- Page 1 2807616 2807616 2807616 2807616 AMD Geode NX Mini-ITX Motherboard USER’S MANUAL USER’S MANUAL USER’S MANUAL USER’S MANUAL Version 1.0...
- Page 2 AMD is a trademark of Advanced Micro Devices, Inc. Microsoft Windows is a registered trademark of Microsoft Corporation. Winbond is a registered trademark of Winbond Electronics Corporation. All other product names or trademarks are properties of their respective owners. 2807616 User’s Manual...
-
Page 3: Table Of Contents
Table of Contents Introduction ............1 Product Description.............1 Checklist ................2 2807616 Specifications ............3 Board Dimensions ...............4 Installations ............5 Installing the CPU ...............6 Installing the Memory ............7 Setting the Jumpers .............8 Connectors on 2807616.............11 BIOS Setup ............21 Drivers Installation ........ - Page 4 THE 2807616 MINI ITX MOTHERBOARD 2807616 User’s Manual...
-
Page 5: Introduction
INTRODUCTION Introduction Product Description The 2807616 Mini ITX board incorporates a Socket A processor socket that supports AMD Geode NX series processors that support processor speed up to 1.4GHz. With the SIS 741CX chipset, it delivers maximum performance for demanding thin client or embedded applications that require silent system operation. -
Page 6: Checklist
INTRODUCTION Checklist Your 2807616 package should include the items listed below. ® • • • • The 2807616 Pentium M Mini-ITX motherboard • • • • This User’s Manual • • • • 1 CD containing chipset drivers and flash memory utility •... -
Page 7: 2807616 Specifications
4 ports on board Pin header for 2 additional ports (USB 2.0) Audio SiS 964 built-in audio + AC97 codec, SPDIF support; 2W+2W volume amplifier Others 1394, ATX power connector Mechanical and Environmental 170mm x 170mm Dimensions 2807616 User’s Manual... -
Page 8: Board Dimensions
INTRODUCTION Board Dimensions 2807616 User’s Manual... -
Page 9: Installations
INSTALLATIONS Installations This section provides information on how to use the jumpers and connectors on the 2807616 in order to set up a workable system. The topics covered are: Installing the CPU ................ 6 Installing the Memory..............7 Setting the Jumpers............... 8 Connectors on 2807616.............. -
Page 10: Installing The Cpu
INSTALLATIONS Installing the CPU The 2807616 board supports a Socket A processor socket for AMD NX Series processors. The Socket A processor socket comes with a lever to secure the processor. Raise this lever to about a 90° angle to allow the insertion of the processor. -
Page 11: Installing The Memory
INSTALLATIONS Installing the Memory The 2807616 board supports one DDR memory socket for a maximum total memory of 1GB in DDR memory type. Installing and Removing Memory Modules To install the DDR modules, locate the memory slot on the board and perform the following steps: 1. -
Page 12: Setting The Jumpers
INSTALLATIONS Setting the Jumpers Jumpers are used on 2807616 to select various settings and features according to your needs and applications. Contact your supplier if you have doubts about the best configuration for your needs. The following lists the connectors on 2807616 and their respective functions. -
Page 13: Jumper Locations On 2807616
INSTALLATIONS Jumper Locations on 2807616 Jumpers on 2807616 ................ Page JP8: CompactFlash Slave/Master Selection ......... 10 JP9: 1394 EPROM Write Selection ............. 10 JP12: Clear CMOS Setting..............10 JP14: RTL8110S-32 LAN Enable / Disable ........10 2807616 User’s Manual... -
Page 14: Jp8: Compactflash Slave/Master Selection
