SERVICE MANUAL

CONTENTS

LCD COLOR TV

LC-13SH1U

MODEL

In the interests of user-safety (Required by safety

regulations in some countries) the set should be

restored to its original condition and only parts

identical to those specified be used.

This document has been published to be used for

after sales service only.

The contents are subject to change without notice.

LC-13SH1U

S74Y1LC13SH1U

Page

Chapters

Table of Contents

Summary of Contents for Sharp LC-13SH1U

Page 1: Table Of Contents
LC-13SH1U SERVICE MANUAL S74Y1LC13SH1U LCD COLOR TV LC-13SH1U MODEL In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified be used. CONTENTS Page SPECIFICATIONS ..........................
Page 2: Specifications
SPECIFICATIONS <TUNER> ANT. Input ......75ohm Unbal., F type Reference Level ....20Vp-p (CRT Green Cathode) Test Input Signal ....400Hz 30% modulation Description Condition Unit Nominal Limit Picture 45.75 1. Intermediate Freq. Sound 41.25 CH-2 dBµV 2. Color Killer Sens. CH-10 dBµV CH-55...
Page 3 <VIDEO> Description Condition Unit Nominal Limit Horizontal 1. Over Scan Vertical 8500+10MPCD °K ±0.01 2. Color Temperature ( 80% WHITE ) 0.292 ±0.01 0.307 9000 °K ±0.01 3. Color Temperature ( 40% WHITE ) 0.286 ±0.01 0.299 Horizontal line 4. Resolution Vertical line <AUDIO>...
Page 4: Important Safeguards And Precautions
IMPORTANT SAFEGUARDS AND PRECAUTIONS Prior to shipment from the factory, our products are strictly inspected for recognized product safety and electrical codes of the countries in which they are to be sold. However, in order to maintain such compliance, it is equally important to implement the following precautions when a set is being serviced.
Page 5 3. Design Alteration Warning - Do not alter or add to assure correct lead dress in the following areas:a. the mechanical or electrical design of this TV receiver. near sharp edges,b. near thermally hot parts-be Design alterations and additions, including, but not sure that leads and components do not touch limited to circuit modifications and the addition of thermally hot parts,c.
Page 6: Important Service Safety Precaution
IMPORTANT SERVICE SAFETY PRECAUTION Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow: • WARNING Use an AC voltmeter having with 5000 ohm per volt, or higher, sensitivity or measure the AC voltage drop 1.
Page 7 PRECAUTIONS A PRENDRE LORS DE LA REPARATION Ne peut effectuer la réparation qu’ un technicien spécialisé qui s’est parfaitement accoutumé à toute vérification de sécurité et aux conseils suivants. conduite électrique ou une prise de terre branchée AVERTISSEMENT à la terre. 1.
Page 8: Standard Notes For Servicing
STANDARD NOTES FOR SERVICING NOTE: CBA AND PWB MEANS PRINTED WIRING Precautions for Using Lead-free Solder BOARD. 1 Employing lead-free solder Circuit Board Indications Pb free mark (as shown below) indicates lead-free solder, and is attached on the PWBs and service a.
Page 9 Soldering Iron Fig. S-1-3 (2) Lift each lead of the flat pack-IC upward one by one, using a sharp pin or wire to which solder will not adhere (iron wire). When heating the pins, use a fine Fig. S-1-1 tip soldering iron or a hot air desoldering machine.
