- Page 1 User’s Manual Mini-ITX M Motherboard 2 2807790 Version 1.0, August 2007...
- Page 2 Copyrights This manual is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer. In general, the manufacturer will not be liable for any direct, indirect, special, incidental or consequential damages arising from the use of inability to use the product or documentation, even if advised of the possibility of such damages.
-
Page 3: Safety Instructions
Safety Instructions Always read the safety instructions carefully. Keep this User’s Manual for future reference. Keep this equipment away from humidity. Lay this equipment on a reliable flat surface before setting it up. The openings on the enclosure are for air convection hence protects the equip- ment from overheating. - Page 4 Shielded interface cables and A.C. power cord, if any, must be used in order to comply with the emission limits. VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU RESEAU. 2807790 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:...
-
Page 5: Table Of Contents
CONTENTS Technical Support ....................ii Safety Instructions ....................iii FCC-B Radio Frequency Interference Statement ........... iv WEEE (Waste Electrical and Electronic Equipment) Statement ........ v Chapter 1 Product Overview ................1-1 Mainboard Specifications ................1-2 Block Diagram ....................1-4 Mainboard Layout ..................1-5 Powre Consumption .................. - Page 6 2807790 Mainboard Mainboard Specifications Processor Support - AMD Sempron ,Athlon 64/64 X2 (Dual Core) processor with AM2 package - 4-pin CPU fan pinheader with Smart Fan Speed Control Supported FSB - Hyper Transport supporting speed up to 1 GHz (2000MT/s)
-
Page 7: Chapter 1 Product Overview
Product Overview Connectors Rear I/O - 1 PS/2 mouse port - 1 PS/2 keyboard port - 2 COM ports - 1 VGA/ HDMI stack connector - 4 USB ports - 5 flexible audio jacks - 1 optical SPDIF-out jack Onboard Connector - 2 USB connectors (4 ports) - 1 parallel port connector (LPT) - 1 LVDS connector... -
Page 8: Block Diagram
2807790 Mainboard Block Diagram... -
Page 9: Mainboard Layout
To p: VGA Port Bottom : HDMI SATA1 SATA2 RS690T Line-I n/ S S-Out SB600 Wi nbond L ine-Out W83627DHG T:RS-Out M:CS -Out J USB 2 CON1 B:SPDIF Out JTV1 J USB 1 PCI1 JAUD1 JFP1 CPUFAN1 SYSFAN1 (2807790 v1.X) Mini ITX Mainboard... -
Page 10: Power Consumption
2807790 Mainboard Power Consumption Component Description AMD Athlon™ 64 x2 Dual Core 2G DDR2 1024MB DDR2 533 *2 Maxtor 80G2807790 NEC DVD-Multi Record ND-4550A 12Vp 3.3V 5VSB -12V AMD ThermNow! Utility 0.81 3.03 1.08 0.032 0.028 79.33 Particle Fuly + VCD + Xcopy 3.07... -
Page 11: Safety Compliance & Mtbf
Product Overview Safety compliance & MTBF Safety compliance Certification Standard number Title of standard EN 55022:1998+A1:2000+A2:2003 Class B Product family standard Limits for harmonic current EN 6100-3-2:2000 Class D emission Limitation of voltage fluctuation EN 6100-3-3:1995+A1:2001 and flicker in low-voltage supply system Immunity EN 55024:1998+A1:2001+A2:2003 Product family standard... -
Page 12: Board Dimension
2807790 Mainboard Board Dimension... -
Page 13: Back Panel & I/O Shield Drawing
Product Overview Back Panel & I/O Shield Drawing... -
Page 14: Chapter 2 Hardware Setup
Hardware Setup Chapter 2 Hardware Setup This chapter provides you with the information about hardware setup procedures. While doing the installation, be careful in holding the components and follow the installation procedures. For some components, if you install in the wrong orientation, the components will not work properly. -
Page 15: Quick Components Guide
2807790 Mainboard Quick Components Guide DIMM1~2, CPU, p.2-3 J1~J2, p.2-4 p.2-16 Back Panel, p.2-8 J4, p.2-15 JPW1, p.2-7 ATX1, p.2-7 IDEB1, p.2-10 J3, p.2-16 SATA1~2, JLVDS1, p.2-11 p.2-15 JLPT1, p.2-13 JAUD1, p.2-12 JCASE1, p.2-11 Mini PCIE, p.2-17 SYSFAN1, p.2-13 PCI1, p.2-17 CPUFAN1, p.2-13... -
Page 16: Memory
Hardware Setup Memory The mainboard provides two 200-pin unbuffered DDR2 400/533/667/800 SO-DIMM slots and supports up to 4GB system memory. DIMM2 200-pin, unbuffered DIMM1 200-pin, unbuffered Installing Memory Modules 1. The memory module has only one notch on the center and will only fit in the right orientation. -
