CASSETTE RECEIVER
RECEPTOR-REPRODUCTOR DE CASSETTE KS-FX470
RADIOCASSETTE
For installation and connections, refer to the separate manual.
Para la instalación y las conexiones, refiérase al manual separado.
Pour l'installation et les raccordements, se référer au manuel séparé.
RM-RK31
INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MANUEL D'INSTRUCTIONS
LOUD
LOUD
DISP
DISP
SCAN
SCAN
7
8
9
10
1 1
12
For customer Use:
Enter below the Model No. and
Serial No. which are located on
the top or bottom of the cabinet.
Retain this information for future
reference.
Model No.
Serial No.
KS-FX470
KS-FX470
Multi
Music
Scan
MO
GET0015-001A
[J]
Advertisement
Table of Contents
Related Manuals for JVC KS-FX470
Summary of Contents for JVC KS-FX470
- Page 1 CASSETTE RECEIVER RECEPTOR-REPRODUCTOR DE CASSETTE KS-FX470 RADIOCASSETTE For installation and connections, refer to the separate manual. Para la instalación y las conexiones, refiérase al manual separado. Pour l’installation et les raccordements, se référer au manuel séparé. INSTRUCTIONS MANUAL DE INSTRUCCIONES MANUEL D’INSTRUCTIONS...
-
Page 2: Table Of Contents
Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. CONTENTS How to reset your unit ... 2 BASIC OPERATIONS ... 4 RADIO OPERATIONS ... - Page 3 OTHER MAIN FUNCTIONS ... 19 Setting the clock ... 19 Changing the general settings (PSM) ... 20 Basic Procedure ... 20 Canceling Advanced SCM ... 21 Selecting the level display ... 21 Selecting the dimmer mode ... 22 Selecting the external component to use ... 22 Detaching the control panel ...
-
Page 4: Basic Operations
BASIC OPERATIONS Note on One-Touch Operation: When you select a source in step 2 below, the power automatically comes on. You do not have to press this button to turn on the power. Adjust the sound as you want (see pages 14 – 18). To drop the volume in a moment Press briefly while listening to any source. -
Page 5: Radio Operations
RADIO OPERATIONS Listening to the radio Select the band (FM1, FM2, FM3 or AM). You can select any one of FM1, FM2, and FM3 to listen to an FM station. To search stations of higher frequencies To search stations of lower frequencies To stop searching before a station is received, press the same button you have pressed for searching. -
Page 6: Storing Stations In Memory
Storing stations in memory You can use one of the following two methods to store broadcasting stations in memory. • Automatic preset of FM stations: SSM (Strong-station Sequential Memory) • Manual preset of both FM and AM stations FM station automatic preset: SSM You can preset 6 local FM stations in each FM band (FM1, FM2 and FM3). -
Page 7: Manual Preset
Manual preset You can preset up to 6 stations in each band (FM1, FM2, FM3 and AM) manually. EXAMPLE: Storing an FM station of 88.3 MHz into the preset channel number 1 of the FM1 band Selected band,preset number and “MEMO”... -
Page 8: Tuning Into A Preset Station
Tuning into a preset station You can easily tune into a preset station. Remember that you must store stations first. If you have not stored them yet, see pages 6 and 7. Select the band (FM1, FM2, FM3 or AM) you want. -
Page 9: Other Convenient Tuner Functions
Other convenient tuner functions MO RND SCAN Scanning broadcast stations When you press SCAN while listening to the radio, station scanning starts. Each time a broadcast is tuned in, scanning stops for about 5 seconds (tuned frequency number flashes on display), and you can check what program is now being broadcasted. If you want to listen to that program, press the same button again to stop scanning. -
Page 10: Tape Operations
TAPE OPERATIONS Listening to a tape • When one side of the tape reaches its end during play, the other side of the tape automatically starts playing. (Auto Reverse) Note on One-Touch Operation: When a cassette is already in the cassette compartment, pressing TAPE 2 3 turns on the unit and starts tape play automatically. - Page 11 To stop play and eject the cassette Press 0. Tape play stops, the control panel opens, then the cassette automatically ejects from the cassette compartment. If you change the source to FM, AM or CD changer, the tape play also stops (without ejecting the cassette this time).
