Galaxy Note 10.1 Key Functions
1
3.5mm headset jack
2
Infrared blaster
3
Front-facing camera lens
4
Light sensor
5
microSD slot
6
Volume keys
7
Power key
8
Speakers
9
S Pen slot
10
Rear-facing camera
11
Camera flash
12
Power/Accessory port and
Connector for USB cable
13
Microphone
7
6
5
4
3
8
2
1
8
9
10 11
13
12

Advertisement

Table of Contents
loading

Related Manuals for Samsung Galaxy Note 10.1

Summary of Contents for Samsung Galaxy Note 10.1

  • Page 1 Galaxy Note 10.1 Key Functions 3.5mm headset jack Infrared blaster Front-facing camera lens 10 11 Light sensor microSD slot Volume keys Power key Speakers S Pen slot Rear-facing camera Camera flash Power/Accessory port and Connector for USB cable Microphone...

  • Page 2: Charging The Battery

    Basic Functions Charging the Battery 1. Carefully slide the Outlet Connector into the Charging Head. Make sure the connection is secure. 2. Connect the USB cable to the Charging Head. Note: Connecting the travel adapter improperly may cause serious damage to the device.

  • Page 3: Troubleshooting

    Basic Functions Turn your device on and off To turn on your device, press and hold the power button for a few seconds until the Galaxy Note 10.1 logo appears. When you turn on your device for the first time, follow the on-screen instructions to set up your device.
  • Page 4 2. Slide the Off button to the right to turn Wi-Fi On. 3. Select the desired network under Wi-Fi networks, enter password if applicable and tap Connect. You are now connected to a Wi-Fi network to use your Galaxy Note 10.1.
  • Page 5 Basic Functions Adding a Google Account 1. From the Home screen tap Apps > Settings > Accounts and sync. 2. Tap + Add account at the top right corner of the screen. 3. Select Google. Select Existing to enter your email and password or select New to create a Google account.
  • Page 6 Basic Functions Back Key Home Key Screen Capture Key You can always return to the You can return to the home screen You can take a picture of your screen previous page by selecting the back by selecting the Home key at the at any time by selecting this key.
  • Page 7 Basic Functions Navigation Key Google Search To access recently used applications, select the You can easily access the Google search button at the the bottom left of the screen to view the applications you top left hand of the screen. From here you can either have accessed recently.
  • Page 8 Basic Functions Accessing the App Menu 1. From the Home screen, select Apps in the top right corner to access the application list. 2. Select an application. 3. Select the Back key to return to the previous screen; Select the Home key to return to the Home screen.
  • Page 9 Using the S Pen ™ The Samsung Galaxy Note 10.1 comes with an S Pen that enables you to navigate your device with the touch of the pen and lets you use handwriting and free-form drawing to communicate. You can even convert your handwriting to text plus capture, create and share with the preloaded S Memo app.
  • Page 10 Personalize Your Galaxy Note 10.1 Changing the Wallpaper 1. Tap and hold the Home screen to display the Home screen menu. 2. Select Home screen, Lock screen or Home and lock screens under Set wallpaper for. 3. Select from pictures in your Gallery or the pre-loaded live and standard wallpapers.
  • Page 11 Personalize Your Galaxy Note 10.1 Adding Widgets 1. Scroll to the Home screen where you want to place the widget. 2. Tap the Apps icon, then select Widgets. 3. Tap and hold the widget and drag it to the desired location.
  • Page 12 Personalize Your Galaxy Note 10.1 Setting App Shortcuts 1. Scroll to the Home screen where you want to place the app. 2. Tap the Apps icon, then select Apps. 3. Tap and hold the desired application and drag it to the desired location.
  • Page 13 Email Setting Up Email 1. From the Home screen tap Apps > Email. 2. Enter your email address, password and tap Next. 3. Select which type of email account you are setting up. (POP3, IMAP or Microsoft Exchange Account) 4. You will need to enter your user name, password and server information depending on the type of email account or you can change the settings by tapping Manual setup at the top right-hand side of the screen.
  • Page 14 Video Chat Using Google Talk for Video Chat 1. From the Home screen, select Apps > Talk. (You must be signed into your Google Account to use this function.) 2. Select your Google account name to sign in. 3. Contacts that have video chat capabilites will have a video camera icon next to their name.
  • Page 15 Taking a Photo or Video Take a Photo 1. From the Home screen, tap Apps > Camera. 2. Tap the grey Camera icon on the right side to take a photo. Changing to the Front Camera 1. Tap the Camera icon on the left side to change to the front facing camera for self portraits.
  • Page 16 Taking a Photo or Video Take a Video 1. From the camera function, tap and drag down to video mode. 2. Tap the red button on the right to begin recording a video. Changing to the Front Video Camera Tap the Video Camera icon on the left side to change to the front facing video camera for self recording.
  • Page 17 Browse the Web 1. From the Home screen, select Internet. 2. You can add another page by tapping the + on the tab to the right. 3. To bookmark a web page, select the icon. To view all of the web pages you have bookmarked, select the icon on the top right side of the screen.
  • Page 18 Google Mobile™ Services The following Google Mobile Services require a Google account: ™ • Google Play ™ • Gmail ™ • Google Maps ™ • Google Search ™ • YouTube ™ • Google Talk ™ • Google+ ™ • Google+ Messenger ™...
  • Page 19 Google Play™ Downloading Apps from Google Play™ 1. From the Home screen, select Apps > Play Store. 2. You can shop for Apps, Music, Books or Movies by tapping on the related tabs on the right hand side of the screen. You can also search by typing the name of the content you are searching for in the Search Google Play box on the top of the screen.
  • Page 20 Google Play™ Manage or Remove Apps 1. From the Home screen, tap Apps > Settings > Application manager > All. 2. To remove an app you have downloaded, select the app > Uninstall > OK.
  • Page 21 Smart Remote Setting Up Smart Remote 1. Go to Applications and launch Smart Remote. 2. Follow the on-screen instructions to set up the app. 3. For best performance, point your Galaxy Note 10.1 at the equipment you want to control.
  • Page 22 Watch Something Great Using Smart Remote Smart Remote suggests Top Picks based on your favorite programs. Tag shows you like and cut ones you don’t. The more you rate, the better the recommendations. Tap Watch On TV, sit back, and enjoy. Control your entertainment system with convenient buttons and simple gestures.
  • Page 23 2. Select the box after reading the Terms and Conditions. Then tap Accept. 3. To set up a Samsung Account, tap My Media > Sign Up. You will need to enter your Email address, password, date of birth, first and last name and zip code. Select the box to agree to the terms and conditions and select Sign Up.

  • Page 24: Samsung Mobile Products And Recycling

    For assistance, please go to Samsung.com to download a comprehensive User Guide. You can also contact Customer Service at 1-800-SAMSUNG to speak with a Customer Service Representative. Samsung Mobile Products and Recycling Samsung cares for the environment and encourages its customers to recycle Samsung mobile devices and genuine Samsung accessories, and other unwanted electronics, in accordance with local regulations and through an approved recycler.
