The SLEEP button allows you to set a time to turn off the TV automatically. Battery Installation Your Universal Remote requires two (2) new AAA alkaline batteries. To install the batteries: 1. On the back of the remote, push and slide the cover off.
3. Press and slide the battery cover back into place. Note: Programmed codes will remain in memory for a short period of time allowing for battery replacement. If batteries have been dead for a prolonged period of time, reprogramming may be required. Button Description...
Programming For TV 1. Manually turn on the TV. 2. Press and hold the SETUP button until the INDICATOR LIGHT lights, then release the SETUP button. 3. Press and release the TV button (the INDICATOR LIGHT will blink then remain lit). 4.
Programming For VCR 1. Manually turn on the VCR. 2. Press and hold the SETUP button until the INDICATOR LIGHT lights, then release the SETUP button. 3. Press and release the VCR button (the INDICATOR LIGHT will blink then remain lit). 4.
Programming For Cable Box or Satellite Receiver The CAB • SAT button is defaulted to RCA/GE/ProScan DBS systems, however other DBS systems can be programmed to this button. 1. Manually turn on the cable box or satellite receiver. 2. Press and hold the SETUP button until the INDICATOR LIGHT lights, then release...
Programming for DVD•AUX The DVD•AUX button can be used for a DVD play- er. It can also be assigned to any other type of device (another TV , VCR, DVD, CD Player, or audio receiver). 1. Manually turn on the the device you wish to assign to the DVD•AUX button...
Programming With Code Search If your TV, VCR, DVD Player, cable box or satel- lite receiver does not respond after you have tried all the codes for your brand, or if your brand is not listed, try searching for your code by following the steps below.
Retrieving Codes If you need to find the three-digit code for your TV, VCR, DVD Player, DBS Receiver, or Cable Box after your device is set-up using Code Search, use this procedure. 1. Press and hold SETUP until the INDICATOR LIGHT lights, then release SETUP.
Television Menu Function The TV Menu is used to make changes in the TV settings such as setting color, channels, timers, etc. Entering the TV Menu Mode: Push the TV button on the remote. 2. Push the MENU button. This puts the remote in TV Menu Mode.
Page 12
Exiting the TV Menu Mode: To exit the Menu Mode and clear the TV screen push the TV button on the remote. The INDICATOR LIGHT should go out indicating the remote is now out of TV Menu Mode and will revert to it’s normal mode of operation.
DBS Menu Function The DBS Menu is used to navigate thru the Guide screens, to make changes in the DBS set- tings such as channel lists, passwords, etc. Entering the DBS Menu Mode: 1. Push the CBL•SAT button on the remote. 2.
Page 14
Exiting the DBS Menu Mode: To exit the Menu Mode and clear the TV screen push the CBL•SAT button on the remote. The INDICATOR LIGHT should go out indicating the remote is now out of DBS Menu Mode and will revert to it’s normal mode of operation.
Sleep Feature This feature will turn off your TV at the time you choose from 1 to 99 minutes. To P rogram Sleep Feature: 1. Press and hold the SLEEP button. INDICATOR LIGHT will stay lit. Release the SLEEP button. Enter time in minutes using the numerical...
Trouble Shooting Pr oblem Indicator light not blinking when you press any key The remote does not operate your device Not performing commands properly Problems programming a TV/VCR Combo Unit VCR not recording Channel up and down do not function on an RCA TV Problems changing channels...
Reprogramming may be required after batteries are removed. 90 Day Limited Warranty Jasco Products Company warrants this product to be free from manufacturing defects for a period of ninety days from the original date of consumer pur- chase.
Óndice La Descripción Del Botón Instalación De la Batería Descripcion de Botones Programación para la Televisor Programación para el VCR Programación para la CBL•SAT El Botón de DVD•AUX Programación con Búsqueda del Código Extraer Códigos Función Del Menú De la Televisión Función Del Menú...
ENTER El botón de "ENTER" se utiliza para terminar la selección de canal para algunas marcas de la TV. También se utiliza para terminar el proceso de la entrada del código. VOL & CHAN Las flechas VOL (volumen) y CH (del canal) aumente o dis- minuya los números de canal o volumen.
Programación para la Televisor Gire manualmente la prensa de la TV Presione y sostenga el botón de SETUP hasta que las luces de INDICATOR LIGHT, después suelta el botón de la SETUP. Presione y soltar el botón de la TV (sigue habiendo INDICATOR LIGHT entonces centelleo se encendió).
Programación para el VCR 1. Gire manualmente la prensa del VCR. Presione y sostenga el botón de SETUP hasta que las luces INDICATOR LIGHT, después suelta el botón de SETUP. Presione y soltar el botón del VCR (sigue habiendo INDICATOR LIGHT entonces centelleo se encendió).
Programación para la Caja Del Cable El botón de CBL•SAT se omite los sistemas de RCA/GE/Proscan DBS, sin embargo,otros sistemas de DBS se pueden programar a este botón. 1. Gire manualmente La caja del cable. 2. Presione y sostenga el botón de SETUP hasta que las luces de INDICATOR LIGHT, después suelta el...
Programación para el DVD•AUX El botón de DVD•AUX omite los sistemas de RCA/GE/ProScan DBS. El botón de DVD•AUX permite que usted asigne otra TV, VCR, o caja del cable. To asigna otro dispositivo al botón de DVD•AUX: Gire manualmente el dispositivo que usted desea asignar al botón de DVD•AUX (caja de la TV, del VCR...
Programación con Búsqueda del Código El botón de DVD•AUX se puede utilizar para un jugador de DVD. Puede también ser asignado a cualquier otro tipo de dispositivo (otra TV, VCR, DVD, jugador de CD, o receptor audio, receptor satellite).. Gire el dispositivo que usted desea programar.
Extraer Códigos Si usted necesita encontrar el código tridigital para su caja de la TV, del VCR o del cable, DVD player después de que su dispositivo set-up usando CODE SEARCH, utilice este pro- cedimiento. Presione y sostenga SETUP hasta que las luces de INDICATOR LIGHT, después suelta SETUP.
Función Del Menú De la Televisión El menú de la TV se utiliza para realizar cambios en las configuraciones de la TV tales como fijar color, los canales, los temporizadores, el etc. Entrar en el modo del menú de la TV Empuje el botón de la TV en el telecontrol.
Page 28
Dar salida al modo del menú de la TV Para salir del modo y del claro del menú la pantalla de la TV empuja el botón de la TV en el remoto. La luz de Indicador debe salir indicando que el remoto ahora está...
Función Del Menú De la DBS Entrar en el modo del menú de la DBS: Empuje el botón de la CBL•SAT en el telecontrol. Empuje el botón del MENU. Esto pone el telecontrol en modo del menú de la DBS. El menú de la DBS debe ahora ser visible en la televisión.
Dar salida al modo el menú de la DBS: Para salir del modo y del claro del menú la pantalla de la TV empuja el botón de la CBL•SAT en el remoto. La luz de Indicador debe salir indicando que el remoto ahora está...
Dejan la televisión dirigida alejada. (La característica del sueño no trabajará a menos que el remoto se deje la television dirigida.) Para dar vuelta Apagado Al Temporizador Del Sueño: El programa del temporizador del sueño será cancelado y restauración a cero por cualquiera del siguiente: Presione y sostenga el botón del sueno hasta que...
Garantia Limitada de Noventa Jasco Products Company garantiza este producto por un periodo de noventa días desde la fecha de la compra original, como libre de defectos de fabricación. Esta garantía está lim- itada a la reparación o reemplazo de este producto y no se...
