Page 1 Toshiba Personal Computer Satellite T130D/Satellite ProT130D/PORTEGE T130D Maintenance Manual TOSHIBA CORPORATION File Number 960-Q08 Satellite T130D/Satellite ProT130D/PORTEGE T130DMaintenance Manual (960-Q08)
Page 2 © 2009 by Toshiba Corporation. All rights reserved. Under the copyright laws, this manual cannot be reproduced in any form without the prior written permission of Toshiba. No patent liability is assumed with respect to the use of the information contained herein.
Page 3 NOTE: “Note” contains general information that relates to your safe maintenance service. Improper repair of the computer may result in safety hazards. Toshiba requires service technicians and authorized dealers or service providers to ensure the following safety precautions are adhered to strictly.
Page 4 The manual is divided into the following parts: Chapter 1 Hardware Overview describes the Satellite T130D, Satellite Pro T130D, and PORTEGE T130D system unit and each FRU. Chapter 2 Troubleshooting Procedures explains how to diagnose and resolve FRU problems. Chapter 3 Test and Diagnostics describes how to perform test and diagnostic operations for maintenance service.
Page 5 Text that you are instructed to type in is shown in the boldface type below: DISKCOPY A: B: The display Text generated by the computer that appears on its display is presented in the typeface below: Format complete System transferred Satellite T130D/Satellite ProT130D/PORTEGE T130DMaintenance Manual (960-Q08)
Page 6: Table Of Contents
Table of Contents Chapter 1 Hardware Overview Features ..........................1 System Block Diagram ....................6 2.5-inch Hard Disk Drive....................9 Keyboard........................12 TFT Color Display.......................13 Power Rails ........................15 Batteries ........................16 AC Adapter ........................19 Satellite T130D/Satellite ProT130D/PORTEGE T130DMaintenance Manual (960-Q08)
Page 7 Diagnostic Test Program Execution Check ......19 Procedure 2 Connector Check and Replacement Check......20 Touch pad Troubleshooting ..................21 Procedure 1 Diagnostic Test Program Execution Check ......21 Procedure 2 Connector Check and Replacement Check......22 Satellite T130D/Satellite ProT130D/PORTEGE T130DMaintenance Manual (960-Q08)
Page 8 Diagnostic Test Program Execution Check ......36 Procedure 2 Connect Check and Replacement Check…………………….36 2.15 3G Troubleshooting .....................37 Procedure 1 Connector Check and Replacement Check......37 2.16 Camera Troubleshooting....................38 Procedure 1 Camera Execution Check............38 Procedure 2 Connect Check and Replacement Check…………………….38 Satellite T130D/Satellite ProT130D/PORTEGE T130DMaintenance Manual (960-Q08)
Page 9 Procedure 1 Diagnostic Test Program Execution Check ......41 Procedure 2 Connect Check and Replacement Check…………………….41 2.20 LED Troubleshooting ....................42 Procedure 1 Each function Execution Check..........42 Procedure 2 Connect Check and Replacement Check……………………42 Satellite T130D/Satellite ProT130D/PORTEGE T130DMaintenance Manual (960-Q08)
Page 10 3.14 Error Codes and Error Status Names ................55 3.15 Running Test........................57 3.16 DMI INFOEMATION ....................58 3.17 Log Utilities .........................60 3.18 System Configuration ....................62 3.19 Running Test Edit Item....................63 3.20 Common Tests and Operation ..................65 Satellite T130D/Satellite ProT130D/PORTEGE T130DMaintenance Manual (960-Q08)
Page 11 I/O board ........................43 4.12 System Board ......................45 4.13 CPU ..........................50 4.14 LCD unit ........................52 4.15 Web Camera Module ....................56 4.16 Application for Thermal grease on CPU and North Bridge…………………………59 4.17 Speaker Box………………………………………………………………………….61 Satellite T130D/Satellite ProT130D/PORTEGE T130DMaintenance Manual (960-Q08)
Page 12 Appendices Appendix A Handling the LCD Module ................1 Appendix B Board Layout .....................1 Appendix C Pin Assignments....................1 Appendix D Keyboard Scan/Character Codes ...............1 Appendix E Key Layout......................1 Appendix F Wiring Diagrams....................1 Satellite T130D/Satellite ProT130D/PORTEGE T130DMaintenance Manual (960-Q08)
Page 13: Chapter 1 Hardware Overview
Chapter 1 Hardware Overview Chapter 1 Hardware Overview Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 14: System Block Diagram
Features ......................... 1 System Block Diagram ....................6 2.5-inch Hard Disk Drive....................9 Keyboard........................12 TFT Color Display...................... 13 Power Rails ......................... 15 Batteries ........................16 AC Adapter ......................... 19 Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 15 Time required for charges of main battery ............. 17 Table 1-7-3 Data preservation time ..................17 Table 1-7-4 Time required for charge of RTC battery ............18 Table 1-8-1 AC adapter specifications ................19 Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 16: Features
Chapter 1 Hardware Overview Features 1.1 Features The Satellite T130D, Satellite T130D, PORTEGE T130D (AMD Platform) features are listed below. Microprocessor Microprocessor that is used will be different by the model. It supports processors as follows -1.6GHz (18W), Turion X2 Neo Dual-Core Processor L625 -1.5GHz (18W), Athlon X2 Neo Dual-Core Processor L325...
Page 17 Some computers in this series are equipped with a Wireless LAN card. The computer has built-in support for Ethernet LAN (10 megabits per second, 10BASE-T) and Fast Ethernet LAN (100 megabits per second, 100 BASE-TX). Satellite T130D,Satellite ProT130D,PORTEGE T130D Maintenance Manual (960-Q08)
Page 18 Some computers in this series offer Bluetooth wireless communication functionality. This module is Version 2.1+EDR. Wireless WAN Some models are equipped with a Wireless WAN module. Security Kensington Lock, Hard Disk Drive Password 3D Accelerometer for Hard Disk Drive Satellite T130D,Satellite ProT130D,PORTEGE T130D Maintenance Manual (960-Q08)
Page 19: Figure 1-1-1 Left Of The Computer
4. FAN HOLE 14.Hall-sensor 5. Keyboard 6. Touch Pad 7. Touch Pad Control Right Button 8. Touch Pad Control Light Button 9. Display Screen 10. Web Camera 11. Microphone Figure 1-1-1 left of the computer Satellite T130D,Satellite ProT130D,PORTEGE T130D Maintenance Manual (960-Q08)
Page 20: Figure 1-1-2 Right Of The Computer
1. LAN jack 8. DC-IN jack 2. USB port 3. USB port 4. Microphone jack 5. Headphone Jack 6. Bridge Media Slot 7. Wireless LAN/Wireless WAN Antennas Figure 1-1-2 right of the computer Satellite T130D,Satellite ProT130D,PORTEGE T130D Maintenance Manual (960-Q08)
Page 21: System Block Diagram
Chapter 1 Hardware Overview 1.2 System Block Diagram Figure 1-2-1 shows the system block diagram. Figure 1-1-1 System block diagram for AMD Platform Satellite T130D,Satellite ProT130D,PORTEGE T130D Maintenance Manual (960-Q08)
Page 22  South Bridge (AMD SB710)  PCI Host Bus Controller  USB Controllers  SMBus Controller  Interrupt Controller  DMA Controller  LPC Host Bus Controller  SATA Controller  Legacy IDE Emulation Support Satellite T130D,Satellite ProT130D,PORTEGE T130D Maintenance Manual (960-Q08)
Page 23 EC–[WO/CIR WPCE775CA0DG)] – HD Audio (CONEXANT CX20583-10Z) Card Reader controller (REALTEAK RTS5159 ) 10/100 LAN controller (Atheros AR8132M) Mini Card Wireless LAN (BTO) IEEE802.11b/g or IEEE802.11b/g/n Wireless WAN (BTO) HSPA Blue tooth Bluetooth V2.1+EDR. (BTO) Satellite T130D,Satellite ProT130D,PORTEGE T130D Maintenance Manual (960-Q08)
Page 24: Inch Hard Disk Drive
Outline (mm) dimensions Depth 100.2 +/- 0.25 (mm) Weight (g) 97/98 97/98 101//102 101//102 Parameter Standard value Hitachi Hitachi Hitachi Hitachi HTS545025B9A300 HTS545032B9A300 HTS545040B9A300 HTS545050B9A300 Width (mm) Outline Height dimensions (mm) Depth (mm) Satellite T130D,Satellite ProT130D,PORTEGE T130D Maintenance Manual (960-Q08)
Page 25: Table 1-3-2 2.5-Inch Hdd Dimensions
320GB 400GB 500 GB Speed (RPM) 5,400 Data transfer Rate 363~952 typical - To/From Media - T0/From Host 3GBytes bus transfer rate (MB/s) 3Gbps Average random seek time (read) (ms) Power-on-to-ready (sec) 3.5(typ)/9.5(Max) Satellite T130D,Satellite ProT130D,PORTEGE T130D Maintenance Manual (960-Q08)
Page 26: Table 1-3-3 2.5-Inch Hdd Specifications
Data transfer Rate - To/From Media 117MB/s Max. - T0/From Host 3Gbps bus transfer rate 3Gbps (MB/s) Average random seek 12.0ms/14.0ms time (read) (ms) Power-on-to-ready 4.0 (typ) (sec) Table 1-3-3 2.5-inch HDD specifications Satellite T130D,Satellite ProT130D,PORTEGE T130D Maintenance Manual (960-Q08)
Page 27: Keyboard
Figure 1-4-1 is a view of the keyboard for US style Figure 1-4-1 Keyboard for US style Figure 1-4-2 is a view of the keyboard for UK style Figure 1-4-2 Keyboard for UK style See Appendix E for details of the keyboard layout Satellite T130D,Satellite ProT130D,PORTEGE T130D Maintenance Manual (960-Q08)
Page 28: Tft Color Display
Chapter 1 Hardware Overview 1.5 TFT Color Display The Satellite T130D, Satellite T130D, PORTEGE T130D use LED to control backlight. 1.5.1 LCD Function Block Figure 1-5-1 shows a view of the LCD Function Block and Table 1-5-2 lists the specifications.
