DIGITAL VIDEO CAMERA
GR-DVL822
Please visit our Homepage on the World Wide Web and
answer our Consumer Survey (in English only):
http://www.jvc-victor.co.jp/english/index-e.html
For Accessories:
http://www.jvc-victor.co.jp/english/accessory/
INSTRUCTIONS
CONTENTS
AUTOMATIC DEMONSTRATION
GETTING STARTED
TAPE
RECORDING & PLAYBACK
TAPE RECORDING ........................ 16 – 20
TAPE PLAYBACK .......................... 21 – 24
MEMORY CARD
RECORDING & PLAYBACK
MEMORY CARD RECORDING ......... 26 – 27
MEMORY CARD PLAYBACK ............ 28 – 29
ADVANCED FEATURES .................... 30 – 34
ADVANCED FEATURES
FOR RECORDING ........................... 36 – 43
USING MENUS FOR
DETAILED ADJUSTMENT .............. 44 – 49
DUBBING ..................................... 50 – 52
USING THE REMOTE CONTROL UNIT .... 53 – 62
SYSTEM CONNECTIONS ......................... 63
REFERENCES
DETAILS ............................................. 65
TROUBLESHOOTING ...................... 66 – 69
USER MAINTENANCE ............................ 70
CAUTIONS .................................... 71 – 73
SPECIFICATIONS ........................... 74 – 75
INDEX ......................................... 76 – 82
TERMS ............................... 83 – Back Cover
For Customer Use:
Enter below the Model No. and Serial
No. which is located on the bottom of the
camcorder. Retain this information for
future reference.
Model No.
Serial No.
LYT1038-001A
ENGLISH
6
7 – 14
15 – 24
25 – 34
35 – 63
64 – Back Cover
EN
Advertisement
Chapters
Table of Contents
Related Manuals for JVC GR-DVL822U
Summary of Contents for JVC GR-DVL822U
-
Page 1: Digital Video Camera
DIGITAL VIDEO CAMERA GR-DVL822 Please visit our Homepage on the World Wide Web and answer our Consumer Survey (in English only): http://www.jvc-victor.co.jp/english/index-e.html For Accessories: http://www.jvc-victor.co.jp/english/accessory/ INSTRUCTIONS CONTENTS AUTOMATIC DEMONSTRATION GETTING STARTED TAPE RECORDING & PLAYBACK TAPE RECORDING ... 16 – 20 TAPE PLAYBACK ... -
Page 2: Safety Precautions
However, live recording and LCD monitor/viewfinder playback are possible anywhere. Use the JVC BN-V408U/V416U/V428U battery packs and, to recharge them or to supply power to the camcorder from an AC outlet, use the provided multi-voltage AC Adapter. (An appropriate conversion adapter may be necessary to accommodate different designs of AC outlets in different countries.) -
Page 3: Important Product Safety Instructions
When the equipment is installed in a cabinet or on a shelf, make sure that it has sufficient space on all sides to allow for ventilation (10 cm (3-15/16") or more on both sides, on top and at the rear). Do not block the ventilation holes. - Page 4 The following notes concern possible physical damage to the camcorder and to the user. When carrying, be sure to always securely attach and use the provided shoulder strap. Carrying or holding the camcorder by the viewfinder and/or the LCD monitor can result in dropping the unit, or in a malfunction.
