- Page 1 IM3028 09/2010 Rev. 0b LINC FEED 45 OPERATOR’S MANUAL MANUALE OPERATIVO BEDIENUNGSANLEITUNG MANUAL DE INSTRUCCIONES MANUEL D'UTILISATION BRUKSANVISNING OG DELELISTE GEBRUIKSAANWIJZING INSTRUKCJA OBSŁUGI KÄYTTÖOHJE Lincoln Electric Bester Sp. z.o.o. ul. Jana III Sobieskiego 19A, 58-260 Bielawa, Poland www.lincolnelectric.eu...
-
Page 2: Declaration Of Conformity
2006/95/CEE, 2004/108/CEE and has been designed in compliance with the following standards: EN 60974-1, EN60974-5, EN 60974-10 (2009) Paweł Lipiński Operations Director Lincoln Electric Bester Sp. z.o.o., ul. Jana III Sobieskiego 19A, 58-260 Bielawa, Poland 12/05 English English... -
Page 3: Table Of Contents
12/05 THANKS! For having choosen the QUALITY of the Lincoln Electric products. Please Examine Package and Equipment for Damage. Claims for material damaged in shipment must be notified immediately to the dealer. For future reference record in the table below your equipment identification information. Model Name, Code &... -
Page 4: Safety
Failure to follow the instructions in this manual could cause serious personal injury, loss of life, or damage to this equipment. Read and understand the following explanations of the warning symbols. Lincoln Electric is not responsible for damages caused by improper installation, improper care or abnormal operation. -
Page 5: Installation And Operator Instructions
CYLINDER MAY EXPLODE IF DAMAGED: Use only compressed gas cylinders containing the correct shielding gas for the process used and properly operating regulators designed for the gas and pressure used. Always keep cylinders in an upright position securely chained to a fixed support. Do not move or transport gas cylinders with the protection cap removed. - Page 6 Wire Drive: 4-Roll wire drive compatible with 37mm Set Knob: Changes the value on the MSP4 display. drive rolls. Left Button: Changes the MSP4 display to show the Cold Inch / Gas Purge Switch: This switch enables Weld Mode or Arc Control. wire feeding or gas flow without turning on output voltage.
- Page 7 Many variables beyond the control of welding torch. The Lincoln Electric Company affect the results obtained in applying these programs. These variables include, Set the wire feeding speed in the position of about but are not limited to welding procedure, plate chemistry 10m/min by the Left Knob [2] (see Figure 1.).
- Page 8 The steps for operating the Power Source will vary GMAW (MIG) Synergic Welding Display depending upon the user interface of the welding Synergic CV programs feature an ideal voltage best system. The flexibility of the Power Source lets the user suited for most procedures.
- Page 9 Example 1: Memory 2 Step Trigger: Simple operation Effect Range Description The simplest trigger operation occurs with a 2 Step Job1..Job8 Allows memorizing the selected weld trigger and the Start, Crater and Burnback functions all mode. set to OFF (See Figure Below). For this sequence: ...
- Page 10 2 Step Trigger 2 Step Trigger Start = On Start = On Crater = Off Crater =On Burnback = On Burnback = On Idle Preflow Strike Upslope Weld Burnback Postflow Idle Idle Preflow Strike Upslope Weld Down Burnback Postflow Idle slope Shielding Shielding...
- Page 11 Example 5: SET-UP FEATURES MENU 4 Step Trigger: Manual control of Start and Crater The Setup Menu gives access to the set-up times with Burnback ON configuration. Stored in the set-up configuration are The 4 step trigger sequence gives the most flexibility user parameters that generally need to be set only at when the Start, Crater and Burnback functions are installation.
- Page 12 Switch when using a Lincoln Dual Schedule gun. seconds. When in 2-step, the system operates identical to the The postflow time value is maintained when External Switch selection. To operate in 4-step: switching between MIG and TIG modes. When machine output on/off is controlled via ...
-
Page 13: Routine Maintenance
True = Sensing for the electrode (67) and work (21) recommended to contact the nearest technical service is measured at the studs of the power source and center or Lincoln Electric. Maintenance or repairs the DIP switch settings are overridden. -
Page 14: Electromagnetic Compatibility (Emc)
Lincoln Electric. Before installing the machine, the operator must check the work area for any devices that may malfunction because of electromagnetic disturbances. -
Page 15: Spare Parts
12/05 Part List reading instructions Do not use this part list for a machine if its code number is not listed. Contact the Lincoln Electric Service Department for any code number not listed. Use the illustration of assembly page and the table below to determine where the part is located for your particular code machine. - Page 16 è conforme alle seguenti direttive: 2006/95/CEE, 2004/108/CEE ed è stato progettato in conformità alle seguenti norme: EN 60974-1, EN60974-5, EN 60974-10 (2009) Paweł Lipiński Operations Director Lincoln Electric Bester Sp. z.o.o., ul. Jana III Sobieskiego 19A, 58-260 Bielawa, Poland 12/05 Italiano Italiano...
- Page 17 Varusteet K10349-PG-xM Välikaapeli (kaasu), saatavissa 5, 10, 15 ja 30 m:n pituisena. K10349-PGW-xM Välikaapeli (kaasu, vesi), saatavissa 5, 10, 15, 20, 25 ja 30 m:n pituisena. K10158 Muoviadapteri 15 kg:n keloille. K10343 Innershield poltin adapteri. Syöttöpyörät ja ohjausputket 2 - pyörävedolle Umpilangat: KP14017-0.8 0,6-0,8mm...
- Page 18 Spare Parts SP50194 Rev. 1 07/03 LINC FEED 45 ASSEMBLY PAGE NAME CODE K NO.: FIGURE NO.: NO.: 50194 K14072-1 LINC FEED 45 Figure A Figure B Spare Parts - Electrical Schematic Spare Parts - Electrical Schematic...
- Page 19 Figure A-B: Machine Assembly Item Description Part Number LOCK 0654-610-004R QUICK CONNECTOR MALE 0744-000-151R QUICK CONNECTOR FEMALE 0744-000-152R WIRE REEL SPINDLE 0744-000-192R WIRE DRIVE 0744-000-241R PLASTIC SHROUD ASSEMBLY 0749-901-003R SOCKET MALE 1158-641-110R GAS SOLENOID 0972-423-038R FRONT WHEEL 1029-660-003R REAR WHEEL 1029-660-081R PROTECTION WASHER 0744-200-108R...
- Page 20 Figure C Figure C: Wire Drive Assembly Item Description Part Number FEED PLATE 0646-233-002R FIXING ARM COMPL. 0646-233-015R INLET GUIDE 0646-233-025R AXIS PRESSURE ARM 0646-233-003R SPRING PRESSURE ARM 0646-233-013R PRESSURE ARM COMPL.L 0646-233-007R INTERMEDIATE GUIDE 0646-233-023R AXIS DRIVE ROLL 0646-233-020R GEAR WHEEL ROLL 0646-231-090R GEAR WHEEL MOTOR...
- Page 21 Electrical Schematic LINC FEED 45 Spare Parts - Electrical Schematic Spare Parts - Electrical Schematic...