Page 29 Chapter 1 Hardware Overview 1.5.2 LCD Module Satellite T130D,Satellite ProT130D,PORTEGE T130D Maintenance Manual (960-Q08)
Page 30: Power Rails
No Main Battery(with RTC battery) Suspend mode Boot mode +5VPCU +3VPCU +3V_S5 +3VSUS +1.8VSUS +SMDDR_VTERM +SMDDR_VREF +1.8V +1.5V 1.25 +1.2V 1.05 +1.05v 1.0~1.2 +NB_CORE 0.7~1.2 VCC_CORE 3.266 +VCCRTC Table 1-6-1 Congo Power supply output rating Satellite T130D,Satellite ProT130D,PORTEGE T130D Maintenance Manual (960-Q08)
Page 31: Batteries
When the AC adapter is connected, normal charging is used while the system is turned on and quick charge is used while the system is turned off. Refer to the following Table 1-7-2. Satellite T130D,Satellite ProT130D,PORTEGE T130D Maintenance Manual (960-Q08)
Page 32: Table 1-7-2 Time Required For Charges Of Main Battery
About 5 days About 50 days Table 1-7-3 Data retaining time If USB Seep and Charge function is enabled, the computer’s battery will discharge during hibernation or when the computer is turned off. Satellite T130D,Satellite ProT130D,PORTEGE T130D Maintenance Manual (960-Q08)
Page 33: Table 1-7-4 Time Required For Charge Of Rtc Battery
Table 1-7-4 lists the Time required for charges of RTC battery and data retaining time. Condition Time Charging time About 24 hours Data retaining time About 30days Table 1-7-4 Time required for charges of RTC battery Satellite T130D,Satellite ProT130D,PORTEGE T130D Maintenance Manual (960-Q08)
Page 34: Ac Adapter
Parameter Specification With Led DELTA/ LITE-ON DELTA/ LITE-ON Power Input voltage AC 100V/240V Input frequency 50Hz/60Hz Input current ≦ 1.5A Output voltage DC 19V Output current 3.42A 3.42A Table 1-8-1 AC adapter specifications Satellite T130D,Satellite ProT130D,PORTEGE T130D Maintenance Manual (960-Q08)
Page 35: Chapter 2 Troubleshooting Procedures
Chapter 2 Troubleshooting Procedures Chapter 2 Troubleshooting Procedures Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 36: Troubleshooting Flowchart
Procedure 2 Connector Check and Replacement Check......20 Touch pad Troubleshooting ..................21 Procedure 1 Diagnostic Test Program Execution Check ......21 Procedure 2 Connector Check and Replacement Check......22 Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 37 3G Troubleshooting ....................37 Procedure 1 Connector Check and Replacement Check......37 2.16 Camera Troubleshooting..................... 38 Procedure 1 Camera Execution Check............38 Procedure 2 Connect Check and Replacement Check…………………….38 Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 38 Diagnostic Test Program Execution Check ......41 Procedure 2 Connect Check and Replacement Check…………………….41 2.20 LED Troubleshooting ....................42 Procedure 1 Each function Execution Check..........42 Procedure 2 Connect Check and Replacement Check……………………42 Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 39: Troubleshooting
The implement for the Diagnostics procedures is referred to Chapter 3. Also, following implements are necessary: 1. Phillips screwdrivers (For replacement procedures) 2. Implements for debugging port check  Toshiba Free-DOS system FD Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 40: Troubleshooting Flowchart
Before going through the flowchart steps, verify the following:  Ask him or her to enter the password if a password is registered.  Verify with the customer that Toshiba Windows is installed on the hard disk. Non- Windows operating systems can cause the computer to malfunction.
Page 41 Chapter 2 Troubleshooting Procedures Figure 2-2-1 Troubleshooting flowchart (1/2) Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 42 2. If an error is detected on the hard disk test, perform the HDD Troubleshooting Procedures in Section 2.5. 3. If an error is found on the keyboard test (DIAGNOSTICS TEST) and pressed key display test, perform the Keyboard Troubleshooting Procedures in Section 2.6. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 43 9. If an error is detected on the Bluetooth test, perform the Bluetooth Troubleshooting Procedures in Section 2.12. 10. If an error is detected on the HDMI test, perform the HDMI Troubleshooting Procedures in Section 2.13 Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 44: Power Supply Troubleshooting
The system is driven by only a battery and the battery level (at being switched on) is low. Doesn’t light Any condition other than those above. Table 2-3-1 Battery icon Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 45 Check 2 If the DC IN icon does not light, go to Procedure 3. Check 3 If the battery icon does not light orange or green, go to Procedure 4. NOTE: Use a supplied AC adapter. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 46: Procedure 2 Connection Check
Make sure the AC adapter is firmly plugged into the DC IN socket. Check 2 Make sure the battery pack is properly installed. If it is properly installed, go to Check 3. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 47 If the battery pack is still not charged, go to Check 5. Check 5 Replace the battery pack with a new one. If the battery pack is still not charged, go to Procedure 4. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 48: Procedure 4 Replacement Check
Battery pack may be faulty. Replace it with a new one. If the problem still occurs, perform Check 2. Check 2 System board may be faulty. Replace it with a new one. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 49: System Board Troubleshooting
Procedure 1 and continue with the other procedures as instructed. The procedures described in this section are: Procedure 1: Message Check Procedure 2: Diagnostic Test Program Execution Check Procedure 3: Replacement Check Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 50: Procedure 1 Message Check
RTC memory (CMOS type memory) is not the same as the actual configuration or when the data is lost. If you press the F2 key as the message instructs, the SETUP screen appears to set the system configuration. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 51: Procedure 2 Diagnostic Test Program Execution Check
If an error is detected during these tests, go to Procedure 4. Procedure 3 Replacement Check System board may be faulty. Disassemble the computer following the steps described in Chapter 4, Replacement Procedures and replace system board with a new one. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 52: Hdd Troubleshooting
User’s Manual. Procedure 1 Partition Check Insert the Toshiba Free-DOS system disk and start the computer. Perform the following checks: Input C: and press Enter. If you cannot change to drive C, go to Check 2. If you Check 1 can change to drive C, go to Procedure 2.
Page 53: Message Check
2.5” HDD(s) and the connector(s) of system board may be defective (Refer to the steps described in Chapter 4, Replacement Procedures for disassembling.). Insert HDD(s) to the connector(s) firmly. If it is (or they are) firmly connected, go to Procedure 3. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 54: Format Check
If HDD is formatted, set the 2.5” HDD partition using Free-DOS FDISK command. If you cannot format 2.5” HDD using the Tests and Diagnostic program, go to Procedure 4. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 55: Procedure 4 Diagnostic Test Program Execution Check
ECC Recover Enabled HDC Error Seek Error Time Out Error Drive Not Ready Undefined Error Write Fault Status Error No Sense Error Other Error Table 2-5-1 HDD error code & status Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 56: Procedure 5 Connector Check And Replacement Check
Chapter 4, Replacement Procedures and check the operation. If the problem still occurs, perform Check 3. Check 3 System board may be faulty. Replace it with a new one following the instructions in Chapter 4, Replacement Procedures. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 57: Keyboard Troubleshooting
Diagnostic Program. Refer to Chapter 3, Tests and Diagnostics, for more information on how to perform the test program. If an error occurs, go to Procedure 2. If an error does not occur, keyboard is functioning properly. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 58: Procedure 2 Connector Check And Replacement Check
Chapter 4, Replacement Procedures. If the problem still occurs, perform Check 3. Check 3 System board may be faulty. Replace it with a new one following the instructions in Chapter 4, Replacement Procedures. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 59: Touch Pad Troubleshooting
Diagnostics, for more information on how to perform the test program. If an error occurs, go to Procedure 2. If an error does not occur, Touch pad is functioning properly. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 60: Procedure 2 Connector Check And Replacement Check
Chapter 4, Replacement Procedures. If the problem still occurs, perform Check 3. Check 3 System board may be faulty. Replace it with a new one following the instructions in Chapter 4, Replacement Procedures Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 61: Display Troubleshooting
