Data System) allows FM stations to send an additional signal along with their regular program signals. For example, the station send their station names, as well as information about what type of program they broadcast, such as sports or music, etc. By receiving the RDS signals, this unit can do the following: •... - Page 10 Mode 1 (AF:on) Network-Tracking is activated. Switches to another station, within the same network, broadcasting the same programme when the receiving signals from the current station become weak. Mode 2 (AF:off) Network-Tracking is deactivated. The same programme can be received on different frequencies. Programme 1 broadcasting on frequency A Programme 1 broadcasting on...
-
Page 11: Using Standby Reception
Using Standby Reception Standby Reception allows the unit to switch temporarily to a programme of your favorite programme (PTY: Programme Type) and Traffic Announcement (TA) from the current source (another FM station, CD, and other connected components). Note: Standby Reception will not work if you are listening to an AM station. TA Standby Reception •... -
Page 12: Searching Your Favorite Programme
Selecting Your Favorite Programme for PTY Standby Reception You can select your favorite programme for PTY Standby Reception to store in memory. When shipped from the factory, “NEWS” is stored as the programme type for PTY Standby Reception. 1, 4 Searching Your Favorite Programme You can search one of your 6 favorite programme types stored in memory. - Page 13 To store your favorite programme types 1, 5 Press and hold the number button for more than 2 seconds to store the PTY code selected into the preset number you want. PTY preset number appears, and selected code name and “MEMORY” alternates on the display.
-
Page 14: To Search Your Favorite Programme Type
To search your favorite programme type • If there is a station broadcasting a programme of the same PTY code you selected, that station is tuned in. • If there is no station broadcasting a programme of the same PTY code you selected, the station will not change. -
Page 15: Other Convenient Rds Functions And Adjustments
Other convenient RDS functions and adjustments Automatic selection of the station when using the number buttons Usually when you press the number button, the preset station is tuned in. However, when the preset station is an RDS station, something different will happen. If the signals from that preset station are not sufficient for good reception, this unit starts searching another station broadcasting the same programme as the original preset station is broadcasting, then if any station broadcasting the same programme is found, the station will be tuned in. -
Page 16: Automatic Clock Adjustment
Automatic clock adjustment When shipped from the factory, the clock built in this unit is set to be readjust automatically using the CT (Clock Time) data in the RDS signal. If you do not want to use automatic clock adjustment, follow the procedure below. •... - Page 17 PTY codes Indications on the display NE WS IN FOR M SPO RTS TALK ROC K CLS RO CK AD LT HIT SO FT RC K TO P 40 CO UN TRY O LD IE S S OFT Descriptions of the PTY Codes NEWS: News reports, either local or network in origin.
-
Page 18: Cd Operations
CD OPERATIONS Playing a CD Notes: • When a CD is inserted up side down, “PLEASE EJECT” appears on the display. When you open the control panel by pressing 0, the CD automatically ejects. • When you play the CD Text, the disc title and performer appear on the display. Then the current track and elapsed playing time appears on the display. -
Page 19: Locating A Track Or A Particular Portion On A Cd
Locating a track or a particular portion on a CD ¢ To fast forward or reverse the track Press and hold ¢ Press and hold 4 To go to the next track or the previous track Press ¢ next track. Each time you press the button consecutively, the beginning of the next track is located and played back. -
Page 20: Selecting Cd Playback Modes
Selecting CD playback modes To play back tracks at random (Random Play) You can play back all tracks on the CD at random. Each time you press MO/RND (Mono/Random) while playing a CD, CD MO/RND random play mode turns on and off alternately. When the random mode is turned on, the RND indicator lights up on the display and a track randomly selected starts playing. -
Page 21: Prohibiting Cd Ejection
To play back only intros (Intro Scan) Each time you press RPT/INT (Repeat/Intro) briefly while playing a CD, CD intro scan mode turns on and off alternately. When the intro scan mode is turned on, “INTRO” appears on the display for 5 seconds and the track number flashes. -
Page 22: Playing The Cd Text
Playing the CD Text In a CD Text, some information about the disc (its disc title, performer and track title) is recorded. You can show these disc information on the display. DISP Notes: • The display shows up to 12 characters at one time and scrolls if there are more than 12 characters. See also “Selecting the scroll mode”... -
Page 23: Sound Adjustments
SOUND ADJUSTMENTS Selecting preset sound modes You can select a preset sound adjustment suitable to the music genre: Each time you press SOUND, the sound control mode (SCM) changes as follows. SOUND Indication (Flat sound) BEAT Rock or disco music SOFT Quiet background music Light music... -
Page 24: Adjusting The Sound
Adjusting the sound You can adjust the sound characteristics to your preference. Indication BASS Adjust the bass TREBLE Adjust the treble FADER* Adjust the front and rear speaker balance BALANCE Adjust the left and right speaker balance LOUDNESS Boost low and high frequencies to produce a well-balanced sound at low volume level. -
Page 25: Storing Your Own Sound Adjustments
Storing your own sound adjustments You can adjust the sound modes (BEAT, SOFT, POP: see page 23) to your preference and store your own adjustments in memory. 3 1,4 SOUND Within 5 seconds SOUND Repeat the same procedure to store other settings. To reset to the factory settings Repeat the same procedure and reassign the preset values listed in the table on page 23. -
Page 26: Other Main Functions
OTHER MAIN FUNCTIONS Setting the clock You can also set the clock system either to 24 hours or 12 hours. (See page 29.) DISP To check the current clock time while the unit is turned off, press DISP. The power turns on, the clock time is shown for 5 seconds, then the power turns off. 3, 5 2, 4 Press and hold the button for more than... -
Page 27: Changing The General Settings (Psm)
Changing the general settings (PSM) You can change the items listed on the next page by using the PSM (Preferred Setting Mode) control. Basic Procedure Press and hold the button for more than 2 seconds so that “PSM” appears on the lower part of the display. - Page 28 Select. CLOCK HOUR Hour adjustment CLOCK MINUTE Minute adjustment CLOCK24H/12H 24/12-hour time display AUTO ADJUST Automatic setting of the clock DISPLAY MODE Display mode PTY STANDBY PTY standby PTY SEARCH PTY search TA VOLUME Traffic announcement volume LEVEL METER Level display DIMMER MODE Dimmer CRUISE MODE...
