CONTENTS Introduction Safety Notes Identification of parts Installation of the Indoor unit Installation of the Outdoor unit Operation instructions Disconnection and reconnection Trouble shooting Maintenance Energy saving tips Specification...
Introduction Thank you for choosing this split air conditioner to provide you and your family with all of the “Home Comfort” requirements for your home, or office. The appliance can be moved from room to room within your home and set-up in just minutes.
SAFETY NOTES 1. Do not connect to any AC socket outlet that is damaged. 2. Do not use in the following locations:- Next to a source of fire. An area where oil is likely to splash. An area exposed to direct sunlight. An area where water is likely to splash Near a bath, shower or a swimming pool In a greenhouse...
Page 5
Warning In order to ensure the long, reliable and safe functioning of the air conditioner, the following safety points should be observed.
Installation of the Indoor Unit Note:- With all the various methods of installation detailed below it is important to ensure there are no kinks, twists or sharp bends in the umbilical cord. Method 1 The umbilical chord cord can pass though a partly open door or window.
Installation of the Outdoor Unit Method 1 The outdoor unit can be placed directly on a patio or balcony and when used in this way it does not require the use of the fixing brackets or straps. Note It is necessary to leave a gap of at least 5cm between the rear of the unit and the outside wall and also to ensure that no large objects are placed closer than 120cm from the front of the unit.
Page 9
Water Full Alarm The GPACU12H has a unique system to dispel condensation automatically but in certain circumstances some water may collect in the water tank within the machine. When this tank becomes full, the water full indicator will illuminate red and the machine will stop working.
Disconnection and Reconnection (The following procedures should be carried out by a suitably qualified person to avoid expensive mistakes). Steps in Disconnection 6. Use the 2 spanners provided to disconnect 1. Turn off the air conditioner and remove the the 2 pipes. plug from the power socket.
Trouble Shooting (The majority of malfunctions are minor and triggered by problems that can be easily resolved before calling for service. Please refer to the following table for sequential inspection) PROBLEMS REASONS SOLUTIONS • • Air conditioner Power has been cut off. Wait for power to be stops operating.
Maintenance (Periodic cleaning and maintenance will maximise the air conditioner’s functions and keep it running at optimum efficiency) Maintenance on the front Filter cleaning panel and housing Check once a week The air filter should be cleaned Turn off the power to the machine and periodically.
Energy saving Tips. (Periodic cleaning, maintenance and proper use will not only maximise the air conditioner’s functions but also can avoid unnecessary expense). Clean the filter periodically Take note of the following points • When using it in normal conditions, •...
Please recycle where facilities exist. Check with your local authority or retailer for recycling advice. GET Plc, Key Point, 3-17, High Street, Potters Bar, Herts EN6 5AJ Helpline Telephone no. 0121 565 7770 AR0849 Ed.B...