Page 17: Cpu (Central Processing Unit)
2807790 Mainboard CPU (Central Processing Unit) The mainboard supports AMD Athlon64/ 64x2 & Sempron processors. The mainboard ® uses a CPU socket called Socket AM2 for easy CPU installation. When you are installing the CPU, make sure the CPU has a heat sink and a cooling fan attached on the top to prevent overheating. -
Page 18: Cpu Installation Procedures For Socket Am2
Hardware Setup CPU Installation Procedures for Socket AM2 1. Please turn off the power and unplug the power cord before Op en Lev er installing the CPU. Slid ing 2. Pull the lever sideways away 90 de gree Pla te from the socket. -
Page 19: Installing Amd Socket Am2 Cpu Cooler Set
2807790 Mainboard Installing AMD Socket AM2 CPU Cooler Set When you are installing the CPU, make sure the CPU has a heat sink and a cooling fan attached on the top to prevent overheating. If you do not have the heat sink and cooling fan, contact your dealer to purchase and install them before turning on the computer. -
Page 20: Power Supply
Hardware Setup Power Supply ATX 20-Pin System Power Connector: ATX1 This connector allows you to connect to an ATX power supply. To connect to the ATX power supply, make sure the plug of the power supply is inserted in the proper orientation and the pins are aligned. -
Page 21: Back Panel
2807790 Mainboard Back Panel Line-In/ RS-Out SS-Out Serial Port VGA Port M ouse Line-Out CS-Out Mic-In SPDIF-Out Keyboard Serial Port HDMI Port Mouse/Keyboard Connector The standard PS/2 mouse/keyboard DIN connector is for a PS/2 mouse/keyboard. ® ® Serial Port The serial port is a 16550A high speed communications port that sends/ receives 16 bytes FIFOs. - Page 22 Hardware Setup VGA Port The DB15-pin female connector is provided for video monitors. HDMI Port The High-Definition Multimedia Interface (HDMI) is an all-digital audio/video interface capable of transmitting uncompressed streams. HDMI supports all TV format, including standard, enhanced, or high-definition video, plus multi-channel digital audio on a single cable.
-
Page 23: Connectors
2807790 Mainboard Connectors IDE Connector: IDEB1 The mainboard has a 32-bit Enhanced PCI IDE and Ultra DMA 33/66/100/133 controller that provides PIO mode 0~4, Bus Master, and Ultra DMA 33/66/100/133 function. You can connect hard disk drives, CD-ROM and other IDE devices. - Page 24 Hardware Setup Serial ATA Connectors: SATA1, SATA2 SATA1~SATA2 are high-speed SATA interface ports and support SATA data rates of 300MB/s. Each SATA connector can connect to 1 hard disk device and is fully compliant with Serial ATA 2.0 specifications. SATA1 SATA2 Important Please do not fold the Serial ATA cable into 90-degree angle.
- Page 25 2807790 Mainboard Audio Amplifier Connector: JAUD1 The 6W JAUD1 is used to connect audio amplifiers to enhance audio performance. Pin Definition SIGNAL JAUD1 AMP_R+ AMP_R- AMP_L+ AMP_L- Front Panel Connector: JFP1 The mainboard provides one front panel connector for electrical connection to the front panel switches and LEDs.
- Page 26 Hardware Setup Fan Power Connectors: CPUFAN1, SYSFAN1 The fan power connectors support system cooling fan with +12V. When connecting the wire to the connectors, always take note that the red wire is the positive and should be connected to the +12V, the black wire is Ground and should be connected to GND.
- Page 27 2807790 Mainboard Front USB Connector: JUSB1/ JUSB2 The USB 2.0 pinheader is compliant with Intel I/O Connectivity Design Guide. USB 2. ® 0 technology increases data transfer rate up to a maximum throughput of 480Mbps, which is 40 times faster than USB 1.1, and is ideal for connecting high-speed USB interface peripherals such as USB HDD, digital cameras, MP3 players, printers, modems and the like.
- Page 28 Hardware Setup LVDS Flat Panel Connector: JLVDS1 The LVDS (Low Voltage Differential Signal) Display Matrix connector provides a digital interface typically HDMI LVDS TV OUT used with flat panels. After connecting an LVDS interfaced flat panel to the JLVDS1, be HDMI sure to check the panel datasheet and set the LVDS...
