IBM TotalStorage SAN04M-R SAN Router
Installation and Service Manual
Service information: 2027 / R04
Read Before Using
This product contains software that is licensed under written license agreements. Your use of such software is subject to
the license agreements under which they are provided.
GC26-7764-02

Advertisement

Table of Contents
loading

Summary of Contents for IBM SAN04M-R

  • Page 1 IBM TotalStorage SAN04M-R SAN Router Installation and Service Manual Service information: 2027 / R04 Read Before Using This product contains software that is licensed under written license agreements. Your use of such software is subject to the license agreements under which they are provided.
  • Page 3 IBM TotalStorage SAN04M-R SAN Router Installation and Service Manual Service information: 2027 / R04 GC26-7764-02...
  • Page 4 Third Edition (February 2007) © Copyright International Business Machines Corporation 2005, 2007. All rights reserved. US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract with IBM Corp.
  • Page 5: Table Of Contents

    Task 3: Powering up the SAN Router..........14 Task 4: Preparing to configure the SAN Router......16 Task 5: Connecting the VT100 or emulation terminal to the RS-232 management port..............18 Task 6: Preparing the SAN Router for Element Manager access ..............20 © Copyright IBM Corp. 2007...
  • Page 6 E/OSi.................... 42 Element Manager................ 42 Retrieving the system log ..............42 Accessing SNMP alerts or alarms ........... 43 Cleaning fiber-optic components ............ 46 Chapter 4 Parts catalog Parts catalog..................49 RoHS Information ..............49 SAN04M-R SAN Router Installation And Service Manual...
  • Page 7 FRU list ....................50 Miscellaneous parts ................51 Power cords and receptacles ............52 Chapter 5 Removal and replacement procedures Procedural notes.................55 Replace SFP optical transceiver............55 Appendix A Specifications Port characteristics ................59 Size and weight .................59 Power requirements ................59 Power consumption ................60 Environmental requirements ............60 Small form factor pluggable ............60 Notices Trademarks ..................63...
  • Page 8 SAN04M-R SAN Router Installation And Service Manual...
  • Page 9 Tables IBM products and SAN management documentation-E/OSi ....xii SAN Router features ..................5 Element Manager software functions ............6 SANvergence Manager and Element Manager platform requirement ..8 Installation task summary ................11 Default Management and SAN Router addresses ........17 Default TCP port addresses ................
  • Page 10 SAN04M-R SAN Router Installation And Service Manual...
  • Page 11 Firmware upgrade dialog box ..............39 Retrieve the System Log dialog box ............43 Power supply alert shown in trap viewer ..........46 Clean fiber-optic components ............... 47 Miscellaneous parts ..................51 Power cords ..................... 52 © Copyright IBM Corp. 2007...
  • Page 12 SAN04M-R SAN Router Installation And Service Manual...
  • Page 13: Preface

    Preface This manual provides the information required to install and prepare the IBM TotalStorage SAN04M-R for configuration to operate with E/OSi in an Ethernet/IP or Fibre Channel (FC) data network. Who should use this manual This publication is intended for trained service representatives...
  • Page 14: Ordering Manuals

    • McDATA SANvergence Manager User Manual (620-000189) • McDATA Eclipse 1620 SAN Router Administration and Configuration Manual (620-000205) Ordering manuals To order a printed copy of this publication, contact your IBM Branch office or you can locate (and purchase) books online at: http://www.elink.ibmlink.ibm.com/public/applications/publicatio ns/cgibin/pbi.cgi...
  • Page 15: How To Send Your Comments

    Safety and environmental notices ATTENTION ! The IBM TotalStorage SAN04M-R is not designed to be installed and serviced by customers. Installation and servicing of the SAN04M-R should be performed by qualified service representatives only.
  • Page 16 To avoid these hazards, ensure that your system electrical requirements do not exceed branch circuit protection requirements. Refer to the information that is provided with your device or the power rating label for electrical specifications. (D002) SAN04M-R SAN Router Installation And Service Manual...
  • Page 17 DANGER If the receptacle has a metal shell, do not touch the shell until you have completed the voltage and grounding checks. Improper wiring or grounding could place dangerous voltage on the metal shell. If any of the conditions are not as described, STOP. Ensure the improper voltage or impedance conditions are corrected before proceeding.
  • Page 18: Labels

