MBT-4000 Multi-Band Transceiver System
Remote Control
Command
Valid on
Parameter
(Instruction
Type
Code and
BDC, or
qualifier)
Slope Adjust
SSA=x.x
BDC
BUC
Set
SSW=xy
MBT
Redundancy
Switch
Set RTC Time
TIM=hhmmss
All
Retrieve
N/A
All
Number of
unread
Stored Alarms
Arguments
MBT,
for Command
(Note that all arguments are ASCII numeric codes – i.e.,
or Response
BUC
to Query
3 bytes,
Command or Query.
numeric
Slope adjust level, valid from 0.0 to 1.0 with 0.1 resolution.
Example: SSA=0.3
2 bytes
Command only.
SSW control the switches dedicated to Slot1 or 2, and sets them
to either Port A or Port B.
Syntax: SSW=xy, where:
x = 1 or 2 depicting Slot 1 or 2
y = A or B depicting the switch direction.
Direction
A
Switched to Converter on MBT_A
B
Switched to Converter on MBT_B
6 bytes,
Command or Query.
numeric
A command in the form hhmmss, indicating the time from
midnight, where:
hh = hours, between 00 and 23
mm = minutes, between 00 and 59
ss = seconds, between 00 and 59
Example: TIM=231259 would be 23 hours, 12 minutes and 59
seconds from midnight.
2 bytes,
Query only.
numeric
Returns the number of Stored Events which remain unread, in
the form xx.
Example reply: TNA=18
Description of Arguments
ASCII codes between 48 and 57)
A–22
Revision 4
MN/MBT4000.IOM
Response to
Query
Command
(Instruction
(Target to
Code and
Controller)
qualifier)
SSA= (message OK)
SSA?
SSA? (received OK,
but invalid arguments
found)
SSA* (message OK,
but not permitted in
current mode)
SSA! (command not
accepted by MBT-
4000 base unit. It
must be addressed
to BUC or BDC sub-
units)
SSW=(message OK)
N/A
SSW=xy
TIM = (message OK)
TIM?
TIM? (received OK,
but invalid arguments
found)
TIM * (message OK,
but not permitted in
current mode)
N/A
TNA?
Response to
Query
(Target to
Controller)
SSA=x.x
(same format as
command
arguments)
N/A
TIM=hhmmss
(same format as
command
arguments)
TNA=xx
(see description
for details of
arguments)
