JVC LYT0152-001B Instructions Manual

Digital video camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

DIGITAL VIDEO CAMERA

GR-DV3
INSTRUCTIONS
Please visit our CyberCam Homepage on
the World Wide Web and answer our
Consumer Survey (in English only):
http://www.jvc-victor.co.jp/index-e.html
For Customer Use:
Enter below the Model No. and Serial
No. which is located on the bottom of
cabinet. Retain this information for
future reference.
Model No.
Serial No.
ENGLISH
EN
LYT0152-001B

Advertisement

Table of Contents
loading

Related Manuals for JVC LYT0152-001B

Summary of Contents for JVC LYT0152-001B

  • Page 1: Digital Video Camera

    World Wide Web and answer our Consumer Survey (in English only): http://www.jvc-victor.co.jp/index-e.html For Customer Use: Enter below the Model No. and Serial No. which is located on the bottom of cabinet. Retain this information for future reference. Model No. Serial No. LYT0152-001B ENGLISH...

  • Page 2: Safety Notes

    Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. This camcorder is designed to be used with NTSC-type color television signals. It cannot be used for playback with a television of a different standard.

  • Page 3: Important Product Safety Instructions

    IMPORTANT PRODUCT SAFETY INSTRUCTIONS Electrical energy can perform many useful functions. But improper use can result in potential electrical shock or fire hazards. This product has been engineered and manufactured to assure your personal safety. In order not to defeat the built-in safeguards, observe the following basic rules for its installation, use and servicing.
  • Page 4 1. Accessories To avoid personal injury: • Do not place this product on an unstable cart, stand, tripod, bracket or table. It may fall, causing serious injury to a child or adult, and serious damage to the product. • Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with the product.

  • Page 5: Safety Precautions

    If this happens, place the battery pack in your pocket or other warm, protected place for a short time, then re-attach it to the camcorder. As long as the battery pack itself is not cold, it should not affect perform- ance.

  • Page 6: Provided Accessories

    AC Power Adapter/Charger DC cord AA-V68U Remote control unit MiniDV Cassette Tape 30 min RM-V705B (DVM-30) M-DV30ME Grip/Hand strap Battery pack BN-V607U Lithium battery CR2025 VIDEO/AUDIO cable (for remote control unit) (camcorder to TV or VCR, ø3.5 mini-plug 4 RCA plug)

  • Page 7: About Dv

    Chrominance (C) Color Difference AUDIO Signal (B-Y) This camcorder separates the data into blocks, writing one block of each data type on each track of the tape. Head tracking direction Sub-Code Area The Time Code and Date/Time data are written here, separate from the video data.

  • Page 8: Table Of Contents

    PROVIDED ACCESSORIES ABOUT DV GETTING STARTED Charging The Battery Pack ... 10 Installing The Battery Pack ... 11 Indoor Use ... 12 Using The Battery Holder ... 12 Date/Time Settings ... 13 Loading/Unloading A Cassette ... 14 Recording Mode Setting ... 15 Grip Strap Attachment ...
  • Page 9 For More Accurate Random Assemble Editing... 66 TROUBLESHOOTING AFTER USE CONTROLS, INDICATIONS AND CONNECTORS Camcorder ... 74 AC Charger Station (optional) ... 76 Remote Control Unit (optional) ... 77 Indications During Recording ... 78 Indications During Playback And Digital Dubbing... 79 Warning Indications ...

  • Page 10: Getting Started

    AC Power Adapter/Charger AA-V68U DC OUT jack NOTES: If you connect the camcorder’s DC cord to the adapter during battery charging, power is supplied to the camcorder and charging stops. When using the AC Power Adapter/Charger, be marks are sure to use the supplied power cord only.

  • Page 11: Installing The Battery Pack

    ** The BN-V856U battery, as well as the AA-V80U AC Power Adapter/Charger for charging it, is included in the optional VU-V856KITU Extended-Use Battery Pack Kit. Installing The Battery Pack The battery pack does not charge while in the camcorder. Before installation, make sure the battery pack has been charged fully. Battery cover BN-V607U x 2 BN-V607U &...

  • Page 12: Indoor Use

    Indoor Use When using the camcorder indoors, you can use the AC Power Adapter/Charger (provided) instead of a battery. Remove. CONNECT DC CORD TO CAMCORDER Insert the coupler of the provided DC cord into the camcorder. CONNECT DC CORD TO AC POWER...