Insert the Diagnostics disk, turn on the computer and run the test. Refer to Chapter 3, Tests and Diagnostics for details. If an error is detected, go to Procedure 3. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 62: Procedure 3
Disassemble the computer following the steps described in Chapter 4, Replacement Procedures. If the connection is loose, reconnect firmly and restart the computer. If the problem still occurs, go to Procedure 4. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 63: Procedure 4 Replacement Check
Chapter 4, Replacement Procedure and test the display again. If the problem still occurs, perform Check 3. Check 3 System board may be faulty. Replace it with a new one following the instructions in Chapter 4, Replacement Procedure. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 64: Lan Troubleshooting
LAN cable may be faulty. Replace it with a new one. If the problem still occurs, perform Check 3. Check 3 System board may be faulty. Replace it with a new one following the instruction in Chapter 4. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 65: Wireless Lan Troubleshooting
LAN. Perform the test following the instructions described in Chapter 3. If the computer passes the test, the function is correctly working. If the computer does not pass the test, perform Procedure 2. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 66: Procedure 2
Wireless LAN card. If wireless LAN antenna cables are not connected properly, connect them firmly and perform Procedure 1. If the problem still occurs, go to the procedure 3. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 67: Procedure 3 Replacement Check
Chapter 4, Replacement Procedures. If the problem still occurs, perform Check 3. Check3 System board may be faulty. Replace it with a new one following the instructions in Chapter 4, Replacement Procedures. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 68: Sound Troubleshooting
The connection of sound system is shown in the following figure. As the connection may be defective, disassemble the PC and check each connection. If the problem still occurs, go to Procedure 2. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 69: Procedure 2 Replacement Check
Chapter 4. If the problem still occurs, perform Check 6. Check 6 Audio board/System board may be faulty. Replace it with a new one following the instructions in Chapter 4. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 70: Bluetooth Troubleshooting
Bluetooth may be faulty. Replace it with a new one following the steps in Chapter 4. If the problem still occurs, perform Check 4. Check 4 System board may be faulty. Replace it with a new one following the instruction in Chapter 4. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 71 Chapter 2 Troubleshooting Procedures Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 72: Hdmi Troubleshooting
If the external monitor works correctly, the internal LCD may be faulty. Go to Procedure 3. If the external monitor appears to have the same problem as the internal monitor, system board may be faulty. Go to Procedure 2. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 73: Procedure 3 Connector And Cable Check
HDMI monitor connected to HDMI&USB board by an HDMI cable. If the connection is loose, reconnect firmly and restart the computer. If the problem still occurs, go to Procedure 4. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 74: Procedure 4 Replacement Check
HDMI&USB board may be faulty. Replace it with a new one following the instructions in Chapter 3, Replacement Procedure. Check 4 System board may be faulty. Replace it with a new one following the instructions in Chapter 4, Replacement Procedure. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 75: Memory Troubleshooting
RAM may be faulty. Replace it with a new one. If the problem still occurs, perform Check 3. Check 3 The slot and MB may be faulty. Replace it with a new one following the instruction in Chapter 4. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 76: Troubleshooting
3G card may be faulty. Replace it with a new one following the steps in Chapter 4. Check 3 If the problem still occurs, perform Check 4. Check 4 System board may be faulty. Replace it with a new one following the instruction in Chapter 4. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 77: Camera Troubleshooting
Camera may be faulty. Replace it with a new one following the instruction in Chapter 4. Check 4 System board may be faulty. Replace it with a new one following the instruction in Chapter 4. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 78: Microphone Troubleshooting
CCD cable or Microphone may be faulty. Replace it with a new one. If the problem still occurs, perform Check 3. Check 3 System board may be faulty. Replace it with a new one following the instruction in Chapter 4. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 79: Crt Troubleshooting
Chapter 4, Replacement Procedure, and then test again. If the problem still occurs, perform Check 3. Check 3 System board may be faulty. Replace it with a new one following the instructions in Chapter 4, Replacement Procedure. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 80: Usb Troubleshooting
HDMI/B or Audio/B may be faulty. Replace it with a new one. If the problem still occurs, perform Check 3. Check 3 The system board may be faulty. Replace it with a new one following the instruction in Chapter 4. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 81: Led Troubleshooting
Touchpad/B may be faulty. Replace it with a new one. If the problem still occurs, perform Check 3. Check 3 The system board may be faulty. Replace it with a new one following the instruction in Chapter 4. Satellite T130D and Pro T130D and PORTEGE T130DMaintenance Manual (960-Q08)
Page 82: Chapter 3 Diagnostic Programs
Chapter 3 Test Program for Field Chapter 3 Diagnostic Programs _____________________________________________________________________ Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 83: Tests And Diagnostics Software Overview
3.16 DMI INFOEMATION .................... 58 3.17 Log Utilities ......................60 3.18 System Configuration ..................... 62 3.19 Running Test Edit Item................... 63 3.20 Common Tests and Operation ................65 _____________________________________________________________________ Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 84 Chapter 3 Test Program for Field. Chapter 3 Diagnostic Programs Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 85: Tests And Diagnostics Software Overview
Chapter 3 Test Program for Field. Tests and Diagnostics Software Overview This chapter explains how to use the Tests and Diagnostics Software for the Satellite T130D, Satellite Pro T130D and PORTEGE T130D computer systems. NOTES: Before starting the Tests and Diagnostics software: 1.
Page 86: Executing The Diagnostic Test
04.LOG UTILITIES 05.SYSTEM CONFIGURATION 06.OPTION 99.EXIT 3. To select the Diagnostic Test from the Diagnostics Menu use the arrow keys to set the highlight bar to 01 and press Enter. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 87 11. Item 88 sets the floppy disk drive and hard disk drive errors retry count. Item 99 exits the submenu of the Diagnostic Test and returns to the Diagnostics Menu. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 88 14. MEMORY2 TEST 07. REAL TIME CLOCK TEST 88. FDD&HDD ERROR RETRY COUNT SET 99. EXIT TO DIAGNOSTICS MENU Use the arrow keys to highlight the desired option and press Enter. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 89 Table 3-1 in Section 3.3 lists the function of each test on the subtest menu. Table 3-2 in Section 3.15 lists the error codes and error status for each error. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 90: Subtest Names
640* 200 Graphics Display 640* 480 Graphics Display Display Page “H” Pattern Display Video DAC Register W/R/C Color Graphics Display Color Attributes Display Color Tiling Table 3-3-1 Subtest Names (1/3) Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 91 HIGH RESOLUTION VRAM W/R/C Test DISPLAY TEST 640* 480 Mode Display 800* 600 Mode Display 1024* 768 Mode Display “H” Pattern Display Focus Test (“E” Pattern) Table 3-3-1 Subtest Names (2/3) Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 92 1 point W/R/C Test MEMORY2 All one/zero Test Walking 1/Walking 0 Test(Left) Walking 1/Walking 0 Test(Right) Walking 1/Walking 0 Test(Left /Right) Table 3-3-1 Subtest Names (3/3) *This test cannot support. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 93: System Test
