Page 2: Instrument Panel Overview
9. Automatic transmission selector lever or SU11001a manual transmission gear shift lever 10. Parking brake lever 11. Power door lock switch (without power windows) 12. Hood lock release lever 13. Window lock switch 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 3 8. Car audio 9. Cigarette lighter/Power outlet SU11002a 10. Ashtray/Coin box 11. Ignition switch 12. Tilt steering lock release lever 13. Power rear view mirror control switches 14. Instrument panel light control knob 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 4: Instrument Cluster Overview
Instrument cluster overview DType A SU11007a 1. Service reminder indicators and 3. Fuel gauge 5. Trip meter reset knob indicator lights 4. Odometer and two trip meters 2. Speedometer 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 5 DType B SU11009a 1. Service reminder indicators and 4. Odometer and two trip meters 6. Trip meter reset button indicator lights 5. Fuel gauge 7. Tachometer 2. Speedometer 3. Extinction canceling button 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 6: Indicator Symbols On The Instrument Panel
(in blue) High engine coolant temperature warning light ∗ ∗ (in red) Open door warning light ∗ : For details, see “Service reminder indicators and warning ∗ buzzers” in Section 1–5. SRS warning light 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 7: Table Of Contents
..........2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 8: Keys
Toyota dealer using the key To protect items locked in the trunk when number. using valet parking, leave the sub key with the attendant.
Page 9: Side Doors
Vehicles with power windows (passen- ger’s side) 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 10 We recommend us- To lock: Push the switch down on the ing this feature whenever small children front side. are in the vehicle. To unlock: Push the switch down on the rear side. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 11 Pushing the switch twice within 3 seconds unlocks all the doors simultaneously. At this time, parking lights, side marker lights and tail lights flash twice. Unlocking operation 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 12 “LOCK” to “ON” position. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 13 _ When replacing the transmitter bat- tery, be careful not to lose the com- ponents. _ Replace only with same or equivalent type recommended by a Toyota dealer. _ Dispose of used battery according to the local laws. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 14 Water may cause unexpected that may cause undesired operation. rust. _ Do not touch or move any compo- nents inside of the transmitter, or it may interfere with proper opera- tion. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 15: Power Windows
To open: Lightly push down the switch. Increase the separation between the To close: Pull up the switch. equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 16 The window moves as long as you hold the switch. To open: Push down the switch. To close: Pull up the switch. If you push in the window lock switch on the driver’s door, the passengers’ windows cannot be operated. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 17: Trunk Lid
Use the window lock switch to down on it. After closing the trunk lid, try prevent them from making unex- pulling it up to make sure it is securely pected use of the switches. closed. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 18 (glow–in–the–dark) handle will continue to glow for a time after the trunk lid is closed. Exposing the handle to stronger light will cause it to glow longer. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 19: Hood
After locking the rear seatbacks, try fold- occur. ing them down to make sure they are securely locked, otherwise someone could get into the trunk by folding down a rear seat. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 20 Then lower the hood and make sure it locks into place. If nec- essary, press down gently on the front edge to lock it. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 21: Theft Deterrent System
3. Close and lock all the doors, trunk and hood. The indicator light will come on when all the doors, trunk and hood are closed and locked. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 22: Fuel Tank Cap
Open the trunk with the key. is disconnected and then reconnected. If the system does not work properly, have it checked by your Toyota dealer. Type B 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 23 In hot weath- Make sure the cap is tightened securely. er, fuel under pressure could cause injury by spraying out of the filler neck if the cap is suddenly re- moved. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 24 The indicator lamp goes off after driving several times. If the indicator lamp does not go off, contact your Toyota dealer as soon as possible. CAUTION Make sure the cap is tightened se- curely to prevent fuel spillage in case of an accident.
Page 25 ..........2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 26: Seats
Move your seat to the rear as far collision. as you can while still reaching the pedals comfortably. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 27 While adjusting the seat, do not put your hands under the seat or near the moving parts. Otherwise, your hands or fingers may be caught and injured. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 28 In the event rearward to make sure it is secured of a frontal collision, the more the in place. seat is reclined, the greater the risk of personal injury. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 29: Fold-Down Rear Seat
The seat will slide forward. Each seatback may be folded separately. 2. Move the seat to the front–most posi- tion. After passengers are in, lift up the seat- back and return the seat until it locks. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 30 Insert the key into the hole (light gray) webbing of the rear center seat belt on the buckle to release tab 1 (light when left seatback folded gray), and allow the belt to retract. down. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 31 Insert tab 2 into the buckle 3. for ready use. You will hear a click when the tab locks If the seat belt does not function into the buckle. normally, immediately contact your Toyota dealer. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 32: Head Restraints
If an accident occurs and the seat belts are not worn properly, the force of the rapid infla- tion of the airbag may cause death or serious injury to the child. Rear seat 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 33 Inspect the belt system periodically. Check for cuts, fraying, and loose parts. Damaged parts should be re- placed. disassemble modify the system. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 34 Toyota dealer. Do not use the seat until the seat belt is fixed. It cannot slow, easy motion will allow the belt to extend, and you can move around freely. protect an adult occupant or your child from injury. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 35 Position the lap belt as low as possible on your hips—not on your waist, then ad- just it to a snug fit by pulling the shoulder portion upward through the latch plate. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 36 See the information in the following the rear center seat belt. (See “Fold–down columns. rear seat” in this section for the instruc- tion of how to correctly connect the seat belt.) 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 37 Never use the seat belt extender if you can fasten the seat belt without 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 38 This helps prevent damage to the vehicle interior and extend- er itself. When not in use, remove the extender and store in the vehicle for future use. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 39 86 in Sec- ing sensor and airbag sensor. Collisions occurring at certain speeds and tion 1–5.) angles may cause the seat belt preten- sioners and SRS airbags not to operate all together. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 40 The light comes on or flashes while sole driving. If either front seat belt does not retract or can not be pulled out due to a malfunction or activation of the relevant front seat belt pretensioner. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 41: Srs Driver And Front Passenger Airbags
