Dear Customer, Thank you for purchasing the JVC Compact VHS camcorder. Before use, please read the safety information and precautions contained in the following pages to ensure safe use of this product. Using This Instruction Manual • All major sections and subsections are listed in the Table Of Contents ( •...
16 – 19, 46 – 53) Menu Adjustment pg. 30, 31, 32) Integrated Auto Light pg. 24) Camcorder is designed exclusively for the VHS-C video cassette. Only cassettes marked VHS-C can be used with this unit. HQ VHS is compatible with existing VHS equipment.
USING THE REMOTE CONTROL UNIT Random Assemble Editing ... 56 Insert Editing (VIDEO) ... 60 Insert Editing (Insert A Still Image From The Built-in Memory Onto A Tape) ... 61 Audio Dubbing ... 62 TROUBLESHOOTING INDEX Controls, Connectors And Indicators ... 66 Indications...
Failure to do so can result in a camcorder malfunction. Power This camcorder’s 3-way power supply system lets you To AC outlet choose the most appropriate source of power. NOTES: No function is available without power supply.
The CHARGE indicator may not light properly with a brand new battery pack, or with one that has been stored for an extended period. In this case, remove and reattach the battery pack and recharge it. The CHARGE indicator should blink during recharging. If it doesn’t, contact your nearest JVC dealer. To DC IN jack...
See “SAFETY PRECAUTIONS” ( on safe handling of lithium batteries. To avoid losing the battery and/or battery holder, place the camcorder with the grip side up as shown in the illustration when inserting/removing the battery. (cont.) pg. 2) for information...
“EXIT”, and press it. The Menu Screen reappears with the highlight bar on “RETURN”. CLOSE MENU SCREEN Press the Select Dial. NOTE: To display the date and time in the camcorder’s display and on a connected TV, see “Date/Time Insert” pg. 28).
System Select Switch MENU Button Select Dial Power Switch Viewfinder Tape length indicator Display Menu Screen NEXT M . W . B . AUTO D . ZOOM TELE MACRO DATE TIME TAPE LENGTH PICTURE FINE SNAPSHOT FULL RETURN TAPE LENGTH TAPE LENGTH Setting Menu EXIT...
Make sure the Erase Protection tab is in the position that allows recording. If not, slide the tab. Some cassettes have removable tabs. If the tab has been removed, cover the hole with adhesive tape. The cassette holder cannot be opened while the camcorder is in the record mode.
Power Zoom Lever Recording Start/Stop Button Set “POWER” to “CAMERA” (“AUTO” or “PRO.”) PAUSE GETTING STARTED Grip Adjustment EXPAND LOOP Separate the Velcro strip. INSERT HAND Pass your right hand through the loop and grasp the grip. ADJUST STRAP LENGTH Adjust so your thumb and fingers can easily operate the Recording Start/Stop Button and Power Zoom Lever.
Then tighten the screw. CAUTION: When using a tripod, be sure to open and extend its legs fully to stabilise the camcorder. To prevent damage to the unit caused by falling over, do not use a small-sized tripod. , then fold it back and...
Set the System Select Switch to “VIDEO”, then set the Power Switch to “CAMERA” (“AUTO” or “PRO.”). •The power lamp lights and the camcorder enters the Record-Standby mode. •The scene you are aimed at appears on the viewfinder screen, with the word “PAUSE”...
The LENS COVER warning blinks for about 5 seconds when the camcorder is turned on with the cover closed. To turn the tally lamp off during recording, refer to pgs.
Open/Close Ring When shooting a still image, it is not recorded onto the tape, but it is stored in the camcorder's built-in memory in the selected Picture Mode. A stored still image data can be transferred to a PC, saved, and processed using a Paint...
Page 17
When the Power Switch is set to “AUTO”, it is not possible to select the Snapshot mode. You can use the Snapshot mode you selected in the “PRO.” mode. If a Snapshot is taken while the camcorder is in the WIDE mode ( pg. 31), the Snapshot image is recorded without the black bars at the top and bottom of the screen.