: 4000 mAh Device chemistry : LION Design voltage : 11100 mV Manufacturer data Specification information: 2.1 Manufacture date : 9/13/2005 Serial no. : 32009 STATUS : INIT [ESC] KEY t Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 94 An access platform is leveling. platform. Test Fixture The Fixture which fixes PC by 90 degree inclination is used. Vibration/shock doesn't take a PCB at the time of T&D inspection. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 95 Display of a Test Program The portion which PC and Test-Fixture contact is green. Set method of PC Upper Judgment If all data is less than ranges, it will be OK. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 96 The display of a test program and the set method of PC are shown below. Display of a Test Program Set method of PC Rear Uppe Judgment If all data is less than ranges, it will be OK. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 97 The display of a test program and the set method of PC are shown below. Display of a Test Program Set method of PC Right Uppe Judgment If all data is less than ranges, it will be OK. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 98 The display of a test program and the set method of PC are shown below. Display of a Test Program Set method of PC Front Uppe Judgment If all data is less than ranges, it will be OK. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 99 A test result is displayed when a test is completed. A display of result is O.K. or NG. And an error flag is returned at the end of a program. OK is 0. NG is 1. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 100: Memory Test
Test data = 1H, 2H, 4H, 8H, 10H, through 80000000H. 4. Fixed data test “16 bit write/ 16 bit read” is executed and the new data is compared to the original data. Test data = FFFFFFFFH, 00000000H, 80018001H Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 101 Protected Modes [32MB - MAX] This subtest first writes data patterns and address data from 32MB to the maximum installed memory, reads the new data, and then compares the result Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 102 This subtest writes a data pattern (CCAA5533H ) in 4KB from 0 to the maximum installed memory, then waits for a memory refresh cycle (16 ms or more), reads the new data, and compares the result with the original data pattern. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 103 Stress Test This subtest writes the following 16KB data patterns to the Write/Read Buffer in conventional memory. FFFFFFFFFFFFFFFF0000000000000000 data: 5555555555555555AAAAAAAAAAAAAAAA CCCCCCCCCCCCCCCC3333333333333333 0000000000000000FFFFFFFFFFFFFFFF AAAAAAAAAAAAAAAA5555555555555555 3333333333333333CCCCCCCCCCCCCCCC FFFFFFFFFFFFFFFF0000000000000000 0000000000000000FFFFFFFFFFFFFFFF 5555555555555555AAAAAAAAAAAAAAAA AAAAAAAAAAAAAAAA5555555555555555 CCCCCCCCCCCCCCCC3333333333333333 3333333333333333CCCCCCCCCCCCCCCC Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 104: Keyboard Test
This subtest is used for the 85 keyboard and functions the same as Subtest 1. Subtest 03 Pressed Key Display [85 Keyboard] This subtest is used for the 85 keyboard and functions the same as Subtest 1. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 105 , screen will display <PRESS> in right rectangle , the program exit . If left and right button short, screen will display <Left and Right Button maybe short >, the program exit. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 106 Chapter 3 Test Program for Field. LEFT PRESS TOUCH_PAD TEST RIGHT PRESS Please Do Not Press the Left and Right Button at the Same Time Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 107: Display Test
RRRRRRRRRRRRRRRRRRRRRRRRRRRRRRRR RRRRRRRRRRRRRRRRRRRRRRRRRRRRRRRR NEXT LINE SHOWS BLINKING DISPLAY BBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB BLUE MAGENTA GREEN CYAN YELLOW WHITE Press [ Enter ] KEY To exit this subtest and return to the Display Test menu: Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 108 Press Enter if NO was selected for Test Loop on the Test Parameter Menu. Press Ctrl + break if YES were selected for Test Loop on the Test Parameter Menu. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 109 Press Enter if NO was selected for Test Loop on the Test Parameter Menu. Press Ctrl + break if YES were selected for Test Loop on the Test Parameter Menu. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 110 Press ENTER to display the following sixteen colors: black, blue, green, cyan, red, magenta, brown, white, dark gray, light blue, light green, light cyan, light red, light magenta, yellow, and intensified white. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 111 Press Enter if NO was selected for Test Loop on the Test Parameter Menu. Press Ctrl + break if YES were selected for Test Loop on the Test Parameter Menu. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 112 Press Enter if NO was selected for Test Loop on the Test Parameter Menu. Press Ctrl + break if YES were selected for Test Loop on the Test Parameter Menu. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 113 Press ENTER to display the following 16 colors: black, blue, green, cyan, red, magenta, brown, white, dark gray, light blue, light green, light cyan, light red, light magenta, yellow, and intensified white using 640*480 video resolutions. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 114 Press Enter if NO was selected for Test Loop on the Test Parameter Menu. Press Ctrl + break if YES were selected for Test Loop on the Test Parameter Menu. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 115 Press Enter if NO was selected for Test Loop on the Test Parameter Menu. Press Ctrl + break if YES were selected for Test Loop on the Test Parameter Menu. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 116 ” displays on the screen and then the screen flickers due will remain blank to the fast screen refresh while the test is executing. Press Ctrl + break to return to the Display Test menu. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 117 Press Enter if NO was selected for Test Loop on the Test Parameter Menu. Press Ctrl + break if YES were selected for Test Loop on the Test Parameter Menu. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 118 Pressing Enter executes VRAM mapping test which indicates vertical lines Press Enter to execute the VRAM mapping test which displays a horizontal line at one dot intervals using Mode 12. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 119 Press Enter to execute the VRAM mapping test which displays a vertical line at four dot intervals using Mode 12. Press [Enter] Key Press Enter to display VRAM mapping test using the all dots Mode. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 120 Press Enter if NO was selected for Test Loop on the Test Parameter Menu. Press Ctrl + break if YES were selected for Test Loop on the Test Parameter Menu. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 121 Press Enter if NO was selected for Test Loop on the Test Parameter Menu. Press Ctrl + break if YES were selected for Test Loop on the Test Parameter Menu. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 122: Hard Disk Test
 Random Subtest 03 Random Address Data This subtest writes random data to 1000 different random addresses on the HDD. This data is then read and compared to the original data. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 123 3.18) to specify the LBA number where the error(s) occurred during Subtest 01. The following message displays on the screen to enter the test sector count. SECTOR COUNT(01~39)?? START ADDRESS (00000000~MAX Address)? Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 124 This subtest writes specified data to a specified sector count, then reads and compares the result. The following message displays on the screen to enter the test data, sector count. TEST DATA ????(=37b3H) SECTOR COUNT(01~39)?? START ADDRESS (00000000~Max Address)? Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 125: Real Time Clock Test
If YES is selected for Test Loop on the Test Parameter menu, the screen above displays and the test is executed again. Press Ctrl + break to return to the Real Time Clock Test menu. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 126 Press Enter if NO was selected for Test Loop on the Test Parameter Menu. Press Ctrl + break if YES were selected for Test Loop on the Test Parameter Menu. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 127: Cache Memory Test
(FFH, FEH, FEH, through 02H, 01H, 00H) is written and the new data is read and compared with the original data. The original cache memory content is then restored to the cache memory. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 128 “working data,” reads the new data and compares the result with the original data. The original cache memory content is then restored to the cache memory. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 129: High Resolution Display Test
If YES is selected for Test Loop on the Test Parameter menu, the screen displays the colors listed above. Press Ctrl + break to return to the High Resolution Display Test menu. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 130 Press Enter if NO was selected for Test Loop on the Test Parameter Menu. Press Ctrl + break if YES were selected for Test Loop on the Test Parameter Menu. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 131 Press Enter if NO was selected for Test Loop on the Test Parameter Menu. Press Ctrl + break if YES was selected for Test Loop on the Test Parameter Menu Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 132 Press Enter if NO was selected for Test Loop on the Test Parameter Menu. Press Ctrl + break if YES were selected for Test Loop on the Test Parameter Menu. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 133 Press Enter if NO was selected for Test Loop on the Test Parameter Menu. Press Ctrl + break if YES were selected for Test Loop on the Test Parameter Menu. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 134 Press Enter if NO was selected for Test Loop on the Test Parameter Menu. Press Ctrl + break if YES were selected for Test Loop on the Test Parameter Menu. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 135: Multimedia Test