Page 10 (4) Bottom of the flat pack-IC is fixed with glue to the 2. Installation CBA; when removing entire flat pack-IC, first apply (1) Using desoldering braid, remove the solder from the soldering iron to center of the flat pack-IC and heat foil of each pin of the flat pack-IC on the CBA so you up.
Page 11 Instructions for Handling Semi-conductors Electrostatic breakdown of the semi-conductors may occur due to a potential difference caused by electrostatic charge during unpacking or repair work. 1. Ground for Human Body Be sure to wear a grounding band (1MΩ) that is properly grounded to remove any static electricity that may be charged on the body.
Page 12: Cabinet Disassembly Instructions
CABINET DISASSEMBLY INSTRUCTIONS NOTE: CBA AND PWB MEANS PRINTED WIRING 2. Disassembly Method BOARD. REMOVAL 1. Disassembly Flowchart REMOVE/*UNHOOK/ LOC. PART Fig. This flowchart indicates the disassembly steps to gain UNLOCK/RELEASE/ Note access to item(s) to be serviced. When reassembling, UNPLUG/DESOLDER follow the steps in reverse order.
Page 13 [1] Rear Cabinet Fig. D1 L0170DC...
Page 14 [8] Front Cabinet [6] Speaker L [3] LCD Main CBA [2] Main CBA [5] Function S-10 [7] Speaker R [4] Liquid Crystal Panel Fig. D2 L0170DC...
Page 15 To Liquid Cristal Panel CLN104 CN310A CN311A Function CBA CN321A CN113B CN112B LCD Main CBA CN111B CN104 CN401 CN402 CN103A CN102A CN101A To Liquid Cristal Panel CN403 Main CBA CN404 CN801 CN802 To Speaker To Speaker Fig. D3 L0170DC...
Page 16: Electrical Adjustment Instructions
ELECTRICAL ADJUSTMENT INSTRUCTIONS NOTE: CBA AND PWB MEANS PRINTED WIRING 1. Initial Setting BOARD. General Enter the Service mode. NOTE: Electrical adjustments are required after replacing circuit Set the each initial data as shown on table 1 below. components and certain mechanical parts. It is important to perform these adjustments only after all repairs and Table 1: Initial Data replacements have been completed.
Page 17 3. Flicker Adjustment BUTTON DATA ( on the service ITEM VALUE Note: Use remote control unit remote control ) 1. Enter the Service mode. (See page 5-1) C-DG ( C/D2 ) Vol down 2. Press “2” button on the remote control unit. T h e C-DB ( C/D2 ) Vol down following screen appears.
Page 18: White Balance Adjustment
The following adjustment normally are not attempted Method 2 in the field. Only when replacing the LCD Panel then adjust as a preparation. Test point Adj. Point Mode Input 5. White Balance Adjustment White Purity VIDEO 1 Screen (APL 80% buttons VIDEO 2 Purpose: To mix red, green and blue beams correctly...
Page 19: C-Brt
6. Sub-Brightness Adjustment Purpose: To mix red, green and blue beams correctly for pure white. Symptom of Misadjustment: White becomes bluish or reddish. Confirmation at [VIDEO-1] 1. Set CG951 to 7/5/3 IRE 3-step grayscale. 7 IRE 5 IRE 3 IRE TEST PATTERN (7/5/3 IRE) 2.
Page 20: Troubleshooting
TROUBLESHOOTING Table of Contents for the Troubleshooting Flow Charts Flow Chart Description Page The power cannot be turned on. The fuse blows out. When the output voltage fluctuates. When buzz sound can be heard in the vicinity of power circuit. AL-8V is not outputted.
Page 21: Flow Chart No.1