-
Page 29: Selecting The Level Display
Selecting 24-hour or 12-hour clock You can change the clock built in this unit either to 24 hour system or 12 hour system. 1. Press and hold SEL (Select) for more than 2 seconds so that “PSM” appears on the lower part of the display. - Page 30 Controlling the volume automatically (Audio Cruise Mode) You can select the proper cruise mode for your car. This unit change the volume level automatically (at 3 possible levels) based on the driving speed of your car by detecting the alternator’s generating frequency (Audio Cruise). If you want to use this mode, follow the procedures below.
- Page 31 To adjust the volume increase rate If you find Audio Cruise increases (or decreases) the volume either too much or too little as the driving speed changes. You can adjust the increase rate by changing the boost level. To change it, follow the procedure below. 1.
-
Page 32: Turning On Or Off The Power Amplifier Switch
Turning on or off the key-touch tone You can deactivate the key-touch tone if you do not want to make it beep when you press a button. When shipped from the factory, the key-touch tone is activated. • ON: Activates the key-touch tone. •... -
Page 33: Adjusting The Contrast Level
Adjusting the contrast level You can adjust the display contrast level (among 1 to 10). When shipped from the factory, the display contrast level is at level 5. 1. Press and hold SEL (Select) for more than 2 seconds so that “PSM” appears on the lower part of the display. -
Page 34: Assigning Names To The Sources
Assigning names to the sources You can assign a name to a CD and the external component connected to the LINE IN plugs. After assigned a name, it will appear on the display when you select it. External component DISP Sources Maximum number of the characters up to 32 characters (up to 40 discs) - Page 35 DISP Repeat steps 3 to 5 until you finish inputting the name. To erase the input characters Insert spaces using the same procedure described above. Notes: • When you assign a name to the 41st disc, “NAME FULL” appears on the display. (In this case, delete unwanted names before assignment.) •...
- Page 36 Available characters Capital letters Small letters Numbers and symbols ” – space space & ’ space < >...
-
Page 37: Detaching The Control Panel
Detaching the control panel You can detach the control panel when leaving the car. When detaching or attaching the control panel, be careful not to damage the connectors on the back of the control panel and on the panel holder. How to detach the control panel Before detaching the control panel, be sure... -
Page 38: Remote Operations
REMOTE OPERATIONS Before using the remote controller: • Aim the remote controller directly at the remote sensor on the main unit. Make sure there is no obstacle in between. • Do not expose the remote sensor to strong light (direct sunlight or artificial lighting). -
Page 39: Using The Remote Controller
Using the remote controller 1 Functions the same as the 2 • Functions as the BAND button while listening to the radio. Each time you press the button, the band changes. • Functions as the DISC + button while listening to the CD changer. -
Page 40: Cd Changer Operations
We recommend that you use one of the CH-X series (ex: CH-X1200) with your unit. If you have another CD automatic changer, consult your JVC car audio dealer for connections. • For example, if your CD automatic changer is one of the KD-MK series, you need a cord (KS-U15K) for connecting it to this unit. - Page 41 To fast forward or reverse the track Press and hold ¢ Press and hold 4 To go to the next track or the previous track Press ¢ next track. Each time you press the button consecutively, the beginning of the next track is located and played back. Press 4 current track.
-
Page 42: Selecting Cd Playback Modes
Selecting CD playback modes To play back tracks at random (Random Play) Each time you press MO/RND (Mono/Random) while playing a CD, CD random play mode changes as follows: MO/RND Mode RND Indicator RANDOM1 RANDOM2 To play back tracks repeatedly (Repeat Play) Each time you press and hold RPT/INT (Repeat/Intro) for more than 1 second while playing a CD, CD repeat play mode changes as follows: Mode... -
Page 43: External Component Operations
EXTERNAL COMPONENT OPERATIONS After connecting a VCR (KZ-V10) to the LINE IN plugs, you can perform the following operations. You can also connect the TV to this unit. Playing VCRs Note: When selecting an external component as the source, the display always shows “VCR …” by pressing these buttouns regardress of whether you connect VCR or not. -
Page 44: Maintenance
• After starting the heater in the car. • If it becomes very humid inside the car. Should this occur, the CD player may malfunction. In this case, eject the CD and leave the unit turned on for a few hours until the moisture evaporates. -
Page 45: Troubleshooting
No CD is in the loading slot (or in the magazine). CD is inserted incorrectly. This unit is not connected to a CD changer correctly. The CD player may function incorrectly. The built-in microcomputer may function incorrectly due to noise, etc. -
Page 46: Specifications
Stereo Separation: 30 dB Capture Ratio: 1.5 dB [AM Tuner] Sensitivity: 20 µV Selectivity: 35 dB CD PLAYER SECTION Type: Compact disc player Signal Detection System: Non-contact optical Number of channels: 2 channels (stereo) , 40 Frequency Response: 5 to 20,000 Hz... - Page 47 VICTOR COMPANY OF JAPAN, LIMITED Printed in Singapore EN, SP, FR 0698MNMMDWJES...