The front passenger airbag is acti- vated even with no passenger in the front seat. Be sure to wear your seat belt properly. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 42 SRS front airbags and the and warning buzzers” on page 86 in Sec- seat belt pretensioners may not activate tion 1–5.) together. For the safety of all occupants, always wear your seat belts properly. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 43 4. Airbag module for front passenger (air- bag and inflator) you should do so at the first opportunity. 5. Airbag sensor assembly The airbag sensor assembly consists of a safing sensor and airbag sensor. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 44 The airbags inflate only cerning the seat belt system, see once. The windshield may be damaged by “Seat belts” in this section. absorbing some of the force of the inflat- ing airbag. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 45 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 46 For instruc- jects in their arms or on their tions concerning the installation of knees. a child restraint system, see “Child restraint” on page 54 in this sec- tion. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 47 “ON” posi- fenders, front end structure, con- tion, or the light remains on. sole, steering column, steering The light comes on or flashes while wheel or dashboard near the front driving. passenger airbag 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 48: Srs Side Airbags
The SRS side airbag on cracked, or otherwise damaged. the passenger seat is activated even with no passenger in the front seat. Be sure to wear your seat belt properly. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 49 “Service reminder indicators side. and warning buzzers” on page 86 in Sec- For the safety of all occupants, always tion 1–5.) wear your seat belts properly. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 50 5. Door side airbag sensor (only only once. 2–door models) The SRS side airbag system is controlled by the airbag sensor assembly. The side airbag sensors consist of a safing sensor and airbag sensor. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 51 “Child restraint” in this section. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 52 Likewise, driver front passenger should not hold objects in their arms or on their knees. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 53 The surface of the seats with the side tion, or the light remains on. airbag (shaded in the illustration) is The light comes on or flashes while scratched, cracked, or otherwise dam- driving. aged. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 54: Child Restraint
Holding a child in properly secured. your arms is not a substitute for a child restraint system. In an acci- dent, child can be crushed against the windshield, or between you and the vehicle’s interior. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 55 It is danger- ous if the side airbag inflates, and the impact could cause death or serious injury to the child. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 56 “—Using a top strap” in this section. child restraint lower anchorages approved for your vehicle may also be used. “—Installation with child restraint lower anchorages” in this section. SU13032 (B) Convertible seat 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 57 If your driving position is not satis- factory, install the child restraint system on the rear right seat. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 58 Keep To hold the infant seat securely, make the lap portion of the belt tight. sure the belt is in the lock mode before letting the belt retract. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 59 Follow all the installation ger. instructions provided by its manufac- turer. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 60 It is dan- gerous if the side airbag inflates, and the impact could cause death or serious injury to the child. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 61 Keep the lap portion of the belt passenger in case of sudden brak- tight. ing or a collision. If your driving position is not satis- factory, install the child restraint system on the rear right seat. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 62 To hold the convertible seat securely, it is secure. Follow all the installation make sure the belt is in the lock mode instructions provided by its manufac- before letting the belt retract. turer. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 63 Always move the seat as far back as possible, because the force of the deploying airbag could cause death or serious injury to the child. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 64 See “Seat belts” for de- of the belt are not twisted. tails. Do not insert coins, clips, etc. in the buckle as this may prevent your child from properly latching the tab and buckle. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 65 Follow the procedure below for a child press the buckle–release button and al- restraint system that use of a top strap low the belt to retract. to secure the system. Follow all the installation instructions provided by its manufacturer. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 66 1. Remove the head restraint. Anchor brackets are installed for each rear seating position. This symbol indicates the location of user ready anchor brackets. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 67 Be sure to replace all covers when the Latch hook onto the anchor anchor bracket is not in use. bracket and tighten the top strap. For instructions to install the child re- straint system, see “Child restraint” in this section. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 68 Child restraint system interfaced with the FMVSS225 specification can be fixed with these anchorages. In this case, it is not necessary to fix the child restraint system with a seat belt on the vehicle. Type A Type B 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 69 Otherwise, this can cause severe inju- ry to the child in case of a sudden braking or collision. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 70: Tilt Steering Wheel
It is a convex mirror with a curved sur- face. Any object seen in a convex mirror will look smaller and farther away than when seen in a flat mirror. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 71 Push the switch to “L” (left) or “R” (right). 2. Control switch—To move the mirror Push the switch in the desired direc- tion. Mirrors can be adjusted when the key is in the “ACC” or “ON” position. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 72: Anti-Glare Inside Rear View Mirror
