CONTROLS
TROUBLESHOOTING
For more details, consult your JVC car audio dealer.
Hex screw
Hex wrench (2.5 mm)
The POWER/PROTECTOR lamp does not light.
o
Change the fuses if the current one is blown.
o
Connect the ground lead securely to a metal part of the car.
o
Turn on the equipment connected to this unit.
o
Use a relay if your system employs too many amplifiers.
o
Confirm the battery voltage (11 V to 16 V).
The POWER/PROTECTOR lamp lights in red and/or the unit heats up abnormally.
o
Use the speakers of suitable impedance.
o
Correct the speaker wirings if they are short-circuited.
o
Make the speaker wirings away from the power cord to prevent DC offset error.
o
Leave the unit turned off for a while to cool it down.
No sound is heard.
o
Confirm the connections for power supply (see "POWER SUPPLY" on page 1).
o
Connect RCA pin cords to the INPUT jacks firmly.
I'J
Control cover
To operate the tollowing controls, remove the hex screws with a provided hex wrench
(2.5 mm) and detach the control cover. Attach it again after your operation.
mf--~:ITPI~~~~~!9'il1~===t-----1m
I
~
00"'00
JJi : 11
lOin
00000000000
DOOIJOODOOOO
III
Alternator noise is heard.
o
Keep the power cords away from the RCA pin cords.
o
Keep the RCA pin cords away from other electrical cables in the car.
o
Connect the ground lead securely to a metal part of the car.
o
Make sure the negative speaker leads do not touch the car chassis.
o
Replace the plugs or use plugs with load resistors.
o
Connect a bypass capacitor across the accessory switches (horn, fan, etc.).
Noise is made when you connect the unit to an AM tuner.
o
Move the speaker and power cords away from the antenna lead.
SPECIFICATIONS
Power Output
Signal-to-Noise Ratio
• Normal Mode: 500 W RMS x 1 channel at 4 Q and,; 1
%
THO
+
N
60 dBA (reference: 1 W into 4 Q)
• Normal Mode:
1 000 W RMS x 1 channel at 2 Q and,; 1
%
THD + N
1 500 W RMS x 1 channel at 1 Q and,; 1 % THD +
N
• Normal Mode:
1 800 W
• External Bridge Mode:
3 000 W
• Normal Mode:
4 Q (1 Q to 8 Q allowance)
• External Bridge Mode:
2 Q (2 Q to 8 Q allowance)
20 Hz to 300 Hz' (+0, -3 dB)
• Subsonic filter cuts off extremely low frequency signals. (The cutoff
frequency is adjustable within the range of 20 Hz to 50 Hz.)
2 V/45 kQ (0.3 V to 6 V, variable)
Less than 0.1
%
(at 100 Hz)
DC 14.4 V (11 V to 16 V allowance)
Negative ground
360 mm x 60 mm x 245 mm (14
3h6
inch x 2
3/8
inch x
9
"h6
inch)
5.00 kg (11.02 Ibs.)
Screw-Dia.4 mm
('h6
inch) x 20 mm (
13 h6
inch) x 4
Hex wrench
4
mm
x
1
3
mm
x
1
2.5 mm
x
1
Spacer x 4
Bracket x 2
Hex screw-M4 x 12 mm
('/2
inch) x 6
Load Impedance
Power Output
Frequency Response
Maximum Power Output
Input Sensitivity/Impedance
Distortion
Power Requirement
Grounding system
Dimensions (WxHxD)
Mass (approx.)
Supplied Accessories
Design and specifications are subject to change without notice
..Ive
_
[European Union only]
BASS BOOST
controller
©
Remote cord
(provided for
RM-RK130)
®
At
Screw-Dia.4 mm
(3/16
inch) x
12
mm
(1/2 inch) (provided for
RM-RK130)
®
Under the
~Shboard, etc.
"
f~rilled
hole
r
_.!~
Wired remote control unit: RM-RK130
(purcha~
separately)
Using JVC's wired remote control unit: RM-RK130 (purchased separately), you can adjus1 the
bass boost in your seat without adjusting the BASS BOOST controller on the amplifier (see
"CONTROLS").
y
A~
Note
Set the BASS BOOST controller on the amplifier to MIN when you use RM-RKt 30.
®
Mount RM-RK130 on a firm surface, such
as
under the dashboard.
®
Connect RM-RK130 to the REMOTE terminal on the amplifier with the remote cord
provided for RM-RK130.
.
©
RM-RK130 boosts the 45 Hz frequency within the range of 0 dB to + 18 dB. Adjust the level.
while listening to the sound.
The POWER lamp lights in green while RM-RK130is turned on.
III
Input LEVEL controller
The input level can be adjusted with this controller when this unit is connected to other source
equipment. Adjust the level while listening to the sound. This controller is preset to MIN when
the unit is shipped.
l!I
LPF (Low-Pass Filler) controller
Adjust the cutoff frequency (the Low-Pass Filter transmits frequencies lower than the cutoff
frequency) within the range of 50 Hz to 300 Hz. Adjust the level while listening to the sound.
This controller is preset to 50 Hz when the unit is shipped.
m
PHASE switch
Select either normal (NOM) or reverse (REV), which reproduce a better sound. This switch is
preset to NOM when the unit is shipped.
II
BASS BOOST controller
Turning this boosts the 45 Hz frequency within the range at 0 dB to
+
18 dB. Adjust the level
while listening to the sound. This controller is preset to MIN when the unit is shipped.
iii
SUBSONIC filter controller
Adjust the cutoff frequency (the subsonic filter rejects frequencies lower than the cutoff
frequency) within the range of 20 Hz to 50 Hz. This controller is preset to 20 Hz when the unit
is shipped.
iii
POWER/PROTECTOR lamp
The lamp lights in green while the unit is turned on.
II
the lamp does not light or lights in red
with the unit on, some trouble has occurred (see "TROUBLESHOOTING").
m
Power indicator
The blue lamp illuminates while the unit is turned on.