-
Page 5: Provided Accessories
NOTE: In order to maintain optimum performance of the camcorder, provided cables may be equipped with one or more core filter. If a cable has only one core filter, the end that is closest to the filter should be connected to the camcorder. -
Page 6: Automatic Demonstration
LCD monitor or viewfinder. How To Attach The Lens Cap To protect the lens, attach the provided lens cap to the camcorder as shown in the illustration. NOTE: To confirm the lens cap is on correctly make sure the cap is flush to the camera. -
Page 7: Table Of Contents
GETTING STARTED GETTING STARTED CONTENTS Power ... 8 – 9 Grip Adjustment ... 10 Viewfinder Adjustment... 10 Shoulder Strap Attachment ... 10 Tripod Mounting... 10 Date/Time Settings... 11 Loading/Unloading A Cassette ... 12 Recording Mode Setting ... 13 Loading A Memory Card ... 14 Picture Quality/Image Size Setting ... -
Page 8: Power
Set the Power Switch to “OFF”. Connect the AC Adapter to the camcorder Plug the AC Adapter into an AC outlet The CHARGE lamp on the camcorder blinks to indicate charging has started. When the CHARGE lamp stops blinking but stays lit, charging is finished. -
Page 9: Power
VU-V856 KIT : BN-V856U battery pack & AA-V80U AC Power Adapter/Charger Read the kit's instruction manual before using. Also, by using the optional JVC VC-VBN856U DC Cord, it will be possible to connect BN-V840U or BN-V856U battery packs to the camcorder and supply power directly to the camcorder. -
Page 10: Grip Adjustment
Strap . Confirm the strap is not twisted. Tripod Mounting When attaching the camcorder to a tripod, extend its legs to stabilize the camcorder. It is not advised to use small sized tripods. This may cause damage to the unit by falling over. -
Page 11: Date/Time Settings
48, 49). Set the Power Switch to “ down the Lock Button located on the switch. The power lamp lights and the camcorder is turned on. Press the MENU/BRIGHT wheel in to access the Menu Screen. Rotate the MENU/BRIGHT wheel to select “... -
Page 12: Loading/Unloading A Cassette
If the tape does not load properly, open the cassette holder cover fully and remove the cassette. A few minutes later, insert it again. When the camcorder is suddenly moved from a cold place to a warm environment, wait a short time before opening the cassette holder cover. -
Page 13: Recording Mode Setting
It is recommended that tapes recorded in the LP mode on this camcorder be played back on this camcorder. During playback of a tape recorded on another camcorder, blocks of noise may appear or there may be momentary pauses in the sound. ” while pressing... -
Page 14: Loading A Memory Card
34. ATTENTION Do not insert/remove the memory card while the camcorder is turned on, as this may cause the memory card to be corrupted or cause the camcorder to become unable to recognize whether or not the card is installed. -
Page 15: Recording & Playback
TAPE RECORDING & PLAYBACK TAPE RECORDING & PLAYBACK CONTENTS TAPE RECORDING ... 16 – 20 Basic Recording... 16 Journalistic Shooting ... 17 Self-Recording ... 17 Operation Mode ... 17 Zooming ... 18 Video Light ... 19 Time Code ... 20 TAPE PLAYBACK ... -
Page 16: Tape Recording
(Approximate) Shooting while using the viewfinder: Close the LCD monitor. • The power lamp lights and the camcorder enters the Record-Standby mode. “PAUSE” is displayed. 3 min appears while recording is in progress. 2 min (Blinking) To Stop Recording . -
Page 17: Journalistic Shooting
Self- Recording To turn on the camcorder, set the Power Switch to any operation mode except “OFF”while pressing down the Lock Button located on the switch. Power lamp Lock Button VIDEO/MEMORY Switch (Open the LCD monitor to access this switch.) When the Power Switch is set to “... -
Page 18: Zooming
Zoom in (T: Telephoto) 1x W 1 x W 2 x W Zoom out (W: Wide angle) Zoom display 1 x W Approximate zoom ratio Power Zoom Lever FEATURE: PURPOSE: To produce the zoom in/out effect, or an instanta- neous change in image magnification. 4 x W OPERATION: Zoom In... -
Page 19: Video Light
Do not affix it directly to a surface such as a table top. It is recommended that you consult your nearest JVC dealer for replacing the video light. Video Light... -
Page 20: Time Code
When recording is resumed, the time code starts counting up again from “00:00:00”. This means the camcorder may record the same time codes as those existing in a previously recorded scene. To prevent this, perform “Recording From The Middle of A Tape”... -
Page 21: Tape Playback
Speaker NOTES: If Stop mode continues for 5 minutes when power is supplied from a battery, the camcorder shuts off automatically. To turn on again, set the Power Switch to “OFF”, then to “PLAY”. The playback picture can be viewed in the LCD monitor, viewfinder or on a connected TV ( You can also view the playback picture on the LCD monitor with it flipped over and pushed against the camera body. -
Page 22: Connections
Connections These are some basic types of connections. When making the connections, refer also to your VCR and TV instruction manuals. A. Connection to a TV or VCR equipped with an S-VIDEO IN and A/V input connectors Connector cover* * When connecting the cables, open this cover. ** The Audio cable is not required for watching still images only. - Page 23 Make sure all units are turned off. Connect the camcorder to a TV or VCR as shown in the illustration ( pg. 22). If using a VCR . . . go to step 3. If not . . . go to step 4.