Daylight driving—Lever at position 1 the mirror. The reflection in the mirror has greater clarity at this position. Night driving—Lever at position 2 Remember that by reducing glare you also lose some rear view clarity. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 73: Vanity Mirrors
Vanity mirrors SU13061 To use the vanity mirrors, swing down the sun visor and open the cover. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 74 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 75 ........2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 76: Headlights And Turn Signals
“OFF” position. when you release the lever. remove the key with the headlights and You can flash the high beam headlights tail lights left on. with the knob turned to “OFF”. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 77: Emergency Flashers
If the turn signal indicator lights (green lights) on the instrument panel flash faster than normal, a front or rear turn signal bulb is burned out. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 78: Instrument Panel Light Control
When all the doors are locked or the ignition switch is turned to “ACC” or “ON” after all the doors are closed, the light fades out. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 79: Windshield Wipers And Washer
Type A Lever position Speed setting glass. Position 1 Intermittent Position 2 Slow Position 3 Fast For a single sweep of the windshield, push the lever up and release it. SU14016 Type B 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 80: Rear Window Defogger
Push the switch once again to turn the defogger off. On some models, the system will automat- ically shut off after the defogger has oper- ated about 15 minutes. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 81 ....... . . Service reminder indicators and warning buzzers ....2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 82 Fill the fuel tank immediately. The indicator lamp goes off after driving several times. If the indicator lamp does not go off, contact your Toyota dealer as SU15004 BS15003 soon as possible. The gauge indicates the approximate...
Page 83 If the indicator lamp does the specified operating range. ing light will come on when the ignition not go off, contact your Toyota dealer as _ Do not continue driving with an key is turned to the “ON” position. After soon as possible.
Page 84 If it keeps lighting on with the into the red zone. This may cause engine fully warmed, contact your Toyota severe engine damage. dealer as soon as possible to service the vehicle. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 85 A reading, then push and hold the button/knob until the me- ter is set to zero. The same process can be applied for resetting the trip meter B. Type B 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 86 Service reminder indicators and warning buzzers If the indicator or buzzer comes on... Do this. If parking brake is off, stop immediately and contact Toyota dealer. Fasten driver’s seat belt. (Indicator and buzzer) Fasten front passenger’s seat belt. Stop and check.
Page 87 If the indicator or buzzer comes on... Do this. Stop and check. Take vehicle to Toyota dealer. Close all doors. Take vehicle to Toyota dealer immediately. Add washer fluid. Stop and check. (in red) 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 88 If the indicator or buzzer comes on... Do this. Key reminder Remove key. buzzer Light reminder Turn off lights. buzzer 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 89 (c) Front Passenger’s Seat Belt NOTICE Reminder Light Do not continue driving if the engine This light reminds you to buckle up the drive belt is broken or loose. front passenger’s seat belt. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 90 Call a ventionally. warning light system itself. Toyota dealer or qualified repair shop for Contact your Toyota dealer as soon as assistance. possible to service the vehicle. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 91 (m) Key Reminder Buzzer This buzzer reminds you to remove the key when you open the driver’s door with the ignition key in the “ACC” or “LOCK” position. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 92 If any service reminder indicator or warn- ing buzzer does not function as described above, have it checked by your Toyota dealer as soon as possible. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 93 ..........2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 94: Ignition Switch With Steering Lock
“LOCK” position and open the driver’s position if the engine is not running. door, a buzzer will remind you to remove The battery will discharge and the the key. ignition could be damaged. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 95: Automatic Transmission
With the brake pedal depressed, shift while 2: Stronger engine braking holding the lock release button in. (The L: Maximum engine braking ignition switch must be in “ON” position.) Shift while holding the lock release button in Shift normally 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 96 Always drive your vehicle with the over- drive on for better fuel economy and quieter driving. If the engine is turned off when the over- drive is off and restarted, the overdrive will automatically be on. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 97 Be sure to turn the switch on immedi- NOTICE ately afterward. When towing a trailer, in order to main- Never shift into reverse while the ve- tain engine braking efficiency, do not hicle is moving. use overdrive. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 98: Manual Transmission
Section 4. The transmission is fully synchronized and upshifting or downshifting is easy. For the best compromise between fuel economy and vehicle performance, you should upshift or downshift at the following speeds: 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 99: Parking Brake
Make sure the vehicle is completely 146 (91) stopped before shifting into reverse. NOTICE SU16007 Do not downshift if you are going faster than the maximum allowable speed for the next lower gear. Type B 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 100 CAUTION Before driving, be sure the parking brake is fully released and the park- ing brake reminder light is off. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 101 Car audio system operating hints ......2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 102 If another function was pre- viously playing, it will come on again. Type 2: AM·FM radio/compact disc player 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 103 Keep in mind that if you are listening to a stereo recording or broadcast, changing the right/left balance will increase the vol- ume of one group of sounds while de- creasing the volume of another. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 104 —Controls and features DType 1 Details of specific buttons, controls, and features are described in the alphabetical list that follows. SU17004 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 105 “TRE –5” to “TRE 5”. automatically reverses and begins to play the other side. This is true whether the cassette was playing or fast forwarding. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 106 Insert a disc. or off according to the mode used for recording the tape. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 107 There must be at least 3 seconds of blank space between tracks in order for the re- peat feature to work correctly. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 108 After the beginning of the tape is lease the “ ” or “ ” under the “SEEK”. reached, the player will automatically Do this again to find another station. start playing the same side. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 109 If you want to return to the beginning of the current track, push the down side of the button one time, quickly. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 110 DType 2 Details of specific buttons, controls and features are described in the alphabetical list that follows. Z17056 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 111 The display vehicle to your Toyota dealer. ranges from F7 to R7. BAL: Adjusts the sound balance between the right and left speakers. The display ranges from L7 to R7. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 112 If the signal becomes extremely weak, the To turn off the repeat feature, push this it will stop scanning. radio switches from stereo to mono recep- button again. tion. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 113 The rest of the title will appear. TUNE (Tuning) Turn the “TUNE” knob clockwise to step up the frequency. Turn the knob counter- clockwise to step down the frequency. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 114 DType 3 Details of specific buttons, controls and features are described in the alphabetical list that follows. Z17047 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 115 F7 to R7. player will stop and then play that same side. If a tape fast–forwards completely, the cassette will play the other side of the tape using the auto–reverse feature. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 116 Eject the disc or magazine. Set the disc or magazine again. “ERROR 4”: Over–current. your Toyota dealer to inspect. If the malfunction still exists, take your vehicle to your Toyota dealer. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 117 To stop with some spoken word, live, or classical scanning, push this button again. If the recordings. player scanned all the tracks on the disc, it will stop scanning. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 118 AM signals. And of course, radio signals have a limited range, and the farther you are from a station, the weaker its signal will be. In addition, reception conditions change constantly as your vehicle moves. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 119 The easiest way to nal signal can be picked up again. clean them is by using a cleaning tape. (A wet type is recommended.) 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 120 CD–R (CD–Recordable) CD–RW (CD–Re–writable) Compact disc players use an invisible CD–ROM Z17039 laser beam which could cause hazard- radiation exposure directed outside the unit. Be sure to operate the player correctly. Low quality discs 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 121 (To see a pin hole, hold the disc up to the light.) Remove discs from the compact disc player when you are not listening to them. Store them in their plastic cases away from moisture, heat, and direct sunlight. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 122 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 123 ........2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 124: Controls
Controls 1. “A/C” Button (on some models) 2. Air intake selector 3. Air flow selector 4. Fan speed selector 5. Temperature selector SZ18006 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 125 3. Floor—Air flows mainly from the floor vents. 4. Floor/Windshield—Air flows mainly from the floor vents and windshield vents. Use with the air intake selector posi- tioned in FRESH. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 126 To turn the air conditioning off, press the button again. SZ18009 Air intake selector Move the lever to select the air source. 1. Recirculate—Recirculates the air inside the vehicle. 2. Fresh—Draws outside air into the sys- tem. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 127: Air Flow Selector Settings
Air flow selector settings Operating tips To cool off your Toyota after it has been parked in the hot sun, drive with the windows open for a few minutes. This vents the hot air, allowing the air conditioning to cool the interior more quickly.
Page 128 Air intake—FRESH (outside air) the vehicle interior while defrosting or cold air comes out from the center Air flow—PANEL defogging the windshield. vents in spite of the position of the air Air conditioning—OFF flow selector. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 129: Instrument Panel Vents
To heat the vehicle interior while de- On humid days, do not blow cold air frosting windshield, choose on the windshield—the difference be- floor/windshield air flow. tween the outside and inside tempera- tures could make the fogging worse. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 130 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 131 ..........2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 132: Clock
1:01—1:29, the time will change to 1:00. If Use a Toyota genuine cigarette lighter or the time is between 1:30—1:59, the time equivalent for replacement. will change to 2:00. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 133: Power Outlet
12V/120W. D To prevent the battery from being discharged, do not use the power outlet longer than necessary when the engine is not running. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 134: Glove Box
To reduce the chance of injury in closed while driving. case of an accident or a sudden stop, always keep the auxiliary box closed while driving. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 135: Cup Holders
Do not place anything else other than cups or drink–cans in the cup holder, as such items may be thrown about and possibly injure people in the ve- hicle during sudden braking or in an accident. Rear (center) 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 136: Floor Mat
Fix the floor mat with locking placed on the floor carpet. If the floor clip into the holes in the floor carpet. slips and interferes with movement of the pedals during driv- ing, it may cause an accident. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 137 ..........2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 138: Break-In Period
Number 91) or higher. Use of unleaded fuel with an octane num- ber or rating lower than stated above will cause persistent heavy knocking. If se- vere, this will lead to engine damage. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 139 Toyota, be sure that it has an octane try changing gasoline brands. If this does The WWFC consists of three categories rating no lower than 87.
Page 140: Operation In Foreign Countries
Operation in foreign countries Three–way catalytic converter If you plan to drive your Toyota in CAUTION another country... First, comply with the vehicle registration Keep people and combustible mate- laws. rials away from the exhaust pipe Second, confirm the availability of the cor- while the engine is running.
Page 141: Engine Exhaust Cautions
Maintenance Guide” “Owner’s ning. If it is unavoidable, however, Manual Supplement”. do so only in an unconfined area and adjust the heating or cooling system to force outside air into the vehicle. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 142: Facts About Engine Oil Consumption