1. POWER SUPPLY SECTION FLOW CHART NO.1 The power cannot be turned on. See FLOW CHART No.2 <The fuse blows out.> Is the fuse (F601) normal? Check if there is any leak or short-circuiting on the primary circuit component, and service it if defective. (Q601,Q603.T601,D605,D606,D607,D608,C605, C606,C610,C654) Is the AL +3.3V line voltage normal?
Page 22: Al+3.3V Is Not Outputted
FLOW CHART NO.6 AL+3.3V is not outputted. Is 3.3V voltage supplied to the cathode of D514? Check D635,C637 and their periphery circuit, and service it if defective. FLOW CHART NO.7 AL+40V is not outputted. Check D645,D646,C644 and their periphery circuit, and service it if defective.
Page 23: Reg+5V(1) Is Not Outputted
FLOW CHART NO.11 REG+5V(1) is not outputted. approximately 12V voltage supplied to Pin(1) of IC604? Check IC604,C603 and their periphery circuit, and service it if defective. FLOW CHART NO.12 REG+5V(2) is not outputted. Check IC603,C673 and their periphery circuit, and service it if defective. FLOW CHART NO.13 P-ON+3.3V(D) is not outputted.
Page 24: Panel+24V Is Not Outputted
FLOW CHART NO.16 PANEL+24V is not outputted. Check Q501,Q502,Q511 and their periphery circuit, and service it if defective. FLOW CHART NO.17 PANEL+5.4V is not outputted. Check Q503,Q504,Q514 and their periphery circuit, and service it if defective. FLOW CHART NO.18 PANEL-12V is not outputted. Check Q505 and the periphery circuit, and service it if defective.
Page 25: The Key Operation Is Not Functioning
FLOW CHART NO.21 The key operation is not functioning. Re-install the switches (SW101,SW102,SW103, SW104,SW105,SW107,SW116) correctly or replace the poor switch. Check the switches (SW101,SW102,SW103,SW104, SW105,SW107,SW116) and their periphery, and service it if defective. FLOW CHART NO.22 No operation is possible from the remote control unit. Check P-ON+3.3V(D) line and service it if defective.
Page 26: Picture Does Not Appear Normally. (Tuner Input / Video Input/S-Video Input.)
2. VIDEO SIGNAL SECTION FLOW CHART NO.23 Picture does not appear normally. (Tuner input / Video input/S-Video input.) Are the video signals inputted to the specific Check the line between each pin of IC781 and input input terminal? terminal and service it if defective. Are the luminance signals inputted to the Check the line between Pin(1) of IC781 and JK721, Pin(1) of IC781?
Page 27: Audio Is Not Outputted Normally. (Tuner Input.)
3. AUDIO SIGNAL SECTION FLOW CHART NO.25 Audio is not outputted normally. (Tuner input.) Are the SIF signal inputted to the Pin(21) of IC851? Check TU1,SF,IC11,CF32 and their periphery circuit, and service it if defective. Are the audio(L/R) signal inputted to the Pin(4,11) of Check IC851 and the periphery circuit, IC852? and service it if defective.
Page 28: Block Diagrams
BLOCK DIAGRAMS System Control Block Diagram L0171BLS...
Page 29 IF/Video Block Diagram L0171BLIF...
Page 30 Audio Block Diagram L0171BLA...
Page 31 LCD Block Diagram L0171BLLCD...
Page 32 Power Supply Block Diagram L0171BLP...
Page 33 LCD Backlight Block Diagram L01711BLLB...
Page 34: Schematic Diagrams/ Cba's And Test Points