-
Page 24: Blank Search
... press 5. NOTES: In step 3, if the current position is at a blank portion the camcorder searches in the reverse direction, and if the current position is at a recorded portion the camcorder searches in the forward direction. -
Page 25: Memory Card
MEMORY CARD RECORDING & PLAYBACK MEMORY CARD RECORDING & PLAYBACK CONTENTS MEMORY CARD RECORDING... 26 – 27 Basic Shooting (Snapshot) ... 26 – 27 MEMORY CARD PLAYBACK ... 28 – 34 Normal Playback ... 28 Auto Playback ... 28 Index Playback ... 29 Viewing File Information ... -
Page 26: Memory Card Recording
Displays the quality of image: F (Fine) or S (Standard) (in order of quality) ( Display Basic Shooting (Snapshot) You can use your camcorder as a digital still camera for taking snapshots. NOTE: You should already have performed the procedures listed below. - Page 27 If shooting is not performed for approx. 5 minutes when the Power Switch is set to “ power is supplied from the battery pack, the camcorder shuts off automatically to save power. To perform shooting again, set the Power Switch to “OFF”, then to “...
-
Page 28: Memory Card Playback
These thumbnail images cannot be transferred to a PC. Images shot with devices (such as JVC GR-DVM70) that are not compatible with DCF cannot be viewed with this camcorder; “UNSUPPORTED FILES” will be displayed. -
Page 29: Index Playback
MENU/BRIGHT Wheel INDEX Button INFO Button Selected image Index number Index Screen Info Screen : 1 0 0 - 0 0 1 0 ’ Operation mode indicator Battery indicator Playback Screen Menu Screen M E NU D I SPLAY OF F RETURN Index Playback You can view several different images stored on the... -
Page 30: Advanced Features
MENU/BRIGHT Wheel Power Switch Lock Button VIDEO/MEMORY Switch (Open the LCD monitor to access this switch.) Display Menu Screen MENU PROTECT DELETE DPOF NO . RESET FORMAT D I SPLAY M E NU PROTECT RENT PROT . AL L CANC . AL L RETURN PROTECT Screen ROTECT... -
Page 31: Deleting Files
RETURN CAUTION Do not remove the memory card or perform any other operation (such as turning off the camcorder) during deletion. Also, be sure to use the provided AC Adapter, as the memory card may be corrupted if the battery becomes exhausted during deletion. If the memory card becomes corrupted, initialize it. -
Page 32: Setting Print Information (Dpof Setting)
AL L 1 ? EXECUTE RETURN Setting Print Information (DPOF Setting) This camcorder is compatible with the DPOF (Digital Print Order Format) standard in order to support future systems such as automatic printing, which records information about the still images you wish to print (such as the number of prints to make). - Page 33 Fast-Forward (3) Button MENU/ Rewind Button (2) BRIGHT Wheel VIDEO/MEMORY Switch (Open the LCD monitor to access this switch.) Display DPOF Screen DPOF SHEETS RETURN DPOF SHEETS DPOF SAVE? EXECUTE CANCEL TO PRINT BY SELECTING STILL IMAGES AND NO. OF PRINTS Perform steps 1 through 3 on pg.
