BERNINA

Baseline Sampler

Deco 330
Select Alphabet tab. Select medium font size. Program BERNINA; touch
OK. Move word up.
Select Alphabet tab; vertical lettering. Program BERNINA; OK. Move right.
Select Alphabet tab. Select Script font. Select Horizontal lettering. Program
Bernina ; touch OK. Rotate 45 º . Move into position.
Embroider. Return carriage to stored position. Trim and mount sample.
artista 165E/185E
To create arched lettering, select, rotate, and place each letter individually,
temporarily saving each one. For greatest accuracy, use placement boxes
(rather than Show function) to arrange letters.
Use indicated font to write Bernina; place in upper right corner of hoop.
Select Temporary Save.
Select Menu; select indicated alphabet. Select B; place to left of vertical
placement line, rotating to fit circle template. Touch Temporary Save.
Touch Menu. Select e; place to right of B so lower corners of placement
boxes touch. Rotate e to fit circle template. Touch Temporary Save.
Continue in this manner, adding letters to complete Bernina. After placing
each letter, touch Temporary Save. Select Retrieve; fine tune letter place-
ment using Show function. Touch Temporary Save after each adjustment.
Repeat this process to form additional baselines shown in illustration.
Embroider, trim, and mount the sample.
artista 200E
To create arched lettering, use the Letter Manipulation dialog box.
Use indicated alphabet to input Bernina; select OK. Select Medium Hoop.
Select Duplicate symbol.
Go to Edit 2. Select Letter Manipulation symbol; choose Vertical Baseline
option and touch OK. Select Move Motif symbol; use Stitch Length (-300)
and Width (+100) knobs to move vertical Bernina to left side of hoop.
Retrieve the other Bernina. Use default baseline (Horizontal), and move
lettering to Stitch Length knob = +100 and Stitch Width knob = +350. Go
to Edit 1. Select Duplicate option. Go to Edit 2. Select Letter Manipulation,
then choose Curved Baseline option ABOVE the smallest green circle; OK.
Move Bernina to Stitch Length knob = +150 and Stitch Width knob = +100.
Go to Edit 1; select Duplicate option. Go to Edit 2; select Letter Manipula-
tion symbol. Choose Curved Baseline BELOW the smallest green circle
option. Position the word at Stitch Length knob = +150 and Stitch Width
knob = -400. Touch OK.
Embroider, trim, and mount the sample.
BERNINA
M Y
ASTERING OUR
©2005 BERNINA® of America, Inc. Permission to copy granted only to Authorized BERNINA
®
Embroidery Module/Machine
E M
®
MBROIDERY ODULE
/M
ACHINE
Mastering
Your
BERNINA
Notes
Embroidery Motif
Deco 330
Gothic & Script
artista 165E
Drifter
artista 185E
Drifter
artista 200E
Alice
Fabric & Stabilizer
8" x 10" rectangle
® Dealers
®
