Macro-Tech 3600VZ Power Amplifier

6 Specifications

These specifications apply to 120 VAC units in stereo
mode with 8 ohm loads and an input sensitivity of 26 dB
unless otherwise specified.
120 VAC, 60 Hz Units: These units are equipped with trans-
formers rated for 120 VAC, 60 Hz power.
International Units: These units are equipped with trans-
formers for either 100 VAC, 50/60 Hz, or 230 VAC, 50/60 Hz
power.
Performance
Frequency Response: ±0.1 dB from 20 Hz to 20 kHz
at 1 watt. See Figure 6.3.
Phase Response: ±10° from 10 Hz to 20 kHz at 1 watt.
See Figure 6.6.
Signal-to-Noise Ratio: Greater than 105 dB below
rated output (20 Hz to 20 kHz, A-weighted); 100 dB
below rated output (20 Hz to 20 kHz, no weighting).
Harmonic Distortion (THD): At rated output, less than
0.05% from 20 Hz to 1 kHz increasing linearly to less
than 0.1% at 20 kHz.
IM Distortion (IMD): Less than 0.05% from 368 milli-
watts to full rated output.
Damping Factor: Greater than 1,000 from 10 Hz to 400
Hz. See Figure 6.4.
Crosstalk: See Figure 6.7.
Slew Rate: Greater than 30 volts per microsecond.
Voltage Gain: (At maximum output) 20:1 ±3% or 26 dB
±0.25 dB at +26 dB sensitivity, and 124.6:1 ±12% or
41.9 dB ±1.0 dB at 0.775 volt sensitivity.
Power
Output Power:
Note: Maximum average watts per channel (unless in
Mono mode) at 1 kHz with 0.1% or less THD.
120 VAC, 60 Hz Units:
Stereo mode with both channels driven:
1800 watts into 2 ohms.
1565 watts into 4 ohms.
1120 watts into 8 ohms.
Bridge-Mono mode:
3505 watts into 4 ohms.
3140 watts into 8 ohms.
Parallel-Mono mode:
3555 watts into 1 ohm.
3190 watts into 2 ohms.
Reference Manual
100 VAC International Units:
Stereo mode with both channels driven:
1460 watts into 2 ohms.
1300 watts into 4 ohms.
980 watts into 8 ohms.
Bridge-Mono mode:
2835 watts into 4 ohms.
2625 watts into 8 ohms.
Parallel-Mono Mode
2820 watts into 1 ohm.
2585 watts into 2 ohms.
120 VAC International Units:
Stereo mode with both channels driven:
1490 watts into 2 ohms.
1300 watts into 4 ohms.
985 watts into 8 ohms.
Bridge-Mono mode:
2980 watts into 4 ohms.
2600 watts into 8 ohms.
Parallel-Mono Mode
2980 watts into 1 ohm.
2600 watts into 2 ohms.
230 VAC International Units:
Stereo mode with both channels driven:
1520 watts into 2 ohms.
1325 watts into 4 ohms.
965 watts into 8 ohms.
Bridge-Mono mode:
2800 watts into 4 ohms.
2515 watts into 8 ohms.
Parallel-Mono Mode
2910 watts into 1 ohm.
2565 watts into 2 ohms.
Load Impedance: Rated for 16, 8, 4, and 2 ohm use
only. Safe with all types of loads, even reactive ones.
AC Power Requirements: 100 VAC, 50/60 Hz; 120
VAC, 50/60 Hz; and 230 VAC, 50/60 Hz units are avail-
able. 230 VAC, 50/60 Hz units can be used with 220
and 240 VAC. All versions draw 90 watts or less at idle.
100 and 120 VAC units can draw up to 30 amps of cur-
rent; 230 VAC units can draw up to 15 amps. Refer to
the back panel for your unit's specifications. Refer to
Section 7 for more details.
It is extremely important to provide sufficient AC power
to the amplifier. Power amplifiers cannot create en-
ergy—they must have the proper voltage and current to
deliver the clean rated power you expect.
