- Page 1 Model No DFF470.. / DFF530.. RN30.. / RN40.. DAEWOO FROST FREE FRIDGE FREEZER Customer Service Support Line: 0844 887 2525 Code : AD241-2a AD241-2a(영)_DESUK.indd 1 2012-06-01 오후 2:39:54...
- Page 2 SAFETY WARNING (R-600a Models Only) This appliance contains a certain amount of isobutane refrigerant (R600a) a natural gas with high environmental compatibility that is, however, also combustible. when transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged.
-
Page 3: Warning / Safety Precautions
WARNING / SAFETY PRECAUTIONS To avoid any risk of personal injury, material damage or incorrect use of the appliance, be sure to observe the following safety precautions. (After reading these owner’s instructions, please keep them in a safe place for reference). Remember to hand them over to any subsequent owner. -
Page 4: Installation
CAUTION Do not store too much food in the appliance. • W hen you open the door, an item may fall out and cause personal injury or material damage. Do not put bottles or any kind of glass in the freezer. • The container may break and cause personal injury. If the wall socket is loose, do not insert the power plug. • It may cause electric shock or fire. Do not disconnect the power cord by pulling on it. • You may disconnect a wire and cause a short circuit. -
Page 5: Spacer Installation
spacer InstallatIon This will maintain a miniumu distance from the wall, therefore providing adequate ventilation. WARNING Use of an earthed socket exclusively For the appliance : • I f you are using a socket with an earthed terminal, you do not require a separate earthed connection. Use of a non-earthed socket : • C onnect the “earthed wire” to the steel plate and bury it at depth of at least 25cm in the ground. leVelIng If the front of the appliance is slightly higher than the rear, the door can be opened and closed more easily. 1. The appliance tilts down to the left. Turn the left adjusting leg in the direction of the arrow until the appliance is lever. 2. The appliance tilts down to the right. Turn the right adjusting leg in the direction of the arrow until the appliance is lever. -
Page 6: Preparing The Fridge / Freezer
preparIng the FrIdge / Freezer To Prepare your appliance for use and check that it is running correctly, take the following steps. 1. Install removed all shelves and compartments during transport in the correct positions. 2. C lean the fridge / freezer and accessories to remove any dust that accumulated during packing and shipping. 3. T he interior light should be turned on when the refrigerator door’s opened. 4. S et the temperature control to the coldest temperature and let the refrigerator operate for one hour. The freezer should get slightly chilled and the motor should run smoothly with a soft hum and no noise. Your fridge / freezer is operated by a compressor which switches “on and off” to maintain the internal temperature. When compressor is new, it requires running in for a period of up to five months. During this period, it may be slightly noisy. This is quite normal and does not represent a fault. 5. Store food once the temperature in the refrigerator is sufficiently low. It takes a few hours after starting the refrigerator to reach the proper temperature. If the appliance does not operate correctly, check the electricity supply. If the problem persists, contact your dealer. 6. Allow the appliance to stand for 2 hours before plugging in. 7. A whooshing noise can sometimes be heard when first installed. Don't worry the cases will soon settle. This product has been designed, constructed and marketed in accordance with EEC directives 2006/95/CE, 2004/108/CE, and 96/57 Please read this manual carefully to ensure maximum satisfaction from your appliance. Keep the manual in a safe place for... - Page 7 descrIptIon oF YoUr reFrIgerator 1. DFF470.. / RN30.. series Window Multi duct Pocket “R” (2EA) Shelves (2EA) Multi duct Knob control Case Glass Vegetable(1EA) Pocket “J”(1EA) Vegetable case Case F “A”(3EA) Case F “B”(1EA) Adjustable foot AD241-2a(영)_DESUK.indd 5 2012-06-01 오후 2:39:58...
- Page 8 2. DFF530.. / RN40.. series Window Multi duct Shelves (3EA) Pocket “R” (3EA) Multi duct Knob control Case Glass Vegetable(1EA) Pocket “J”(1EA) Vegetable case Case F “A”(2EA) Shelves Glass F (2EA) Case F “B”(1EA) Adjustable foot AD241-2a(영)_DESUK.indd 6 2012-06-01 오후 2:39:58...
-
Page 9: Name Of Each Part & Function
naMe oF each part & FUnctIon 1. DFF470.. / RN30.. series POCKET POCKET “R” - P ut the egg tray on the pocket or store short bottled food, packed drinks and spice containers, etc. - Storing beer bottles, little bottled drinks, etc. POCKET “J” - Storing big bottled drinks, juice, etc. - Arrange drinks clearly using “GUIDE BOTTLE”. SHELVES Provided to store day to day food. VEGETABLE CASE It keeps vegetables fresh. CASE A TOP CASE - P ut the ice box left side in the top case to make ice fast. - Page 10 2. DFF530.. / RN40.. series POCKET POCKET “R” - P ut the egg tray on the pocket or store short bottled food, packed drinks and spice containers, etc. - Storing beer bottles, little bottled drinks, etc. POCKET “J” - Storing big bottled drinks, juice, etc. - Arrange drinks clearly using “GUIDE BOTTLE”. SHELVES Provided to store day to day food. VEGETABLE CASE It keeps vegetables fresh. CASE F A TOP CASE - P ut the ice box left side in the top case to make ice fast. - Store frozen food. MIDDLE CASE - Store frozen food.