  • Page 13: Date/Time Settings

    24 hours to charge the clock lithium battery. Then perform the date/time setting before using the camcorder. It is also possible to use the camcorder without the date/time setting. NOTE: If you don’t exit the Date/Time Menu, the clock display will not move but the camcorder’s internal...

  • Page 14: Loading/Unloading A Cassette

    Loading/Unloading A Cassette The camcorder needs to be powered up to load or eject a cassette. OPEN/EJECT switch Make sure the window side is facing out. Erase protection switch** OPEN CASSETTE COVER Turn the power on, then slide the OPEN/EJECT switch in the direction of the arrow.

  • Page 15: Recording Mode Setting

    It is recommended that tapes recorded in the LP mode on this camcorder be played back on this camcorder. During playback of a tape recorded on another camcorder, blocks of noise may appear or there may be momentary pauses in the sound.

  • Page 16: Grip Strap Attachment

    Pull firmly to ensure secure attachment. •To use the strap as a hand strap, thread the strap through the length adjuster when attaching it to the camcorder. Sub hand strap eyelet GETTING STARTED START/STOP ATTACH GRIP STRAP TO SUB...

  • Page 17: Tripod Mounting

    TURN ON CAMCORDER Pull out the viewfinder fully. Tripod Mounting Align the tripod’s screw with the mounting socket on the bottom of the camcorder. Diopter adjust lever ADJUST DIOPTER Slide the Diopter Adjust Lever located on the bottom of the viewfinder.

  • Page 18: Remote Control Unit

    Remote Control Unit You can use the RM-V705B to control the camcorder. When using the remote control, be sure to point it at the remote sensor. The transmitted beam effective area for indoor use is approx. 5 m. The transmitted beam may not be effective or may cause incorrect operation if the remote sensor is directly exposed to sunlight or powerful lighting.

  • Page 19: Operation Mode

    White Balance Adjustment settings are effective. Allows you (camcorder operator) to become part of the scene once the Self-Timer: camcorder is set. This mode is similar to the Self-Timer on film cameras. Allows you to play back a recording, Playback: PLAY Allows you to switch off the camcorder.

  • Page 20: Recording

    STOP RECORDING Press START/STOP again to stop recording. • The camcorder re-enters Record-Standby mode. RECORDING pg. 10 – 19). Set the Power Dial to “ ” pg. 13). Even if they don’t appear during pg.

  • Page 21: Adjust Brightness

    If 5 minutes elapse in the Record-Standby mode, power shuts off automatically to conserve energy and protect the heads. To turn the camcorder on again, push back and pull out the viewfinder again. As long as you don’t take out the tape you...
  • Page 22 Recording From The Middle Of A Tape When removing a tape on which you were recording, or when you resume recording on a tape after playing back the recording previously made (without taking the tape out between recordings), perform this proce- dure.
  • Page 23 When recording is resumed, the time code starts counting up again from “00:00:00”. This means the camcorder may record the same time codes as those existing in a previously recorded scene. To prevent leaving a blank portion on a tape, perform the procedure in “Recording From The Middle of A Tape”...
  • Page 24 Zoom Select any one of the three powers of magnification and get “closer” to the subject ( Simply set the zoom switch to either zoom in (towards “T”) or zoom out (towards “W”). The zoom speed is variable — the quicker you set the zoom switch, the quicker the zoom action. NOTES: In Full Auto mode (when the Power Dial is set to “...