    The actual product safety labels may differ from these sample safety labels: DANGER Hazardous voltage, current, or energy levels are present inside any component that has this label attached. (L001) Do not service, there are no serviceable parts. SAN04M-R SAN Router Installation And Service Manual...
  • Page 19 DANGER Rack-mounted devices are not to be used as a shelf or work space. (L002) DANGER Multiple power cords (L003) To remove all power to the device, disconnect all power cords. Caution notices A caution notice calls attention to a situation that is potentially hazardous to people because of some existing condition.
  • Page 20 __ Repair or disassemble. Exchange only with the IBM-approved part. Recycle or discard the battery as instructed by local regulations. In the United States, IBM has a process for the collection of this battery. For information, call 1-800-426-4333. Have the IBM part number for the battery unit available when you call.
  • Page 21 CAUTION The doors and covers to the product are to be closed at all times except for service by trained service personnel. All covers must be replaced and doors locked at the conclusion of the service operation. (C013) CAUTION The system contains circuit cards and/or assemblies that contain lead solder.
  • Page 22: Product Recycling And Disposal

    IBM encourages owners of information technology (IT) equipment to responsibly recycle their equipment when it is no longer needed. IBM offers a variety of product return programs and services in several countries to assist equipment owners in recycling their IT products. Information on IBM product...
  • Page 23 IBM’s Internet site at http://www.ibm.com/ibm/environment/products/prp.shtml Note: This mark applies only to countries within the European Union (EU) and Norway. Appliances are labeled in accordance with European Directive 2002/96/EC concerning waste electrical and electronic equipment (WEEE).
  • Page 24 EEE on the environment and human health due to the potential presence of hazardous substances in EEE. For proper collection and treatment, contact your local IBM representative. xxii SAN04M-R SAN Router Installation And Service Manual...
  • Page 25: Introduction

    Before installing the SAN Router Working with SFPs Introduction IBM offers a family of Fibre Channel switching products that allow implementation of a storage area network (SAN) topology in Fibre Channel Protocol (FCP) or fibre connection (FICON) environments. IBM offers several alternatives to build a robust and scalable SAN infrastructure that meets the customer’s data center requirements.
  • Page 26: San Router, Front View

    Definition Power 1 connector FC port 1 (1 Gbps) FC port 2 (1 Gbps) SFP FC or GE port (1 Gbps) FE RJ45 port (100 Mbps) SFP FC or GE port (1 Gbps) SAN04M-R SAN Router Installation And Service Manual...
  • Page 27: San Router Physical Description

    Definition FE RJ45 port (100 Mbps) Management port RS-232 Serial Management port RJ-45 Power Status 1 Power Status 2 System Light Power 2 connector SAN Router physical description All ports and connectors are located on the front of the SAN Router, as described in the following paragraphs.
  • Page 28: Operational Features

    Telnet from the RJ45 port is also available. Operational features The SAN Router features are described in Table 2, SAN Router features. Some features are optional and may not be present in some SAN Router software versions. SAN04M-R SAN Router Installation And Service Manual...
  • Page 29: San Router Features

    SAN Router features Table 2 Feature Description Intelligent Ports Two intelligent ports, which can be configured for Internet Small Computer Systems Interface (iSCSI) or Internet Fibre Channel Protocol (iFCP). Internet Fibre Channel The SAN Router supports the IETF draft standard for Protocol (iFCP) iFCP, which provides connectivity and networking for standards track...
  • Page 30: Element Manager Overview

