Table of Motherboard Components
LABEL
1. CPU Socket
2. SYS_FAN
3. CPU_FAN
4. DDR3_1~2
5. ATX_POWER Standard 24-pin ATX power connector
6. SATA1~6
7. F_PANEL
8. F_USB1~2
9. USB3F
10. PWR_FAN
11. SPK
12. CLR_CMOS Clear CMOS jumper
13. LPT
14. COM
15. TPM
16. CASE
17. PCIE1~2
18. SPDIFO
19. PCI
20. PCIEX16
21. F_AUDIO
22. ATX12V
COMPONENTS
FM2 for AMD TRINITY processors
System cooling fan connector
CPU cooling fan connector
240-pin DDR3 SDRAM slots
Serial ATA 6Gb/s connectors
Front panel switch/LED header
Front panel USB 2.0 headers
(F_USB1 supports EZ Charger function)
Front panel USB 3.0 header
Power cooling fan connector
Speaker header
Parallel port header
Serial port header
Trusted Platform Module
Case open header
PCI Express x1 slots
SPDIF out header
32-bit PCI add-on card slot
PCI Express slot for graphics interface
Front panel audio header
4-pin +12V power connector