FEATURE: PURPOSE: There are two image settings you can choose from when storing in the camcorder's memory: FINE and STANDARD. FINE allows you to shoot up to approx. 30 still images in a format based on JPEG (Joint Photographic Experts Group). Since the quality of image is better than “STANDARD”, “FINE”...
Page 19
To store the still images you shot, we recommend that you transfer them to a computer and save them on disk ( pg. 47), or transfer them to a VCR connected to the camcorder and record them onto a tape. When the remaining number indicator displays “0” (blinking), it is not possible to continue storing pictures until you delete some shots to make room for new ones.
This interesting feature lets you record two types of digital still images that look like photographs onto a tape, as well as keeping them in the camcorder’s built-in memory. It is a great way to spice up footage of events such as parties, weddings and graduations.
Page 21
47). The image data transferred to a Windows PC can also be further processed using Mr. Photo Gold. If a snapshot is taken while the camcorder is in the WIDE mode ( recorded without the black bars at the top and bottom of the screen.
Page 22
Zoom in Display Approximate zoom ratio Power Zoom Lever RECORDING FEATURE: PURPOSE: To produce the zoom in/out effect, or an instantaneous change in image magnification. Digital circuitry extends the maximum magnification offered by optical zoom. This system is called Digital Zoom out Zoom.
Retake FEATURE: PURPOSE: To re-record certain segments. OPERATION: 1) Make sure the camcorder is in the Record–Standby mode. 2) Press either RETAKE to reach the start point for new recording. Pressing “F” forwards the tape and pressing “R” reverses it.
30 cm. between the video light and people or objects. Do not use near flammable or explosive materials. It is recommended that you consult your nearest JVC dealer for replacing the video light. RECORDING Basic Features (cont.) Video Light...
RECORDING Advanced Features [Ex.: Fader] Fade in Display EFFECT After 2 sec. MOSAIC EFFECT MOSAIC FADER MOSAIC SHUTTER SLIDE (No indication) System Select Switch EFFECT Button Recording Start/Stop Button Fade/Wipe These effects let you make pro-style scene transitions. Fade- or wipe-in works at recording start, and fade- or wipe-out works at recording end or when you enter Record–Standby mode.
Display After 2 sec. P.AE : SEPIA : SEPIA SEPIA SPORTS ND : ND EFFECT FG : TWILIGHT S1/2000 NEGA/POSI P.AE Button System Select Switch RECORDING Programme AE With Special Effects All you have to do to access any of the variety of shooting effects is press P.AE.
Page 27
Use together with Wide ( for the authentic look of a classic Hollywood movie. • When the Power Switch is set to “D.S.C.”, the scene is stored in black-and-white in the camcorder’s memory. SPORTS Sports High shutter speed clearly captures fast-moving action.
Page 28
Even if you shoot with the date/time displayed during Digital Still Camera Shooting, they will not be recorded. AUTO DATE Your camcorder automatically records the date for about 5 seconds after recording is initiated in the following situations: • After changing the date.
TITLE DATE TIME DISP. RETURN CONGRATULATIONS Instant Titles The camcorder has eight preset titles in memory. You can superimpose one of them above a previously stored title as shown in the illustration on left. SELECT OPERATION SYSTEM AND MODE Set the System Select Switch to “VIDEO”, and set the Power Switch to “PRO.”.
RECORDING Advanced Features (cont.) Using Menu For Detailed Adjustment This camcorder is equipped with an easy-to-use, on-screen menu system that simplifies many of the more detailed camcorder settings. SELECT OPERATION SYSTEM AND MODE The operation system depends on the function you wish to select.
Page 31
WIDE S.LX NORMAL Allows you to superimpose one of eight preset titles ( TITLE* Makes the date/time settings appear in the camcorder or on a connected monitor DATE/TIME pg. 28). DISP.* Menu Screen Available Using The MENU Button This Menu Screen cannot be accessed while recording.