Remarks: The CF socket and its corresponding slave/master Selection is optional. CF Setting Master Slave JP9: 1394 EPROM Write Selection 1394 EPROM For EPROM Write Normal JP12: Clear CMOS Setting JP12 Setting Normal Clear CMOS JP14: RTL8110S-32 LAN Enable / Disable JP14 Gigabit LAN Disable Enable 2807616 User’s Manual... -
Page 15: Connectors On 2807616
INSTALLATIONS Connectors on 2807616 The connectors on 2807616 allow you to connect external devices such as keyboard, floppy disk drives, hard disk drives, printers, etc. The following table lists the connectors on 2807616 and their respective functions. Connector Locations on 2807616 ..........12 KBMS1: PS/2 Keyboard and PS/2 Mouse Connectors.... -
Page 16: Connector Locations On 2807616
INSTALLATIONS Connector Locations on 2807616 Remarks: GB LAN and 1394 are options found on 2807616 only. 2807616 User’s Manual... -
Page 17: Kbms1: Ps/2 Keyboard And Ps/2 Mouse Connectors
Keyboard clock Mouse clock N.C. N.C. CN3: COM1 and VGA Connector Signal Name Pin # Pin # Signal Name Not Used [[[[ Signal Name Pin # Pin # Signal Name Green Blue N.C. N.C. N.C. N.C. HSYNC VSYNC 2807616 User’s Manual... -
Page 18: Cn4: 10/100 Rj-45 And Usb1/2 Ports
The audio connector, from top to bottom, is composed of Line in, Line out and Microphone jacks. PWR1: ATX Power Supply Connector Signal Name Pin # Pin # Signal Name 3.3V 3.3V -12V 3.3V Ground Ground PS-ON Ground Ground Ground Ground Ground Power good 5VSB +12V +12V Ground +3.3V 2807616 User’s Manual... -
Page 19: Fan1: System Fan Power Connector
Host data 15 Ground Protect pin DRQ0 Ground Host IOW Ground Host IOR Ground IOCHRDY Host ALE DACK0 Ground IRQ14 No connect IDE1 Address 1 No connect Address 0 Address 2 Chip select 0 Chip select 1 Activity Ground 2807616 User’s Manual... -
Page 20: Fdd1: Floppy Drive Connector
N.C. FDD1: Floppy Drive Connector FDD1is a slim 26-pin connector and will support up to 2.88MB FDD. Signal Name Pin # Pin # Signal Name INDEX DRV_SEL DSK_CH MOTOR DINST STEP WDATA WGATE TRACK WPROT RDATA SIDE 2807616 User’s Manual... -
Page 21: Cn1: Digital I/O
RTS, Request to send TXD, Transmit data CTS, Clear to send DTR, Data terminal ready RI, Ring indicator GND, ground Not Used J2: 1394 Pin Header Signal Name Signal Name TPA+ TPB+ TPA- TPB- +12V GND7 J4: Mini PCI Connector 2807616 User’s Manual... -
Page 22: J5: System Function Connector
Signal Name CD Audio R Ground Ground CD Audio L CN8: Speaker Connector The J15 connector supports 2W/8ohm stereo audio power amplifier. Pin # Signal Name Audio L Ground Ground Audio R CN9, CN10: Serial ATA Connectors 2807616 User’s Manual... -
Page 23: Cn11: Compact Flash Connector
INSTALLATIONS CN11: Compact Flash Connector J13: IrDA Connector Pin # Signal Name No connect Ir RX Ground Ir TX PCI1: PCI Slot (supports 2 Master) AGP1: MicroAGP Socket 2807616 User’s Manual... - Page 24 INSTALLATIONS This page is intentionally left blank. 2807616 User’s Manual...
-
Page 25: Bios Setup
PNP/PCI Configurations ............... 36 PC Health Status ................37 Frequency/Voltage Control............38 Load Fail-Safe Defaults ..............39 Load Optimized Defaults .............. 39 Set Supervisor/User Password ............39 Save & Exit Setup ................. 39 Exit Without Saving..............39 2807616 User’s Manual... -
Page 26: Bios Introduction
<PgUp> and <PgDn> keys to change entries, <F1> for help and <Esc> to quit. When you enter the Setup utility, the Main Menu screen will appear on the screen. The Main Menu allows you to select from various setup functions and exit choices. 2807616 User’s Manual... - Page 27 These defaults have been carefully chosen by both Award and your system manufacturer to provide the absolute maximum performance and reliability. Changing the defaults could cause the system to become unstable and crash in some cases. 2807616 User’s Manual...
