INSTRUCTION MANUAL
IMPORTANT INFORMATION
GB
sure you understand them before using this unit. Retain these instructions for future
reference.
MANUEL D'INSTRUCTIONS
RENSEIGNEMENTS IMPORTANTS:
FR
atentivement les instructions et assurez- -vous de les avoir comprises. Conservez
les instructions pour référence ultérieure.
BETRIEBSANWEISUNG
WICHTIGE INFORMATION:
DE
Geräts aufmerksam durch. Verwenden Sie es erst, wenn Sie sicher sind, daß Sie
alle Anweisungen verstanden haben und gut aufbewahren.
MANUAL DE INSTRUCCIONES
INFORMACIÓN IMPORTANTE:
ES
asegúrese de entenderlas antes de utilizar esta aparato. Conserve las instruc-
ciones para la referencia en el futuro.
ProMac 320X
: Please read these instructions carefully and make
Avant d'utiliser cet appareil, veuillez lire
Lesen Sie diese Hinweise zur Handhabung des
Lea atentamente las instrucciones y
545123415
12/15/06
Advertisement
Table of Contents
Related Manuals for McCulloch ProMac 320X
Summary of Contents for McCulloch ProMac 320X
- Page 1 ProMac 320X INSTRUCTION MANUAL IMPORTANT INFORMATION : Please read these instructions carefully and make sure you understand them before using this unit. Retain these instructions for future reference. MANUEL D’INSTRUCTIONS RENSEIGNEMENTS IMPORTANTS: Avant d’utiliser cet appareil, veuillez lire atentivement les instructions et assurez- -vous de les avoir comprises. Conservez les instructions pour référence ultérieure.
- Page 2 IDENTIFICATION (WHAT IS WHAT?) 12. Throttle trigger 1. Fuel tank 13. Throttle lock- -out 2. Handlebar 14. Starter handle 3. ON/OFF switch 15. Fuel cap 4. Shoulder strap clamp 16. Primer bulb 5. Shoulder strap 17. Choke lever 6. Trimmer head 7.
- Page 3 WARNING! This brushcutter can be dangerous! Careless or improper use can cause serious or even fatal injury. B. Read and understand the instruction manual before using the brushcutter. C. Always use: Ear protection, eye protection, head protection, boots, and gloves. DANGER! Blade can thrust violently away from material it does not cut.
- Page 4 S Use only 0.095″ (2,4 mm) diameter McCul- WARNING: loch® brand replacement line. Never use The blade continues to wire, rope, string, etc. spin after the throttle is released or, engine is S Install required shield properly before using turned off. The coasting blade can throw objects the unit.
- Page 5 TRANSPORTING AND STORAGE SPECIAL NOTICE: Exposure to vibra- S Allow the engine to cool; secure unit before tions through prolonged use of gasoline pow- storing or transporting in vehicle. ered hand tools could cause blood vessel or S Empty fuel tank before storing or transport- nerve damage in the fingers, hands, and ing the unit.
- Page 6 NOTE: A one-half twist is built in the shoul- der strap to allow the strap to rest flat on the Secondary Hole shoulder. 2. Adjust the strap, allowing the hook to be about 6 inches (15 cm) below the waist. 3.
- Page 7 3. Pivot shield until bolt passes through hole in bracket. 4. Reinstall nut and tighten securely with wrench (provided). NOTE: If your unit has a plastic cover over the threads on the threaded shaft, remove the covering to expose the threads. Before instal- 30 inches ling the trimmer head, make sure the dust cup (76 cm)
- Page 8 These 10. Remove the screwdriver. parts must be provided by McCulloch and 11. Turn blade by hand. If the blade binds installed as shown below. Failure to use proper against the shield, or appears to be uneven,...
- Page 9 OPERATION Throttle WARNING: Starter Handle Lock- -out Be sure to read the fuel information in the safety rules before you be- gin. If you do not understand the safety rules, do not attempt to fuel your unit. Contact an Choke authorized service dealer.
- Page 10 NOTE: Upper than 6 pulls. If engine still doesn’t Shaft start, it is probably flooded. Proceed to Coupler STARTING A FLOODED ENGINE. LOOSEN 9. Once the engine starts, allow it to run 10 Lower seconds, then move the choke lever to OFF Attachment CHOKE by aligning lever with position shown on decal (see following illustration).
- Page 11 OPERATING POSITION the shield in place when the tool is being oper- ated. To advance line: ALWAYS WEAR: S Operate the engine at full throttle. Hearing S Hold the trimmer head parallel to and above the grassy area. Protection S Tap the bottom of the trimmer head lightly on Eye Protection the ground one time.
- Page 12 OPERATING INSTRUCTIONS FOR Trimming USE WITH WEED BLADE S Blade Thrust is a reaction that only occurs when using a bladed unit. This reaction can cause serious injury such as amputation. Carefully study this section. It is important that you understand what causes blade thrust, how you can reduce the chance of its occurring, and how you can remain in control of unit if blade thrust occurs.
- Page 13 S Do not raise the engine above your waist as S Cut while swinging the upper part of your the blade can come dangerously close to body from left to right. your body. S As you move forward to the next area to cut, S Do not swing unit with such force that you be sure to maintain your balance and footing.
- Page 14 S Never use for spreading chemicals, fertilizers, WARNING: or other substances which may contain toxic Inspect the area before materials. starting the unit. Remove all debris and hard S To avoid spreading fire, do not use near leaf or objects such as rocks, glass, wire, etc. that brush fires, fireplaces, barbecue pits,...
- Page 15 thrown into the eyes and face and cause seri- WARNING: ous injury or blindness. Keep the pruner away from power lines or electrical wires. WARNING: Inspect the area where S Only use for pruning limbs or branches up to 4 inches in diameter.
- Page 16 4. Replace with a pre-wound spool, or re- place line using a 4,5 meters length of 2,4 9. Insert the ends of the lines through exit mm diameter McCulloch® brand line. holes in the sides of the cover. 5. When installing new line on an existing 10.
- Page 17 CARBURETOR ADJUSTMENT S Turn idle speed screw counterclockwise to decrease engine speed if trimmer head WARNING: moves or spins at idle speed. Keep others away when making idle speed adjustments. The trimmer WARNING: Recheck the idle speed head will be spinning during most of this pro- after each adjustment.
- Page 18 TROUBLESHOOTING TABLE WARNING: Always stop unit and disconnect spark plug before performing all of the recommended remedies below except remedies that require operation of the unit. TROUBLE CAUSE REMEDY Engine will not 1. ON/OFF switch in OFF 1. Move ON/OFF switch to ON position. start.
- Page 19 EC Declaration of Conformity (Only applies to Europe) We, Husqvarna Outdoor Products Italia, S.p.A., Valmadrera, Italy. Tel: +39- -0341- -203211, declare that the brushcutter model McCulloch ProMac 320X from serial numbers 2005- -252N00001 and onwards, comply with the requirements of the COUNCIL’S DIRECTIVES: of 22 June 1998 “relating to machinery”...
- Page 20 TECHNICAL DATA SHEET ODEL: ProMac 320X Blade Trimmer ENGINE Displacement, cm Maximum engine power, measured in accordance with ISO 8893, kW ENGINE ROTATIONAL SPEEDS At maximum engine power, rpm 7000 7000 Maximum rotational frequency of the spindle 10000 10000 Engine speed at recommended maximum...