SCHEMATIC DIAGRAMS / CBA’S AND TEST POINTS NOTE: CBA AND PWB MEANS PRINTED WIRING BOARD. Standard Notes Many electrical and mechanical parts in this chassis have special characteristics. These characteristics often pass unnoticed and the protection afforded by them cannot necessarily be obtained by using replacement components rated for higher voltage, wattage, etc.
Page 35 LIST OF CAUTION, NOTES, AND SYMBOLS USED IN THE SCHEMATIC DIAGRAMS ON THE FOLLOWING PAGES: 1. CAUTION: FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH SAME TYPE_A,_V FUSE. ATTENTION: UTILISER UN FUSIBLE DE RECHANGE DE MEME TYPE DE_A,_V. 2.
Page 36 Main 1/5 Schematic Diagram NOTE: CBA AND PWB MEANS PRINTED WIRING BOARD. MAIN 1/5 Ref No. Position IC502 IC503 IC504 IC505 IC506 TRANSISTORS Q401 Q403 Q404 Q405 Q406 Q407 Q427 Q428 Q501 Q502 Q503 Q504 Q505 Q507 Q508 Q509 Q511 Q512 Q513 Q514...
Page 37 Main 2/5 Schematic Diagram NOTE: CBA AND PWB MEANS PRINTED WIRING BOARD. MAIN 2/5 Ref No. Position TRANSISTORS Q408 Q409 Q410 Q411 Q412 Q415 Q416 Q419 Q420 Q421 Q422 Q423 Q424 Q425 Q426 CONNECTORS CN401 CN402 CN403 CN404 L0171SCM2...
Page 38 Main 3/5 Schematic Diagram NOTE: CBA AND PWB MEANS PRINTED WIRING BOARD. MAIN 3/5 Ref No. Position IC11 IC851 IC852 TRANSISTORS Q709 TEST POINT TP300 L0171SCM3...
Page 39 Main 4/5 Schematic Diagram NOTE: CBA AND PWB MEANS PRINTED WIRING BOARD. MAIN 4/5 Ref No. Position IC781 IC801 TRANSISTORS Q701 Q702 Q703 Q704 Q705 Q706 Q707 Q708 Q802 Q803 CONNECTORS CN103A CN801 CN802 8-10 L0171SCM4...
Page 40 Main 5/5 Schematic Diagram CAUTION ! NOTE : CAUTION: FOR CONTINUED PROTECTION AGAINST RISK Fixed voltage ( or Auto voltage selectable ) power supply circuit is used in this unit. The voltage for parts in hot circuit is OF FIRE, REPLACE ONLY WITH SAME TYPE 4A, 125V FUSE. If Main Fuse (F601) is blown, check to see that all components in the power supply measured using hot GND as a ATTENTION: UTILISER UN FUSIBLE DE RECHANGE DE...
Page 41 Function Schematic Diagram NOTE: CBA AND PWB MEANS PRINTED WIRING BOARD. 8-13 8-14 L0171SCF...
Page 42 LCD Main 1/2 Schematic Diagram NOTE: CBA AND PWB MEANS PRINTED WIRING BOARD. LCD 1/2 Ref No. Position IC202 IC275 IC276 IC333 TRANSISTORS Q251 Q252 Q253 Q254 Q272 CONNECTORS CN111B CN112B CN311A CN321A 8-15 8-16 L0171SCLCD1...
Page 43 LCD Main 2/2 Schematic Diagram NOTE: CBA AND PWB MEANS PRINTED WIRING BOARD. LCD 2/2 Ref No. Position IC161 IC181 TRANSISTORS Q121 Q161 CONNECTORS CN113B CN114 CN115 CN310A 8-17 8-18 L0171SCLCD2...
Page 44 Main CBA Top View BECAUSE A HOT CHASSIS GROUND IS PRESENT IN THE POWER CAUTION ! CAUTION: FOR CONTINUED PROTECTION AGAINST RISK Fixed voltage ( or Auto voltage selectable ) power supply circuit is used in this unit. OF FIRE, REPLACE ONLY WITH SAME TYPE 4A, 125V FUSE. SUPPLY CIRCUIT, AN ISOLATION TRANSFORMER MUST BE USED.
Page 45 Main CBA Bottom View CAUTION ! CAUTION: FOR CONTINUED PROTECTION AGAINST RISK BECAUSE A HOT CHASSIS GROUND IS PRESENT IN THE POWER Fixed voltage ( or Auto voltage selectable ) power supply circuit is used in this unit. OF FIRE, REPLACE ONLY WITH SAME TYPE 4A, 125V FUSE. SUPPLY CIRCUIT, AN ISOLATION TRANSFORMER MUST BE USED.
Page 46 Function CBA Top View NOTE: CBA AND PWB MEANS PRINTED WIRING BOARD. FUNCTION Ref No. Position TRANSISTOR Q101 CONNECTOR CLN104A Function CBA Bottom View BL0170F01011-2 8-23 8-24...
Page 47: Waveforms & Voltage Chart
