Page 1: Table Of Contents
MICROWAVE OVEN SMH7159WC SMH7159BC SMH7159CC SERVICE Manual MICROWAVE OVEN CONTENTS 1. Precaution 2. Specifications 3. Operating Instructions 4. Disassembly and Reassembly 5. Alignment and Adjustments 6. Trouble shooting 7. Exploded Views and Parts List 8. PCB Diagrams 9. Schematic Diagrams... - Page 2 PRECAUTIONS TO BE OBSERVED BEFORE AND DURING SERVICING TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not operate or allow the oven to be (c) Before turning on microwave power operated with the door open. for any service test or inspection within (b) Make the following safety checks on the microwave generating all ovens to be serviced before activating...
-
Page 3: Precaution
Instruct owner not to use oven until it has Examples include integrated circuits and been brought into compliance. field -effect transistors. Samsung Electronics America, Inc. Immediately before handling any Headquarters 105 Challenger Road semiconductor components or assemblies, drain the electrostatic charge from your Ridge field Pack, New Jersey 07660-0511 body by touching a known earth ground. -
Page 4: Specifications
1-2 Special Servicing Precautions (Continued) 19. Use replacement components that have the 16. Always connect a test instrument's ground lead to the instrument chassis ground before same ratings, especially for flame resistance connecting the positive lead; always remove and dielectric strength specifications. A the instrument's ground lead last. -
Page 5: Specifications
2. Specifications 2-1 Table of Specifications TIMER 99 MINUTES 99 SECONDS POWER SOURCE 120V 60Hz, AC POWER CONSUMPTION MICROWAVE : 1,580W OUTPUT POWER FROM 100 TO 1000W(10 LEVEL POWER) (IEC-705 TEST PROCEDURE) OPERATING FREQUENCY 2,450MHz MAGNETRON OM75PH(10)ESS COOLING METHOD COOLING FAN MOTOR OUTSIDE DIMENSIONS "(W) x 16 "(H) x 15... -
Page 6: Operating Instructions
3. Operating Instructions 3-1 Control Panel 3-2 Features & External Views Door Ventilation Holes Oven Light Safety Interlock Holes Control Panel Handle Auto Side Hood Intake Holes Door Latches Glass Tray Guide Roller 382.5mm 759mm - 4 -... -
Page 7: Vent Blower
INSTALLATION The Microwave Oven is supported by a special bracket assembly (mounting system) supplied with the oven. The bracket assembly must be mounted to the wall with toggle bolts through the wall, and a lag screw into a wall stud. After the bracket assembly is installed, the unit can be slid over the two rails of the bracket assembly. -
Page 8: Automatic Fan
REUSABLE GREASE FILTERS The metal filter trap grease released by foods on the cooktop. They also prevent flames from foods on the cooktop from damaging the inside of the microwave. For this reason, the filters must ALWAYS be in place when the hood the vent fan is used. The grease filter should be cleaned once a month, or as needed. -
Page 9: Disassembly And Reassembly
4. Disassembly and Reassembly MAGNETRON, MOTOR ASSEMBLY, VENT BLOWER AND HIGH VOLTAGE TRANSFORMER Oven must be removed from wall. REMOVING OVEN FROM WALL (2 PEOPLE REQUIRED) Oven is hooked on metal tabs at bottom of wall mounting plate and to cabinet by (3) top cabinet bolts. 4-1 Replacement of High Voltage Transformer and Fan Motor Assembly. -
Page 10: Replacement Of Door Assembly
4-3 Replacement of Door Assembly 4-3-1 Removal of Door "C" Open the door and remove the door by pulling up from hinge holes. Door "A" Door "C" 4-3-2 Removal of Door "E" Door "E" Following the procedure as shown in the figure, insert and bend a thin metal plate between Door "E"... -
Page 11: Reassembly Test
4-3-4 Reassembly Test After replacement of the defective component parts of the door, reassemble it and follow the instructions below for proper installation and adjustment so as to prevent an excessive microwave leakage. 1. When mounting the door to the oven, be sure to adjust the door parallel to the bottom line of the oven face plate by moving the upper hinge and lower hinge in the direction necessary for proper alignment. -
Page 12: Replacement Of Stirrer Motor
4-6 Replacement of stirrer motor 1. Disconnect power and remove grille screws(2). 2. Remove grille and the bracket duct upper screw(1). 3. Remove the bracket duct upper and disconnect the stirrer motor wire. 4. Remove stirrer motor screws(2) and pull the stirrer motor. -
Page 13: Replacement Of Control Circuit Board
4-8 Replacement of Control Circuit Board 4-8-1 Removal of Control Box 1. Disconnect power and remove grille. Screw 2. Be sure to ground any static electric charge in your body and never touch the control circuit. 3. Disconnect the connectors from the control circuit board. -
Page 14: Alignment And Adjustments