-
Page 12: Finding The Beginning Of A Tune
Finding the beginning of a tune Multi Music Scan allows you to automatically start playback from the beginning of a specified tune. You can specify up to 9 tunes ahead of or before the current tune. During playback To locate a tune ahead of the current tune on the tape To locate a tune before... -
Page 13: Other Convenient Tape Functions
Other convenient tape functions Skipping the blank portions on the tape You can skip blank portions between the tunes. (Blank Skip) When this function is on, the unit skips blank portions of 15 seconds or more, fast-forwards to the next tunes, then starts playing it. •... -
Page 14: Sound Adjustments
SOUND ADJUSTMENTS Adjusting the sound You can adjust the treble/bass sound and the speaker balance. Indication Adjust the bass (Bass) Adjust the treble (Treble) Adjust the front and rear speaker (Fader)* balance Adjust the left and right speaker (Balance) balance Adjust the volume (Volume) Note:... -
Page 15: Turning On/Off The Loudness Function
Turning on/off the loudness function The human ear is less sensitive to low and high frequencies at low volumes. The loudness function can boost these frequencies to produce well-balanced sound at low volume level. Turn on or off the loudness function. Each time you press LOUD, the loudness function turns on and off alternately. -
Page 16: Using The Sound Control Memory
Using the Sound Control Memory You can select and store a preset sound adjustment suitable to each playback source. (Advanced SCM) Selecting and storing the sound modes Once you select a sound mode, it is stored in memory, and will be recalled every time you select the same source. -
Page 17: Recalling The Sound Modes
Recalling the sound modes Notes: • You can adjust each sound mode to your preference, and store it in memory. If you want to adjust and store your original sound mode, see “Storing your own sound adjustments” on page 18. •... -
Page 18: Storing Your Own Sound Adjustments
Storing your own sound adjustments You can adjust the sound modes (BEAT, SOFT, POP: see page 16) to your preference and store your own adjustments in memory. Within 5 seconds Within 5 seconds Within 5 seconds Repeat the same procedure to store other settings. To reset to the factory settings Repeat the same procedure and reassign the preset values listed in the table on page 16. -
Page 19: Other Main Functions
OTHER MAIN FUNCTIONS Setting the clock Press and hold SEL (Select) for more than 2 seconds so that one of the PSM items appears on the display. To check the current clock time (changing the display mode) Press DISP repeatedly. Each time you press the button, the display mode changes as follows: During tuner operation: Band Clock... -
Page 20: Changing The General Settings (Psm)
Changing the general settings (PSM) You can change the items listed on the next page by using the PSM (Preferred Setting Mode) control. Basic Procedure Press and hold SEL (Select) for more than 2 seconds so that one of the PSM items appears on the display. -
Page 21: Canceling Advanced Scm
Select. CLOCK H Hour adjustment CLOCK M Minute adjustment SCM LINK Sound control memory linkage LEVEL Level display DIMMER Dimmer B. SKIP Blank skip EXT IN External component * Displayed only when one of the following sources is selected — FM, AM and tape. •... -
Page 22: Selecting The Dimmer Mode
Selecting the dimmer mode When you turn on the car head lights, the display automatically dims (Auto Dimmer). When shipped from the factory, Auto Dimmer mode is activated. • AUTO: Activates Auto Dimmer. • ON: Always dims the display. • OFF: Cancels Auto Dimmer. -
Page 23: Detaching The Control Panel
Detaching the control panel You can detach the control panel when leaving the car. When detaching or attaching the control panel, be careful not to damage the connectors on the back of the control panel and on the panel holder. How to detach the control panel Before detaching the control panel, be sure... -
Page 24: Remote Operations
REMOTE OPERATIONS Before using the remote controller: • Aim the remote controller directly at the remote sensor on the main unit. Make sure there is no obstacle in between. • Do not expose the remote sensor to strong light (direct sunlight or artificial lighting). -
Page 25: Using The Remote Controller
