- Page 1 Model No RN-33.. NO-Frost Combi Refrigerator Code : AD302-1 AD302-1(영).indd 1 2012-11-05 오후 12:16:48...
- Page 2 SAFETY WARNING (R-600a Models Only) This appliance contains a certain amount of isobutane refrigerant (R600a) a natural gas with high environmental compatibility that is, however, also combustible. when transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged.
-
Page 3: Warning / Safety Precautions
WARNING / SAFETY PRECAUTIONS To avoid any risk of personal injury, material damage or incorrect use of the appliance, be sure to observe the following safety precautions. (After reading these owner’s instructions, please keep them in a safe place for reference). Remember to hand them over to any subsequent owner. -
Page 4: Installing The Fridge / Freezer
CAUTION Do not store too much food in the appliance. • W hen you open the door, an item may fall out and cause personal injury or material damage. Do not put bottles or any kind of glass in the freezer. • T he container may break and cause personal injury. If the wall socket is loose, do not insert the power plug. • I t may cause electric shock or fire. -
Page 5: Preparing The Fridge / Freezer
WARNING Use of an earthed socket exclusively For the appliance : • I f you are using a socket with an earthed terminal, you do not require a separate earthed connection. Use of a non-earthed socket : • C onnect the “earthed wire” to the steel plate and bury it at depth of at least 25cm in the ground. leVelIng If the front of the appliance is slightly higher than the rear, the door can be opened and closed more easily. 1. The appliance tilts down to the left. Turn the left adjusting leg in the direction of the arrow until the appliance is lever. 2. The appliance tilts down to the right. Turn the right adjusting leg in the direction of the arrow until the appliance is lever. -
Page 6: About This Product
aBOUt thIs PrOdUCt ■ This is designed for domestic household use only. ■ Use the 4-star freezer compartment - to freeze fresh and cooked foods, - to store deep-frozen and frozen product, - to make ice-cubes. ■ Use the refrigerator compartment - to store fresh foods, - to cool drinks. ■ The freezer and refrigerator compartment defrost automatically. ■ Owing to cool air circulation (multi-airflow system) an even temperature is maintained on every shelf of the refrigerator compartment. ■ The electronic control panel or control knob enable you to control the temperature of refrigerator compartment. BeFOre COnneCtIng tO the MaIns 1. Wait 2 hours after delivery before you connect the appliance to the power supply, in order to ensure trouble-free operation. 2. Check the product label which locates refrigerator compartment wall for voltage, refrigerant and other information. 3. The socket should be easily accessible and not directly behind the appliance. 4. Electrical connections must be made in accordance with local regulations. The appliance must be earthed as described by law (connected through a properly earthed plug and socket). The manufacturer rejects all liability for injury to persons and animals or damage to property resulting from failure to comply with this requirement. 5. A 10A fuse or one of higher value must be used in the socket circuit. 6. If the appliance plug and the wall socket are incompatible, the socket must be replaced by a qualified electrician. 7. If the supply cord is damaged, it must be replaced by the manufacturer, his service agent or a similarly qualified person 8. Do not use extension leads or multiple adapters, etc. AD302-1(영).indd 4 2012-11-05 오후 12:16:50... - Page 7 desCrIPtIOn OF YOUr reFrIgeratOr Window Multi duct Shelves (3EA) Pocket “R” (3EA) Multi duct Case Glass Vegetable(1EA) Pocket “J”(1EA) Vegetable case Case F “A”(2EA) Shelves Glass F (2EA) Case F “B”(1EA) Adjustable foot AD302-1(영).indd 5 2012-11-05 오후 12:16:50...
-
Page 8: Name Of Each Part & Function
naMe OF eaCh Part & FUnCtIOn SHELVES POCKET “R” - P ut the egg tray on the pocket or store short bottled food, packed drinks and spice containers, etc. - Storing beer bottles, little bottled drinks, etc. POCKET “J” - Storing big bottled drinks, juice, etc. - Arrange drinks clearly using “GUIDE BOTTLE”. SHELVES Provided to store day to day food. VEGETABLE CASE It keeps vegetables fresh. CASE F A TOP CASE - P ut the ice box left side in the top case to make ice fast. - Store frozen food. -
Page 9: Protecting The Environment
dIsCOnneCtIOn NOTE: Does not apply in the UK. Electrical disconnection : remove the plug from the mains, or (if applicable) disconnect the two-pole circuit breaker upstream from the socket. PrOteCtIng the enVIrOnMent - The packaging may be completely recycled, as confirmed by the recycling symbol; follow local disposal regulations. - The appliance is manufactured form reusable materials. - W hen you decide to scrap this product, please check the cable to be disconnected from the mains. Then cut off the cable and dispose of the product according to local waste disposal laws. - T his product is free of CFC’s (cooling circuit contains R134a or R-600a). This use R-600a or R134a as a refrigerant. Check the compressor label on the rear of the appliance or the rating label inside the fridge to see which refrigerant is used for your refrigerator. 2 hodiny Keep room dry and well Keep more than 5cm Clean interior with a damp Best room temperature Wait 2 hours before distance space at the top Range- +16°C to 32°C connecting to the mains ventilated. cloth. for ventilation. IMPORTANT 1. A lthough this product was carefully checked before packing. Please check the product for damage and for correct closing of the doors. Complaints must be reported to your retailer within 24 hours of delivery. -