5. Alignment and Adjustments PRECAUTION 1. High voltage is present at the high voltage terminals during any cook cycle. 2. It is neither necessary nor advisable to attempt measurement of the high voltage. 3. Before touching any oven components or wiring, always unplug the oven from its power source and discharge the high voltage capacitor. -
Page 15: High Voltage Capacitor
5-4 High Voltage Capacitor 1. Check continuity of the capacitor with the meter set at the highest resistance scale. 2. Once the capacitor is charged, a normal capacitor shows continuity for a short time, and then indicates 9M Ω . 3. -
Page 16: Vent Exhaust Blower Motor
5-8 VENT EXHAUST BLOWER MOTOR THIS COMPONENT REQUIRE REMOVAL OF MICROWAVE OVEN FROM INSTALLATION FOR SERVICING. The blower is a two speed (HI-LO) capacitor run blower assembly located on top of the micro- wave oven. The blower is operated by low DAMPER ASM voltage relays located on the smart board. -
Page 17: Hood Thermal Cutout
5-9 THERMAL CUTOUT(TCO'S) There are 4 different thermal cutouts in this unit with 4 different purposes. They are : 1. Oven thermal cutout (flame sensor), on cavity top. 2. Hood thermal cutout, on floor of control area. 3. Bottom thermal cutout, on floor of control area. 4. -
Page 18: Bottom Thermal Cutout
5-9-3 Bottom Thermal Cutout THIS COMPONENT REQUIRE REMOVAL OF MICROWAVE OVEN FROM INSTALLATION FOR HOOD THERMAL CUTOUT SERVICING. During a fire on the stove the heat could be intense enough to close the Hood Thermal Cutout and force the fan to run. While at moderate high temperature we do want it to run, however during a fire it is advantage- ous to NOT have the vent fan running. - Page 19 5-10 SENSOR The Sensor Cooking Function uses a special gas sensor which detects both humidity(steam) and VENT MOTOR hydrocarbons(food odors) during the cooking process. Before conducting either of the sensor tests below, ensure the unit is plugged into a will outlet for at least 5 minutes.
-
Page 20: Output Power Of Magnetron
5-11 Output Power of Magnetron CAUTION MICROWAVE RADIATION PERSONNEL SHOULD NOT ALLOW EXPOSURE TO MICROWAVE RADIATION FROM MICROWAVE GENERATOR OR OTHER PARTS CONDUCTING MICROWAVE ENERGY. The output power of the magnetron can be measured by performing a water temperature rise test. Equipment needed : * Two 1-liter cylindrical borosilicate glass vessel (Outside diameter 190 mm) * One glass thermometer with mercury column... -
Page 21: Procedure For Measurement Of Microwave Energy Leakage
2) If the radiation leakage is more than 4 mW/cm after determining that all parts are in good condition, functioning properly and the identical parts are replaced as listed in this manual notify that fact to ; SAMSUNG ELECTRONICS AMERICA, INC. SERVICE DIVISION 400 VALLEY ROAD, SUITE 201 MT. -
Page 22: Troubleshooting
6. Troubleshooting PRECAUTION 1. CHECK GROUNDING BEFORE CHECKING FOR TROUBLE. 2. BE CAREFUL OF THE HIGH VOLTAGE CIRCUIT. 3. DISCHARGE THE HIGH VOLTAGE CAPACITOR. 4. WHEN CHECKING THE CONTINUITY OF THE SWITCHES OR TRANSFORMER, DISCONNECT ONE LEAD WIRE FROM THESE PARTS AND THEN CHECK CONTINUITY WITHOUT THE POWER SOURCE ON. - Page 23 6-1 Electrical Malfunction(continued) SYMPTOM CAUSE CORRECTIONS Oven lamp and fan motor turn on 1. Misadjustment or loose wiring Adjust door and latch switches. of primary latch switch 2. Defective primary latch switch Oven can program but timer 1. Open or loose wiring of does not start.
-
Page 24: Exploded Views And Parts List
7. Exploded Views and Parts List 7-1 Exploded Views P024 P012 W002 P003 P025 P006 P036 P039 P002 M024 P016 P032 M050 M036 P004 P037 M030 P001 M087 M001 C081 M059 M034 P093 M069 M015 M020 M035 P180 M059 M029 M049 P058 M093... -
Page 25: Main Parts List
BUTTON-LOCK -,-,OTR5,-,-,TB53) H025 DE62-00045A INSULATION-FILM SMH7155WC,INSULATION,T0. H027 DE66-00150A GEAR-MAIN SMH7155WC,PA(NYLON#66),-,-,-,- H030 DE97-00453B ASSY-COVER FILTER REAR SMH7159WC,GRY COA H031 DE97-00454B ASSY-COVER FILTER FRONT SMH7159WC,GRY CO H032 DE31-00030A MOTOR DRIVE MSEDC10Q21,SLIDE-OTR,-,60Hz, BASE-BOTTOM H033 3405-001072 SWITCH-MICRO 125/250V,16A,120gf,- BKT-SW H035 DE61-00596C HOLDER-MAGNET SMH7159WC,-,T0.6,-,-,GRY/C top-plt... - Page 26 SMH7155WC,SECC,T T001 DE74-20016A TRAY-COOKING GLASS,T5.0,M551T,-,- T017 DE92-90495A ASSY-GUIDE ROLLER OTR6-ALL,T/T+S/T,PI-15 T033 DE97-00438A ASSY-WIRE RACK SMH6150WC,W/RACK+S/RACK,A U001 DE97-00444C ASSY-BASE BOTTOM SMH7159WC,GRY COAT,-,- U002 4713-001013 LAMP-INCANDESCENT 130V,-,40W,ORG,E17/20, U003 DE47-00006A HOLDER-LAMP -,250V,75W,250X187 2POLE,OTR U004 DE61-00319A BRACKET-BOTTOM LAMP OTR-9,SECC,T0.4,-,-, U005 DE67-40063A GLASS-COOKTOP LAMP -,GLASS,T3.2,W59,L159...