Move the highlight bar to the subtest you want to execute and press Enter. NOTE: Use the Toshiba Backup CD-ROM for Subtests 01, 02, and 03. Because CDROM driver issue, the Multimedia function can’t test, this is limitation.
Page 136: Memory2 Test
Walking 1/Walking 0 test (Right) Tee test method is the same as Subtest2. However, the data to be used differs. 80008000800080007FFF7FFF7FFF7FFF 4000400040004000BFFFBFFFBFFFBFFF Subtest 04 Walking 1/Walking 0 test (Left/ Right) Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 137 Chapter 3 Test Program for Field. Tee test method is the same as Subtest2. However, the data to be used differs. 7FFF7FFF7FFF7FFF8000800080008000 BFFFBFFFBFFFBFFF4000400040004000 DFFFDFFFDFFFDFFF2000200020002000 FFFBFFFBFFFBFFFB0004000400040004 FFFDFFFDFFFDFFFD0002000200020002 FFFEFFFEFFFEFFFE0001000100010001 80008000800080007FFF7FFF7FFF7FFF 4000400040004000BFFFBFFFBFFFBFFF 0004000400040004FFFBFFFBFFFBFFFB 0002000200020002FFFDFFFDFFFDFFFD 0001000100010001FFFEFFFEFFFEFFFE Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 138: Error Codes And Error Status Names
DMA Boundary Error Bad Sector Bad Track Error ECC Error ECC Recover Enabled HDC Error Seek Error Time Out Error Drive Not Ready Table 3-15-1 Error codes and error status names (1/2) Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 139 Drive Not Ready Other Error Table 3-15-1 Error codes and error status names (2/2) NOTE: If error status name is Other Error, please reference the Error Code for error information Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 140: Running Test
File. 7. This program is executed according to the Count Loop number selected in the Running Test Edit Item, see Section 3.20. To terminate the program, press Ctrl + Break. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 141: Dmi Infoemation
6. Model Select [1]Dyn-Jpn [2]Tos-Jpn [3]Tos-Eng [4]Tos-FR 7. Write UUID ( XXXXXXXXXXXXXXXX ) 8. Brightness Write ( XXXXXXXX ) a. SLP2.0 Build Sig [1]Non OS [2]OS b. Wireless LAN ID ( 001E4CXXXXXX ) Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 142 NOTE: The SLP2.0 is Microsoft SPEC, call “System Locked Pre-Installation”or”SLP”, It is for OEM pre install Windows and no need to Active, If you select Non OS , then you need to Active your OS before you use . Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 143: Log Utilities
Error Status Pass Count Subtest Number Read Data Test Name Write Data Error Count Error Name and Detail [[1:Next, 2:Prev, 3:Exit, 4;Clear, 5:FD Log Read, 6:FD Log Write, 7:Log Save]] Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 144 Test Abbreviations System Test Memory Test Keyboard Test Display Test Floppy Disk Test Hard Disk Test Real Time Clock Test Cache Memory Test Height Resolution Display Test Multimedia Test Memory2 Test Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 145: System Configuration
* - XXXMB MEMORY SIZE * - XXX CPU * - 1 Vedio Chip XXXXXXXXXXXXX * - 1 ODD DRIVE(S):XXXXXXXX FW Rev.:XXXX Press Enter to return to the Diagnostics Menu. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 146: Running Test Edit Item
Subtest 08 Display Page Floppy Disk Test Subtest 02 Sequential W/R/C Hard Disk Test Subtest 01 Sequential Read Real Time Clock Test Subtest 02 Backup Memory Test Tab: HELP (Key Operation) Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 147 8. Select 03 from the Diagnostics Menu and press Enter to execute the Running Test. NOTE: If press Ctrl+break in the run-in process, please press more one any key to exit. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 148: Common Tests And Operation
Subtest No. Displays the Subtest number in the following format: ffgg ff = Subtest No. gg = Step Number (Will be blank if the test does not have a Step Number.) Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 149 Test Address Displays the Test Address. (The format differs for each test.) Error Status Displays the error status. Error Name Displays the name of the error. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 150: Test Stop Display
“+” mark. For example: [a] [Enter] Press the “a” key, and then press the [Enter] key. [Ctrl] + [c] Press the [Ctrl] key and the “c” key simultaneously. Satellite T130D,Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 151: Replacement Procedures
Chapter 4 Replacement Procedures Chapter 4 Replacement Procedures Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 152: Safety Precautions
4.13 CPU Heat Sink......................50 4.14 LCD unit ........................52 4.15 Web Camera Module ....................56 4.16 Application for Thermal grease on CPU and North Bridge…………………………59 4.17 Speaker Box………………………………………………………………………….61 Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 153 Remove the screws (front) and Top cover assembly........36 Figure 4-9-3 Disconnect the touch pad flat cable/LAN cable ........... 37 Figure 4-10-1 Remove the touch FFC cable………..………….…………………………..40 Figure 4-10-2 Loose the screws…………………...……………………………....41 Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 154 Figure 4-16-2 Apply silicon grease for North Bridge and CPU………….………………..60 Figure 4-17-1 Removing the securing screws at left side………….………………………61 Figure 4-17-2 Removing the securing screws at right side………….……………………..62 Figure 4-17-3 Removing the Speaker Box………….……………………………………..62 Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 155: Overview
 Removing a LCD unit All FRUs down to the “4.2 Battery pack”to”4.5 Keyboard” and “4.9 Top Cover Assembly” and “4.8 Display Assembly” above LCD unit must be removed. Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 156: Safety Precautions
Toshiba. 5. To prevent electric shock, ensure that all replacement parts are compatible with the computer and that all cables and connectors are securely connected. Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 157: Before You Begin
9. As all parts have sharp edges and corners, take care not to cut yourself. 10. After replacing an FRU, check that the computer and replaced part operate correctly. Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 158: Disassembly Procedure
Normal pin connectors are used for all other cables. Simply pull out or push in these connectors to disconnect or reconnect. Pressure plate connector Spring connector Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 159: Assembly Procedure
One Philips screwdriver with type 1 bit (for screws other than above)  Tweezers (for lifting screws)  ESD mats (lay on work table or floor)  An ESD wrist strap and heel grounder  Anti-static carpet or flooring Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 160: Screw Tightening Torque
G r ip a r e a “Special length screw” means screws whose length is indicated in an integral number to the first decimal places such as 2.5 mm, 2.8 mm and so on. Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 161: Screw Notation
B: Bind screw F: Thin head screw S: Super thin head screw T: Tapping screw U: Other screws (Unique screws: pan head, stud, etc.) Example: B6 … 6mm bind screw Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 162: Battery Pack
4. Slide and hold the battery release latch (2) to free the battery pack after moving the battery release latch (1) into it unlock position – pick the battery pack out of the computer from fillister. Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 163 NOTE: Check visually the battery terminals and clean off any dirt with a dry cloth. 1. Turn off the power of the computer. 2. Disconnect the AC adapter and all external devices from the computer. Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 164 3. Attach the battery cover to the battery pack. 4. Insert the battery pack 5. Ensure the battery release latch (2) is moved into its locked position LATCH 2 Figure 4-2-2 Install the battery pack Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 165: Hdd
3. Remove the following screws securing the HDD assembly.  M2.03.0B FLAT BIND screw 4. Disconnect the HDD assembly from the connector on the system board. MAIN HDD Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 166 Turn Figure 4-3-1 the computer upside down CAUTION: When a HDD is installed, they are installed in the position as the following figure. Figure 4-3-2 Remove HDD assembly Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 167 2. Insert the HDD assembly into the HDD slot and connect it carefully to the MAIN HDD on the system board. 3. Use a T6-bit TORX to secure the HDD assembly with the following screw.  M2.04.0B T6 screw Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 168: Memory Module