-
Page 34: Making A New Folder
“RETURN” and press it. Do not perform any other operation (such as turning off the camcorder) during initialization. Also, be sure to use the provided AC Adapter, as the memory card may be corrupted if the battery becomes exhausted during initialization. -
Page 35: Advanced Features
ADVANCED FEATURES FOR RECORDING ... 36 – 37 USING MENUS FOR DETAILED ADJUSTMENT ... 44 – 49 DUBBING ... 50 – 52 USING THE REMOTE CONTROL UNIT ... 53 – 62 SYSTEM CONNECTIONS ... 63 ADVANCED FEATURES CONTENTS Night-Alive ... 36 Program AE With Special Effects ... -
Page 36: For Recording
• “Video light” when LIGHT OFF/AUTO/ON is set to “AUTO” ( pg. 19). During Night-Alive, it may be difficult to bring the camcorder into focus. To prevent this, use of manual focus and/or a tripod is recommended. MENU/BRIGHT Wheel Lock Button... - Page 37 43) is initially set to can be changed to your desired setting. When Twilight is chosen, the camcorder automatically adjusts the focus from approx. 10 m (32 ft) to infinity. From less than 10 m (32 ft), adjust the focus manually.
-
Page 38: Fade/Wipe Effects
IMPORTANT Some Fade/Wipe Effects cannot be used with certain modes of Program AE with special effects ( 37). If an unusable Fade/Wipe Effect is selected, its indicator blinks or goes out. Lock Button MENU/BRIGHT Wheel Power Switch Recording Start/Stop Button VIDEO/MEMORY Switch (Open the LCD monitor to access this switch.) - Page 39 Fader And Wipe Menu Menu FADER — WHITE FADER — BLACK FADER — B.W WIPE — CORNER WIPE — WINDOW WIPE — SLIDE WIPE — DOOR WIPE — SCROLL WIPE — SHUTTER Effect Fade in or out with a white screen. Fade in or out with a black screen.
-
Page 40: Snapshot (For Tape Recording)
Rotate the MENU/BRIGHT wheel to select the RETURN” and press it twice. The Menu Screen SNAPSHOT RECORDING Press SNAPSHOT. “PHOTO” appears while the for approx. 6 seconds, then the camcorder re-enters the Record-Standby mode. for approx. 6 seconds, then the normal recording resumes. -
Page 41: Auto Focus/Manual Focus
FEATURE: PURPOSE: The camcorder’s Full Range AF system offers continuous shooting ability from close-up (as close as approx. 5 cm (2") to the subject) to infinity. However, correct focus may not be obtainable in the situations listed below (in these cases use manual focusing): •... -
Page 42: Exposure Control
Exposure Control Manual exposure adjustment is recommended in the following situations: • When shooting using reverse lighting or when the background is too bright. • When shooting on a reflective natural background such as at the beach or when skiing. •... -
Page 43: White Balance Adjustment
If the white balance is correct, all other colors will be accurately reproduced. The white balance is usually adjusted automatically. However, more advanced camcorder operators control this function manually to achieve a more professional color/tint reproduction. Set the Power Switch to “... -
Page 44: Using Menus For Detailed Adjustment
D I SPL Normal Screen USING MENUS FOR DETAILED ADJUSTMENT For Recording Menu This camcorder is equipped with an easy-to-use, on-screen menu system that simplifies many of the more detailed camcorder settings ( Set the Power Switch to “ down the Lock Button located on the switch. - Page 45 • When shooting scenes with movement in various directions. • When shooting scenes with low-contrast backgrounds. Switch off this mode when recording with the camcorder on a tripod. The “ ” indicator blinks or goes out if the Stabilizer cannot be used.
