- Page 1 INSTRUCTION MANUAL MclNTOSH MODEL MC-60 60 WATT POWER AMPLIFIER Type A-121 Serial No. 5F846 and above MclNTOSH LABORATORY, INC. 2 Chambers St. Binghamton, N. Y. U.S.A.
- Page 3 ELECTRICAL AND MECHANICAL SPECIFICATIONS Specifications for the Mclntosh Model MC-60 Audio Amplifier 117/125 volts, 50/60 cycles Power Supply 280 watts at 60 watts output Power Consumption 155 watts at zero signal output 60 watts continuous Power Output Input #1, 0. 5 volts to 30 volts, with gain control Input Level Input #2, 2.
- Page 4 Turn the "GAIN" control fully counter clockwise. When a signal source of 0. 5 volts or more is used to drive the MC-60, such as the output of a tuner, tape recorder, or other pre-amplifiers, plug the source into the"0. 5 VOLT"...
-
Page 5: U4Gb
When the MC-60 is used with Mclntosh Pre-Amplifier equipment, tuners, or other associated equipment, the MC-60 power cord may be plugged into the receptacle at the rear of these units. When thus connected the power switch of these units controls the MC-60. GUARANTEE We guarantee the performance of this equipment arid the mechanical and electrical workmanship to be free of defects for a period of 90 days. - Page 6 DC Volts DC Volts AC Volts Resistance No Signal at 60W out at 60W out Pin No. Tube Unit Off 12AX7 270K 6.3V ac to Pin 9 0 to 70 4 & 5 27 OK 0 to 70 KT-88/6550 0 to 70 6.
- Page 8 038-177 Be102002...