    Port Configuration Fibre Channel and TCP Ports (supporting iSCSI and iFCP) Management Port Static Routing iFCP Setup iFCP Setup Configuration Remote Connections Configuration Port Redundancy Configuration iSCSI Configuration Device Configuration RADIUS Server Configuration SAN04M-R SAN Router Installation And Service Manual...
  • Page 31 Table 3 Element Manager software functions (Continued) Feature Description SAN Router Operations System Log Upgrade Firmware Reset the SAN Router Configuration Backup, and Restore Save Configuration Monitoring Device View LEDs and icons, system information icons Message Log Setting Polling Interval Reports and Statistics Ping GE Port Statistics...
  • Page 32: Software Requirements

    EFCM or PC Anywhere, are coresident with SANvergence Manager. b. DirectX 9.0b or later must be installed on the management workstation if additional software programs, such as EFCM or PC Anywhere, are coresident with SANvergence Manager. SAN04M-R SAN Router Installation And Service Manual...
  • Page 33: Before Installing The San Router

    Four SFP optics are included for multi-mode Fiber connectivity. • Release Notes. • Software and Documentation CD. • Two power cord retainers. • Torx Tool T10 (used with the rack mount kit only). If any items are damaged or missing, contact IBM: Chapter 1: Overview...
  • Page 34: Working With Sfps

    -within the United States and Canada, contact the IBM Quality Hotline toll-free 1-800-442-6773 -in other locations, direct dial: 770-858-8459. The rack mount kit is shipped separately from the router. Working with SFPs ATTENTION! Small Form Factor Pluggable (SFPs) are static-sensitive devices.
  • Page 35: Installing The San Router

    Installation task summary Task number and description Required or optional Page Task 1: Verifying installation requirements. Required performed by IBM service personnel. Task 2: Mounting the SAN Router. Required performed by IBM service personnel. Task 3: Powering up the SAN Router.
  • Page 36: Task 1: Verifying Installation Requirements

    Router. Ensure that a site plan is prepared, configuration planning tasks are complete, planning considerations are evaluated, and related planning checklists are complete. Refer to the IBM TotalStorage Products in a SAN Environment Planning Manual for information. Gathering preliminary site information Obtain and record the following information.
  • Page 37 • HBA vendor, model, driver version, topology setting (Pt-Pt, Loop, etc.). FC/iSCSI target information: • FC target/array model, firmware version, drive details. • SCSI bridge vendor, model, (Crossroads, etc.) and SCSI device details. FC Sub-fabric interconnect information: • FC switch vendor, model, firmware version, interconnect mode, domain ID, active zoneset.
  • Page 38: Task 2: Mounting The San Router

    The SAN Router is equipped with two universal power supplies that adjust to the 110V - 220V standards used in various countries. Two 120 VAC three-conductor power cords are shipped with the SAN Router. SAN04M-R SAN Router Installation And Service Manual...
  • Page 39 The SAN Router has no power switch and will power up when it is connected to a live power source. Either power supply can maintain power for the SAN Router; however, we recommend connecting both power supplies, each to a separate power source, for redundancy protection.
  • Page 40: Task 4: Preparing To Configure The San Router

    VT100 or emulation terminal to the RS-232 management port Task 6: Preparing the SAN Router for Element Manager access page 20. Table Table 7, and Table 8 list and describe the default settings for the IP SAN Router. SAN04M-R SAN Router Installation And Service Manual...
  • Page 41: Default Management And San Router Addresses

    Refer to Table 6 for the default setting for the Management Port IP address, which is the only IP address that must be changed using CLI to provide access for out-of-band management. All other default setting can be changed using the Element Manager. To set the SAN Router IP address, you can use one of three methods: 1.
  • Page 42: Task 5: Connecting The Vt100 Or Emulation Terminal To The

    Router. See Figure 3, Management port to management terminal connection. • Connect the male end of the cable to the RS-232 port on the terminal. See Figure 3, Management port to management terminal connection. SAN04M-R SAN Router Installation And Service Manual...
  • Page 43: Terminal Emulator Settings