1000 km (600 miles) or more. This is because the oil is gradually becoming diluted with fuel or moisture, making it appear that the oil level has not changed. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 143: Brake System
For detailed information on oil level check, see “Checking the engine oil level” in Sec- tion 7–2. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 144 This means that the anti–lock brake system is in the self– check mode, and does not indicate a mal- function. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 145 The use of tires other than specified may fail to detect the accurate turning speed resulting in a longer stopping dis- tance. Type B 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 146: Brake Pad Wear Limit Indicators
Toyota dealer as soon as possible. Expensive ro- tor damage can result if the pads are not replaced when necessary. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 147: Your Toyota's Identification
This is the primary identification number ing, and impair the driver’s control for your Toyota. It is used in registering of the vehicle. In an accident they the ownership of your vehicle. may injure the vehicle occupants.
Page 148: Theft Prevention Labels
NOTICE The engine number is stamped on the You should not attempt to remove the engine block as shown. theft prevention labels as it may vio- late certain state or federal laws. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 149: Types Of Tires
All season tires, however, do not have adequate traction performance compared with snow tires in heavy or loose snow. Also, all season tires fall short in accel- eration handling performance compared with summer tires in highway driving. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 150 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 151 ..........How to save fuel and make your vehicle last longer, too ..2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 152: Before Starting The Engine
Simply restart it, using the correct proce- dure given in normal starting. If the engine will not start... See “If your vehicle will not start” in Sec- tion 4. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 153: Tips For Driving In Various Conditions
If they still do not work safely, pull to the side of the road and call a Toyota dealer for assistance. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 154: Winter Driving Tips
If you are not sure about Driving over 140 km/h (85 mph) may equivalent. which oil to use, call your Toyota deal- result in tire failure, loss of control er—he will be pleased to help. See Section 7–2 for details about coolant and possible injury.
Page 155: Dinghy Towing
NOTICE Dinghy towing does not eliminate the possibility of damage to your vehicle. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 156: Trailer Towing
Do not tow your vehicle from the 3. Release the parking brake. rear. This may cause serious damage After dinghy towing, let the engine idle for to your vehicle. more than 3 minutes before driving the vehicle. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 157: How To Save Fuel And Make Your Vehicle Last Longer, Too
“Owner’s Manual Supplement”.) gear as quickly as possible. Maintain a moderate speed on high- ways. The faster you drive,the greater the fuel consumption. By reducing your speed, you will cut down on fuel con- sumption. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 158 Never turn off the engine to coast down hills. Your power steering and brake booster will not function with- out the engine running. Also, the emission control system operates properly only when the engine is run- ning. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 159: In Case Of An Emergency
........If you lose your wireless remote control transmitter ... . . 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 160: If Your Vehicle Will Not Start
Do not pull– or push–start the ve- hicle. It may damage the vehicle or cause a collision when the engine starts. Also the three–way catalytic converter may overheat and become a fire hazard. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 161 Then get immediate medical attention. If possible, continue to apply water with a sponge or cloth while en route to the medical office. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 162 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 163: If Your Engine Stalls While Driving
(for example, lights left on), will not work so steering and braking Wait until the steam subsides before you should have it checked at your Toyota will be much harder than usual. opening the hood. If there is no coolant dealer.
Page 164: If You Have A Flat Tire
Personal injury may occur. out under pressure. Do not start or run the engine while your vehicle is supported by the jack. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 165 The compact spare tire saves space in to remove and change the tire. your luggage compartment, and its lighter weight helps to improve fuel economy and permits easier installation in case of a flat tire. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 166 The standard tire should be re- age locations. paired and replaced as soon as possible. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 167 Then secure the tire by repeating the above removal steps in reverse order to prevent it from flying forward during a collision or sudden braking. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 168 Be careful that the ornament to avoid unexpected person- wrench does not slip off the nut. al injury. Do not remove the nuts yet—just unscrew them about one–half turn. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 169 To raise the vehicle, insert the jack handle into the jack (it is a loose fit) and turn it clockwise. As the jack touches the vehicle and begins to lift, double–check that it is properly positioned. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 170 Then lift up the wheel and get at least the top bolt started through its hole. Wiggle the tire and press it back over the other bolts. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 171 Make sure the wrench is securely en- gaged over the nut. Tighten each nut a little at a time in the order shown. Repeat the process until all the nuts are tight. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 172 Take due care in handling the orna- reduce the possibility of personal in- ment to avoid unexpected personal jury during a collision or sudden injury. braking. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 173: If Your Vehicle Becomes Stuck
SU41054b _ If your vehicle remains stuck after or damage to nearby people or ob- jects. rocking the vehicle several times, consider other ways such as tow- ing. (b) Using flat bed truck 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 174 If towing is necessary, we recommend (a) Towing with wheel lift type truck Automatic transmission: you to have it done by your Toyota From front—Release the parking brake. Use a towing dolly under the front dealer or a commercial tow truck ser- wheels.
Page 175 —Emergency towing If towing is necessary, we recommend (c) Towing with sliding type you to have it done by your Toyota truck dealer or a commercial tow truck ser- vice. If a towing service is not available in an emergency, your vehicle may be...