-
Page 27: Door Parts List
7-3 Door Parts List ASSY DOOR - D049 D006 D005 D004 D054 D024 D007 D002 D011 D017 D020 Code No. Description Specification Q'ty Remark D002 DE64-00328E DOOR-A SMH7150WC,PC,-,-,-,-,WHT,- D004 DE94-00586B ASSY DOOR-E SSOTR7,COATING,- D005 DE01-00091A FILM-DOOR -,POLYESTER,-,L458,T0.015,W198 D006 DE64-00337A DOOR-C MO1650WA,PP,T2.0,-,-,-,BLK,- D007 DE61-00151A... -
Page 28: Control Parts List
C005 C001 C004 C009 Code No. Description Specification Q'ty Remark C001 DE94-00587B ASSY CONTROL-PANEL -,SSOTR6,WHT,- C003 RA-SLOTR-01 ASSY PCB PARTS SMH7159WC,120V60HZ SENSOR C004 DE34-00183B SWITCH MEMBRANE SMH7159WC/XAA,SEA,150.9* C005 DE64-00331B CONTROL-PANEL SSOTR,GOOD-DESIGN,PC LEXAN C009 DE64-00416A WINDOW-DISPLAY SSOTR,GOOD-DESIGN,SAN,T2. C073 DE97-00255A ASSY-BRACKET C/PANEL... -
Page 29: Standard Parts List
7-5 Standard Parts List Code No. Description Specification Q'ty Remark 6002-001170 SCREW-TAPPING FH,STAR,2,M4,L12,SIL,SWRCH18A B/D-LATCH 6002-001174 SCREW-TAPPING FH,+,2S,M4,L12,NI PLT,MSWR GRILLE DE60-10012A SCREW-TAP TITE -,SWR10,M4,L10,TH,+,-,3,ZPC2,- P-CORD DE60-10045A SCREW-TAP PH -,-,FEFZY,-,PH,M3,-,L6,-,- DE60-10051A SCREW-TAP PH -,-,MSWR,-,PH,M4,-,L6,-,- S/T-MO DE60-10052A SCREW-TAP PH -,-,FEFZY,-,PH,M4,-,L8,-,- BKT-HI DE60-10052A SCREW-TAP PH -,-,FEFZY,-,PH,M4,-,L8,-,- T/T-MO DE60-10063A... - Page 30 8. P.C.B Diagrams 8-1 P.C.B Diagrams ( This Document can not be used without Samsung's authorization ) -24V -24V +12V 5V-1 TMP87PM14F KIA7805AF LVT1 ZMM55CV1 SLV-1350U(P) P51 60 NP-4 23 SMW250-05AV_RED GS1G 1000uF 100uF KRC246 NP-3 22 100nF P53 62...
- Page 31 8-2 P.C.B Pasts List Code No. Description Specification Q'ty Remark 3501-001050 RELAY-MINIATURE 24VDC,200mW,5A,1FormA,10mS,5mS RY07 3501-001063 RELAY-MINIATURE 24Vdc,408mW,3A,1FormC,10mS,5mS RY06 3501-001155 RELAY-MINIATURE 24VDC,200MW,3000MA,1FORMA,10MS,10MS RY01,03~05,08 3501-001188 RELAY-POWER 24V DC,0.53W,-,1FormA,9.3ms,10mS RY02 3708-000530 CONNECTOR-FPC/FC/PIC 16P,2.54mm,STRAIGHT,SN CN01 DE07-10089A V.F.DISPLAY SVM-07SS25,GRN,7G,111SEG,78.4X VFD1 DE09-00071A IC MICOM TMP87PM74F,OTP-32K,QFP 8BIT-80PIN,-,-,-,- IC01 DE26-20144A TRANS-L.V...
-
Page 32: Schematic Diagrams
9. Schematic Diagrams 9-1 Schematic Diagram S ( This Document can not be used without Samsung's authorization ) - 30 -... - Page 33 ELECTRONICS This Service Manual is a property of Samsung Electronics Co.,Ltd. © Samsung Electronics Co., Ltd. July 2003 Any unauthorized use of Manual can be punished under applicable Printed in Korea International and/or domestic law Code No. : DE68-03132A...