    Management port to management terminal connection Figure 3 Location Description Connect null modem cable here. Connect other end to VT100 or emulation terminal. Set the 10/100 Ethernet out-of-band management address from here. (This connection does not require an IP address.) Connect this port to the external WAN/MAN/LAN Network router using a standard RJ45 CAT 5 cable.
  • Page 44: Task 6: Preparing The San Router For Element Manager Access

    3. Set or change management port IP address using the CLI: • At the command prompt enter: set mgmt portaddr <IP address><subnet mask> where: IP address = IP address of the management port SAN04M-R SAN Router Installation And Service Manual...
  • Page 45: Task 7: Initiating The Element Manager

    If you choose to continue configuring the SAN Router using CLI, please see the E/OSi Command Line Interface for IBM TotalStorage User Manual. Task 7: Initiating the Element Manager 1. Connect the standard RJ45 Cat 5 Ethernet cable from the LAN to the 10/100 management port (RJ45).
  • Page 46: Before You Connect The San Router To The Network

    Connect the iSCSI port to the iSCSI initiator or dedicated iSCSI LAN network. NOTE: Ensure that you have the IP addressing information available so these ports can be correctly configured for the connected network. SAN04M-R SAN Router Installation And Service Manual...
  • Page 47: Task 9: Connecting Fibre Channel Ports

    Intelligent ports Figure 4 Location Description Port 3 SFP Port 3 RJ45 Port 4 SFP Port 4 RJ45 Task 9: Connecting fibre channel ports Fibre Channel port connections These ports are the 1 Gbps SFP ports labeled ports 1 and 2 on the front of the SAN Router as shown in Figure 5, Fibre Channel ports.
  • Page 48: Task 10: Configure And Enable Call Home Notification

    EFC Manager Software User Manual. IP address management Figure 6, IP addresses associated with SAN Router for an illustration of the IP addresses associated with the SAN Router and how they are used in the network. SAN04M-R SAN Router Installation And Service Manual...
  • Page 49: Sfp Connectors And Cables

    External Network (iFCP/iSCSI) iFCP/iSCSI IP Address iFCP/iSCSI IP Address Port Port Internal Internal IP Address IP Address Router Inband SAN Router IP Address GE Port Internal Network (May contain other McDATA Switches) Figure 6 IP addresses associated with SAN Router SFP connectors and cables Each of the Fibre Channel/Gigabit Ethernet ports on the SAN Router has a socket for a Small Form Factor Pluggable (SFP) transceiver.
  • Page 50: Sfp Cable Requirements

    Cable specifications Both copper and fiber optic cable can be used on the SAN Router. Table 11 lists compatible cable types. NOTE: SFPs are available; please contact your sales representative for a quote. SAN04M-R SAN Router Installation And Service Manual...
  • Page 51: Cable Guidelines

    Compatible cable types Table 11 Type of Cable Range SFP Type 62.5 um Multi-Mode Fiber Optic FC/GE 2-300 m Short wave laser 50 um Multi-Mode Fiber Optic FC/GE 2-500 m Short wave laser 9 um Single Mode Fiber Optic 2-10 Km Long wave laser Copper 0-30 m (equalized cable)
  • Page 52: Management Port Pinouts

    Not used in the SAN Router. Input of the SAN Router. Output of the SAN Router. Output of the SAN Router. Ground Not used in the SAN Router. Connected to Pin 8. Connected to Pin 7. SAN04M-R SAN Router Installation And Service Manual...
  • Page 53: Rj45 Port Pinout

    RJ45 port pinout Figure 8, RJ45 pinout Table 13, RJ45 pinout description describe the RJ45 and 100/1000 Ethernet pinouts for the SAN Router. 1 3 4 5 6 7 8 RJ45 pinout Figure 8 RJ45 pinout description Table 13 Pin number Signal Comment 100 Ω...
  • Page 54 1. Insert the SFP through the port cover into the connector until the connector is firmly connected to the SFP. You should hear an audible click as it snaps into place. 2. Remove the protective plugs. 3. Install the fiber cabling. SAN04M-R SAN Router Installation And Service Manual...
  • Page 55: San Router Firmware Default Values