(See Figure 4-4-1 to 4-4-2). 1. Loose the screw securing the memory slot cover. 2. Remove the memory slot cover. 3. Open the left and right latches and remove a memory module. Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 169 Chapter 4 Replacement Procedures Figure 4-4-1 Remove memory slot cover Figure 4-4-2 Remove a memory module Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 170 Confirm that the new memory is detected correctly. 4. If the memory is not detected, check that it is connected correctly. Figure 4-4-3 Insert a memory module Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 171: Keyboard
M2.0x3.0B Flat BIND screws 6. Insert your finger into the slot between keyboard and Top cover Assembly. Then lift up the keyboard to remove it. 7. Disconnect keyboard cable. Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 172 Chapter 4 Replacement Procedures Figure 4-5-1 Remove 2 screws for KB Holder Figure 4-5-2 Remove 2 screws for Keyboard Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 173: Installing The Keyboard
3. Install the K/B holder by pressing it from the topside. 4. Upside down the computer and secure the KB holder with the following screw.  M2.02.0B FLAT BIND screw Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 174: Wireless Lan Card And Bt Module
Disconnect the wireless LAN antenna cable from the connectors on a wireless LAN card. Remove a wireless LAN card from the connector on the system board. Figure 4-6-1 Wireless LAN card Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 175 Chapter 4 Replacement Procedures Figure 4-6-2 Remove a wireless LAN card Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 176 3. Put the wireless LAN antenna cable on the right location from the guide. Then install BT module on the base and connect BT cable on system board. (See Figure 4-6-3) Figure 4-6-3 Cables layout on motherboard Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 177: G Module Card
Disconnect the 3G module antenna cable from the connectors on a 3G module card Remove a 3G module card from the connector on the system board. Figure 4-7-1 3G module card Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 178 Chapter 4 Replacement Procedures Figure 4-7-2 Remove a 3G module card Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 179 2. Connect the 3G module antenna cable to the terminals on a 3G module card. 3. Put the 3G module antenna cable on the bottom location from the guide. Figure 4-7-3 Cables layout on motherboard Satellite T130D, Satellite Pro T130D , and PORTEGE T130D Maintenance Manual (960-Q08)
Page 180: Display Assembly
1. Close the display and turn the computer upside down. 2. Remove the battery pack (See Figure 4-2-1) 3. Open HDD Door Figure 4-8-1 Remove the screws (securing display assembly) 4. Remove the screws from the bottom side. 4-26 Satellite T130D, Satellite Pro T130D, and PORTEGE T130DMaintenance Manual (960-Q08)
Page 181 Figure 4-8-2 Remove the screws (from bottom side) 5. Disassemble KB Holder and KB screw (See Figure 4-5-1) 6. Remove the screws from the top side and remove the cover. 4-27 Satellite T130D, Satellite Pro T130D, and PORTEGE T130DMaintenance Manual (960-Q08)
Page 182 Figure 4-8-3 Remove the screws (from top side) 7. Disconnect the FFC and cables. 8. Disassembly TOP ASSY 9. Pull out the wireless LAN antenna from the guide with two hands. 4-28 Satellite T130D, Satellite Pro T130D, and PORTEGE T130DMaintenance Manual (960-Q08)
Page 183 Figure 4-8-4 Remove the Wireless Antenna and LCD cable 10. Pull out the LCD cables from the guide of system board. Figure 4-8-5 Remove the LCD cable from system board 4-29 Satellite T130D, Satellite Pro T130D, and PORTEGE T130DMaintenance Manual (960-Q08)
Page 184 Chapter 4 Replacement Procedures 11. Pull out the LCD cables from the guide of LCD panel. Figure 4-8-6 Remove the LCD cable from LCD panel 4-30 Satellite T130D, Satellite Pro T130D, and PORTEGE T130DMaintenance Manual (960-Q08)
Page 185 M2.56.5 FLAT BIND screw x2(Lock tight) M2.5*6.5 2pcs M2.5*3 4pcs Figure 4-8-7 Remove the hinge screws 12. Remove the display assembly with two hands holding from the base assembly. 4-31 Satellite T130D, Satellite Pro T130D, and PORTEGE T130DMaintenance Manual (960-Q08)
Page 186: Installing The Display Assembly
M2.56.5 FLAT BIND screw x2(Lock tight) M2.5*3 4pcs M2.5*6.5 2pcs Figure 4-8-8 Securing the hinge screws NOTE: Be sure to apply the locktight to the screws instructed in the figure above. 4-32 Satellite T130D, Satellite Pro T130D, and PORTEGE T130DMaintenance Manual (960-Q08)
Page 187 5. Pass the cables to the back of computer through the slot. 6. Arrange the Wireless LAN antenna along the guide and contact with the connector with hands. 4-33 Satellite T130D, Satellite Pro T130D, and PORTEGE T130DMaintenance Manual (960-Q08)
Page 188 7. Install the LAN board and Top cover Assembly of the system. NOTE: If Fingerprint or Dust left on LCD screen during disassembly and assembly LCD units, please follow Appendix A to clean it. 4-34 Satellite T130D, Satellite Pro T130D, and PORTEGE T130DMaintenance Manual (960-Q08)
Page 189: Top Cover Assembly
 M2-0.42 FLAT BIND screw Back  M2.56.5 FLAT BIND screw Back  M2.05.0 FLAT BIND screw Back M2-0.4*2 6pcs M2.5*6.5 2pcs M2.0*5.0 11pcs Figure 4-9-1 Remove the screws (back) 4-35 Satellite T130D, Satellite Pro T130D, and PORTEGE T130DMaintenance Manual (960-Q08)
Page 190 M2.05.0 FLAT BIND screw Back M2*5 7pcs Figure 4-9-2 Remove the screws (front) and Top cover assembly 4. Disconnect the touch pad flat cable/LAN cable/Power cable from the connector on the system board. 4-36 Satellite T130D, Satellite Pro T130D, and PORTEGE T130DMaintenance Manual (960-Q08)
Page 191 Chapter 4 Replacement Procedures Figure 4-9-3 Disconnect the touch pad flat cable/LAN cable 4-37 Satellite T130D, Satellite Pro T130D, and PORTEGE T130DMaintenance Manual (960-Q08)
Page 192 FLAT BIND screw Back  M2.56.5 FLAT BIND screw Back  M2.05.0 FLAT BIND screw Back 4. Free the cable from cable-drain when through the antenna cable to PCB hole. 4-38 Satellite T130D, Satellite Pro T130D, and PORTEGE T130DMaintenance Manual (960-Q08)
Page 193: Touch Pad
 M2.0x3.0 SUPER THIN HEAD screw 3. Remove the touch pad board and touch pad plate. 4. Peel off and remove the touch pad from the Top cover assembly. 4-39 Satellite T130D, Satellite Pro T130D, and PORTEGE T130DMaintenance Manual (960-Q08)
Page 194 Chapter 4 Replacement Procedures Figure 4-10-1 Remove the touch FFC cable 4-40 Satellite T130D, Satellite Pro T130D, and PORTEGE T130DMaintenance Manual (960-Q08)
Page 195 Chapter 4 Replacement Procedures M2*2-I 5pcs M2-0.4*2 2pcs M2.0*3.0 2pcs Figure 4-10-2 Loose the screws Figure 4-10-3 Remove the touchpad and touchpad board 4-41 Satellite T130D, Satellite Pro T130D, and PORTEGE T130DMaintenance Manual (960-Q08)
Page 196 4. Stick the insulator on the touch pad plate. 5. Connect the touch pad flat cable to the connector on the touch pad and stick the glass tape on the connector. 4-42 Satellite T130D, Satellite Pro T130D, and PORTEGE T130DMaintenance Manual (960-Q08)
Page 197: I/O Board
1. Pull out the I/O Board FFC, LAN FFC, Speaker cable from I/O board connector. 2. Loose the below screws and then incline pull out I/O Board.  M2.0x3.0 FLAT BIND screw Figure 4-11-1 Remove the I/O Board 4-43 Satellite T130D, Satellite Pro T130D, and PORTEGE T130DMaintenance Manual (960-Q08)
Page 198 2. Insert the I/O Board FFC, LAN FFC, Speaker cable into base case and connect I/O board cable and speaker cable NOTE: Be careful not to catch the cables between Top cover assembly and base assembly. 4-44 Satellite T130D, Satellite Pro T130D, and PORTEGE T130DMaintenance Manual (960-Q08)
Page 199: System Board
2. Remove the following screws securing the system board and remove the system board.  M2.03.0 screw Figure 4-12-1 Remove the system board Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 200 CRT cable, BT wire, SIM FFC, TP board FFC, Power Board FFC, DC-IN cable to the connector on the system board. 3. Connect the power cable to the connector on the system board. Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 201 1. Pull the away the socket of RTC battery and use a clamp to hold RTC battery tightly. 2. Rotate battery through the way then remove it. Figure 4-12-2 Remove the RTC battery-step_1 Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 202 Chapter 4 Replacement Procedures Figure 4-12-3 Remove the RTC battery-step_2 Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 203 The following describes the procedure for installing the RTC battery unit (See Figure 4-12-4). 1. Press the force vertically then lock the RTC battery tightly. Figure 4-12-4 Install the RTC battery Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 204: Cpu Heat Sink
NOTE: When removing the heat sink holder, be sure to remove the screws in the reverse order of the number marked on the holder. Figure 4-13-1 Remove the CPU heat sink Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 205 Secure the following screws securing the heat sink holder along 1 to 3.  M2.03.0 screw  Disconnect the Heat sink cable from the connector on the system board Connect the Heat sink cable from the connector on the system board Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 206: Lcd Unit