- Page 46 Menu Screen Explanations (cont.) TELE MACRO WIDE MODE CINEMA SQUEEZE S.WIDE WIND BEEP BEEP MELODY TALLY : Factory-preset NOTES: The “ MANUAL” settings are effective only when the Power Switch is set to “ “ SYSTEM” functions which are set when the Power Switch is set to “ Switch is set to “PLAY”...
- Page 47 The date/time is always displayed. TIME Time code is not displayed. CODE Time code is displayed on the camcorder and on the connected TV. Frame numbers are not displayed during recording. CLOCK ADJ. Allows you to set the current date and time ( QUALITY Refer to “Picture Quality/Image Size Setting”...
-
Page 48: For Playback Menu
NOTES: “REC MODE” can be set when the Power Switch is set to “PLAY” or “ When “S/AV INPUT” is set to “ON”, camcorder playback cannot be viewed on the AV output. pg. 60). Set the VIDEO/MEMORY Switch to “VIDEO”, Press the MENU/BRIGHT wheel in. -
Page 49: Playback Sound
Playback Sound During tape playback, the camcorder detects the sound mode in which the recording was made, and plays the sound back. Select the type of sound to accompany your playback picture. According to the menu access explanation on pg. 48, select “SOUND MODE” or “12BIT MODE” from the Menu Screen and set it to the desired parameter. -
Page 50: Dubbing
* When connecting the cables, open this cover. ** Connect when an S-Video cable is not used. To Use This Camcorder As A Recorder . . . 1. Set the VIDEO/MEMORY Switch to “VIDEO”, then set the camcorder’s Power Switch to “PLAY”... -
Page 51: Dubbing To Or From A Video Unit Equipped With A Dv Connector
DV connector [To Use This Camcorder As A Recorder] 1. Set this camcorder’s VIDEO/MEMORY Switch to “VIDEO”, then the Power Switch to “PLAY” while pressing down the Lock Button located on the switch. 2. Set “REC MODE” to “SP” or “LP” in the Menu Screen ( 3. -
Page 52: Dubbing Still Images Recorded On A Tape To A Memory Card
SNAPSHOT Button Power Switch Lock Button Display Menu Screen COPY – OF F Play/Pause MENU/ Button (4/6) BRIGHT Wheel VIDEO/MEMORY Switch (Open the LCD monitor to access this switch.) DUBBING Dubbing Still Images Recorded On A Tape To A Memory Card Still images can be dubbed from a tape to a memory card. -
Page 53: Using The Remote Control Unit
USING THE REMOTE CONTROL UNIT The Full-Function Remote Control Unit can operate this camcorder from a distance as well as the basic operations (Playback, Stop, Pause, Fast-Forward and Rewind) of your VCR. It also makes additional playback functions possible. If you want to perform Random Assemble Editing ( –... - Page 54 Switch set to the camera position (“ ” or “ Transmits the beam signal. Zoom in/out ( pg. 18) — — — — Functions the same as the Recording Start/Stop Button on the camcorder. — — — — — — — & –...
-
Page 55: Playback Zoom
1) Press PLAY (4) to find the scene of interest. 2) Press the Zoom Buttons (T/W) on the remote control. Make sure the remote control is pointed at the camcorder's remote sensor. Pressing T zooms in. To end zoom, press and hold W until magnification returns to normal. - Page 56 You are now ready to try Random Assemble BRAND Editing. CODE Although the MBR is compatible with JVC VCRs and those of many other makers, it may not work with yours or may offer limited functions. NOTES: If the VCR’s power does not come on in step 1, try another code from the VCR CODE LIST.
- Page 57 A JVC VCR equipped with a remote pause connector ..connect the editing cable to the Remote PAUSE connector. A JVC VCR not equipped with a remote pause connector but equipped with an R.A.EDIT connector . . . To EDIT ...