-
Page 11: Protecting The Environment
dIsconnectIon NOTE: Electrical disconnection : remove the plug from the mains, or (if applicable) disconnect the two-pole circuit breaker upstream from the socket. protectIng the enVIronMent - The packaging may be completely recycled, as confirmed by the recycling symbol; follow local disposal regulations. - The appliance is manufactured form reusable materials. - W hen you decide to scrap this product, please check the cable to be disconnected from the mains. Then cut off the cable and dispose of the product according to local waste disposal laws. - T his product is free of CFC’s (cooling circuit contains R-600a as a refrigerant) 2 hours Keep room dry and well Keep more than 5cm Clean interior with a damp Best room temperature Wait 2 hours before distance space at the top Range- +16°C to 32°C connecting to the mains ventilated. cloth. for ventilation. IMPORTANT 1. A lthough this product was carefully checked before packing. Please check the product for damage and for correct closing of the doors. Complaints must be reported to your retailer within 24 hours of delivery. -
Page 12: Observe Ambient Temperature
Always unplug before cleaning If the power cord is damaged, Ice cubes and ice lollies Do not allow children to play straight out of the freezer are or hide in the refrigerator to and servicing. it must be replaced by the manufacturer or its service too cold for consuming. They prevent the risk of trapping agent or a similarly qualified may cause ‘cold’ burns. and suffocation. person in order to avoid a hazard. oBserVe aMBIent teMperatUre This refrigerator is designed to operate in ambient temperature specified by its category, which marked on the rating plate. Climatic category Ambient temperature from…to +10°C to +32°C +16°C to +32°C +16°C to +38°C +16°C to +43°C NOTE Internal temperature may be affected by such factors as the location of the refrigerator, ambient temperature and frequency of door opening. hoW to Use the reFrIgerator coMpartMent and Freezer coMpartMent Connect the lead to the main (at least wait 2 hours after delivery; refer to section “Before connecting to the mains”) Food can be stored after 3 to 4 hours of cooling. -
Page 13: Notes On Freezing And Storage
[FREEZER COMPARTMENT] For ordinary use (SET “MID”) The control has three setting from LOW to HIGH. Control knob is at the rear side of top freezer drawer right hand corner wall. HIGH (FREEZER CONTROL KNOB) NOTE : Initially, both compartments temperatures are set “MID” position automatically. notes on FreezIng and storage 1. Follow storage times indicated by the frozen food manufacturer. Make sure that the packaging is undamaged. 2. Save energy : minimize opening of the door by storing identical food items together. 3. Items suitable for freezing : meat, poultry, fresh fish, vegetables, fruits, dairy products, bread, baked goods, pre-cooked meals. 4. Items not suitable for freezing : lettuces, radishes, grapes, whole apples and pears, fatty meats. 5. W hen you freeze food yourself, pack it in appropriate quantities. In order to freeze food right through do not exceed the following quantities to best preserve the quality: - fruits and vegetables : up to 1kg, - meat : up to 2.5kg. 6. B lanch vegetables after washing and cutting them. (2-3 minutes in boiling water; then quickly cool them down in cold water. When you use a steamer or microwave oven, follow the operating instructions). -
Page 14: Changing Door Opening Direction
changIng door openIng dIrectIon 1. Remove the Door Assembly ⓐ Remove ‘Top Cover Hinge’ and ‘Top Hinge’ ⓑ Carefully remove ‘Refrigerator Door’. ⓒ Remove ‘Middle Hinge’ and ‘Cover middle hinge’. ⓓ Carefully remove ‘Freezer Door’. ⓔ Remove ‘Under Hinge’. ⓕ Remove ‘Adjustable foot’. 2. Reverse the Door Accessories ⓖ R everse the position of ‘Cover Bushing Freezer Door’. ⓖ ⓖ ⓗ ⓗ Reverse the position of ‘Door Stoppers’. ⓗ E-12 AD241-2a(영)_DESUK.indd 12 2012-06-01 오후 2:40:01... - Page 15 3. Reassemble the Freezer and Fridge Door ⓟ ⓘ Assemble the ‘Under Hinge’ on the left. ⓞ ⓙ Assemble the ‘Adjustable foot’ on the right. ⓞ ⓝ ⓚ Attach the ‘Freezer Door’ to Cabniet. ⓜ ⓛ Assemble the ‘Middle Hinge’ on the left. (Remove ‘Washer’) ⓛ ⓜ Assemble the ‘Cover Middle Hinge’ on the right. ⓝ A ttach the ‘Refrigerator Door’ to Cabinet. (Be careful not to drop door). ⓞ A ssemble ‘Top’ hinge on the left. ⓙ ⓘ ⓟ Fix the ‘Hinge Cover’ with screw. ⓚ E-13 AD241-2a(영)_DESUK.indd 13 2012-06-01 오후 2:40:01...