  • Page 25: Advanced Features

    Press the Select Dial twice. Selection is complete and the menu disappears. NOTES: Connect the camcorder to a TV and set “ON SCREEN” to “ON” in the Date/Time Menu. The display appears on the connected TV . The Indicator/Display function overrides these settings.
  • Page 26 ENGAGE 5S MODE Then press START/STOP. The tally lamp lights and beep sounds to indicate the start of recording, and after 5 seconds the camcorder enters Record-Standby mode. • If you press and hold START/STOP within 5 seconds after recording starts, Record- Standby mode is not engaged.
  • Page 27 Self-Timer Once the camcorder is set, the camcorder operator can become part of the scene in a more natural way adding the final touch to a memorable picture. Lock button Power lamp Power Dial START/STOP button When the START/STOP button is pressed,...
  • Page 28 Snapshot Use your camcorder like a regular camera and take a snapshot, or several of them in succession. PHOTO During snapshot SNAPSHOT button Select Dial SELECT OPERATION MODE First turn the Power Dial to “ ” while pressing down the lock button located on the dial.
  • Page 29 FULL* (Snapshot mode with no frame) MULTI 4 (Multi-Analyzer 4) : There is a momentary camera shutter-type blackout. Motor Drive mode: Keeping the SNAPSHOT Button pressed provides an effect similar to serial photography. (The interval between the still pictures: approx. 0.7 seconds.) FRAME* (Snapshot mode with frame)
  • Page 30 Menus The Recording Menu allows you to set these functions: Recording Mode, Wide Mode, Zoom Magnification, Digital Image Stabilizer, Gain Up, Date/Time Menu, System Menu . The following selection procedure applies to Recording Mode, Wide Mode, Zoom Magnifica- tion, Stabilization and Gain Up . Please refer to pages 31, 32 for details.
  • Page 31 REC MODE WIDE MODE ZOOM GAIN UP TO DATE / TIME MENU TO SYSTEM MENU REC MODE (Recording mode) You can change the tape recording speed. LP tape speed is slower than SP, allowing LP to record 1.5 times longer than SP. NOTES: Tapes shot in LP mode are recommended to be played back on this unit.
  • Page 32 During Full-Auto mode, 40X is selected automatically. DIS (Digital Image Stabilizer) When recording while holding the camcorder in your hand, or when shooting a subject with little or no contrast, subtle hand movements will cause shakiness in the recorded image.
  • Page 33 System Menu The System Menu allows you to set the following functions: Snapshot, Scene, Beep/Tally, Wind Cut, Sound Mode, ID numbers and Demonstration Mode. Lock button Power Dial Select Dial SELECT OPERATION MODE First turn the Power Dial to “ ” while pressing down the lock button located on the dial, make sure the viewfinder is pulled out.

  • Page 34: Photo Mode

    P.AE/Effects ( confirm how these functions operate. When the camcorder is turned off, “DEMO. MODE” is set to “OFF”. NOTE: If a tape is in the camcorder, the Demo mode cannot be turned on. Advanced Features (Cont.) PIN-UP FULL MULTI 4 ANIM.

  • Page 35: Start Recording

    FADE/WIPE Effects IMPORTANT: If certain P.AE/Effects ( pg. 42) are activated, some Fade/Wipe Effects cannot be used. If you select a Fade/ Wipe Effect that is unusable in the current situation, the indication blinks. Use these to spice up the transition from one scene to the next. You can also vary transitions from scene to scene.
  • Page 36 Press START/STOP to start recording, and the Fade In or Wipe In occurs automatically. ACTIVATE FADE OUT OR WIPE OUT When you want to stop recording the scene, press START/STOP. Before the camcorder enters the Record-Standby mode, the Fade Out or Wipe Out occurs automatically. RECORDING...
  • Page 37 RESUME RECORDING If you start recording a new scene within 5 minutes of the end of the previous recording (without having turned the camcorder’s power off), the previous scene wipes out, revealing the new scene. Previous scene end Wipe In...
  • Page 38 Random Variations When is selected, the camcorder chooses one of the fades/wipes at random. RECORDING NOTE: The Picture Wipe/Dissolve feature is not available when Random Fader is activated. START/STOP button Advanced Features (Cont.) START RECORDING Press START/STOP. The camcorder does the rest, selecting an effect at random.
  • Page 39 FADER AND WIPE MENU MENU FADER — WHITE FADER — BLACK FADER — MOSAIC FADER — B.W WIPE — CORNER WIPE — WINDOW WIPE — SLIDE WIPE — DOOR WIPE — SCROLL WIPE — SHUTTER Fade in or out with a white screen. Fade in or out with a black screen.
  • Page 40 The new scene wipes in over the previous one from the center toward the top and bottom of the screen. When this function is activated, the camcorder randomly selects the effect used in scene transition (from the Fade and Wipe effects).
  • Page 41 P.AE/Effects IMPORTANT: If certain Fades or Wipes ( P.AE/Effect that is unusable in the current situation, the effect’s symbol begins flashing. You can choose any one of the effects from the P.AE/Effect Menu. FOCUS AUTO EXPOSURE AUTO W. BALANCE AUTO FADER / WIPE P.
  • Page 42 White Balance ( pg. 46) is initially set to but can be changed to your desired setting. When Twilight is chosen, the camcorder automatically adjusts the focus from approx. 10 m to infinity. From less than 10 m, adjust the focus manually.
  • Page 43 Manual Focus Adjustment The camcorder, in most cases, adjusts the focus from approx. 5 cm to infinity automatically. However, when focusing is difficult or when the subject is not in the middle of the viewfinder, adjust the focus manually. Factory preset is “AUTO”.
  • Page 44 Exposure Control Usually this is adjusted automatically. However, when the background is too bright or too dark in compari- son with the subject, the exposure could be corrected manually. Factory preset is “AUTO”. Lock button Power Dial Select Dial SELECT OPERATION MODE First turn the Power Dial to “...
  • Page 45 Iris Lock Use this function when shooting a moving subject, when zooming, when the subject changes its distance (thus its size in the viewfinder), or when you want to lock the brightness level. When the subject is close, keep the iris locked. Even when the subject moves away from you, the image will not darken.
  • Page 46 A term that refers to the correctness of color reproduction under various lighting. If the white balance is correct, all other colors will be accurately reproduced. The white balance is usually adjusted automatically. However, the more advanced camcorder operator would prefer to control this function manually and achieve a more professional color/tint reproduction.
  • Page 47 Manual White Balance Operation If the camera is operating in manual mode, perform a Manual White Balance when shooting under various types of lighting White paper Lock button Power Dial Select Dial SELECT OPERATION MODE Follow steps 1 through 4 of the white balance adjustment ( pg.