Page 176 Before towing, release the parking brake and put the transmission in neutral (manu- al) or “N” (automatic). The key must be in “ACC” (engine off) or “ON” (engine run- ning). 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 177 When installing the eyelet on the ve- hicle, be sure to tighten the front eyelet securely. If the tightening is loose, it may come off when being towed and result in death or serious injury. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 178: If You Cannot Shift Automatic Transmission Selector Lever
If you cannot shift automatic transmission selector lever If you lose your keys You can purchase a new key at your Toyota dealer if you can give them the key number. See the suggestion given in “Keys” in Section 1–2.
Page 179: If You Lose Your Wireless Remote Control Transmitter
Have the registered identification numbers of your transmitters deleted from your ve- hicle by your Toyota dealer as soon as possible to avoid the possibility of theft or an accident. Then, have the identification number of your new transmitter registered.
Page 180 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 181: Corrosion Prevention And Appearance Care
........2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 182 Now, it is up to you. Proper more harm than good to simply wet the High temperatures will cause corrosion care of your Toyota can help ensure long– mud and debris without removing them. to those components of the vehicle term corrosion prevention.
Page 183 It may fly off so damp it will cause corrosion. Even if the wheel and cause accidents while your garage is heated, a wet vehicle can the vehicle is moving. corrode if the ventilation is poor. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 184 Always remove the plastic bumpers if the paint. your vehicle is re–painted and placed in a high heat paint waxing booth. High temperatures could damage the bumpers. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 185 NOTICE _ Do not use dye or bleach on the belts—it may weaken them. _ Do not use the belts until they be- come dry. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 186 Immediately clean any spill using the method mentioned above. If you have any questions about the cleaning of your Toyota, your local Toyota dealer will be pleased to answer them. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 187 ......Emissions inspection and maintenance (I/M) programs ..For scheduled maintenance information, please refer to the “Scheduled Maintenance Guide” or “Owner’s Manual Supplement”. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 188 Simple instructions for how to per- or if you prefer, your Toyota dealer will be without invalidating this warranty. See form them are presented in Section 7. pleased to do them at a nominal cost. “Owner’s Warranty Information Booklet”...
Page 189 Information Booklet” or “Owner’s Manual should investigate the cause or take your check the nuts for looseness. Tighten Supplement” for the details. vehicle to your Toyota dealer or a quali- them if necessary. fied service shop immediately. It is recom- Tire rotation...
Page 190 Make sure that the leased. Brake fluid level belt webbings are not cut, frayed, worn or Make sure the brake fluid level is correct. damaged. See Section 7–2 for additional information. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 191 If you notice any of these clues, take your Check the level on the dipstick with the mance, sounds, and visual tip–offs that vehicle to your Toyota dealer as soon as engine turned off and the vehicle parked indicate service is needed. Some impor- possible.
Page 192 Also, if the malfunction indicator lamp had come on recently due to temporary mal- function such as a loose fuel tank cap, your vehicle may not pass the I/M test. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 193 ......... 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 194: Engine Compartment Overview
2. Engine oil filler cap 3. Power steering fluid reservoir 4. Brake fluid reservoir 5. Battery 6. Fuse blocks 7. Engine coolant reservoir 8. Radiator 9. Condenser 10. Electric cooling fan SU71001c 11. Engine oil level dipstick 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 195: Fuse Locations
“Parts and tools”. SY71004 Utmost care should be taken when work- ing on your vehicle to prevent accidental injury. Here are a few precautions that you should be especially careful to ob- serve: 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 196 State of California to from damaging the parts or paint. cause cancer reproductive harm. Wash hands after handling. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 197: Parts And Tools
ADDING WASHER FLUID Tools: Funnel (only for adding coolant) Parts: Water CHECKING BRAKE FLUID Washer fluid containing antifreeze (for Parts (if level is low): winter use) SAE J1703 or FMVSS No.116 DOT 3 brake fluid 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 198: Positioning The Jack
Pantograph jack ..Never get under the vehicle when the vehicle is supported by the jack alone; use vehicle support stands. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 199 When raising the vehicle, do not place any objects on top of or un- derneath the jack. NOTICE Make sure to place the jack correctly, or your vehicle may be damaged. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 200 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 201 Aluminum wheel precautions ....... . 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 202: Checking The Engine Oil Level
Oil quantity, L (qt., lmp. qt.): as it will go, or the reading will not be 1.5 (1.6, 1.3) correct. 4. Pull the dipstick out and look at the oil level while holding a rag under the end. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 203 If SAE 5W–30 oil is not available, SAE 10W–30 oil may be used. However, it API02 should be replaced with SAE 5W–30 at the next oil change. ILSAC certification mark 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 204: Checking The Engine Coolant Level
Read the coolant container for information If you can find no leak, have your Toyota on freeze protection. Follow the manufac- dealer test the cap pressure and check turer’s directions for how much to mix for leaks in the cooling system.
Page 205: Checking The Radiator And Condenser
Toyota vehicles. Please contact your Toyota dealer for further details of “Toyota Genuine Long Life Coolant” range. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 206: Checking Brake Fluid
If the level is low, add SAE J1703 or FMVSS No.116 DOT 3 brake fluid to the brake reservoir. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 207 “HOT” range. If the level is at the low side of either range, add automatic transmission fluid DEXRONrII or III to bring the level within the range. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 208: Checking Tire Pressure
The passenger and luggage life and make your vehicle less safe to weight should be located so that the drive. vehicle is balanced. If a tire frequently needs refilling, have it checked by your Toyota dealer. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 209: Checking And Replacing Tires
The lower the tread, the higher originally installed tires. the risk of skidding. The effectiveness of snow tires is lost if the tread wears down below 4 mm (0.16 in.). 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 210: Rotating Tires
See “If you have a flat tire” in Section 4 for tire change procedure. See “If you have a flat tire” in Section 4 for tire change procedure. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 211: Installing Snow Tires And Chains