Using the remote controller 1 Functions the same as the 2 • Functions as the BAND button while listening to the radio. 3 • Functions as the PRESET button while listening to the RM-RK31 4 Functions the same as the control dial on the main unit. 5 Selects the sound mode. -
Page 26: Cd Changer Operations
We recommend that you use one of the CH-X series with your unit. If you have another CD automatic changer, consult your JVC car audio dealer for connections. • For example, if your CD automatic changer is one of the KD-MK series, you need a cord (KS-U15K) for connecting it to this unit. -
Page 27: To Go To A Particular Disc Directly
To fast-forward or reverse the track Press and hold ¢ Press and hold 4 To go to the next tracks or the previous tracks Press ¢ the next track. Each time you press the button consecutively, the beginning of the next tracks is located and played back. -
Page 28: Selecting Cd Playback Modes
Selecting CD playback modes To play back tracks at random (Random Play) Each time you press MO RND (Monaural/Random) while playing a CD, CD random play mode changes as follows: Mode RND Indicator RND1 Lights RND2 Flashes To play back tracks repeatedly (Repeat Play) Each time you press repeat play mode changes as follows: Mode... -
Page 29: External Component Operations
EXTERNAL COMPONENT OPERATIONS Playing an external component You can connect the external component to the CD changer jack on the rear using the Line Input Adaptor KS-U57 (not supplied). Preparations: • For connecting the Line Input Adaptor KS-U57 and the external component, refer to the Installation/ Connection Manual (separate volume). -
Page 30: Maintenance
MAINTENANCE To extend the lifetime of the unit This unit requires very little attention, but you will be able to extend the life of the unit if you follow the instructions below. To clean the heads To keep the tape clean CAUTIONS: •... -
Page 31: Troubleshooting
TROUBLESHOOTING What appears to be trouble is not always serious. Check the following points before calling a service center. Symptoms • A cassette tape cannot be inserted. • Cassette tapes become hot. • Tape sound is at very low level and sound quality is degraded. -
Page 32: Specifications
SPECIFICATIONS AUDIO AMPLIFIER SECTION Maximum Power Output: Front: 45 W per channel Rear: 45 W per channel Continuous Power Output (RMS): Front: 17 W per channel into 4 Ω, 40Hz to 20 000 Hz at no more than 0.8% total harmonic distortion. Rear: 17 W per channel into 4 Ω, 40Hz to 20 000 Hz at no more than 0.8% total harmonic distortion. - Page 33 http://www.jvcmobile.com Visit us on-line for Technical Support & Customer Satisfaction Survey. US RESIDENTS ONLY Having TROUBLE with operation? Please reset your unit Refer to page of How to Reset Still having trouble?? USA ONLY Call 1-800-252-5722 http://www.jvcservice.com We can help you! VICTOR COMPANY OF JAPAN, LIMITED EN, SP, FR 1000HISFLEJES...
-
Page 34: Localizacion De Averias
• The following illustration shows a typical installation. However, you should make adjustments corresponding to your specific car. If you have any questions or require information regarding installation kits, consult your JVC car audio dealer or a company supplying kits. Before mounting: Press (Control Panel Release) to detach the control panel if already attached. - Page 35 • When using the optional stay • Cuando emplea un soporte opcional • Lors de l'utilisation du hauban en option Fire wall Tabique a prueba de incendios Cloison Washer Arandela Rondelle Dashboard Tablero de instrumentos Tableau de bord Sleeve Cubierta Manchon Removing the unit •...
-
Page 36: Electrical Connections
NEGATIVA solamente. Si su vehículo no posee este sistema, será necesario un inversor de tensión, que puede ser adquirido en los concesionarios de JVC de equipos de audio para automóviles. • Reemplace el fusible por uno con la corriente especificada. Si el fusible se quemase frecuentemente consulte con su concesionario de JVC de equipos de audio para automóviles. - Page 37 Amplifier / Amplificador / Amplificateur Rear speakers Altavoces posteriores Haut-parleur arrière INPUT JVC Amplifier Amplificador de JVC Amplificateur JVC Signal cord (not supplied with this unit) Cable de señal (no suministrado con esta unidad) Cordon de signal (non fourni avec cet appareil) LINE OUT...
