- Page 1 IP Phone Quick Guide LIP-8002E/8002AE Please read this manual carefully before operating your set. Retain it for future reference.
-
Page 2: Important Safety Information
Laws. LG-Ericsson reserves the right to make changes in specifications at any time without notice. The information furnished by LG-Ericsson in this material is believed to be accurate and reliable, but is not warranted to be true in all cases. -
Page 3: Regulatory Information
LIP-8002E/2AE Quick Guide Regulatory information European Union Declarations of Conformity LG-Ericsson Co., Ltd. declare that the equipment specified in this document bearing the “ CE” mark conforms to the European Union Radio and Telecommunications Terminal Equipment Directive(R&TTE 1999/5/EC), including the Electromagnetic Compatibility Directive(2004/108/EC) and Low Voltage Directive(2006/95/EC). - Page 4 LIP-8002E/2AE Quick Guide LIP-8002E/8002AE The LG-Ericsson IP phone (LIP-8002E/8002AE) is Internet Protocol (IP) phones designed to support hosted telephony services over a managed IP network. The LIP-8002E/8002AE Phone has fixed feature buttons, flexible buttons that are configurable, and dial pad buttons as shown in the figure below.
- Page 5 LIP-8002E/2AE Quick Guide LIP-8002E/8002AE Keyset User Operation The following is provided as quick reference for commonly used features/functions. Complete instructions are included in the User Guide. Placing a Call: ICM Line – • Lift handset or press SPEAKER button. • Dial the extension number from the keypad.
- Page 6 LIP-8002E/2AE Quick Guide Delete Auto Call Number Redial (ACNR): • Press the REDIAL button if it has been registered as Flexible key. (iPECS-CM/MG) • When placing an outgoing call to a busy party, press the CALL BACK button. Answering a Call while idle: ICM Line –...
- Page 7 LIP-8002E/2AE Quick Guide Conference: A Conference flex button should be programmed. • Place a call to first member. • If first member answer, press Conf flex button and place a call to second member. • If last member answer, press Conf flex button, twice.
- Page 8 LIP-8002E/2AE Quick Guide 1=Unconditional, 2=Busy, 3=No Answer, 4=Busy/No Answer , 0=Remote • For Forward code 1-4, dial destination number and press * or the SAVE button. • For Forward code 0, press * or the SAVE button. • Dial forwarded station number, password and *.
- Page 9 Note: LIP-8002E/8002AE IP-Phone can be powered by either AC adaptor or Power over Ethernet (PoE, class 1). To use AC power, use only the LG-Ericsson Approved AC power adaptor, which you can order separately. To use PoE, your connected LAN must support PoE.
- Page 10 LIP-8002E/2AE Quick Guide Flex Button Program • Press the TRANS/PGM button. • Press the flexible button to be programmed. • Press TRANS/PGM button and User Program Code (refer to the following table). • Press the HOLD/SAVE button. (iPECS-CM/MG) 1) To assign Fixed or Number •...
- Page 11 LIP-8002E/2AE Quick Guide Code Function Remark Authorization Code (Password) Entry Input up to 12 digits DID Call Wait Button Message Wait in Exec/Sec Pair Send SMS Message Register Mobile Ext. Activate Mobile Ext. Register Mobile Ext. CLI Set Wake Up Time...
- Page 12 LIP-8002E/2AE Quick Guide System User Program Codes (SBG) Code Function Remark Intercom Answer Mode Select ICM Signal mode, 1:HF, 2:Tone, 3:Privacy Headset/Speakerphone mode 0:H, 1:S Select Headset Ring type 1:S, 2:H, 3:Both Set Wake-Up Time Once/Permanent & Hour/Min Erase Wake-Up Time...
- Page 13 LIP-8002E/2AE Quick Guide System User Program Codes (iPECS-CM/MG) Code Function Remark Answer Mode(H/T/P) Select ICM Signal mode, 1:HF, 2:Tone, 3:Privacy Station Name Program Input up to 12 characters iPECS-CM: Index(1-5) + Type(1~5, 1:Once, 2:Daily, 3:Mon~Fri, 4:Mon~Sat, 5:Date), + HHMM(24-hour clock) +...
- Page 14 LIP-8002E/2AE Funktionstaster FORSTYR EJ – Blokerer for indkommende kald. VOLUMEN – Justerer lydniveauet for ringe tone, headset, og håndfri, samt justerer display kontrast (når telefonen er ledig). OMST/PROG – Omstillingstast. Anvendes til omstilling af kald og programmering. HOLD/GEM – Anvendes til at parkere samtaler, samt gemme programmeringsinformation.
- Page 15 LIP-8002E/2AE Kort brugervejledning Dette er en kort brugervejledning. Yderligere information findes i brugervejledningen. Foretage et opkald: Til et lokalnummer – Løft røret eller tryk på HÅNDFRI tasten. Tast lokalnummeret på tastaturet. Til et telefonnummer – Løft røret eller tryk på HÅNDFRI tasten.
- Page 16 LIP-8002E/2AE Sæt te samtalen på HOLD: Tryk på HOLD/GEM tasten under samtalen. Tryk på LINIE tasten for at genoptage samtalen. Konference: Foretag det første opkald. Tryk på KONF. tasten. Foretag det andet opkald. Tryk på KONF. tasten to gange.
- Page 17 LIP-8002E/2AE Programmering af Flextaster Tryk på OMST/PROG tasten. Tryk på den Flextaste der ønskes programmeret. Tryk på OMST/PROG tasten og tast bruger program-koden (se tabellen herunder). Tryk på HOLD/GEM tasten. System Bruger Program-koder Kode Funktion Bemærk Ringetone ved interne kald Vælg Ringe Tone 1-8...
- Page 18 LIP-8002E/2AE System Bruger Program-koder (fortsat) Kode Funktion Bemærk Aktiver forudbestemt besked Vælg besked nr. 00-20 Opret brugerdefineret besked (besked nr. 00) Max. 24 tegn Opret konference rum Slet konference rum Vis konference gruppe Headset/håndfri Headset ringe type 1:Håndfri, 2:Headset, 3:Begge...