    SAN Router firmware default values If you need to restore the default values in the firmware, review Table 14 as the table lists all default values and how you can change or view the default values from Element Manager or SANvergence Manager.
  • Page 56 Auto Reset Port on Severe Errors Enabled Configuration>Port>FC/Ethernet>Advanced Smaller CWND Reduction Disabled Configuration>Port>FC/Ethernet>Advanced Quick Start Disabled Configuration>Port>FC/Ethernet>Advanced Reduced Slow Start Timeout Disabled Configuration>Port>FC/Ethernet>Advanced Disable Standard Congestion Avoidance Disabled Configuration>Port>FC/Ethernet>Advanced Reorder Resistance Disabled Configuration>Port>FC/Ethernet>Advanced SAN04M-R SAN Router Installation And Service Manual...
  • Page 57 SAN Router firmware default values for Element Manager (Continued) Table 14 Element Manager parameters Default setting Element Manager menu hierarchy MTU Size Auto Configuration>Port>FC/Ethernet>Advanced iSCSI parameters Selective ACKnowledgement Disabled Configuration>Port>FC/Ethernet>Advanced Large PDU Enabled Configuration>Port>FC/Ethernet>Advanced Initial R2T Enabled Configuration>Port>FC/Ethernet>Advanced Store and Forward Disabled Configuration>Port>FC/Ethernet>Advanced Target Read Padding...
  • Page 58 TCP Window Size Auto Configuration>iFCP>Remote Connections>Add Exported Zones None Configuration>iFCP>Remote Connections>Add iFCP port redundancy Backup for Port Disabled Configuration>iFCP>Port Redundancy Timeout for backup Activation (in secs) Configuration>iFCP>Port Redundancy Recovery Method Manual Configuration>iFCP>Port Redundancy SAN04M-R SAN Router Installation And Service Manual...
  • Page 59: San Router Firmware Default Values Via Sanvergence

    NOTE: If the SAN Router is shipped pre-installed in a cabinet, the default IP address is set during the cabinet configuration process to 10.xx.yy.zz where: xx is the cabinet number, yy is the product type identifier, which for the SAN Router is 16, and zz is the position in the cabinet, from bottom to top.
  • Page 60 SAN04M-R SAN Router Installation And Service Manual...
  • Page 61: Chapter 3 Maintenance And Troubleshooting

    Installing and configuring a TFTP server application - windows server You can install a TFTP server daemon for Windows 2000 Server or Windows Server 2003 to enable you to access and download firmware to the SAN Router. © Copyright IBM Corp. 2007...
  • Page 62: Download Firmware

    2. Enter or edit the TFTP Server IP address where the firmware image is stored. 3. Enter the filename of the Firmware file that should be present in your TFTP default directory. SAN04M-R SAN Router Installation And Service Manual...
  • Page 63: Activate New Firmware

    4. Click Download.When you download a new version, it is always saved in the inactive location. Firmware upgrade dialog box Figure 9 Activate new firmware To activate the new firmware: 1. Click Activate. The Activate Boot Location dialog displays both firmware locations and their respective build dates.
  • Page 64: Restore Prior Firmware Version

    NOTE: In order to perform troubleshooting effectively, you will need access to the Administration and Configuration Manual as the majority of troubleshooting information is provided in that manual. • For the meaning of LED indicators, see Table 16 on page 41. SAN04M-R SAN Router Installation And Service Manual...
  • Page 65: Leds On The San Router

    • For general troubleshooting, review Troubleshooting resources page 42 for a list of software applications you can use. • Other troubleshooting aids include: Retrieving the system log page 42 and on page 43. These Accessing SNMP alerts or alarms aids should be used in conjunction with the Administration and Configuration Guide troubleshooting procedures.
  • Page 66: Troubleshooting Resources