-
Page 29: Jumpers
2807790 Mainboard Jumpers COM Port Power Jumpers: J1, J2 These jumpers specify the operation voltage of the onboard serial ports. +12V Clear CMOS Jumper: JBAT1 There is a CMOS RAM onboard that has a power supply from external battery to keep the data of system configuration. -
Page 30: Slots
Hardware Setup Slots Mini PCI (Peripheral Component Interconnect) Express Slot The CON1 is Mini PCI-E connector for wireless LAN, TV tuner, and Robson NAND Flash. Mini PCI-E Slot PCI (Peripheral Component Interconnect) Slot The PCI slot supports LAN card, SCSI card, USB card, and other add-on cards that comply with PCI specifications. -
Page 31: Chapter 3 System Resources
System Resources Chapter 3 System Resources This chapter provides information on the following system resources: 1. Watch Dog Timer Setting (p. 3-2) 2. AMI POST Code (p. 3-3) 3. Resource List (p. 3-6) -
Page 32: Watch Dog Timer Setting
2807790 Mainboard3 Watch Dog Timer Setting Software code SIO_IDX equ 4EH SIO_DTA equ 4FH Timer equ 10; reset after 10 seconds 1. Enter configuration mode mov dx,SIO_IDX mov al,87h out dx,al out dx,al 2. Set to LDN 08 mov dx,SIO_IDX... -
Page 33: Ami Post Code
System Resources AMI POST Code Bootblock Initialization Code Checkpoinits The Bootblock initialization code sets up the chipset, memory and other components before system memory is available. The following table describes the type of check- points that may occur during the bootblock initialization portion of the BIOS: Bootblock Initialization Code Checkpoint list Checkpoint Description... - Page 34 2807790 Mainboard Post Code Checkpoints The POST code checkpoints are the largest set of checkpoints during the BIOS preboot process. The following table describes the type of checkpoints that may occur during the POST portion of the BIOS: Checkpoint Description Disable NMI, Parity, video for EGA, and DMA controllers.
- Page 35 System Resources Checkpoint Description Initializes different devices through DIM. Initializes DMAC-1 & DMAC-2. Initializes RTC date/time. Test for total memory installed in the system. Also, Check for DEL or ESC keys to limit memory test. Display total memory in the system. Mid POST initialization of chipset registers.
-
Page 36: Resource List
2807790 Mainboard Resource List SB600 GPIO Config. Multiplexed Power G PIO Pi n Type Function GPIO0 I/OD(3.3V) M ain GPIO1 I/O(3.3V) M ain GPIO2 I/O(3.3V) M ain GPIO3 I/O(3.3V) M ain M ain GPIO4 I/O(3.3V) M ain GPIO5 I/O(3.3V) GPIO6 I/OD(3.3V) -
Page 37: System Resources
System Resources SB600 GPM Config. Multiplexed Power GP M Pi n Type Function USB OverC urrent USB_OC0# Standby GPM#0 I/O(S5_3.3V) USB OverC urrent USB_OC1# Standby GPM#1 I/O(S5_3.3V) Standby GPM#2 I/O(S5_3.3V) Standby GPM#3 I/O(S5_3.3V) Standby GPM#4 I/O(S5_3.3V) WLAN _PWRON Standby GPM#5 I/O/OD(S5_3.3V) GPM6# Standby... - Page 38 2807790 Mainboard I/O Map I/O Port Description 0000-000F DMA Controller 1 0020-0021 Interrupt Controller 1 002E-002F SIO Port 0040-0043 ystem Timer 004E-004F TPM Port 0060, 0064 Keyboard Controller 0070-0073 RTC and CMOS 0080-0090 DMA Controller Page Registers 0092 Port 92h...
- Page 39 System Resources PCI Devices PCI Device Device Ven. ID Dev. ID Bus# Dev# Func# ATi Host Bridge 1002 7910 ATi PCI-to-PCI Bridge 1002 7912 ATi PCI-to-PCI Bridge 1002 7914 ATi PCI-to-PCI Bridge 1002 7915 ATi PCI-to-PCI Bridge 1002 7916 ATi IDE Controller 1002 4380 ATi OHCI USB Controller...
- Page 40 2807790 Mainboard SMBus Resource Allocation SMBus Resource Allocation Device Address Description MS-6 0101 111X ACPI Controller DIMM Slot 1010 0000 ISA Interrupt Allocation ISA Interrupt Allocation Description IRQ0 System Timer IRQ1 Keyboard Controller IRQ2 Cascade Interrupt IRQ3 COM2 IRQ4 COM1...
- Page 41 Any advice or comments about our products and service, or anything we can help you with please don’t hesitate to contact with us. We will do our best to support your products, projects and business. Address: Global American, Inc. 17 Hampshire Drive Hudson, NH 03051 Telephone: Toll Free (U.S.
