Merlin Condor 1380 Instruction Manual page 6

7
Remove the backing of the double sided
tape on the vertical fin and install it to the
stabiliser
9
Carefully widen the tail of the
2 -3 mm
11
Insert the pushrod clips into the middle hole
on the vertical fin and stabiliser arms
13
Open the canopy as shown above
8
10
fuselage by
12
14
6
Remove the backing of the double sided
tape on the bottom of the stabiliser
Insert the fin and stabiliser into the tail of the
fuselage pressing firmly to ensure double
sided tape adheres
After assembly check the symmetry and
alignment of the main wing and tail
Ensuring the power switch is OFF plug in
and install the battery