WAVEFORMS & VOLTAGE CHART MAIN LCD MAIN CN101A CN104 CN310A CN311A PIN NO. Voltage / WF No. PIN NO. Voltage / WF No. PIN NO. Voltage / WF No. PIN NO. Voltage / WF No. 12.4 WF11 WF11 WF11 WF16 WF11 WF17 WF11...
Page 48 Pin 7 of CN103A (MAIN) Pin 17 of CN113B (LCD MAIN) WF1 ~ WF10 = Waveforms to be observed at Waveform check points. (Shown in Schematic Diagram.) Input: NTSC Color Bar Signal (with 1kHz Audio Signal) 20µs VIDEO-C 0.2V Pin 9 of CN102A Pin 1 of CN103A Pin 9 of CN103A (MAIN)
Page 49 LCD CBA WF11 ~ WF20 = Waveforms to be observed at Measurement Point Waveform check points. CAUTION! (Shown in Schematic Diagram.) Since the handling of CN310A,CN311A and CN321A tends to lead to destruction easily , be careful of it enough. (especially CN321A.) Input: NTSC Color Bar Signal (with 1kHz Audio Signal) CN101A CN102A...
Page 50 WF21 ~ WF32 = Waveforms to be observed at Waveform check points. (Shown in Schematic Diagram.) Input: NTSC Color Bar Signal (with 1kHz Audio Signal) Pin 8 of CN311A Pin 12 of CN311A Pin 25 of CN321A WF21 WF25 WF29 (LCD MAIN) (LCD MAIN) (LCD MAIN)
Page 51: Wiring Diagram
WIRING DIAGRAM 10-1 L0171WI...
Page 52: Ic Pin Function Descriptions
IC PIN FUNCTION DESCRIPTIONS IC11 (VIF/SIF) IC505 (PST600L) Signal Signal Function Function Name Name Video out Video Output Input Power Supply Video in Video det Input Power Supply Vout Output Power Supply Video det out Video det Output IC506 (NJM78L09A) APC Filter Signal VCO_F/B...
Page 53 Signal Signal Function Function Name Name Adjust Variable De-Emphasis Switching Control SPE FIL Level Switching Control I2C/PARA Control Mode Switching Video Signal Input AGCSW Not Used Video Signal Input MODE Not Used X-COM Video Signal Output FOMO Not Used Y-Com Video Signal Output MUTE Not Used...
Page 54 Signal Function Name Not Used Not Used Switching Control Switching Control Audio (L ch) Input Audio (L ch) Input X-COM Audio (L ch) Output Audio (L ch) Input Audio (L ch) Input Power Supply L0170PIN 11-3...
Page 55: Exploded Views
EXPLODED VIEWS NOTE: CBA AND PWB MEANS PRINTED WIRING BOARD. Cabinet NOTE: The LCD Main CBA is one of two types (Type :A or Type:B). When ordering the LCD Main CBA, only Type: B (new version) is supplied. Therefore, install it by using four screws L9.
Page 56 LCD Panel Display L0170LEX 12-3...
Page 57 Packing Some Ref. Numbers are not in sequence. TAPE TAPE PACKING TAPE PACKING TAPE PACKING TAPE L0170PEX 12-4...
Page 58: Mechanical Parts List
3. PART NO. 4. DESCRIPTION suivants. in USA: Contact your nearest SHARP Parts Distributor to 1. NUMERO DU MODELE 2. NO. DE REF order. For location of SHARP Parts Distributor, Please call Toll-Free; 1-800-BE-SHARP 3.
Page 59 Ref. No. Part No. Description SP802 9HSSD0807XQ002 SPEAKER S0407F10 9HS1EM320121 CARTON 9HS1EM020053 STYROFOAM TOP L0170UA 9HS1EM020054 STYROFOAM BOTTOM L0170UA 9HS0EM301908 SET BAG L0110UA 9HS0EM408420 BAG POLYETHYLENE 235X365XT0.03 9HS1EMN20180 OWNER’S MANUAL L0270UA”EN/FR” 9HSREMT21SH001 REMOTE CONTROL RRMCGA336WJSA 9HSB0M451T0001 DRY BATTERY R6P/2S 9HS1EMN20181 OWNER’S MANUAL SPANISH/WARRANTY 9HS1EMN20157 QUESTIONNAIRE CARD L0170UA...
Page 60: Electrical Parts List