Page 10: Observe Ambient Temperature
Always unplug before cleaning If the power cord is damaged, Ice cubes and ice lollies Do not allow children to play straight out of the freezer are or hide in the refrigerator to and servicing. it must be replaced by the too cold for consuming. They prevent the risk of trapping manufacturer or its service agent or a similarly qualified may cause ‘cold’ burns. and suffocation. person in order to avoid a hazard. OBserVe aMBIent teMPeratUre This refrigerator is designed to operate in ambient temperature specified by its category, which marked on the rating plate. Climatic category Ambient temperature from…to +10°C to +32°C +16°C to +32°C +16°C to +38°C +16°C to +43°C NOTE Internal temperature may be affected by such factors as the location of the refrigerator, ambient temperature and frequency of door opening. hOW tO Use the reFrIgeratOr COMPartMent and Freezer COMPartMent Connect the lead to the main (at least wait 2 hours after delivery; refer to section “Before connecting to the mains”) Food can be stored after 3 to 4 hours of cooling. -
Page 11: Notes On Freezing And Storage
- The interior light switches on when the door is opened - The compressor operates and starts cooling. 1. I f you want to change the compartment temperature, push the “TEMP button”. If you press this button, the lamps of position will change and the order is as follows. NOR → HIGH NOR → MAX → MIN → LOW NOR 2. W hen you push the “S-COOL button”, The lamp of “Scool” ( ) will flicker with beep. And you push the button again, the lamp of the memorized step will light. 3. T he suitable storage temperature for fresh food is provided at “ NOR ” position at an ambient temperature of 16 °C to 32 °C NOTE: Initially, both compartments temperatures are set “ NOR ” position automatically. 4. D efrosting Control Your appliance is frost free, which means there is no need to manually defrost. It will be carried out automatically. If you want to prevent an undue rise in the temperature of the frozen food while defrosting the appliance, Please wrap the frozen food in several layers of paper such sa newspaper. [FREEZER COMPARTMENT] For ordinary use (SET “MID”) The control has three setting from LOW to HIGH. HIGH (FREEZER CONTROL KNOB) nOtes On FreezIng and stOrage 1. Follow storage times indicated by the frozen food manufacturer. Make sure that the packaging is undamaged. -
Page 12: After Sales Service
When PUrChasIng FrOzen FOOd 1. Make sure that the packaging is undamaged (damage may have caused the food to deteriorate). Bulging packs or packs which are marked with liquid stains could have been improperly stored and may have been partially thawed. 2. Leave frozen food purchases until last and transport the items in insulated bags. 3. Place the items in the freezer as soon as possible. 4. Do not refreeze partially thawed food. Consume it within 24 hours. 5. Observe the date of consumption and storage information. CleanIng 1. Always disconnect the appliance from the mains supply. 2. Do not use abrasives. Periodically clean with a sponge dampened in lukewarm water. A neutral pH detergent may be used. Rinse and dry with a soft cloth. 3. Wipe the outside with a soft cloth dampened in water. 4. Periodically clean the front grille and the radiator at the back with a vacuum cleaner or a brush PrOlOnged dIsUse 1. E mpty the refrigerator and freezer compartments. 2. U nplug the appliance from the mains. 3. C lean and dry both compartments. 4. L eave the doors open to prevent the formation of unpleasant odors. aFter sales serVICe Before contacting our After Sales Service Department: 1. T ry to remedy the problem (please read section “trouble shooting guide”). 2. R estart the appliance to check whether the fault repeats. If the malfunction persists, switch off the appliance and try again after an hour. -
Page 13: Appliance Packaging Information
aPPlIanCe PaCKagIng InFOrMatIOn All material are environmentally sound! They can be dumped or burned at an incineration plant without danger! About the materials: The plastics can be recycled and are identified as follows: ■ PE : for polyethylene, e.g. the outer covering and the bags in the interior. ■ PS : for polystyrene foam, e.g. the pads, which are all free of chlorofluorocarbon. The carton parts are made from recycled paper and should be disposed of at a waste-paper recycling collection location. dIsPOsal OF Old aPPlIanCes For environmental reasons, refrigeration appliances must be disposed of properly. This applies to your old appliance, and –at the end of its service life- for your new appliance as well. Warning! Before disposing of old appliances make them remove or destroy any snap or latch closures. This eliminates the danger that playing children lock themselves into the appliance (danger of suffocation!) or place themselves into other life- endangering situations. Disposal : • The appliance may not be disposed of with domestic waste or bulky refuse. • The refrigerant circuit, especially the heat exchanger at back of the appliance, may not be damaged. • Information concerning collection schedules or locations can be obtained from the local disposal authorities or town hall. NOTICE The lamp and the alarm of the refrigerator can be switched off even though the doors are not completely closed. NoTe : The edge of the refrigerator door and the front side of the refrigerator cabinet may be hot. This is normal and intended to prevent the formation of condensation.