Page 32
This feature allows you to set the parameters for Self-Timer ( Lapse recording ( TALLY LAMP* This number is necessary when connecting the camcorder to a device such as a computer JLIP ID NO. using the J terminal (JLIP). The numbers range from 01 to 99. Factory setting is 07.
System Select Switch Select Dial Power Switch Display Menu Screen FOCUS AUTO EXPOSURE AUTO WIDE S . LX TITLE DATE TIME DISP. RETURN EXPOSURE EXPOSURE Menu AUTO MANU EXIT Manual Exposure Screen Exposure control level counter To brighten the image –...
RECORDING Advanced Features (cont.) Focusing AUTO FOCUS The camcorder’s Full Range AF system offers continuous shooting ability from close-up to infinity. However, correct focus may not be obtainable in the situations listed below (in these cases use manual focusing): •When two subjects overlap in the same scene.
System Select Switch Select Dial Power Switch Display Menu Screen FOCUS AUTO EXPOSURE AUTO WIDE S . LX TITLE DATE TIME DISP. RETURN FOCUS FOCUS Menu AUTO MANU EXIT Manual Focus Screen MANUAL FOCUS NOTE: You should already have made the necessary viewfinder adjustments ( pg.
If the white balance is correct, all other colours will be accurately reproduced. The white balance is usually adjusted automatically. However, the more advanced camcorder operator would prefer to control this function manually and achieve a more professional colour/tint reproduction.
Page 37
White paper System Select Switch Select Dial Power Switch Display Menu Screen NEXT M . W . B . AUTO D . ZOOM TELE MACRO DATE TIME TAPE LENGTH PICTURE FINE SNAPSHOT FULL RETURN M.W.B. M.W.B. Menu AUTO : FINE : CLOUD : HALOGEN EXIT...
Page 38
Self-Timer You can set the delay between pressing the Recording Start/Stop button and the actual start of recording. If you secure the camcorder, you (or whoever is operating the camcorder) can enter the scene before recording starts. NOTE: Before performing the following steps, make sure that: The System Select Switch is set to “VIDEO”...
RELEASE ANIMATION MODE Set “REC TIME” in the Menu screen to “OFF”. NOTES: For best results, make sure the camcorder is secured when shooting in Animation or Time- Lapse mode. Fade- or wipe-in/out cannot be performed during Animation or Time-Lapse shooting.
Press REW (2) to rewind, or FF (3) to fast-forward the tape during Stop mode. NOTES: The camcorder shuts off automatically after about 5 minutes in Stop mode. To turn on again, set the Power Switch to “POWER OFF”, then to “PLAY”.
“AT” blinks. When Auto Tracking finishes, the indication disappears. NOTES: When noise bars appear during playback, the camcorder enters the Auto Tracking mode and “AT” is displayed. Manual Tracking may not work with tapes recorded on other VCRs or camcorders.
Set to “VIDEO”. REW (2) Button FF (3) Button PLAY/PAUSE (4/6) Button STOP (5) Button COUNTER R/M Button VIDEO PLAYBACK Power Switch FEATURE: PURPOSE: To pause during playback. OPERATION: 1) Press PLAY/PAUSE (4/6) during playback. 2) To resume normal playback, press PLAY/PAUSE (4/6) again.
Using The Cassette Adapter Cassette Adapter Use this to play back a VHS-C video cassette recorded with this camcorder on a VHS VCR. It is fully compatible with any VHS video cassette recorder. The C-P7U adapter is battery powered and automatically performs tape loading and unloading.
These are some basic types of connections. When making connections, refer also to your VCR and TV instruction manuals. Basic Connections Use the provided Video and Audio cables. Connector cover* Connection For Tape Dubbing Use the provided Video and Audio cables. Connector cover* * When connecting the cables, open this cover.