3. PART NO. 4. DESCRIPTION suivants. in USA: Contact your nearest SHARP Parts Distributor to order. For location of SHARP Parts Distributor, 1. NUMERO DU MODELE 2. NO. DE REF Please call Toll-Free; 1-800-BE-SHARP 3.
Page 61 Ref. No. Part No. Description C131 9HSHD1JZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V C132 9HSHD1JZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V C161 9HSA0K470SP062 CHIP ELECTROLYTIC CAP. 47µ/6.3V M C163 9HSA1J010SP062 CHIP ELECTROLYTIC CAP. 1µF/50V M C165 9HSA1J010SP062 CHIP ELECTROLYTIC CAP. 1µF/50V M C171 9HSHD1JJ3CH150 CHIP CERAMIC CAP.
Page 62 Ref. No. Part No. Description C267 9HSA1C100SP062 CHIP E.C CHIP E.C 10µ/16V C268 9HSHD1CK30B105 CHIP CERAMIC CAP. B K 1µF/16V C269 9HSA1J4R7SP062 CHIP ELECTROLYTIC CAP. 4.7µF/50V C270 9HSHD1JK30B104 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V C271 9HSHD1JK30B104 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V C272 9HSA1C100SP062 CHIP E.C CHIP E.C 10µ/16V...
Page 63 Ref. No. Part No. Description CN310A 9HSC9SD50ER003 FPC/FFC CONNECTOR IMSA-9637S-50Y905 CN311A 9HSC9SD20ER003 FPC/FFC CONNECTOR IMSA-9637S-20Y905 CN321A 9HSC9SD30ER003 FPC FFC CONNECTOR IMSA-9637S-30Y905 DIODES D251 9HSD1Z001SS250 SWITCHING DIODE 1SS250 D255 9HSD1Z001SS250 SWITCHING DIODE 1SS250 D256 9HSD1Z00DAN222 SWITCHING DIODE DAN222 TL D271 9HSD1Z001SS250 SWITCHING DIODE 1SS250 D273 9HSD1Z00RB481K...
Page 64 Ref. No. Part No. Description CHIP RES.(1608) 1/10W J 100 Ω R188 9HSRXAJR5Z0101 CHIP RES.(1608) 1/10W J 100 Ω R189 9HSRXAJR5Z0101 CHIP RES.(1608) 1/10W J 56 Ω R201 9HSRXAJR5Z0560 CHIP RES.(1608) 1/10W J 56 Ω R202 9HSRXAJR5Z0560 CHIP RES.(1608) 1/10W 0 Ω R203 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W J 56 Ω...
Page 65 Ref. No. Part No. Description CHIP RES.(1608) 1/10W J 10k Ω R298 9HSRXAJR5Z0103 CHIP RES.(1608) 1/10W 0 Ω R299 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω R341 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω R342 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω R343 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω...
Page 66 Ref. No. Part No. Description 9HSHD1AZ30F105 CHIP CERAMIC CAP. F Z 1µF/10V 9HSE1AMASSL101 ELECTROLYTIC CAP. 100µF/10V M H7 9HSHD1JK30B103 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V 9HSHD1JK30B103 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V 9HSE1JMASSLR47 ELECTROLYTIC CAP. 0.47µF/50V M H7 9HSA1J103TU011 CERAMIC CAP.(AX) B K 0.01µF/50V 9HSHD1JJ3CH470 CHIP CERAMIC CAP.(1608) CH J 47pF/50V 9HSHD1JD3CH6R0...
Page 67 Ref. No. Part No. Description C544 9HSHD1JK30B103 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V C601# 9HST2E104MS037 METALLIZED FILM CAP. 0.1µF/250V C602# 9HST2E104MS037 METALLIZED FILM CAP. 0.1µF/250V C603 9HSE1AMASSL101 ELECTROLYTIC CAP. 100µF/10V M H7 C605 9HSCD2JKP0B103 CERAMIC CAP. B K 0.01µF/500V C606 9HSCD2JKP0B103 CERAMIC CAP.
Page 68 Ref. No. Part No. Description C803 9HSMA1JJS00104 FILM CAP.(P) 0.1µF/50V J C804 9HSMA1JJS00104 FILM CAP.(P) 0.1µF/50V J C805 9HSE1JMASSL100 ELECTROLYTIC CAP. 10µF/50V M H7 C809 9HSE1JMASSL100 ELECTROLYTIC CAP. 10µF/50V M H7 C810 9HSHD1AZ30F105 CHIP CERAMIC CAP. F Z 1µF/10V C811 9HSE1CMASSL101 ELECTROLYTIC CAP.
