- Page 1 A P R O U D H E R I T A G E O F E X P E R I E N C E & Q U A L I T Y W i n e C o o l e r V T - 1 2 T E D S ( 1 2 b o t t l e ) O W N E R ’...
- Page 2 Y o u r W i n e C e l l a r This unit can be used for storage and/or service. The unit has a glass door and soft interior light that you can leave on to elegantly display your wine. S e r v i n g W i n e s Storing wines at the proper temperature is important.
-
Page 3: General Operating Instructions
Upon receipt and inspection of unit, the supply cord must be replaced if it is damaged. Contact our customer service at 1-800-777-8466 or info@vinotemp.com. Please read and follow all safety rules and operating instructions before using. -
Page 4: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..........5 ELECTRICAL CONNECTION ............6 TECHNICAL DATA ............... 6 COOLER DIAGRAM ..............7 INSTALLATION INSTRUCTIONS ............. 8 CARE AND MAINTENANCE ............9 TROUBLESHOOTING GUIDE ............10 TERMS OF SALE AND WARRANTY ..........11 SERVICE &... -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: • Use this appliance only as described in th is manual. Other uses are not recommended and may cause fire, electric shock or injury. •... -
Page 6: Electrical Connection
It is strongly recommended that you do not use an adapter or an extension cord with this unit. Please ensure that the appliance is plugged directly into the electrical outlet. TECHNICAL DATA Model No. VT-12TEDS Capacity 12 Bottles Voltage 110V AC Current 0.8A(77°F/25°C) -
Page 7: Cooler Diagram
COOLER DIAGRAM 1. Hinge Cover 7. Temperature C ontrol Knob 2. Light 8. Light Switch 3. Fan Cover 9. Magnetic Seal 4. Shelf 10. Glass 5. Foot 11. Door Handle 6. Water Box CIRCUIT DIAGRAM 1 7 6 2 1 S o u t h S u s a n a R o a d , R a n c h o D o m i n g u e z , C a l i f o r n i a 9 0 2 2 1 i n f o @ v i n o t e m p . -
Page 8: Installation Instructions
• Check to be sure the follo wing parts are included: For VT-12TEDS, 3 Slide out shelves 1 instruction manual • Before connecting the appliance to the power source, let it stand upright for approximately 2 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation. -
Page 9: Care And Maintenance
CARE AND MAINTENANCE Cleaning your wine cellar: • Unplug the wine cellar and remove the bottles and shelves. • Wash the inside with warm water or a baking soda solution. The solution should be about 2 tablespoons of baking soda to a quart of water. •... -
Page 10: Problems With Your Wine Cellar
You can solve many common wine cellar problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before contacting Vinotemp at info@vinotemp.com TROUBLESHOOTING GUIDE PROBLEM POSSIBLE CAUSE Wine cellar does not •... -
Page 11: Terms Of Sale And Warranty
Note: Unfinished wood is subject to warping; all wood surfaces must be sealed before placing cellar into service. Improper placement of the unit will void the warranty. By Vinotemp in writing, any third party repair facility must be pre-approved before providing parts rranty does not cover damage due to such things as accident, misuse, abuse, mishand free of charge. -
Page 12: Service & Important Notice
WARNING: Please do not place the unit within reach of children. For adult use only. Contact info@vinotemp.com with any questions or visit www.vinotemp.com 17621 S. Susana Road Rancho Dominguez, CA 90221 www.vinotemp.com...