CONNECT VCR OUTPUT TO TV INPUT Refer to your VCR’s instruction manual. SUPPLY POWER Turn on the camcorder, the VCR and the TV. SELECT MODE Set the VCR to its AUX input mode, and set the TV to its VIDEO mode.
The playback picture can also be viewed on a con- nected TV ( same as described in this section. When viewing a playback picture on a connected TV, it may jitter slightly. To move the page back Basic Playback pg. 44, 45). Camcorder operation is the...
Use the AC Power Adapter/Charger as the power supply instead of the battery pack. The still images stored in the camcorder’s memory are not automatically removed after being transferred to the PC. If you wish to remove those still images from the camcorder's memory, delete them ( Windows ®...
DELETE RETURN Normal Screen D.S.C. PLAYBACK Using Menu For Detailed Adjustment This camcorder is equipped with an easy-to-use, on-screen menu system that simplifies many of the more detailed camcorder settings. SELECT OPERATION SYSTEM AND MODE Set the System Select Switch to “D.S.C.”, and set the Power Switch to “PLAY”.
Page 49
CAUTION: While “ENTER” is selected on the Delete Execute Menu and it is blinking, switching off the camcorder or removing the power supply unit (battery pack or AC Power Adapter/Charger) may cause the camcorder’s built-in memory to become corrupt. Never remove the power supply unit at this stage.
Page 50
System Select Switch MENU Button Select Dial Display MENU Menu Screen INDEX SLIDE SHOW 1 SLIDE SHOW 2 PROTECT DELETE RETURN < > E X I T INDEX INDEX Menu Playback Screen D.S.C. PLAYBACK Index You can view all still images stored in memory six at a time.
Page 51
System Select Switch MENU Button Select Dial Power Switch Display MENU Menu Screen INDEX SLIDE SHOW 1 SLIDE SHOW 2 PROTECT DELETE RETURN < > EXIT PROTECT PROTECT Menu < > EXIT PROTECT A padlock mark appears. Protect This mode helps prevent accidental erasure of images. Put a padlock mark next to the desired still image, and that still image cannot be deleted.
Page 52
System Select Switch MENU Button Select Dial Display MENU Menu Screen INDEX SLIDE SHOW 1 SLIDE SHOW 2 PROTECT DELETE RETURN DELETE DELETE Menu SELECT EXIT < > N E X T DELETE In case of “SELECT” Delete Select Menu DELETE CANCEL ENTER...
Page 53
FINE mode. If the remaining number of shots is not 30 in the FINE mode or 60 in the STANDARD mode when “ALL” is selected on the DELETE Menu, initialize the camcorder’s memory ( pg. 47).
Retake (rewind)/Quick Review ( — — Functions same as snapshot button on the camcorder. ( pg. 16, 20) Functions the same as the Recording Start/Stop Button on the camcorder. Ineffective Zoom in and out ( pg. 22) — — —...
Transmitted beam effective area Remote sensor When using the remote control, be sure to point it at the remote sensor. The illustration shows the approximate transmitted beam effective area for indoor use. The transmitted beam may not be effective or may cause incorrect operation outdoors or when the remote sensor is directly exposed to sunlight or powerful lighting.
Page 56
VCR CTL BUTTONS VCR BRAND NAME (A) (B) PHILIPS IMPORTANT Although the MBR is compatible with JVC VCRs and those of many other makers, it may not work with yours or may offer limited functions. SANYO NOTES: SELECO, SHARP SONY...
Page 57
CONNECT TO . . . JVC VCR EQUIPPED WITH REMOTE PAUSE TERMINAL Connect the editing cable to the Remote PAUSE terminal. JVC VCR NOT EQUIPPED WITH REMOTE Open the cover. PAUSE TERMINAL BUT EQUIPPED WITH R.A. EDIT CONNECTOR Connect the editing cable to the R.A.EDIT connector.