    This could include ports going up and down, mSNS unable to zone, a SAN Router task failing, and so on. The System Log is a fixed size. New entries are written to the beginning of the log overwriting the oldest entries. The log may be SAN04M-R SAN Router Installation And Service Manual...
  • Page 67: Accessing Snmp Alerts Or Alarms

    cleared out from time to time, so it is important to remember that the log may not include every error. To upload the System Log from the SAN Router to the management workstation, follow these instructions: 1. Select File>System Log>Retrieve to display the Retrieve System Log dialog box (Figure 10 on page 43).
  • Page 68 SNMP alerts or alarms that are useful in resolving hardware errors (this is not a complete list, review the Administration and Configuration Manual for a complete list of all SNMP alerts): SAN04M-R SAN Router Installation And Service Manual...
  • Page 69: Snmp Alerts Or Alarm Definitions

    SNMP alerts or alarm definitions Table 17 Alert or alarm name Description Cold Start The SAN Router is powered on, or rebooted. Informational only message, no action required. Link Down A GE interface loses an active link signal. Link Up A GE interface acquires an active link signal.
  • Page 70: Cleaning Fiber-Optic Components

    — Keep the air nozzle approximately 50 millimeters (two inches) from the end of the connector and hold the can upright. — Blow compressed air on the surfaces and end of the connector continuously for approximately five seconds. SAN04M-R SAN Router Installation And Service Manual...
  • Page 71: Clean Fiber-Optic Components

    Figure 12 Clean fiber-optic components 3. Gently wipe the end-face and other surfaces of the connector with an alcohol pad as shown in part 2 of Figure 12. Ensure the pad makes full contact with the surface to be cleaned. Wait approximately five seconds for cleaned surfaces to dry.
  • Page 72 SAN04M-R SAN Router Installation And Service Manual...
  • Page 73: Chapter 4 Parts Catalog

    When ordering spare parts, you must install RoHS compliant parts in any unit that contains a serial number that ends with the letter N. For example, if the serial number is 130000N, then that unit contains © Copyright IBM Corp. 2007...
  • Page 74: Fru List

    There are only two FRUs, the optics and the base assembly. FRU list-front accessible Table 18 Non-RoHS part RoHS part number number Description 22R6008 23R0680 Base assembly Reference Only Optical transceiver, XCVR,TRI-RATE,850NM,3.3V,SFP, DD SAN04M-R SAN Router Installation And Service Manual...
  • Page 75: Miscellaneous Parts

    Miscellaneous parts Figure 13 illustrates miscellaneous parts. Table 19 is the associated parts list. The table includes reference numbers to Figure 13, part numbers, descriptions, and quantities. Miscellaneous parts Figure 13 Miscellaneous parts list Table 19 Reference Part Number Description Reference only Plug, loopback, LC connector...
  • Page 76: Power Cords And Receptacles

    Power cords and receptacles Figure 14 illustrates optional power cords, receptacles, and associated parts list. The table includes reference numbers to Figure 14, feature numbers, and descriptions. 7, 11,15 12, 13,14 Power cords Figure 14 SAN04M-R SAN Router Installation And Service Manual...
  • Page 77: Power Cord Part Number List

    Power cord part number list Table 20 Ref. Part number Description Reference Only Power cord, AC, North America NEMA 5-15P straight, 125 volts, 10 amps, 3.0 meters Receptacle: NEMA 5-15R Reference Only Power cord, AC, United Kingdom BS 1363 right angle, 250 volts, 10 amps, 2.8 meters Receptacle: BS 1363 Reference Only Power cord, AC, European Community...
  • Page 78 NEMA 6-15P straight, 250 volts, 10 amps, 2.8 meters Receptacle: NEMA 6-15R Reference Only Power cord, AC, Japan JIS 8303 straight, 125 volts, 12 amps, 2.5 meters Receptacle: NEMA 5-15R Power cord, AC, 20V/10 A for cabinet installation SAN04M-R SAN Router Installation And Service Manual...
  • Page 79: Removal And Replacement Procedures