  • Page 48: Playback

    You can watch what you’ve recorded in the viewfinder. Power Dial Power lamp Lock button SELECT OPERATION MODE Turn the Power Dial to “PLAY” while pressing down the lock button located on the dial. The Power lamp comes on. PULL OUT VIEWFINDER Pull out the viewfinder.
  • Page 49 To temporarily stop playback, press 6/4. Press again to resume playback. If still playback contin- ues for more than about 3 minutes, the camcorder’s Stop mode is automatically engaged. After 5 minutes in the stop mode, the camcorder’s power is automatically turned off.

  • Page 50: Advanced Features

    Press the Play button to start playback. ACTIVATE ZOOM Press the zoom buttons (T/W) on the remote control. Make sure the remote control is pointed at the camcorder's remote sensor. • Pressing T zooms in. END ZOOM Press and hold W until magnification returns to normal.
  • Page 51 START PLAYBACK Press the Play button (4). ACCESS PLAYBACK EFFECT SELECT MENU Point the remote control at the camcorder’s remote sensor and press EFFECT. The PLAY- BACK EFFECT Select Menu appears. SELECT PLAYBACK EFFECT Move the pointer and highlight bar to the desired effect by pressing EFFECT.

  • Page 52: Playback Menu

    Playback Menu The Playback Menu allows you to set the following functions: Playback Sound (32 kHz, 48 kHz), Synchro Comp, Display and Time Code . The following procedure applies to all except Synchro Comp ( 48kHz MODE FULL SOUND 32kHz MODE SOUND1 SYNCHRO 0 .
  • Page 53 Playback Sound During playback, the camcorder detects the sound mode in which the recording was made, and plays the sound back. Select the type of sound to accompany your playback picture. (32 kHz is preset to “SOUND 1” and 48 kHz is preset to “FULL SOUND”.)

  • Page 54: Basic Connections

    VCR/TV Connection (when connecting directly to the camcorder) Please refer to your VCR and/or TV instruction manual(s) when connecting. To AV OUT connector Connector is under the cover. Core filter VIDEO/AUDIO cable (provided) PLAYBACK Basic Connections To VIDEO IN connector...
  • Page 55 AV OUT connector. When using the provided VIDEO/AUDIO cable, make sure you connect the end of the cable with the core filter to the camcorder. The core filter improves performance of equipment. Make sure you adjust the TV sound volume to its minimum level to avoid a sudden burst of sound when the camcorder is turned on.
  • Page 56 CONFIRM POWER-OFF STATUS Make sure the camcorder’s power is off. ATTACH AND LOCKS Align the mark on the camcorder with the one on the AC Charger Station and slide the camcorder to the AC Charger Station in the direction of the arrow. Slide the lock lever on the AC Charger Station in the direction of the arrow until it clicks.
  • Page 57 The charging time for two BN-V607U battery packs is approx. 190 minutes. NOTE: To charge the battery pack installed in the camcorder, be sure to switch off the camcorder first. If it is not switched off, charging will not begin.