-
Page 28: Standard Cmos Setup
The following describes each item of this menu. Date The date format is: Day : Sun to Sat Month : 1 to 12 Date : 1 to 31 Year : 1999 to 2099 2807616 User’s Manual... - Page 29 These fields identify the types of floppy disk drive A or drive B that has been installed in the computer. The available specifications are: 360KB 1.2MB 720KB 1.44MB 2.88MB 5.25 in. 5.25 in. 3.5 in. 3.5 in. 3.5 in. 2807616 User’s Manual...
- Page 30 The system boot will not be halted for a disk error; it will stop for all other errors. All, But Disk/Key The system boot will not be halted for a key- board or disk error; it will stop for all others. 2807616 User’s Manual...
-
Page 31: Advanced Bios Features
When the CPU requests data, the system transfers the requested data from the main DRAM into cache memory, for even faster access by the CPU. These items allow you to enable (speed up memory access) or disable the cache function. By default, these items are enabled. 2807616 User’s Manual... - Page 32 When enabled, you can set the two typematic controls listed next. By default, this field is set to Disabled. Typematic Rate (Chars/Sec) When the typematic rate is enabled, the system registers repeated keystrokes speeds. Settings are from 6 to 30 characters per second. 2807616 User’s Manual...
- Page 33 BIOS code from the slow ROM in which it resides into faster RAM Small Logo (EPA) Show The EPA logo appears at the right side of the monitor screen when the system is boot up. The default setting is Enabled. 2807616 User’s Manual...
-
Page 34: Advanced Chipset Features
CPU Command ACK Limit (8) AGP & P2P Bridge Control The fields in this option and their respective default settings are as follows: AGP Aperture Size (64MB) AGP Fast Write Support (Disabled) AGP Data Transfer Rate (Auto) 2807616 User’s Manual... - Page 35 Memory Hole At 15M-16M In order to improve performance, certain space in memory can be reserved for ISA cards. This memory must be mapped into the memory space below 16 MB. The choices are Enabled and Disabled. 2807616 User’s Manual...
-
Page 36: Integrated Peripherals
6 Ports Menu Level > USB Ports Number Enabled USB 2.0 Supports USB Keyboard Support Disabled USB Mouse Support Disabled SIS AC97 Audio Enabled SIS 10/100M Ethernet Enabled SIS Serial ATA Controller Enabled SIS Serial ATA Mode 2807616 User’s Manual... - Page 37 This option allows you to select the onboard FDD port. Onboard Serial Port These fields allow you to select the onboard serial ports and their addresses. The default values for these ports are: Serial Port 1 3F8/IRQ4 Serial Port 2 2F8/IRQ3 2807616 User’s Manual...
-
Page 38: Power Management Setup
Suspend => Off: Screen off when system is in SUSPEND mode. • Susp, Stby => Off: Screen off when system is in STANDBY or SUSPEND mode. • All modes => Off: Screen off when system is in DOZE, STANDBY or SUSPEND mode. 2807616 User’s Manual... - Page 39 The default setting is Always Off. PM Wake Up Events Users can enable system events (IRQ, Ring Power Up, MACPME Power Up, PCIPME Power Up, PS2KB Wakeup, PS2MS Wakeup, Power up by Alarm) to wake up the system. 2807616 User’s Manual...
-
Page 40: Pnp/Pci Configurations
This field allows you to set whether or not MPEG ISA/VESA VGA cards can work with PCI/VGA. When this field is enabled, a PCI/VGA can work with an MPEG ISA/VESA VGA card. When this field is disabled, a PCI/VGA cannot work with an MPEG ISA/VESA card. 2807616 User’s Manual... -
Page 41: Pc Health Status
Shutdown Temperature This field allows the user to set the temperature by which the system automatically shuts down once the threshold temperature is reached. This function can help prevent damage to the system that is caused by overheating. 2807616 User’s Manual... -
Page 42: Frequency/Voltage Control
Auto Detect PCI Clk This field enables or disables the auto detection of the PCI clock. Spread Spectrum This field sets the value of the spread spectrum. The default setting is Disabled. This field is for CE testing use only 2807616 User’s Manual... -
Page 43: Load Fail-Safe Defaults
Select this option to exit the Setup utility without saving the changes you have made in this session. Typing “Y” will quit the Setup utility without saving the modifications. Typing “N” will return you to Setup utility. 2807616 User’s Manual... - Page 44 BIOS SETUP This page is intentionally left blank. 2807616 User’s Manual...