-
Page 16: After Sales Service
cleanIng 1. Always disconnect the appliance from the mains supply. 2. Do not use abrasives. Periodically clean with a sponge dampened in lukewarm water. A neutral pH detergent may be used. Rinse and dry with a soft cloth. 3. Wipe the outside with a soft cloth dampened in water. 4. Periodically clean the front grille and the radiator at the back with a vacuum cleaner or a brush prolonged dIsUse 1. Empty the refrigerator and freezer compartments. 2. Unplug the appliance from the mains. 3. Clean and dry both compartments. 4. Leave the doors open to prevent the formation of unpleasant odors. aFter sales serVIce Before contacting our After Sales Service Department: 1. Try to remedy the problem (please read section “trouble shooting guide”). 2. R estart the appliance to check whether the fault repeats. If the malfunction persists, switch off the appliance and try again after an hour. 3. If the malfunction still persists, then contact our Customer Service, specifying: - the nature of the problem, - the appliance model number, - your full address, telephone number and area code. NOTE : Door opening direction changes carried out by our Customer Service are not covered by the terms of guarantee. troUBleshootIng gUIde 1. T he appliance does not work. Check: - power failure, - properly inserted plug, - (if applicable) connection of the two-pole circuit breaker, - damage to the mains lead, - correct setting of the temperature controls. 2. T he temperature inside the compartments is not low enough, Check for: - closure of the doors, - installation near a heat source, - correct setting of the refrigerator / freezer control knob,... - Page 17 Q: My refrigerator is not cold enough? A: • Ensure the temperature is not set to low; • E nsure the refrigerator is not in direct sunlight or is close to a heat source such as a radiator. The refrigerator works at its best when the ambient temperature is between 16°C and 32°C; • E nsure there is sufficient space (at least 10cm’s) between the refrigerator and the wall behind. Q: Food in the fridge compartment is freezing? A: • Ensure the temperature is not set to strong; • Ensure the ambient temperature is greater than 5°C. • Foods can be frozen if the ambient temperature is below 5°C; • E nsure foods with high water content are not stored close to the cold air spout. Please store these types of foods towards the front of the refrigerator. Q: The refrigerator is making a sound noise? A: • Ensure the refrigerator is positioned on a level, even floor;...
-
Page 18: General Advice
• I f a visit is required and the conditions of the Guarantee are fully satisfied a repair may be offered without charge. • I f a replacement appliance is required a charge may be made which reflects the wear and tear on the original appliance. • I f no fault is found with the appliance a ‘Call out Charge’ will be made. • I f a fault occurs which you cannot resolve through this instruction book(refer to troubleshooting guide & FAQ section), please contact our customer help line. The Daewoo Electronics Help Line: 0844 887 2525 Monday-Thursday (9:00 AM-5:30 PM) / Friday(9:00 AM-4:15 PM) Out of hours: send your enquiry to us www.daewooelectronics.co.uk/contact-daewoo.aspx You will need to tell them The Make: Daewoo The Model: See receipt or inside of the fridge compartment right hand side wall. -
Page 19: Appliance Packaging Information
applIance pacKagIng InForMatIon All material are environmentally sound! They can be dumped or burned at an incineration plant without danger! About the materials: The plastics can be recycled and are identified as follows: ■ PE : for polyethylene, e.g. the outer covering and the bags in the interior. ■ PS : for polystyrene foam, e.g. the pads, which are all free of chlorofluorocarbon. The carton parts are made from recycled paper and should be disposed of at a waste-paper recycling collection location. dIsposal oF old applIances For environmental reasons, refrigeration appliances must be disposed of properly. This applies to your old appliance, and –at the end of its service life- for your new appliance as well. Warning! Before disposing of old appliances make them remove or destroy any snap or latch closures. This eliminates the danger that playing children lock themselves into the appliance (danger of suffocation!) or place themselves into other life- endangering situations. Disposal : • The appliance may not be disposed of with domestic waste or bulky refuse. • The refrigerant circuit, especially the heat exchanger at back of the appliance, may not be damaged. • Information concerning collection schedules or locations can be obtained from the local disposal authorities or town hall. NOTICE Ensure the fridge door closed completely because the interior light can be switched off although the door is not completely closed. NoTe : The edge of the refrigerator door and the front side of the refrigerator cabinet may be hot. This is normal and intended to prevent the formation of condensation.