5. With the bottom edge of the LCD unit on the display cover, lift only the top edge of the LCD unit. After peeling off the kapton tape, disconnect the LCD harness from the connector on the back of the LCD. 6. Remove the LCD unit. Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 207 Chapter 4 Replacement Procedures Figure 4-14-2 Remove the LCD unit Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 208 7. Remove the following screws securing the LCD support (LCD unit side) and remove the hinge from the LCD unit.  M2.0x2.5 screw Figure 4-14-3 Remove the LCD hinge Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 209 5. Cover screws with Screw MYLAR cover x4 NOTE: When installing the display mask, make sure there is no gap between the display mask and the display cover. Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 210: Web Camera Module
(See Figure 4-15-1 to 4-15-2). Pull off the connector of Web Camera module. Peel off the glue of Web Camera module. Figure 4-15-1 Remove the connector of Web Camera module Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 211 Chapter 4 Replacement Procedures Figure 4-15-2 Peel off the glue of Web Camera module Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 212 Installing Web Camera module The following describes the procedure for installing the Web Camera module. 1. Pull in the glue of Web Camera Module. 2. Connect the connector of Web Camera module. Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 213: Application For Thermal Grease On Cpu And North Bridge
(See Figure 4-16-1) The thermal grease on North Bridge and CPU Figure 4-16-1 Intel &AMD Thermal grease on North Bridge and CPU A000018310 THERMAL GREASE FCR-AS A000063980 THERMAL GREASE 7762 Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 214 Chapter 4 Replacement Procedures II. Use grease on North Bridge and CPU 0.15cc for one repair. Figure 4-16-2 Apply silicon grease for North Bridge and CPU Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 215: Speaker Box
The following describes the procedure for removing Speaker Box. (See Figure 4-17-1 to 4- 17-3). Remove the following screws securing Speaker Box.  M2.02.5 screw x 4 Removing the Speaker Box. Figure 4-17-1 Removing the securing screws at left side. Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 216 Chapter 4 Replacement Procedures Figure 4-17-2 Removing the securing screws at right side Figure 4-17-3 Removing the Speaker Box. Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 217 Chapter 4 Replacement Procedures Installing Speaker Box The following describes the procedure for installing Speaker Box. Installing the Speaker Box. Securing Speaker Box of following screws.  M2.02.5 screw x 4 Satellite T130D, Satellite Pro T130D, and PORTEGE T130D Maintenance Manual (960-Q08)
Page 218 Appendices Satellite T130D,Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 219: Appendix A Handling The Lcd Module
CN12 Blue Tooth Connector ................6 C.12 CN14 Battery Connector…………………..………………………………….6 C.13 CN15 FAN Connector ..................7 C.14 CN16 CRT Connector..................7 C.15 CN17 CRT Connector..................7 C.16 CN18 HDT Connector ..................8 Satellite T130D and Satellite ProT130D Maintenance Manual (960-Q08)
Page 220 CN23 MINI PCI-E Card 3G Connector............18 Appendix D Display Codes ....................1 Display Codes ....................1 Appendix E Keyboard Layout .................... 1 United States (US) Keyboard................1 United Kingdom (UK) Keyboard ..............1 Japan Keyboard....................2 Satellite T130D and Satellite ProT130D Maintenance Manual (960-Q08)
Page 221: Appendix F Wiring Diagrams
Appendix F Wiring Diagrams..................... 1 RGB Monitor ID Wraparound Connector ............1 LAN Loopbak Connector ................. 1 Appendix G BIOS Rewrite Procedures ................1 Appendix H EC/KBC Rewrite Procedures ................ 1 Appendix I Reliability......................1 Satellite T130D and Satellite ProT130D Maintenance Manual (960-Q08)
Page 222: Appendix A Handling The Lcd Module
LCD cover before securing the module with screws. Do not force the module into place, because stress can affect its performance. Also, the panel’s polarized surface is easily scarred, so be careful when handling it. PORTEGE T130D Satellite T130D, Satellite Pro T130D, and Maintenance Manual (960-Q08)
Page 223 4. If water or other liquid is left on the panel’s surface for a long period, it can change the screen’s tint or stain it. Be sure to quickly wipe off any liquid with cloth or ionic PORTEGE T130D Satellite T130D, Satellite Pro T130D, and Maintenance Manual (960-Q08)
Page 224 6. CMOS-LSI circuits are used in the module, so guard against damage from electrostatic discharge. Be sure to wear a wrist or ankle ground when handling the module. PORTEGE T130D Satellite T130D, Satellite Pro T130D, and Maintenance Manual (960-Q08)
Page 225 Handling the LCD Module PORTEGE T130D Satellite T130D, Satellite Pro T130D, and Maintenance Manual (960-Q08)
Page 226 8. Do not store the module at temperatures below specifications. Cold can cause the liquid crystals to freeze, lose their elasticity or otherwise suffer damage. 9. Do not disassemble the LCD module. Disassembly can cause malfunctions. PORTEGE T130D Satellite T130D, Satellite Pro T130D, and Maintenance Manual (960-Q08)
Page 227 10. If you transport the module, do not use packing material that contains epoxy resin (amine) or silicon glue (alcohol or oxide). These materials can release gas that can damage the panel’s polarization. PORTEGE T130D Satellite T130D, Satellite Pro T130D, and Maintenance Manual (960-Q08)
Page 228 Board Layout Appendix B Appendix B Board Layout B.1 System Board CN14 CN11 CN12 Figure B-1-1 System board layout (front) Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 229 Board Layout CN17 CN15 CN16 CN18 CN19 CN20 CN21 CN22 CN10 CN23 Figure B-1-2 System board layout (Back) Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 230 CN19 SATA HDD CONN (19) CN20 DDRII CONN (20) CN21 DDRII CONN (21) CN22 MINI Card Slot#2 (3G) CONN (22) CN23 MINI Card Slot#1 (WiFi) CONN (23) LAN IC Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 231 Board Layout (24) Embedded Controller IC (25) Clock generator (26) (27) Memory Side Port (28) North Bridge (29) South Bridge Table B-1-3 System board ICs and connectors Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 232 LED3 BATT LED (06) LED4 HDD LED (07) LED5 Bridge Media LED (08) LED6 W-LAN LED (09) LED7 WiMAX/3G LED (10) HALL Sensor Table B-2-2 Touch Pad board connectors Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 233 <Back layout> Figure B-2-3 Touch Pad board layout (Back) Location Function (01) TP Board to TP Module CONN (02) TP Board to M/B CONN Table B-2-4 Touch Pad board connectors Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 234 <Front layout> Figure B-3-1 Finger Print Board layout (Front) Location Function (01) CRT to M/B CONN (02) CRT CONN (03) CRT to M/B CONN Table B-3-2 CRT Board connectors Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 235 Board Layout <Back layout> Figure B-3-3 CRT Board layout (Back) Location Function CRT ESD protection, level-shifting ,sync impedance (01) matching IC Table B-3-4 Finger Print Board connectors Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 236 Board Layout B.4 Power Board <Front layout> Figure B-4-1 Power Board layout (Front) Location Function (01) Power SW (02) LED1 Power LED Table B-4-2 Power Board connectors Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 237 Board Layout <Back layout> Figure B-4-3 Power Board layout (Back) Location Function (01) Power/B to M/B CONN Table B-4-4 Power Board connectors Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 238 Board Layout B.5 SIM (3G) Board <Front layout> Figure B-5-1 SIM (3G) Board layout (Front) Location Function (01) SIM(3G)/B to M/B CONN Table B-5-2 SIM (3G) Board connectors Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 239 Board Layout <Back layout> Figure B-5-3 SIM (3G) Board layout (Back) Location Function (01) JSIM1 SIM Card CONN Table B-5-4 SIM (3G) Board connectors Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 240 B.6 HDMI Board <Front layout> Figure B-6-1 HDMI Board layout (Front) Location Function (01) HDMI CONN (02) USB CONN (03) HDMI/B to M/B CONN Table B-6-2 HDMI Board connectors Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 241 Board Layout <Back layout> Figure B-6-3 HDMI Board layout (Back) Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 242 Board Layout B.7 ADO+MMC Board <Front layout> Figure B-7-1 ADO+MMC Board layout (Front) Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 243 (07) 5 IN 1 Card Reader CONN (08) CN10 Inner Speaker CONN (09) CN11 Reserved MIC CONN (10) CN4501 ADO+MMC Board to M/B CONN Table B-7-2 ADO+MMC Board connectors Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 244 Board Layout <Back layout> Figure B-7-3 ADO+MMC Board layout (Back) Location Function (01) Codec IC (02) Carder Reader IC Table B-7-4 ADO+MMC Board IC Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 245 MIC_GND INT_MIC_R USBP10-_LCD USBP10+_LCD LCD_DDCCLK LCD_DDCDAT INT_TXLCLKOUT- INT_TXLCLKOUT+ INT_TXLOUT2- INT_TXLOUT2+ INT_TXLOUT1- INT_TXLOUT1+ INT_TXLOUT0- INT_TXLOUT0+ LVDS_VADJ DISPON CN2 Power/B Connector PIN No. Signal name PIN No. Signal name +3VPCU NBSWON# PWR/B_LED#_Q Satellite T130D, Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 246 PIN No. Signal name K_LED_P MY16 MX17 K_LED_P MY14 MY13 MY10 MY11 MY12 MY15 K_LED_P