Page 69 Ref. No. Part No. Description D434 9HSD1Z001SS400 SWITCHING DIODE 1SS400 D435 9HSD1Z001SS400 SWITCHING DIODE 1SS400 D436 9HSD1Z001SS400 SWITCHING DIODE 1SS400 D437 9HSD1Z001SS400 SWITCHING DIODE 1SS400 D438 9HSD1Z001SS400 SWITCHING DIODE 1SS400 D439 9HSD1Z001SS400 SWITCHING DIODE 1SS400 D440 9HSD1Z001SS400 SWITCHING DIODE 1SS400 D441 9HSD1Z001SS400 SWITCHING DIODE 1SS400...
Page 70 Ref. No. Part No. Description D543 9HSD1Z001SS400 SWITCHING DIODE 1SS400 D547 9HSD1Z001SS400 SWITCHING DIODE 1SS400 D549 9HSD1Z001SS400 SWITCHING DIODE 1SS400 D605# 9HSDLZ001N5397 DIODE 1N5397-B D606# 9HSDLZ001N5397 DIODE 1N5397-B D607# 9HSDLZ001N5397 DIODE 1N5397-B D608# 9HSDLZ001N5397 DIODE 1N5397-B D609 9HSDTB0MTZJ5R6 ZENER DIODE MTZJT-775.6B D611# 9HSDTB00MTZJ22 ZENER DIODE MTZJT-7722B...
Page 71 Ref. No. Part No. Description L602# 9HSLBG00ZTU012 LINE FILTER TLF14CB3321R0 L630 9HSJW7.5T PCB JUMPER D0.6-P7.5 L632 9HSLAXJATTU220 INDUCTOR 22µH-J-26T L701 9HSJW5.0T PCB JUMPER D0.6-P5.0 L851 9HSJW5.0T PCB JUMPER D0.6-P5.0 TRANSISTORS 9HSQSF02SC2785 TRANSISTOR 2SC2785(F) Q401# 9HSQSF02SC2785 TRANSISTOR 2SC2785(F) Q403 9HSQSZ00BA1F4M RES. BUILT-IN TRANSISTOR BA1F4M-T Q404 9HSQSF02SC2785 TRANSISTOR 2SC2785(F)
Page 72 Ref. No. Part No. Description CHIP RES.(1608) 1/10W J 180 Ω 9HSRXAJR5Z0181 CHIP RES.(1608) 1/10W J 150 Ω 9HSRXAJR5Z0151 CHIP RES.(1608) 1/10W J 220 Ω 9HSRXAJR5Z0221 CHIP RES.(1608) 1/10W J 6.8k Ω 9HSRXAJR5Z0682 CHIP RES.(1608) 1/10W 0 Ω 9HSRXAZR5Z0000 CARBON RES. 1/4W J 10k Ω 9HSCX4JATZ0103 CARBON RES.
Page 73 Ref. No. Part No. Description CHIP RES.(1608) 1/10W J 10k Ω R482 9HSRXAJR5Z0103 CHIP RES.(1608) 1/10W J 10k Ω R483 9HSRXAJR5Z0103 CHIP RES.(1608) 1/10W J 1k Ω R484 9HSRXAJR5Z0102 CHIP RES.(1608) 1/10W J 10k Ω R485 9HSRXAJR5Z0103 CHIP RES.(1608) 1/10W J 10k Ω R486 9HSRXAJR5Z0103 CHIP RES.(1608) 1/10W J 1k Ω...
Page 74 Ref. No. Part No. Description CARBON RES. 1/4W J 820 Ω R621 9HSCX4JATZ0821 R622 9HSJW5.0T PCB JUMPER D0.6-P5.0 CARBON RES. 1/4W J 2.2k Ω R623 9HSCX4JATZ0222 CHIP RES.(1608) 1/10W J 47k Ω R633 9HSRXAJR5Z0473 CHIP RES.(1608) 1/10W J 15k Ω R634# 9HSRXAJR5Z0153 CHIP RES.(1608) 1/10W J 27k Ω...
Page 75 Ref. No. Part No. Description CHIP RES.(1608) 1/10W J 10k Ω R786 9HSRXAJR5Z0103 CHIP RES.(1608) 1/10W J 10k Ω R787 9HSRXAJR5Z0103 CHIP RES.(1608) 1/10W J 10k Ω R788 9HSRXAJR5Z0103 CHIP RES.(1608) 1/10W J 10k Ω R789 9HSRXAJR5Z0103 CHIP RES.(1608) 1/10W J 10k Ω R791 9HSRXAJR5Z0103 CARBON RES.
Page 76 Ref. No. Part No. Description CHIP RES.(1608) 1/10W 0 Ω J179 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω J229 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω J249 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω J286 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω J292 9HSRXAZR5Z0000 JK721 9HSYEJ040JC001 Y/C JACK YKF51-5558N...
Page 77 Ref. No. Part No. Description SW101 9HSST0101AL060 TACT SWITCH SKHHARA010 SW102 9HSST0101AL060 TACT SWITCH SKHHARA010 SW103 9HSST0101AL060 TACT SWITCH SKHHARA010 SW104 9HSST0101AL060 TACT SWITCH SKHHARA010 SW105 9HSST0101AL060 TACT SWITCH SKHHARA010 SW107 9HSST0101AL060 TACT SWITCH SKHHARA010 SW116 9HSST0101AL060 TACT SWITCH SKHHARA010 MISCELLANEOUS CLN104 9HSX1L0170-003...
Page 78 LC-13SH1U © COPYRIGHT 2004 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