  • Page 58: Advanced Connections

    Connection to the Digital Printer GV-DT1 (optional) allows you to print out the images or to transfer the captured image from the Digital Printer to a personal computer. It is also possible to copy recorded scenes from the camcorder onto another video unit equipped with a DV connector. This function is called Digital Dubbing ( pg.
  • Page 59 NOTES: You cannot use the battery pack installed in the camcorder as the power supply since a digital signal is output from the DV OUT/IN connector only when using the AC Power Adapter/Charger or the optional AC Charger Station.

  • Page 60: Editing

    Dubbing You can copy recorded scenes from the camcorder onto a videotape. Refer to your VCR’s instruction manual for details. PLAY STOP RM-V705B (provided) (Recording deck) MAKE CONNECTIONS Connect the camcorder to your VCR as shown in the illustration on page 54 or 56.

  • Page 61: Digital Dubbing

    Digital Dubbing It is also possible to copy recorded scenes from the camcorder onto other video unit equipped with a DV connector. Since a digital signal is sent, there is little if any image or sound deterioration. Coupuler To DV OUT/IN connector Connector is under the cover.

  • Page 62: Using The Optional Station Kit

    (A) (B) NAME PHILIPS PANASONIC IMPORTANT Although the MBR is compatible with JVC VCRs and those of many other makers, it may not work with yours or may offer limited functions. NOTES: SANYO If the VCR’s power doesn’t come on in step 1, try another code from the VCR CODE LIST.

  • Page 63: Random Assemble Editing

    EDIT connector on the AC Charger Station to the VCR’s remote pause terminal using an editing cable. If you use a JVC VCR not equipped with a remote pause terminal or a non-JVC VCR, connect the AC Charger Station’s EDIT connector to the remote control’s remote pause connector using an editing...
  • Page 64 Since time codes register time only as accurately as seconds, the time code total time may not match the total program time exactly. Turning off the camcorder’s power erases all registered Edit-In and Edit-Out points. If you use Sepia or Monotone P.AE/Effects, you can’t use the Dissolve or Black &...
  • Page 65 When the editing cable is connected to the Pause terminal during dubbing, make sure the remote control is pointed at the VCR’s sensor, and that the path between the two is unobstructed. If, during Random Assemble Editing, you press any button on the camcorder, its Record-Standby mode is automatically engaged.

  • Page 66: For More Accurate Random Assemble Editing

    Some VCRs make the transition from Record-Standby to Record mode faster than others. Even if you begin editing for the camcorder and the VCR at exactly the same time, you may lose scenes you wanted, or find that you’ve recorded scenes you didn’t want. For a cleanly edited tape, confirm and adjust the timing of the camcorder against your VCR.
  • Page 67 Adjustment of VCR‘s against Camcorder Timing (Recording deck) Select Dial ACCESS PLAYBACK MENU Point the remote control at the camcorder’s remote sensor and press R.A. EDIT ON/OFF to make the Random Assemble Editing menu disappear, then press MENU. The Playback Menu appears on the TV screen.

  • Page 68: Troubleshooting

    If, after following the steps in the chart below, the problem still exists, please consult your nearest JVC dealer. SYMPTOM 1. No power is supplied. 2. “SET DATE/TIME!” appears. 3. Recording cannot be performed. 4. There is no playback picture.
  • Page 69 SYMPTOM 10. The tape is moving, but there’s no picture. 11. In the 5-Second mode, recording ends before 5 seconds have elapsed. 12. Snapshot mode cannot be used. 13. Digital Zoom doesn’t work. 14. P.AE/Effects and Fade/ Wipe Effects don’t work. 15.
  • Page 70 Edit-In and Edit-Out points, as they will all be erased ( pg. 37). • The camcorder automati- cally shuts off after 5 minutes have elapsed in the Record-Standby mode. Make sure you continue operations within 5 minutes...
  • Page 71 SYMPTOM 25. During recording, sound cannot be heard. 26. During recording, the date/time does not appear. 27. The indicators and messages do not appear on screen. 28. The indicators do not appear in the viewfinder. 29. The viewfinder indications blink. 30.
  • Page 72 If the indication remains even though you repeat the above two or three times, please consult your nearest JVC dealer. 34 • To protect the battery, it is recommended to charge it in places with a temperature of 10°C to 30°C (50°F to 86°F) (...

