Thank you for purchasing a Panasonic product.
Please read this document before using the unit and save it for future reference.
For detailed information about the features of your phone system, refer to the
Operating Instructions, which is available by tapping
visiting the support page for this product at the address below.
http://www.panasonic.net/pcc/support/tel/sdect
Please access our online customer survey:
http://panasonic.net/pcc/tel/q
Premium Design Phone with Touchscreen
KX-PRX120E
Model No.
in the home screen or by
Quick Guide
Advertisement
Table of Contents
Related Manuals for Panasonic KX-PRX120E
Summary of Contents for Panasonic KX-PRX120E
-
Page 1: Quick Guide
Premium Design Phone with Touchscreen KX-PRX120E Model No. Thank you for purchasing a Panasonic product. Please read this document before using the unit and save it for future reference. For detailed information about the features of your phone system, refer to the... -
Page 2: Accessory Information
KX-A405 Key finder KX-TGA20EX Contact Panasonic or the authorised sales department listed on the back cover for the headset available in your area. You can register up to 4 optional key finders to your phone system. By registering a key finder to the base unit and then attaching the key finder to an easily misplaced item, such as your house or car keys, you can use your handset to find the item. -
Page 3: Expanding Your Phone System
R In the event of problems, you should contact your equipment supplier in the first instance. Declaration of Conformity: R Panasonic System Networks Co., Ltd. declares that this equipment is in compliance with the essential requirements and other relevant provisions of Radio & Telecommunications Terminal Equipment (R&TTE) Directive 1999/5/EC. - Page 4 R Android is a trademark of Google Inc. ® R The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license. ® R Wi-Fi is a registered mark of the Wi-Fi Alliance.
-
Page 5: For Your Safety
Important Information such devices to malfunction resulting in an accident. For your safety R Do not allow the AC adaptor or telephone line cord to be excessively pulled, bent or To prevent severe injury and loss of life/ placed under heavy objects. property, read this section carefully before R Keep all accessories, including the using the product to ensure proper and safe... - Page 6 Important Information information, consult the manufacturer of 15.3 cm between a wireless device and an your vehicle or its equipment. implanted medical device such as R Turn the product off when boarding an pacemaker or implanted cardioverter aeroplane. Await instructions from flight defibrillator to avoid potential interference staff regarding the use of electronic devices with the medical device.
-
Page 7: Important Safety Instructions
Base unit location/avoiding noise manual. R Only use a compatible charger to charge The base unit and other compatible Panasonic the battery. Do not tamper with the charger. units use radio waves to communicate with Failure to follow these instructions may each other. -
Page 8: Other Information
Important Information Routine care Information for Users on Collection and Disposal of Old Equipment and R Wipe the outer surface of the product used Batteries with a soft moist cloth. R Do not use benzine, thinner, or any abrasive powder. Other information CAUTION: Risk of explosion if battery is replaced by an incorrect type. -
Page 9: End-User Licence
Licence: Panasonic System Networks Co., Ltd. 1. You may use the software installed in and/ (“Panasonic”) shall not be liable for loss of or delivered by this product. data or other incidental or consequential 2. You may transfer your rights under this... -
Page 10: Specifications
Important Information content or other third-party content by this R Maximum: approx. 4.0 W product or its operator. This document and Operating conditions any related product documentation may refer R 0 °C–40 °C, 20 %–80 % relative air to services and applications that are provided humidity (dry) by third parties. -
Page 11: Preparing The Base Unit
E DSL/ADSL service users only: Connect your DSL/ADSL filter (not supplied). Note: R Use only the supplied Panasonic AC adaptor PNLV226E. R Use only the supplied telephone line cord. Preparing the charger A Insert the AC adaptor plug to the unit until you hear a click. - Page 12 Getting Started R To avoid loss of data or malfunction, do not damage, carelessly handle, or short-circuit the gold-coloured contacts of the microSD card. Remove the handset’s cover. Open the microSD card cover by sliding it toward the nearest side of the handset (A) and then lifting up (B).
-
Page 13: Charging The Handset
Getting Started Charging the handset Charge the handset for about 5 hours before initial use. The charge indicator (A) lights while the handset is charging and turns off when the handset is fully charged. Important: R If the handset is placed into the charger while talking on the phone, the call is not disconnected. -
Page 14: Battery Charging
Battery use and replacement R Use only the supplied battery. For replacement, use only the Panasonic rechargeable battery noted on page 2. R The battery might swell when its life is close to an end. This is dependent on the usage conditions and is not a problem. -
Page 15: Handset Overview
Getting Started Getting to know your phone system Handset overview A Headset jack B Power button C Charge indicator D Volume button ( E Touchscreen F Micro USB jack G Front camera H Receiver (menu) button J Home button (back) button L Microphone M Speaker N Charge contacts... -
Page 16: Turning The Handset On And Off
Getting Started Base unit overview N (locator) button Handsets registered to the base unit will ring when you press this button. This can be useful when you want to locate a misplaced handset. Turning the handset on and off To turn the handset on, press and hold the power button on the top of the handset. If the lock screen appears, unlock the screen (page 16). -
Page 17: Home Button
Getting Started Add or create a Google account. Configure Wi-Fi settings (displayed only if you choose to configure a Google account). Note: R Some items may be displayed in English regardless of the display language setting. Setting up a Google account Configuring your handset to synchronise with your Google account is an easy way to synchronise contacts and other information between different devices, such as computers or smartphones, and your phone system’s handset. -
Page 18: Landline App
Getting Started Note: R The buttons are displayed in most screens. They appear at the bottom of the handset next to the home button, and turn off if you do not use them for a while. To display the buttons after they have turned off, simply touch the area of the handset where they would normally be displayed. -
Page 19: Using The Call Logs
Getting Started Using the call logs The handset and base unit each log your calls, allowing you to check a record of your calls. The following symbols are used to indicate each type of call stored in the call logs. Important: R Caller ID is required to log missed and answered calls (page 22). -
Page 20: Adding Contacts
Getting Started Preset audio profiles – [General]: You can select the desired ringtone, ringer volume, etc. – [Silent]: The ringer is turned off. – [Outdoor]: The settings of the [General] profile are used. The ringer volume is set to the maximum level. -
Page 21: Display Language
Getting Started Tap [Answering system]. R The handset connects to the base unit. R The number of messages is displayed at the top of the screen. To play all new messages: → Tap [Play new message]. To play all messages: →... -
Page 22: Troubleshooting
Getting Started Troubleshooting Problem Cause and/or solution R The handset is too far from the base unit. Move closer. is displayed. R The base unit’s AC adaptor is not properly connected. Reconnect AC adaptor to the base unit. R The handset is not registered to the base unit. Register it. See the Operating Instructions for more information (download information is on page 1). -
Page 23: Conditions Of Guarantee
8. The guarantee period applicable to this product shall be 12 months. Please keep these operating instructions with your receipt. Panasonic U.K. a branch of Panasonic Marketing Europe GmbH Receipt No. Date of purchase Model No. - Page 24 B Check if telephone line cord is connected. C Reinsert the battery and restart the handset. D Read troubleshooting page in the Operating Instructions. If you still have any problems, please call the Panasonic DECT Helpline 0844 844 3899 (U.K.)