Do not use snow tires other than the manufacturer’s recommended size, as this may cause dangerous handling characteristics resulting in loss of control. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 212 B Width of side chain 10 (0.39) C Length of side chain 30 (1.18) D Diameter of cross chain: 4 (0.16) E width of cross chain 14 (0.55) F Length of cross chain 25 (0.98) 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 213: Replacing Wheels
2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 214 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 215 ........2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 216: Checking Battery Condition
Overtightening may damage the cal office. battery case. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 217: Battery Recharging Precautions
NOTICE Toyota dealer. Never recharge the battery while the CLEAR Have battery engine is running. Also, be sure all checked by your accessories are turned off. LIGHT Toyota dealer. YELLOW 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 218: Checking And Replacing Fuses
Blown spare fuses and keep them in your ve- the name of the circuit for each fuse. See hicle for emergencies. Section 8 of this manual for the functions controlled by each circuit. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 219: Adding Washer Fluid
When replacing tem. Have your Toyota dealer correct it as light comes on, the washer tank may be a bulb, make sure the ignition switch and soon as possible.
Page 220 If the connector is tight, wiggle it. License plate lights High mounted stoplight Interior light — Trunk light A: HB2 halogen bulbs B: HB4 halogen bulbs C: Single end bulbs (amber) D: Wedge base bulbs E: Double end bulbs 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 221 Aiming is not necessary after replacing the bulb. When aiming adjustment is nec- essary, contact your Toyota dealer. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 222 SU73013d 2. Pull the bulb out of the bulb base. 3. Install a new bulb base by turning it clockwise to the front of the vehicle. If the connector is tight, wiggle it. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 223 —Rear side marker/stop/tail, rear turn signal, back–up lights SU73014b SU73033a SU73056 a: Rear side marker b: Stop/tail lights c: Rear turn signal light d: Back–up lights SU73055 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 224 —License plate lights —High mounted stoplight SU73034c SU73030 SU73032 SU73025c SU73031 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 225 ........... . . 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 226: Dimensions And Weight
Rear tread mm (in.): 1420 (55.9) Vehicle capacity weight (occupants+luggage) kg(lb.): 351 (775) ∗ 1 With Sports Fender And Rocker Panel Extensions ∗ 2 With P175/65R14 81S tires ∗ 3 With P185/60R15 84T tires 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 227: Service Specifications
Coolant type: DENSO K16R–U Recommended oil viscosity: “Toyota Genuine Long Life Coolant” is BKR5EYA filled in your Toyota vehicle. In order to SAE 5W–30 Spark plug gap, mm(in.): avoid technical problems, we strongly 0.8 (0.031) recommend using “Toyota Genuine Long Life Coolant”...
Page 228 Fluid type: Toyota Genuine ATF Type T–IV Wheel free play: Less than 30 mm (1.2 in.) Change automatic transmission fluid only as necessary. Power steering fluid type: Automatic transmission fluid DEXRON_II or III 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 229: Tires
Wheel nut torque, N·m (kgf·m, ft·Ibf): 103 (10.5, 76) NOTE: For a complete information on tires (e.g. replacing tires or replacing wheels), see “Checking tire pressure” through “Aluminum wheel precautions”, page 208 through 213 in Section 7–2. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 230: Fuses
20. FOG 15 A: Front fog lights 12. ACC 15 A: Clock, radio, cigarette light- 6. HORN 15 A: Horn 13. A.C 7.5 A: Air conditioning system 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 231 “ST”, “AM2”, “H–LP LH”, and “H–LP RH” fuse 30. ALT 100 or 120 A: “ECU–B”, “TAIL”, “D/L”, “OBD”, “A.C”, “HTR”, “POWER”, “STOP” and “FL DEF” fuses 31. ABS 60 A: Anti–lock brake system 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 232 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 233 ........2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 234 However, mum section width. NHTSA cannot become involved For example: Treadwear 200 Traction AA in individual problems between Temperature A you, your dealer, or Toyota Motor Sales, U.S.A., Inc. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 235 Federal Motor Vehicle Safety Standard No. 109. Grades B and A represent higher levels of perfor- mance on the laboratory test wheel than the minimum required by law. 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 236 2003 ECHO from Aug. ’02 Prod. (OM52481U)
Page 237 Owner’s Warranty Information...
Page 238 Table of Contents Introduction Satisfaction Down the Road Transportation Assistance If You Need Assistance Warranty Coverages at a Glance Your Warranties in Detail General Warranty Provisions New Vehicle Limited Warranty Federal Emission Control Warranty California Emission Control Warranty Tire Limited Warranty Your Responsibilities Operation and Maintenance Obtaining Warranty Service...
Page 239: Satisfaction Down The Road
Our excellent warranty coverage is evidence that we stand behind the ence. We want you to be a satisfied member of the Toyota family for — —...
Page 240: Transportation Assistance
Vehicle Limited Warranty. The policy applies to all 2003 model-year Toyota. We also know how disruptive the loss of transportation Toyotas sold and serviced by authorized Toyota dealerships in the can be to your daily routine.
Page 241: If You Need Assistance
In most cases, a satisfactory Step 3 solution can be reached at this step. If your concern has still not been resolved to your satisfaction, Toyota Step 2 offers additional assistance through the Dispute Settlement Program,...
Page 242 (800)331-4331. P.O. Box 561109 Dallas, TX 75356-1109 If you would like to request a customer claim form, call the Toyota Customer Assistance Center at (800)331-4331. When you call, please have your vehicle identification number, the current mileage on your Toyota and the names of your selling and servicing dealerships.
Page 243: Warranty Coverages At A Glance
Warranty Coverages at a Glance New Vehicle Limited Warranty Basic 36 months / 36,000 miles Powertrain 60 months / 60,000 miles Restraint Systems 60 months / 60,000 miles Corrosion Perforation 60 months / Unlimited miles months Emission Control Warranty 24 months / 24,000 miles Performance Specific Components 96 months / 80,000 miles...
Page 244 General Warranty Provisions Who Is the Warrantor When Warranty Begins The warrantor for these limited warranties is Toyota Motor Sales, U.S.A., The warranty period begins on the vehicle’s in-service date, which is the Inc. (“Toyota”), 19001 South Western Avenue, Torrance, California first date the vehicle is either delivered to an ultimate purchaser, leased, 90509-2991, a California corporation.
Page 245 General Warranty Provisions Limitations The performance of necessary repairs and adjustments is the exclusive remedy under these warranties or any implied warranties. Toyota does not authorize any person to create for it any other obligation or liability in connection with this vehicle.
Page 246: Basic Warranty