-
Page 58: Random Assemble Editing
Since time codes register time only as accurately as (optional) seconds, the time code total time may not match the total program time exactly. Turning off the camcorder’s power erases all registered Edit-In and Edit-Out points. ON/OFF (cont.) SELECT SCENES... - Page 59 9 : 39 Remote Sensor PAUSE VCR REC STBY Rewind the tape in the camcorder to the beginning of the scene you want to edit and press PAUSE (6). Point the remote control towards the VCR’s remote sensor and press VCR REC STBY (q6), or manually engage the VCR’s Record-Pause mode.
-
Page 60: For More Accurate Editing
Some VCRs make the transition from Record-Pause to Record mode faster than others. Even if you begin editing for the camcorder and the VCR at exactly the same time, you may lose scenes you wanted, or find that you have recorded scenes you did not want. For a cleanly edited tape, confirm and adjust the timing of the camcorder against your VCR. -
Page 61: Audio Dubbing
Make sure you only edit recorded areas. If feedback or howling occurs during TV playback, move the camcorder’s microphone away from the TV, or turn down the TV’s volume. If you change from 12-bit to 16-bit in mid-recording and then use the tape for Audio Dubbing, it is not effective from the point where 16-bit recording began. -
Page 62: Insert Editing
PAUSE (6). Press and hold INSERT (w) on the remote control, then press PAUSE (6). “6w” and the Time Code (min.:sec.) appear and the camcorder enters Insert-Pause mode. Press START/STOP to begin editing. • Confirm the insert at the time code you checked in step 1. -
Page 63: System Connections
DV connector-equipped capture board. When using a DV cable, be sure to use the optional JVC VC-VDV206U or VC-VDV204U DV cable depending on the type of DV connector (4 or 6 pins) on the PC, or use the DV cable provided with the capture board. - Page 64 REFERENCES CONTENTS DETAILS ... 65 TROUBLESHOOTING ... 66 – 69 USER MAINTENANCE ... 70 CAUTIONS ... 71 – 73 SPECIFICATIONS ... 74 – 75 INDEX ... 76 – 82 Controls, Connectors And Indicators ... 76 – 77 Indications ... 78 – 82 TERMS ...
-
Page 65: Details
Be sure to use it only in well-ventilated areas. • Set the Power Switch to “PLAY”, “ • Disconnect the AC adapter from the camcorder. • Unplug the AC adapter from the AC outlet. • Detach the battery from the camcorder. -
Page 66: Troubleshooting
If, after following the steps in the chart below, the problem still exists, please consult your nearest JVC dealer. The camcorder is a microcomputer-controlled device. External noise and interference (from a TV, a radio, etc.) might prevent it from functioning properly. In such cases, first disconnect its power supply unit (battery pack, AC Adapter, etc.) and wait a few minutes;... - Page 67 • When the LCD monitor's fluores- cent light reaches the end of its service life, images on the LCD monitor become dark. Consult your nearest JVC dealer. CORRECTIVE ACTION • Press the BACKLIGHT Button pg. 42). • Set “PROGRAM AE” to “SPOTLIGHT”...
- Page 68 LCD monitor indications appear distorted. This is not a defect. • The speaker volume is too great. • Since the analog input mode is engaged, the camcorder is in the Record-Standby mode. — — — — TROUBLESHOOTING CORRECTIVE ACTION •...
- Page 69 If the indication remains even though you repeat the above two or three times, please consult your nearest JVC dealer. Do not eject the cassette. This will cause damage to the tape. • Eject the cassette once and re- insert it, then check if the indication clears.