-
Page 45: Drivers Installation
If you find the items missing, please contact the vendor where you made the purchase. The contents of this section include the following: SIS 741CX Chipset VGA Driver ........42 SIS Chipset Ethernet Driver ..........45 Realtek Gigabit Ethernet Driver........47 Realtek AC97 Codec Driver..........48 2807616 User’s Manual... -
Page 46: Sis 741Cx Chipset Vga Driver
DRIVER INSTALLATION SIS 741CX Chipset VGA Driver 1. Insert the CD that comes with the board. Click TI/Ali/SiS Chipset and then SiS741CX/SiS964 Chipset Drivers. 2807616 User’s Manual... - Page 47 DRIVERS INSTALLATION 2. When the welcome screen to the InstallShield Wizard appears, click Next. 3. Click Next. (Select Typical setup, as default.). 2807616 User’s Manual...
- Page 48 DRIVER INSTALLATION 4. Click Next, when asked to select the Program Folder listed. 5. Click Next for Setup to start the copying process. 6. When prompted, click Finish to restart the computer and for changes to take effect. 2807616 User’s Manual...
-
Page 49: Sis Chipset Ethernet Driver
SIS Chipset Ethernet Driver 1. Insert the CD that comes with the board. Click TI/Ali/SiS Chipset and then SiS PCI Fast Ethernet Adapter Driver. 2. When the InstallShield Wizard appears, click Next to continue with the Ethernet drivers installation. 2807616 User’s Manual... - Page 50 DRIVER INSTALLATION 3. After the drivers are installed succesfully, you will be promted to restart the computer. Restart the computer for changes to take effect. 2807616 User’s Manual...
-
Page 51: Realtek Gigabit Ethernet Driver
1. Insert the CD that comes with the board. Click LAN Card on the left side and then Realtek Network Interface Controller Drivers to execute the REALTEK Gigabit and Fast Ethernet NIC Driver Setup. 2. When the maintenance is complete, click Finish to complete the drivers setup. 2807616 User’s Manual... -
Page 52: Realtek Ac97 Codec Driver
DRIVER INSTALLATION Realtek AC97 Codec Driver 1. Insert the CD that comes with the board. Click TI/Ali/SiS Chipset and then Realtek AC’97 Codec Audio Driver. 2807616 User’s Manual... - Page 53 2. When the welcome screen to the InstallShield Wizard appears, click Next to proceed with the Realtek AC97 Audio Setup. 3. InstallShield Wizard is not complete and you are prompted to restart your computer. Restart the computer for changes to take effect. 2807616 User’s Manual...
-
Page 54: Appendix
Parallel Port #1(LPT1) 360 - 36F Network Ports 3B0 - 3BF Monochrome & Printer adapter 3C0 - 3CF EGA adapter 3D0 - 3DF CGA adapter 3F0h - 3F7h Floppy Disk Controller 3F8h - 3FFh Serial Port #1(COM1) 2807616 User’s Manual... -
Page 55: Interrupt Request Lines (Irq)
Serial Port #2 IRQ4 Serial Port #1 IRQ5 Reserved IRQ6 Floppy Disk Controller IRQ7 Parallel Port #1 IRQ8 Real Time Clock IRQ9 Reserved IRQ10 Reserved IRQ11 Reserved IRQ12 PS/2 Mouse IRQ13 80287 IRQ14 Primary IDE IRQ15 Secondary IDE 2807616 User’s Manual... - Page 56 We will do our best to support you for your products, projects and business Global American Inc. Address 17 Hampshire Drive Hudson, NH 03051 Toll Free (U.S. Only) 800-833-8999 or (603)886-3900 (603)886-4545 Website http://www.globalamericaninc.com sales@globalamericaninc.com E-Mail 2807616 User’s Manual...