  • Page 73: After Use

    AFTER USE Cleaning The Camcorder Open switch (BATTERY) Battery cover Battery pack REMOVE POWER SUPPLY Remove the battery pack or disconnect the AC Charger Station ( pg. 10 – 12). CLEAN EXTERIOR Wipe gently with a soft cloth. •Put cloth in diluted mild soap and wring it well to wipe off heavy dirt.

  • Page 74: Controls, Indications And Connectors

    CONTROLS, INDICATIONS AND CONNECTORS Camcorder Connector cover Pull this out to open. Stereo microphone For use when recording. Lens hood Turn this counterclockwise to release. Lens cover Opens when the viewfinder is pulled out with the Power Dial set to any position except “PLAY”...
  • Page 75 17) Pull out when recording. & Power dial ( pg. 19) Turning the camcorder on/off, recording or playback is possible. START/STOP button ( Starts recording or stops recording to make the camcorder enter the record-standby mode. Zoom switch (T/W) ( Adjusts zoom during recording.

  • Page 76: Ac Charger Station (Optional)

    In such a case, first try turning the camcorder on again, or unplug the JLIP connection cable from the AC Charger Station’s JLIP connector. Then, initialize or run the software again.

  • Page 77: Remote Control Unit (Optional)

    Remote Control Unit (optional) The RM-V712U remote control unit is included in the optional VU-V63KITU Station Kit. PAUSE IN connector ( Connects to a camcorder using an editing cable when performing Random Assemble Editing. START/STOP button ( Starts recording, or stops recording and puts the camcorder in the record-standby mode.

  • Page 78: Indications During Recording

    Appears when the wind cut mode is engaged to cut down on noise created by wind. ( Displays the 5 second mode recording or animation recording mode. Displays the sound mode for approx. 5 seconds after turning on the camcorder. Displays the date/time.

  • Page 79: Indications During Playback And Digital Dubbing

    Appears while in the digital dubbing mode.* Displays the date/time. Displays the brightness of the display. Displays the time code. Appears during digital dubbing when this camcorder is used as a recorder ( 32kHz SOUND1 DEC 25 ’ 98 TC 01 : 28 : 15 –...

  • Page 80: Warning Indications

    Press the reset button after removing the power supply (battery, etc.), and wait a few minutes for the indication to clear. When it does, you can resume using the camcorder. If the indication remains, consult your nearest JVC dealer.

  • Page 81: Cautions

    AC wall outlet other than American National Standard C73 series type use an AC plug adapter, called a “Siemens Plug”, as shown. For this AC plug adapter, consult your nearest JVC dealer. Battery Packs The supplied battery pack is a lithium-ion battery.

  • Page 82: Main Unit

    Also refer to the Cleaning Cassette’s instructions. If, after using the Cleaning Cassette, the problems still exist, consult your nearest JVC dealer. Mechanical moving parts used to move the video heads and video tape tend to become dirty and worn out over time.
  • Page 83 Serious malfunctioning If malfunctioning occurs, stop using the unit immediately and consult your local JVC dealer. The camcorder is a microcomputer-controlled device. External noise and interference (from a TV, a radio, etc.) might prevent it from function- ing properly.

  • Page 84: Specifications

    Operating temperature Dimensions Weight Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject to change without notice. CAMCORDER : DC 6.3 V (using AC Power Adapter/Charger) DC 7.2 V (using Battery) : Approx. 6.5 W...

  • Page 85: Glossary Of Terms

    (See “White Balance”.) AC Power Adapter/Charger Used when charging the battery. Or, when connected directly to the camcorder, it can be used as a power supply. Auto focus Focus can be set for automatic adjustment, for beginners who find the adjustment difficult.

  • Page 86: Index

    Auto Shut off ... Battery ... Battery Low ... Beep/Tally ... Charging ... Cinema ... Classic Film ... Cleaning The Camcorder ... Connections ... Date/Time Display ... Date/Time Settings ... Demonstration Mode ... Digital Dubbing ... Digital Image Stabilizer ...
  • Page 87 P.AE/Effects ... Picture Wipe/Dissolve ... Playback Menu ... Playback Zoom ... Power (AC/Battery) ... Random Assemble Editing ... Record Safety Tab ... Record-Standby ... Recording Format ... Recording Mode ... Recording Menu ... Remote Control ... Self-Timer ... Sepia ... Set VCR Brand ...
  • Page 88 VICTOR COMPANY OF JAPAN, LIMITED Printed in Japan COPYRIGHT© 1998 VICTOR COMPANY OF JAPAN, LTD. 0598HOV...
