POWER MANAGEMENT FEATURE

The power management feature of this product complies with every power
saving requirements of
it automatically reduces unnecessary power consumption of the monitor
when your computer is not in use.
To use the feature, the monitor needs to be connected to a VESA DPMS
computer. There are three power management modes available, these are
described below. The required settings, including the timer setting, should be
made by the computer.
• Stand-by Mode
When the H-sync signal from the computer is off, the monitor enters into
Stand-by Mode which reduces the power consumption to less than 15W.
The screen becomes dark, and the power indicator turns to orange. From
Stand-by Mode, the screen reappears instantaneously when the keyboard
or the mouse is touched again.
• Suspend Mode
When the V-sync signal from the computer is off, the monitor enters into
Suspend Mode which reduces the power consumption to less than 15W.
The screen becomes dark, and the power indicator turns to orange. From
Suspend Mode, the screen reappears instantaneously when the keyboard
or the mouse is touched again.
• Active-off Mode
When both the H and V sync signals from the computer are off, the
monitor enters into Active-off Mode which reduces the power consumption
to less than 5W. The screen becomes dark, and the power indicator turns
to orange. From Active-off Mode, the screen reappears instantaneously
when the keyboard or the mouse is touched again.
•
The power-saving mode can be indicated by the light-emitting diode (LED)
on the front panel:
Mode
Cable
On* Attached
Stand-by Attached
Suspend Attached
Off Attached
Note: The power consumption is calculated without audio power
consumption at power saving status.
E S
NERGY TAR
Signal
H-Sync V-Sync
Yes Yes
No Yes
Yes No
No No
9
®
and VESA DPMS when activated,
Video Indicator Consumption
Active Green
Blank Orange
Blank Orange
Blank Orange
Power
≤ 120 W
≤ 15 W
≤ 15 W
≤
5 W