-
Page 70: User Maintenance
After Use Turn off the camcorder. Slide and hold OPEN/EJECT in the direction of the arrow, then pull the cassette holder cover open until it locks. The cassette holder opens automatically. Remove the cassette. Press “PUSH HERE” to close the cassette holder. -
Page 71: Cautions
In case of connecting the unit’s power cord to an AC wall outlet other than American National Standard C73 series type use an AC plug adapter, called a “Siemens Plug”, as shown. For this AC plug adapter, consult your nearest JVC dealer. Plug adapter Video Light... - Page 72 20 seconds, it stops automatically. Also refer to the cleaning cassette’s instructions. If, after using the cleaning cassette, the problems still exist, consult your nearest JVC dealer. Mechanical moving parts used to move the video heads and video tape tend to become dirty and worn out over time.
- Page 73 Serious malfunctioning If malfunctioning occurs, stop using the unit immediately and consult your local JVC dealer. The camcorder is a microcomputer-controlled device. External noise and interference (from a TV, a radio, etc.) might prevent it from functioning properly.
-
Page 74: Specifications
Speaker Format Signal format Recording/Playback format Cassette Tape speed Maximum recording time (using 80 min. cassette) Camcorder General : DC 11.0 V (Using AC Adapter) DC 7.2 V (Using battery pack) : Approx. 4.5 W : Approx. 5.7 W : Approx. 2.8 W : 79 mm x 89 mm x 184 mm (3-1/8"... -
Page 75: Specifications
Storage media Compression system File size Picture quality Approximate number of storable images S-Video Output Input Video output Video input Audio output Audio input Output Input EDIT Power requirement U.S.A. and Canada Other countries Output Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject to change without notice. -
Page 76: Index
INDEX Controls, Connectors And Indicators PLAY ^ & *... - Page 77 Controls OPEN/EJECT Switch ... • Stop Button [5] ... • BACKLIGHT Button ... • Rewind Button [2] ... • NIGHT Button ... Play/Pause Button [4/6] ... Fast-Forward Button [3] ... Monitor Open Button [PUSH OPEN] ... Diopter Adjustment Control ... Battery Release Button [BATT.
-
Page 78: Indications
Appears when the Insert Editing (w) or Insert Editing Pause (6w) mode is engaged. ( Displays the sound mode for approx. 5 seconds after turning on the camcorder. Displays the Time Code. Displays the image size. Appears and blinks during shooting. - Page 79 LCD Monitor/Viewfinder Indications During Both Tape And Memory Card Recording Appears when the Power Switch is set to “ • : Appears when Night-Alive is engaged. • : Appears when “GAIN UP” is set to “AUTO” and the shutter speed is being automatically adjusted.
- Page 80 LCD Monitor/Viewfinder Indications During Tape Playback SOUND BLANK SEARCH VOLUME 116 : 21 : 25 LCD Monitor/Viewfinder Indications During Memory Card Playback BR I GHT 0 ’ INDEX Indications (cont.) Displays the sound mode. Displays the Blank Search mode. Displays the tape speed. Appears while a tape is running.
-
Page 81: Warning Indications
Appears when the date/time is not set. Appears when the built-in clock battery runs out and the previously set date/time is erased. Consult your nearest JVC dealer for replacement. Appears for 5 seconds after power is turned on if the lens cap is attached. -
Page 82: Index
When an error indication appears, the camcorder turns off automati- cally. Remove the power supply (battery, etc.) and wait a few minutes for the indication to clear. When it does, you can resume using the camcorder. If the indication remains, consult your nearest JVC dealer. -
Page 83: Terms
Brighten The LCD Monitor ... Channels (Left/Right) ... Charge The Battery Pack ... Cinema ... Classic Film ... Clean The Camcorder ... Connections ... pg. 8, 9, 22, 23, 50, 57, 63 Darken The LCD Monitor ... Date/Time Display ... - Page 84 SD Memory Card ... Self-Recording ... Sepia ... Set Remote Control/VCR Code ... Shuttle Search ... Shutter Speed ... Slow Shutter ... Snapshot ... Snapshot Mode ... Snow ... Sound Mode ... Speaker Volume ... Specifications ... Sports ... Spotlight ... Squeeze ...