Page 58
Pressing ON/OFF clears all in- and out-points from memory. Leave a small margin for error around each in-point to ensure the scene is recorded in its entirety. Turning off the camcorder’s power erases all registered in- and out-points. (cont.)
Page 59
Random Assemble Editing. The playback deck must be an R.A. Edit- capable JVC VCR. The recording deck can be... a VCR other than JVC, or a JVC VCR which has neither a Remote PAUSE nor an R.A. EDIT connector How to use: AV IN —...
Page 60
ENGAGE INSERT EDITING MODE Press and hold INSERT, and without releasing INSERT, press and release PAUSE. The Insert Editing mode is engaged. When the scene the camcorder is aimed at appears on the screen, go to the next step. BEGIN INSERT EDITING Press START/STOP.
Page 61
Insert Editing (Insert A Still Image From The Built-in Memory Onto A Tape) You can insert a still image stored in the camcorder's built- in memory into a previously recorded tape, replacing a section of the original recording with minimal picture distortion at the in- and out-points.
Page 62
Press and hold A. DUB, and without releasing A. DUB, press and release PAUSE. BEGIN AUDIO DUBBING Press PLAY. When the counter reaches “0:00:00”, Audio Dubbing stops automatically and the camcorder enters the Audio Dub-Standby mode. Microphone END AUDIO DUBBING Press STOP. NOTES: Do not press FF or REW during Audio Dub-Standby, or the edit points will not be accurate.
TROUBLESHOOTING If, after following the steps in the chart below, the problem still exists, please consult your JVC dealer. The camcorder is a microcomputer-controlled device. External noise and interference (from a TV, a radio, etc.) might prevent it from functioning properly. In such cases, first disconnect its power supply unit (battery pack, AC Power Adapter/Battery Charger, etc.) and clock battery;...
Page 64
Change the Switch position to “VIDEO” ( pg. 40). The video heads are dirty or worn out. Consult your nearest JVC dealer for head cleaning or replacement. This is normal. The Counter Memory Function has been activated pg. 42).
Page 65
(including ones for which you performed the “Protect” function) stored in the camcorder’s memory. If you wish to keep any of the still images that are stored in memory, before initialization first transfer them to a PC and save them. If image data is corrupt, transfer is impossible.
Page 66
& INDEX Controls, Connectors And Indicators 3 4 5 6...
Tripod Mounting Socket ... are located beneath the Random Assemble Editing ( such as a personal computer. For further details consult your nearest JVC dealer. is not possible if the VCR is not equipped with a J terminal. Be careful not to cover this area; a sensor necessary for shooting is built-in here.
Page 68
30MIN MERRY CHRISTMAS 25. 12. 99 FINE 12 FADER NORM LENS COVER PAUSE INDEX TAPE END 22 : 50 : 00 INDEX & Indications...
Page 69
38, 55 recording. In such a case, use the optional Cleaning Cassette. If, after using it, the problems pg. 29 still exist, consult your nearest JVC dealer. pg. 28 ”. When the power is ” blinks (battery — does not necessarily mean that the battery pg.
Page 70
• Do not use near flammable or explosive materials. • It is recommended that you consult your nearest JVC dealer for replacing the video light. General Battery Precautions • When the C-P6U or C-P7U (cassette adapter) is not functioning even when correctly operated, the battery is exhausted.
... vertically, in their original cases. Main Unit 1. For safety, DO NOT ..open the camcorder’s chassis..disassemble or modify the unit..short-circuit the terminals of the battery pack. Keep it away from metallic objects when not in use.
Page 72
Serious malfunctioning If malfunctioning occurs, stop using the unit immediately and consult your local JVC dealer. CAUTIONS For Your Maintenance 1. After Use Set the Power Switch to “POWER OFF” to turn off the camcorder.
•Active Carrying Bag CB-V7U •Remote Control Unit RM-V700U Some accessories are not available in some areas. Please consult your nearest JVC dealer for details on accessories and their availability. E & O.E. Design and specifications subject to change without notice.