    FRU locations and part numbers. Parts Tools required The following tools are required to perform these procedures. • Door key with 5/16-inch socket (only for some equipment cabinets). • Protective cap (provided with the fiber-optic jumper cable). © Copyright IBM Corp. 2007...
  • Page 80 The locking bale rotates up or down, depending on the transceiver manufacturer and port location. a. Disengage the locking mechanism by rotating the wire locking bale up or down 90 degrees. SAN04M-R SAN Router Installation And Service Manual...
  • Page 81 7. Review in either Element Manager or SANvergence Manager to verify the error has been corrected. Replacement To replace an SFP optical transceiver: 1. Remove the replacement transceiver from its packaging. 2. Insert the transceiver into the port receptacle, then engage the locking mechanism by rotating the wire locking bale up or down 90 degrees.
  • Page 82 SAN04M-R SAN Router Installation And Service Manual...
  • Page 83: Specifications

    Height: 4.242 cm (1.67 in) Width: 43.637 cm (17.18 in) Depth: 45.250 cm (17.82 in) Weight: 6.35 kg (~14 lbs) Power requirements U.S./Japan: Nominal 100/120 volts, 50 to 60 Hz Europe/Australia: Nominal 220/240 volts, 50 to 60 Hz © Copyright IBM Corp. 2007...
  • Page 84: Power Consumption

    Redundant dual power supplies,125 watts maximum power each. Environmental requirements Temperature: 5° to 40° C (41° to 104° F) Humidity: 20% to 85% non-condensing Small form factor pluggable Contact your IBM sales representative for information on ordering SFPs. SAN04M-R SAN Router Installation And Service Manual...
  • Page 85: Notices

    This information was developed for products and services offered in the U. S. A. IBM may not offer the products, services, or features discussed in this document in other countries. Consult your local IBM representative for information on the products and services currently available in your area.
  • Page 86 The materials at those web sites are not part of the materials for this IBM product and use of those web sites is at your own risk.
  • Page 87: Trademarks

    Trademarks The following terms are trademarks of the International Business Machines Corporation in the United States, other countries, or both: IBM, ESCON, eServer, FICON. McDATA, EFC Manager, EFCM, Eclipse, OPENready, SANpilot, SANvergence, SANtegrity, Enterprise Operating System, E/OS, E/OSi, and E/OSn are trademarks of McDATA Corporation and its subsidiaries in the United States, other countries, or both.
  • Page 88: Federal Communications Commission (Fcc) Class A Statement

    IBM is not responsible for any radio or television interference caused by unauthorized changes or modifications to this equipment.
  • Page 89: Germany Electromagnetic Compatibility Directive

    Diese Einrichtung kann im Wohnbereich Funkstorungen verursachen; in diesem Fall kann vom Betreiber verlangt werden, angemessene Masnahmen durchzuführen und dafür aufzukommen.” Anmerkung: Um die Einhaltung des EMVG sicherzustellen, sind die Geräte wie in den IBM Handbüchern angegeben zu installieren und zu betreiben.
  • Page 90: People's Republic Of China Class A Electronic Emission Statement

    People’s Republic of China Class A Electronic Emission Statement Korean Class A Electronic Emission Statement Japan VCCI Class A ITE Electronic Emission Statement SAN04M-R SAN Router Installation And Service Manual...
  • Page 91: Index

    FRU removal location of SFP transceiver Power Consumption tools required Power cords FRU replacement power cords SFP transceiver illustrated parts breakdown tools required Power Requirements power status LEDs location of Power supply illustrated parts breakdown © Copyright IBM Corp. 2007...
  • Page 92 Specifications Surface mount procedure System log Terminal emulator settings TFTP server tools and test equipment FRU removal and replacement transceivers, compliance VT100 arrow emulation VT100 terminal Windows NT SAN04M-R SAN Router Installation And Service Manual...
  • Page 93 When you send comments to IBM, you grant IBM a nonexclusive right to use or distribute your comments in any way it believes appropriate without incurring any obligation to you. IBM or any other organizations will only use the personal information that you supply to contact you about the issues that you state on this form.