CAPSLED FN_F10 NUMLED CN4 LAN Connector PIN No. Signal name PIN No. Signal name AVDD_CEN TX1P Satellite T130D, Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 247 SATA_TXP0 SATA_TXN0 SATA_RXN0 SATA_RXP0 CN6 Touchpad Board Connector PIN No. Signal name PIN No. Signal name LID591# TPCLK TPDATA MMC_LED# 3G_LED# RF_LED SATA_LED#_C O BAT_SAT1 BAT_SAT0 SUSLED_EC PWRLED# ACIN +3VPCU Satellite T130D, Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 248 USBP6+ USBP6- CN9 ADO+MMC Board Connector PIN No. Signal name PIN No. Signal name ACZ_SDIN0 ACZ_SDOUT_AUDIO I/O ACZ_SYNC_AUDIO ACZ_RST#_AUDIO BIT_CLK_AUDIO MIC_GND INT_MIC_R SPKR AMP_MUTE# USBOC#0 USBP1+ USBP1- USBP0+ USBP0- USB_EN#0_1 Satellite T130D, Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 249 PIN No. Signal name PIN No. Signal name TERM12 CN11 HDMI Board Connector PIN No. Signal name PIN No. Signal name +5VPCU +5VPCU +5VPCU +5VPCU BUSBP3- BUSBP3+ USB_SLEEP_OC# USB_SLEEP_EN# BOARD_ID2 HDMI_CON_HP Satellite T130D, Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 250 PIN No. Signal name PIN No. Signal name USBP9+ USBP9- WCS_CLK BT_RESET WCS_DAT BT_EN CN14 Battery Connector PIN No. Signal name PIN No. Signal name MBCLK MBDATA TEMP_MBAT MBAT+ MBAT+ Satellite T130D, Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 251 PIN No. Signal name PIN No. Signal name DDCDAT VSYNC DDCCLK HSYNC CRT_R CRT_G CRT_B CN17 CRT Connector PIN No. Signal name PIN No. Signal name DDCDAT DDCCLK VSYNC HSYNC CRT_B Satellite T130D, Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 252 Signal name PIN No. Signal name CPU_LDT_RST# CPU_PWRGD CPU_DBREQ# CPU_DBRDY CPU_TCK CPU_TMS CPU_TDI CPU_TRST# CPU_TDO +1.8VSUS +1.8VSUS CN19 Main SATA HDD Connector PIN No. Signal name PIN No. Signal name SATA_TXP0 Satellite T130D, Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 253 +3.3VSATA1 +3.3VSATA1 +3.3VSATA1 CN20 DDR Connector PI N No. Signal name PIN No. Signal name SMDDR_VREF_DIMM MEM_MA_DATA1 MEM_MA_DATA5 MEM_MA_DATA0 MEM_MA_DATA4 MEM_MA _DM0 MEM_MA_DQS0_N MEM_MA _DQS0_P MEM_MA_DATA6 MEM_MA_DATA7 MEM_MA_DATA2 MEM_MA_DATA3 MEM_MA_DATA12 Satellite T130D, Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 254 MEM_MA _DQS1_P MEM_MA _CLK1_N MEM_MA_DATA14 MEM_MA_DATA15 MEM_MA_DATA11 MEM_MA_DATA10 MEM_MA_DATA16 MEM_MA_DATA17 MEM_MA_DATA17 MEM_MA_DATA20 MEM_MA _DQS2_N MEMHOT_DIMM#_1 MEM_MA _DQS2_P MEM_MA_DM2 MEM_MA_DATA19 MEM_MA_DATA22 MEM_MA_DATA18 MEM_MA_DATA23 MEM_MA_DATA27 MEM_MA_DATA29 MEM_MA_DATA26 MEM_MA_DATA31 MEM_MB_DM3 MEM_MB_DQS3_N MEM_MB_RESET#2 MEM_MB_DQS3_P Satellite T130D, Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 255 MEM_MB_ADD11 MEM_MB_ADD9 MEM_MB_ADD7 MEM_MB_ADD8 MEM_MA_ADD6 +1.8VSUS +1.8VSUS MEM_MB_ADD5 MEM_MB_ADD4 MEM_MB_ADD3 MEM_MB_ADD2 MEM_MB_ADD1 MEM_MB_ADD0 +1.8VSUS +1.8VSUS MEM_MB_ADD10 MEM_MB_BANK1 MEM_MB_BANK0 MEM_MB_RAS# MEM_MB_WE# MEM_MB0_CS#0 +1.8VSUS +1.8VSUS MEM_MB_CAS# MEM_MB0_ODT0 MEM_MB0_CS#1 MEM_MB_ADD13 +1.8VSUS +1.8VSUS MEM_MB0_ODT1 Satellite T130D, Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 256 MEM_MA_DATA38 MEM_MA_DATA_32 MEM_MA_DATA36 MEM_MA_B_DQSQ_N MEM_MA_DM4 MEM_MA_B_DQSQ_P MEM_MA_DATA_34 MEM_MA_DATA_33 MEM_MA_DATA_35 MEM_MA_DATA_39 MEM_MA_DATA_40 MEM_MA_DATA_44 MEM_MA_DATA_41 MEM_MA_DATA_45 MEM_MA_B_DQS5_N MEM_MA_DM5 MEM_MA_B_DQS5_P MEM_MA_DATA_43 MEM_MA_DATA_42 MEM_MA_DATA_46 MEM_MA_DATA_47 MEM_MA_DATA_53 MEM_MA_DATA_49 MEM_MA_DATA_48 MEM_MA_DATA_52 MEM_MA_CLK7_P MEM_MA_CLK7_N MEM_MA_DSQ6_N MEM_MA_DSQ6_P MEM_MA_DM6 Satellite T130D, Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 257 MEM_MA_DATA_59 MEM_MA_DATA_62 PDAT_SMB PCLK_SMB DIM1_SA0 DIM1_SA1 CN21 DDR Connectors PI N No. Signal name PIN No. Signal name SMDDR_VREF_DIMM MEM_MA_DATA0 MEM_MA_DATA4 MEM_MA_DATA1 MEM_MA_DATA5 MEM_MA _DM0 MEM_MA_DQS0_N MEM_MA _DQS0_P MEM_MA_DATA6 MEM_MA_DATA7 Satellite T130D, Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 258 MEM_MA _CLK1_P MEM_MA _DQS1_P MEM_MA _CLK1_N MEM_MA_DATA10 MEM_MA_DATA15 MEM_MA_DATA11 MEM_MA_DATA14 MEM_MA_DATA17 MEM_MA_DATA16 MEM_MA_DATA20 MEM_MA_DATA21 MEM_MA _DQS2_N MEMHOT_DIMM#_2 MEM_MA _DQS2_P MEM_MA_DM2 MEM_MA_DATA22 MEM_MA_DATA19 MEM_MA_DATA23 MEM_MA_DATA18 MEM_MA_DATA29 MEM_MA_DATA28 MEM_MA_DATA25 MEM_MA_DATA24 MEM_MB_DM3 MEM_MB_DQS3_N Satellite T130D, Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 259 MEM_MB_ADD11 MEM_MB_ADD9 MEM_MB_ADD7 MEM_MB_ADD8 MEM_MA_ADD6 +1.8VSUS +1.8VSUS MEM_MB_ADD5 MEM_MB_ADD4 MEM_MB_ADD3 MEM_MB_ADD2 MEM_MB_ADD1 MEM_MB_ADD0 +1.8VSUS +1.8VSUS MEM_MB_ADD10 MEM_MB_BANK1 MEM_MB_BANK0 MEM_MB_RAS# MEM_MB_WE# MEM_MB0_CS#0 +1.8VSUS +1.8VSUS MEM_MB_CAS# MEM_MB0_ODT0 MEM_MB0_CS#1 MEM_MB_ADD13 +1.8VSUS +1.8VSUS MEM_MB0_ODT1 Satellite T130D, Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 260 MEM_MA_DATA35 MEM_MA_DATA_34 MEM_MA_DATA39 MEM_MA_B_DQSQ_N MEM_MA_DM4 MEM_MA_B_DQSQ_P MEM_MA_DATA_36 MEM_MA_DATA_32 MEM_MA_DATA_37 MEM_MA_DATA_33 MEM_MA_DATA_45 MEM_MA_DATA_46 MEM_MA_DATA_44 MEM_MA_DATA_43 MEM_MA_B_DQS5_N MEM_MA_DM5 MEM_MA_B_DQS5_P MEM_MA_DATA_42 MEM_MA_DATA_40 MEM_MA_DATA_41 MEM_MA_DATA_47 MEM_MA_DATA_53 MEM_MA_DATA_48 MEM_MA_DATA_52 MEM_MA_DATA_49 MEM_MA_CLK7_P MEM_MA_CLK7_N MEM_MA_DSQ6_N MEM_MA_DSQ6_P MEM_MA_DM6 Satellite T130D, Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 261 MEM_MA_DATA_63 MEM_MA_DATA_62 MEM_MA_DATA_58 PDAT_SMB PCLK_SMB DIM1_SA0 DIM1_SA1 CN22 MINI PCI-E Card 3G Connector PIN No. Signal name PIN No. Signal name WLAN_WAKE# +3V_3G +1.5V_3G UIM_PWR UIM_DATA CLK_PCIE_MINI2# UIM_CLK CLK_PCIE_MINI2 UIM_RST Satellite T130D, Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 262 PCIE_TXN3 SB_SDATA2 PCIE_TXP3 USBP7- USBP7+ +3V_3G CPUSB# +3V_3G 3G_LED# +1.5V_3G +3V_3G CN23 MINI PCI-E Card WLAN Connector PIN No. Signal name PIN No. Signal name WLAN_WAKE# +3V_WL_VDD WCS_DAT WCS_CLK +1.5V Satellite T130D, Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 263 Pin Assignment LAD0 LAD1 CLK_PCIE_MINI# LAD2 CLK_PCIE_MINI LAD3 LFRAME# RF_EN PLTRST# PCIE_RXN2 +3V_WL_VAUX PCIE_RXP2 +1.5V WL_SMCLK PCIE_TXN2 WL_SMDATA PCIE_TXP2 USBP8- USBP8+ +3V_S5 +3V_WL_VAUX PCLK_DEBUG PCIRST# +1.5V LDRQ0#_SB SERIRQ +3V_WL_VDD Satellite T130D, Satellite ProT130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 264 Display Codes Code set 1 Code set 2 Keytop Note Make Break Make Break ‘ ~ 7 & BkSp Table D-1-1 Scan codes (set 1 and set 2) (1/4) Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 265 Note Make Break Make Break Caps Lock ‘ “ Enter Shift (L) No.102 , < . > Shift (R) Table D-1-1 Scan codes (set 1 and set 2) (2/4) Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 266 Note Make Break Make Break Ctrl Alt (L) Space ALT (R)  Home   PgUp PgDn   Table D-1-1 Scan codes (set 1 and set 2) (3/4) Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 267 5. * This key corresponds to key No. 42 in a 102-key model. 6. * Refer to Table D-6, No. 124 key scan code. 7. * Refer to Table D-7, No. 126 key scan code. Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 268 With right Shift Set 1 E0 AA __________ E0 B6 E0 2A ___________ E0 36 Set 2 E0 F0 12 ________ E0 F0 59 E0 12 ___________ E0 59 Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 269 Table D-1-3 Scan codes in Numlock mode Code set 1 Code set 2 Keytop Make Break Make Break CTRL LALT ARROW NUMERIC Scrl Table D-1-4 Scan codes with Fn key Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 270 Table D-1-5 Scan codes in overlay mode Code set 1 Code set 2 Shift Make Break Make Break Prt Sc Common Ctrl  Shift  Alt  Table D-1-6 No.124 key scan code Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 271 Code set 2 Make Make Pause Common* E1 1D E1 F0 Ctrl* E0 46 7E E0 F0 Table D-1-7 No.126 key scan code *: This key generates only make codes. Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 272 Keyboard Layout Appendix E Keyboard Layout United Status (US) Keyboard Figure E-1-1 US keyboard United Kingdom (UK) Keyboard Figure E-2-1 UK keyboard ________________________________________________________________________________________________________ Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 273 Keyboard Layout Japan Keyboard Figure E-3-1 Japan keyboard ________________________________________________________________________________________________________ Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)
Page 274: Appendix F Wiring Diagrams
B Monitor ID Wraparound connector (16PIN to 16PIN) LAN Loop back Connector (1) BIBAP ‘(TX+) (3) BIDBP (RX+) (4) BIDBN (RX-) (2) BIDAN (TX-) Figure F-2-1 LAN loopback connector Satellite T130D, Satellite Pro T130D and PORTEGE T130D Maintenance Manual (960-Q08)

This manual is also suitable for:

Portege t130d Satellite prot130d

Toshiba Satellite T130D Maintenance Manual

Table of Contents

Chapter 1 Hardware Overview

Chapter 1 Hardware Overview

Chapter 2 Troubleshooting Procedures

Chapter 2 Troubleshooting Procedures

Chapter 3 Diagnostic Programs

Chapter 3 Diagnostic Programs

Chapter 4 Replacement Procedures

Chapter 4 Replacement Procedures

Appendix A Handling the LCD Module

Appendix B Board Layout

Appendix F Wiring Diagrams

Appendix A Handling the Lcd Module

Appendix F Wiring Diagrams

Quick Links

Chapters

Troubleshooting

Related Manuals for Toshiba Satellite T130D

Summary of Contents for Toshiba Satellite T130D

This manual is also suitable for:

Table of Contents