This warranty covers repairs and adjustments needed to correct defects in gears and gaskets, timing chain/belt and cover, flywheel, valve covers, materials or workmanship of any part supplied by Toyota, subject to the oil pan, oil pump, engine mounts, turbocharger housing and all internal exceptions indicated under “What Is Not Covered”...
Page 247 This warranty covers repairs needed to correct defects in materials or that develops perforation from corrosion (rust-through), subject to the workmanship of any seatbelt or air bag system supplied by Toyota, exceptions indicated under “What Is Not Covered” on pages 11–12.
Page 248 Lack of or improper maintenance, including use of fluids other than those specified in the Owner’s Manual Maintenance Expense Maintenance Expense • Installation of non-Genuine Toyota Parts Normal maintenance services such as: Normal maintenance services such as: • Airborne chemicals, tree sap, road debris (including stone chips), •...
Page 249 Toyota does not authorize any person to create for it any other obligation or liability in connection with this vehicle. Toyota shall not be liable Salvage or Total-Loss Vehicles for incidental or consequential damages resulting from breach of Any vehicle that has ever been issued a “salvage”...
Page 250: Dispute Resolution
New Vehicle Limited Warranty DISPUTE RESOLUTION If a dispute arises regarding your warranty coverage, please follow the steps described under “If You Need Assistance” on pages 4–5. Please note that you must use the Dispute Settlement Program before seeking remedies through a court action pursuant to the Magnuson-Moss Warranty Act.
Page 251: Federal Emission Control Warranty
Under the terms of the Emission Performance Warranty and federal regulations, Toyota will make all necessary repairs if both of the Federal regulations require that this warranty be in effect for two years following occur: or 24,000 miles from the vehicle’s in-service date, whichever occurs...
Page 252: Air Induction System
Federal Emission Control Warranty WHAT IS NOT COVERED WARRANTY PARTS LIST These warranty obligations do not apply to failures or non-compliance Air/Fuel Metering System caused by: • Air/fuel ratio feedback control system • The use of replacement parts not certified in accordance with •...
Page 253 Federal Emission Control Warranty Evaporative Control System Positive Crankcase Ventilation (PCV) System • • Charcoal canister Oil filler cap • • Diaphragm valve PCV valve or orifice • Fuel filler cap Other Parts Used in Above Systems • Fuel tank •...
Page 254 Owner’s Manual and the Scheduled Maintenance Guide. your vehicle’s emission control systems, Toyota recommends the use of Toyota will not deny a warranty claim solely because you do not have Genuine Toyota Parts when servicing or repairing the systems.
Page 255 Washington, D.C. 20460 charge. The only exceptions allowed are when you request or agree to a delay, or a delay is caused by factors beyond the control of Toyota or the Vehicles equipped with a California Certified Emission Control System dealership.
Page 256 3) We have performed all emission control system preparations required referred to in Paragraph 4 and furnished with the vehicle is solely that by Toyota prior to the sale of the vehicle as set forth in Toyota’s cur- of the manufacturer.
Page 257: California Emission Control Warranty
CARB regulations require passes the test. This is your Emission Control System PERFORMANCE that Toyota must warrant the emission control system on your vehicle for WARRANTY. the time periods indicated on this page, provided there has been no •...
Page 258 Limited Warranty also apply to this warranty. reasonable amount of time, not to exceed 30 days. You should also be aware that Toyota may deny you warranty coverage if your vehicle or a part has failed due to abuse, neglect, improper main- tenance or unapproved modifications.
Page 259 California Emission Control Warranty PARTS LIST: LONG-TERM EMISSION DEFECT WARRANTY The parts listed here are covered for seven years or 70,000 miles from Catalyst System the vehicle’s in-service date, whichever occurs first. • Catalytic converter (warm-up three-way catalyst) • Exhaust center pipe on Avalon, Corolla Matrix 4WD, Highlander Air/Fuel Metering System equipped with 1MZ-FE, Tacoma and Tundra equipped with 5VZ-FE •...
Page 260: Ignition System
Owner’s Manual and the Scheduled Maintenance Guide. • Charcoal canister on Highlander, Land Cruiser and 4Runner Toyota will not deny a warranty claim solely because you do not have • Fuel tank records to show that you maintained your vehicle. However, any failure...
Page 261 The only exceptions allowed are when you request or agree to If you use replacement parts that have maintenance or replacement a delay, or a delay is caused by factors beyond the control of Toyota or schedules different from those of Genuine Toyota Parts, you must follow the dealership.
Page 262 REPAIR DELAYS IF YOU HAVE QUESTIONS If a Toyota dealership is unable to complete repairs on your vehicle If you have questions or concerns about your vehicle’s California emis- within 30 days, you may have the repairs made under Toyota’s sion warranty coverage, please follow the steps described under “If You...
Page 263: Tire Limited Warranty
(Refer to your local phone directory for dealer Continental General Tire Toyo Tire (U.S.A.) Corporation locations.) Your Toyota dealer may also be able to assist you in obtaining 1800 Continental Blvd. 6261 Katella Ave., Ste. 2B warranty service from the manufacturer.
Page 264: General Information
You can be confident you’re getting the best possible service for your Toyota will not deny a warranty claim solely because you do not have vehicle when you take it to a Toyota dealership. Plus, a Toyota dealer- records to show that you maintained your vehicle.
Page 265 Warranty coverage is not dependent upon the use of any particular brand of replacement parts. However, Toyota recommends using only Genuine Toyota Parts when you need to replace a part on your vehicle. Like all Toyota products, Genuine Toyota Parts are built to the highest standards of quality, durability and performance.
Page 266 Obtaining Warranty Service BY GEOGRAPHIC REGION EMERGENCY REPAIRS If your vehicle is inoperable or unsafe to drive and there is no Toyota In the United States, U.S. Territories dealership reasonably available to make repairs, you may perform the and Canada repairs yourself or have them performed by another automotive service To obtain warranty service in the United States, U.S.
Page 267 Notes...
Page 268 Notes...
Page 269 Notes...
Page 271 (optional; for Toyota customer reference only) Assistance Center at This information is obtained solely for the use of Toyota Motor Sales, U.S.A., Inc. (800) 331-4331. Toyota occasionally sends special promotional offers to registered owners. Check here if you prefer not to receive these offers.
Page 272 Toyota Genuine ATF Type T–IV See page 228 for detailed information. Tire information: See pages 208 through 213. Tire pressure: See page 229. Publication No. OM52481U Part No. 01999-52481 Printed in Japan 01–0208–00 2003 ECHO from Aug. ’02 Prod. (OM52481U)

Toyota 2003 ECHO Owner's Manual

1 2 Section -

1 3 Section -

1 4 Section -

1 6 Section -

1 8 Section -

1 9 Section -

2 Section

3 Section

4 Section

7 1 Section -

7 2 Section -

7 3 Section -

8 Section

Owner's Warranty Information

Quick Links

Chapters

Related Manuals for Toyota 2003 ECHO

Summary of Contents for Toyota 2003 ECHO

Table of Contents
